VBNFQFA-01Outdoor Micro-cell BTS

Nokia Solutions and Networks Tel: (972) 374-3000 6000 Connection Drive Fax: (972) 374-3252 Irving, Texas 75039 September 29, 2014 TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL RE: Confidentiality Request FCC ID: VBNFQFA-01 Please be advised that under the provision of 47 CFR 0.459, the following exhibits are to be held confidential on behalf of Nokia Solutions and Networks. Nokia Solutions and Networks is also requesting these exhibits to become permanently confidential. This non-consumer device is inaccessible to the general public and situated in a secured and locked environment. The equipment is only serviceable by the licensee or his designated technicians, or at the factory. • Operation Description (Theory of Operation) • Block Diagram • Schematics/Parts List • Internal Photos • User Manual • Tuning/Calibration Procedure The bulleted list exhibits are to be held confidential. Confidentiality of the User Manual is maintained by requiring that any party who is supplied the User Manual must sign a non-disclosure agreement. Internal photos are kept confidential by virtue of the fact the cabinet in which the certified equipment is housed is secured with a lock and the cabinet itself is in a secured area only accessible by approved maintenance personnel. The application contains technical information that Nokia Solutions and Networks deems to be trade secrets and proprietary. If made public, the information can be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Sincerely, Steve Mitchell Compliance Engineer

FQFA:

FQFA: FCC Label for FQFA Model number location -086923A for FQFA

Document 75925040 Report 06 Issue 1 September 2014 Report On RF Exposure Compliance Boundary Assessment of the Nokia Solutions and Networks Flexi Base Station Products (698-960 MHz and 1710-2690MHz) TÜV SÜD Product Service, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuv-sud.co.uk Document 75925040 Report 06 Issue 1 Page 1 of 15 REPORT ON RF Exposure Compliance Boundary Assessment of the Nokia Solutions and Networks Flexi Base Station Products (698-960 MHz and 1710-2690MHz) Document 75925040 Report 06 Issue 1 September 2014 PREPARED FOR Nokia Solutions and Networks Oy Kaapelitie 4 Oulu Finland PREPARED BY Maggie Whiting Project Manager APPROVED BY Simon Bennet Authorised Signatory DATED 29 September 2014 Document 75925040 Report 06 Issue 1 Page 2 of 15 CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Product Information ...................................................................................................................... 6 1.4 Summary ...................................................................................................................................... 6 2 TEST DETAILS ............................................................................................................................ 7 2.1 Rationale for Assessment of the RF Exposure Compliance Boundary ........................................ 8 2.2 Defined Limits ............................................................................................................................... 9 2.3 Establishing Wavelength and 1/4 Wavelength ........................................................................... 11 2.4 Far Field Calculations ................................................................................................................. 12 3 DISCLAIMERS AND COPYRIGHT ........................................................................................... 14 3.1 Disclaimers and Copyright .......................................................................................................... 15 Document 75925040 Report 06 Issue 1 Page 3 of 15 SECTION 1 REPORT SUMMARY RF Exposure Compliance Boundary Assessment of the Nokia Solutions and Networks Flexi Base Station Products (698-960 MHz and 1710-2690MHz) Document 75925040 Report 06 Issue 1 Page 4 of 15 1.1 INTRODUCTION The information contained in this report is intended to show verification of the RF Exposure Compliance Boundary Assessment of the Nokia Solutions and Networks Flexi Base Station Products (698-960 MHz and 1710-2690MHz) to the requirements of the applied test specifications. Objective To perform RF Exposure Compliance Boundary Assessment to determine the Equipment Under Test's (EUT’s) compliance of the applied rules. Applicant Nokia Solutions and Networks Manufacturer Nokia Solutions and Networks Oy Manufacturing Description Flexi Base Station Products Model Number(s) Nokia Flexi Base Station Products (698-960 MHz and 1710-2690 MHz) In this document Flexi Base Station Product is a common name for Flexi Lite BTS, Flexi WCDMA Base Station, Flexi Multiradio Base Station, Flexi Multiradio 10 Base Station, Flexi Compact BTS and Flexi Zone BTS, Flexi Multiradio BTS GSM/EDGE and Flexi EDGE BTS Power Variants 2, 5, 10, 20, 30, 40, 50, 60, 70, 80 and 90W Test Specification/Issue/Date EN 62311:2008 FCC KDB 447498D01 RSS-102 Issue 4 March 2010 Radiocommunications (Electromagnetic Radiation – Human Exposure) Standard: 2003 Related Document(s) Council Recommendation 1999/519/EC:1999 FCC CFR 47 Part 1: 2013 FCC CFR 47 Part 2: 2013 Health Canada's Safety Code 6 ARPANSA ICNIRP 1998 National Council on Radiation Protection and Measurements (NRPC) - Report No. 86(1986) 50383:2010 IEEE Std C95.1-2005 Australian Standard 2772.2 – 1988 Document 75925040 Report 06 Issue 1 Page 5 of 15 1.2 BRIEF SUMMARY OF RESULTS 1.2.1 Compliance Boundaries (cm) for General Public Levels Power (W) Frequency Range (MHz) 698-960 1710-2690 Distance (cm) 2 150 100 5 230 150 10 320 210 20 450 290 30 550 350 40 640 410 50 710 460 60 780 500 70 840 540 80 900 580 90 950 610 1.2.2 Compliance Boundaries (cm) for Occupational Levels Power (W) Frequency Range (MHz) 698-960 1710-2690 Distance (cm) 2 70 50 5 110 70 10 150 100 20 210 140 30 260 160 40 290 190 50 330 210 60 360 230 70 390 250 80 410 270 90 440 280 The distances are valid for antenna gain 16.4 dBi and RF power as indicated. For other antenna gains and/or RF-power, the compliance boundaries should be recalculated using the formulas in section 2.3 of this report. Document 75925040 Report 06 Issue 1 Page 6 of 15 1.3 PRODUCT INFORMATION 1.3.1 Attestation The wireless device described within this report has been shown to be capable of compliance with the basic restrictions related to human exposure to electromagnetic fields for both General public and Occupational. The calculations shown in this report were made in accordance the procedures specified in the applied test specification(s). 1.3.2 Technical Description The Equipment under test was a Nokia Solutions and Networks Flexi Base Station Products (698-960 MHz and 1710-2690MHz). A full technical description can be found in the manufacturer’s documentation. All reported calculations were carried out on the relevant information supplied for the Nokia Flexi Base Station Products (698-960 MHz and 1710-2690MHz) to demonstrate compliance with the applied test specification(s) the sample assessed was found to comply with the requirements of the applied rules. 1.4 SUMMARY The RF …

Text truncated - open the document above for the full version.

Document 75927745 Report 01 Issue 1 October 2014 Report On Radio Testing of the Nokia Solutions and Networks Oy Flexi Lite BTS 1.9GHz Radio Access Technology: UTRA (FDD) In accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 24 COMMERCIAL-IN-CONFIDENCE FCC ID: VBNFQFA-01 TÜV SÜD Product Service, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuv-sud.co.uk COMMERCIAL-IN-CONFIDENCE Document 75927745 Report 01 Issue 1 Page 1 of 6 COMMERCIAL-IN-CONFIDENCE REPORT ON Radio Testing of the Nokia Solutions and Networks Oy Flexi Lite BTS 1.9GHz Radio Access Technology: UTRA (FDD) In accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 24 Document 75927745 Report 01 Issue 1 October 2014 PREPARED FOR Nokia Solutions and Networks Oy PO Box 319 Kaapelitie 4 FI-90620 Oulu Finland PREPARED BY Natalie Bennett Senior Administrator, Project Support APPROVED BY Simon Bennett Authorised Signatory DATED 6 October 2014 Document 75927745 Report 01 Issue 1 Page 2 of 6 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 2 DISCLAIMERS AND COPYRIGHT .............................................................................................. 5 2.1 Disclaimers and Copyright ............................................................................................................ 6 ANNEX A Nokia Solutions and Networks OY Test Report No: D5284962 (62 Pages) ............................ A.1 Document 75927745 Report 01 Issue 1 Page 3 of 6 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY Radio Testing of the Nokia Solutions and Networks Oy Flexi Lite BTS 1.9GHz Radio Access Technology: UTRA (FDD) In accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 24 Document 75927745 Report 01 Issue 1 Page 4 of 6 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.1 INTRODUCTION The information contained in this report is intended to show verification of the Radio Testing of the Nokia Solutions and Networks Oy Flexi Multiradio 10 BTS RRH module 2.3 GHz Radio Access Technology: UTRA (FDD) In accordance with (2013). Objective To perform Radio Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Nokia Solutions and Networks Oy Model Number(s) FQFA Serial Number(s) L9143700148 Number of Samples Tested 1 Test Specification/Issue/Date FCC CFR 47 Part 2 (2013) FCC CFR 47 Part 24 (2013) Order Number Date 464/90547579 29 August 2014 Start of Test 17 September 2014 Finish of Test 26 September 2014 Name of Engineer(s) Mika Kallankari Jari Veijola Document 75927745 Report 01 Issue 1 Page 5 of 6 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE SECTION 2 DISCLAIMERS AND COPYRIGHT Document 75927745 Report 01 Issue 1 Page 6 of 6 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 2.1 DISCLAIMERS AND COPYRIGHT This report relates only to the actual item/items tested. This report must not be reproduced, except in its entirety, without the written permission of TÜV SÜD Product Service © 2014 TÜV SÜD Product Service Document 75927745 Report 01 Issue 1 Page A.1 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE ANNEX A NOKIA SOLUTIONS AND NETWORKS OY TEST REPORT NO: D521804962 (62 Pages) TEST REPORT NO: D521804962 FCC ID: VBNFQFA-01 Date: Oulu 01. Oct 2014 Pages: 61 Appendices: - Equipment Under Test: Flexi Lite BTS 1.9GHz Radio Access Technology: UTRA (FDD) Type: FQFA Manufacturer: Nokia Solutions and Networks Oy Address: P.O. Box 319, Kaapelitie 4, FI-90620, Oulu, Finland Task: Conformance test according to the specificarions mentioned below Test Specification(s): FCC 47 CFR part 2 (2013) and FCC 47 CFR part 24 (2013) Result: The EUT complies with the requirements of the specification The results relate only to the items tested as described in this test report. Approved by: Date Signature Jari Virta R&D Line Manager NSN 01. Oct 2014 FCC ID: Test Report No: VBNFQFA-01 D521804962 FCC Part 24 October 1,2014 Page 2 of 61 CONTENTS 1. SUMMARY ...............................................................................................................4 1.1 Test Laboratory .....................................................................................................4 1.2 Time Schedule .......................................................................................................4 1.3 Participants ............................................................................................................4 2. EQUIPMENT UNDER TEST ...................................................................................5 2.1 Configuration of EUT ...........................................................................................5 2.2 Operating Conditions ............................................................................................6 3. TEST CONFIGURATION ........................................................................................7 3.1 Calibration of the Test Equipment ........................................................................7 4. TEST RESULTS ........................................................................................................8 4.1 Test No. 1: RF Power Output (§ 2.1046, § 24.232) ..............................................8 4.1.1. Limits ...........................................................................................................8 4.1.2. Test Procedure and Results ..........................................................................8 4.2 Test No. 2: Modulation Characteristics (§ 2.1047, § 2.201) ...............................11 4.3 Test No. 3: Occupied Band…

Text truncated - open the document above for the full version.
