VBNFXCB-01Cellular Base Station

Restricted Access of Equipment and Documentation Notice Proprietary and Confidential Nokia Siemens Networks RESTRICTED ACCESS OF EQUIPMENT AND DOCUMENTATION NOTICE This Restricted Access of Equipment and Documentation Notice is to inform [insert name of FCC licensee] that access to equipment and related documentation supplied by Nokia Siemens Networks is to be restricted to only authorized users by means to ensure the security of the equipment and confidentiality of related documentation at all times, and only designated professionals shall be allowed to maintain or service the equipment. This notice includes, but is not limited to, internal photographs and user manuals to be held confidential and out of the public domain. Nokia Siemens Networks FCC Licensee By: By: Name: Name: Title: Title: Date: Date: Place: Place:

FCC ID Label for FXCB (FCC ID: VBNFXCB-01)

Nemko Test Report: 10235922RUS1 Applicant: Nokia Siemens Networks 6000 Connection Drive Irving, TX 75039 USA Equipment Under Test: FXCB (E.U.T.) FCC ID: VBNFXCB-01 IC ID: 661W-FXCB In Accordance With: CFR 47, Part 22, Subpart H and Industry Canada RSS-132, Issue 3 Cellular Base Stations Tested By: Nemko USA, Inc. 802 N. Kealy Lewisville, TX 75057-3136 TESTED BY: DATE: 27 February 2013 David Light, Senior Wireless Engineer APPROVED BY: DATE: 11-Mar-2013 Michael Cantwell, Reviewer Number of Pages: 59 Nemko USA, Inc. CFR 47, PART 22, SUBPART H and Industry Canada RSS-132, Issue 3 CELLULAR BASE STATIONS EQUIPMENT: FXCB PROJECT NO.: 10235922RUS1 Page 2 of 59 Table of Contents Section 1. Summary of Test Results .......................................................................... 3 Section 2. General Equipment Specification .............................................................. 5 Section 3. RF Power Output ...................................................................................... 6 Section 4. Occupied Bandwidth ................................................................................. 8 Section 5. Spurious Emissions at Antenna Terminals ............................................. 15 Section 6. Field Strength of Spurious ...................................................................... 46 Section 7. Frequency Stability ................................................................................. 47 Section 8. Test Equipment List ................................................................................ 49 ANNEX A - TEST DETAILS .......................................................................................... 50 ANNEX B - TEST DIAGRAMS ...................................................................................... 56 Nemko USA, Inc. CFR 47, PART 22, SUBPART H and Industry Canada RSS-132, Issue 3 CELLULAR BASE STATIONS EQUIPMENT: FXCB PROJECT NO.: 10235922RUS1 Page 3 of 59 Section 1. Summary of Test Results Manufacturer: Nokia Siemens Networks Model No.: FXCB Serial No.: L9124300880 (WCDMA) L9124800406 (GSM) General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 22, Subpart H and RSS-132, Issue 3. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Nemko USA, Inc. is a NVLAP accredited laboratory. Nemko USA, Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety, for use by the company’s employees only. This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Nemko USA, Inc. is a NVLAP accredited laboratory. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA, Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Inc. CFR 47, PART 22, SUBPART H and Industry Canada RSS-132, Issue 3 CELLULAR BASE STATIONS EQUIPMENT: FXCB PROJECT NO.: 10235922RUS1 Page 4 of 59 Summary Of Test Data NAME OF TEST PARA. NO. SPEC. RESULT RF Power Output 22.913(a) / 5.4 500 W Complies Occupied Bandwidth 22.917 / 5.5 Not defined Complies Spurious Emissions at Antenna Terminals 22.917 / 5.5 -13 dBm Complies Field Strength of Spurious Emissions 22.917 / 5.5 -13 dBm E.R.P. Complies Frequency Stability 22.355 / 5.3 1.5 ppm Complies Footnotes For N/A’s: Nemko USA, Inc. CFR 47, PART 22, SUBPART H and Industry Canada RSS-132, Issue 3 CELLULAR BASE STATIONS EQUIPMENT: FXCB PROJECT NO.: 10235922RUS1 Page 5 of 59 Section 2. General Equipment Specification Supply Voltage Input: -48 Vdc nominal Frequency Band: 869 to 894 MHz Type of Modulation and Designator: GMSK 300KGXW 8PSK 300KG7W QPSK 300KD7W QPSK 5M00D7W 16QAM 5M00D7W 64QAM 5M00D7W Maximum No. of Carriers: 6 Output Impedance: 50 ohms RF Output (Rated): 80 W Band Selection: Software Duplexer Fullband System Description The FXCB is an 850 MHz multi-standard multicarrier radio module that consists of three individual transceivers designed to support GSM/EDGE, WCDMA and LTE in dedicated or concurrent mode. Each module supports up to six GSM/EDGE carriers in GSM/EDGE dedicated mode, upto four WCDMA carriers in WCDMA dedicated mode and upto four 5 MHz LTE carriers in LTE dedicated mode with one radio branch. In concurrent mode, a combination of all three radio technologies is supported with a single radio branch. Each module is capable to serve three radio branches with multiradio multicarrier radios of up to 80 Watts output power per branch. The LTE modulation and concurrent mode operation were not tested under this effort. The transmitter test setup for GSM/EDGE dedicated mode provided GMSK ,QPSK and 8PSK modulation types for both single and multicarrier operation. The transmitter WCDMA dedicated mode provided QPSK, 16QAM and 64QAM modulation types for both single and multicarrier operation. Nemko USA, Inc. CFR 47, PART 22, SUBPART H and Industry Canada RSS-132, Issue 3 CELLULAR BASE STATIONS EQUIPMENT: FXCB PROJECT NO.: 10235922RUS1 Page 6 of 59 Section 3. RF Power Output NAME OF TEST: RF Power Output PARA. NO.: 22.913(a)/5.4 TESTED BY: David Light DATE: 26 February 2013 Test Results: Complies. Measurement Data: Refer to table on next page. Equipment Used: 1036-1082-1054-1065-1472 Measurement Uncertainty: +/- 1.7 dB Temperature: 22 C Relative Humidity: 35 % Nemko…
