VBNFXFB-01FXFB

Restricted Access of Equipment and Documentation Notice Proprietary and Confidential Nokia Siemens Networks RESTRICTED ACCESS OF EQUIPMENT AND DOCUMENTATION NOTICE This Restricted Access of Equipment and Documentation Notice is to inform [insert name of FCC licensee] that access to equipment and related documentation supplied by Nokia Siemens Networks is to be restricted to only authorized users by means to ensure the security of the equipment and confidentiality of related documentation at all times, and only designated professionals shall be allowed to maintain or service the equipment. This notice includes, but is not limited to, internal photographs and user manuals to be held confidential and out of the public domain. Nokia Siemens Networks FCC Licensee By: By: Name: Name: Title: Title: Date: Date: Place: Place:

FCC ID Label for FXFB (FCC ID: VBNFXFB-01)

This device is categorically exempt for rf exposure evaluation according to CFR 47 1.1307 Table 1. RF exposure is addressed at the time of licensing. The rf exposure category is fixed outdoor and the equipment is professionally installed.

Nemko Test Report: 10213234RUS1 Applicant: Nokia Siemens Networks 6000 Connection Drive Irving, TX 75039 USA Equipment Under Test: FXFB (E.U.T.) FCC ID: VBNFXFB-01 In Accordance With: CFR 47, Part 24, Subpart E Broadband PCS Base Stations Tested By: Nemko USA, Inc. 802 N. Kealy Lewisville, TX 75057-3136 TESTED BY: DATE: 25-Aug-2011 David Light, Senior Wireless Engineer APPROVED BY: DATE: 21-Sep-2011 Mike Cantwell, General Manager Number of Pages: 87 Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: FXFB PROJECT NO.: 10213234RUS1 Page 2 of 87 Table of Contents Section 1. Summary of Test Results ............................................................................. 3 Section 2. General Equipment Specification ................................................................. 5 Section 3. RF Power Output .......................................................................................... 6 Section 4. Occupied Bandwidth .................................................................................... 9 Section 5. Spurious Emissions at Antenna Terminals ................................................. 26 Section 6. Field Strength of Spurious .......................................................................... 75 Section 7. Frequency Stability ..................................................................................... 76 Section 8. Test Equipment List .................................................................................... 78 ANNEX A - TEST DETAILS .......................................................................................... 79 ANNEX B - TEST DIAGRAMS ...................................................................................... 85 Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: FXFB PROJECT NO.: 10213234RUS1 Page 3 of 87 Section 1. Summary of Test Results Manufacturer: Nokia Siemens Networks Model No.: FXFB Serial No.: N/A General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 24, Subpart E. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “Summary of Test Data”. Nemko USA, Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety, for use by the company’s employees only. This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Nemko USA, Inc. is a NVLAP accredited laboratory. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA, Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: FXFB PROJECT NO.: 10213234RUS1 Page 4 of 87 Summary Of Test Data NAME OF TEST PART 24 PARA. NO. SPEC. RESULT RF Power Output 24.232 1640 W Complies Occupied Bandwidth 24.238 6.5.1 Complies Spurious Emissions at Antenna Terminals 24.238(a)-13 dBm Complies Field Strength of Spurious Emissions 24.238(a) -13 dBm E.I.R.P. NT 1 Frequency Stability 24.235 +/-1% NT 1 Footnotes: These tests were originally performed on FXFA and were not re-tested since the FXFA and FXFB are electrically equivalent. Note: For the purpose of this test, the FXFB is electrically equivalent to the FXFA. As such, no additional testing was performed for the FXFB. The data presented in this section was compiled for the FXFA from previous Nemko test reports 1026738RUS1 (GSM/EDGE/WCDMA) and 10213334RUS1 (LTE). Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: FXFB PROJECT NO.: 10213234RUS1 Page 5 of 87 Section 2. General Equipment Specification Supply Voltage Input: -48 Vdc nominal Frequency Band: 1930 to 1990 MHz Type of Modulation and Designator: 300KGXW GSM 300KG7W EDGE 5M00D7W QPSK/16QAM/WCDMA 5M00F9W / 10M0F9W / 15M0F9W / 20M0F9W LTE Maximum No. of Carriers: 6 Output Impedance: 50 ohms RF Output (Rated): 60 W .The RF output power must be reduced on the first and last channel of each band when used for GSM, EDGE, QPSK or 16QAM modulations. +47.8 dBm Band Selection: Software Duplexer Fullband System Description The FXFB is an FXFA which has been modified to include a Remote Electrical Tilt (RET) antenna controller module and an external RET connector. Therefore the FXFA and FXFB are deemed to be electrically equivalent. The FXFB is a 1900 MHz multistandard multicarrier radio module that consists of three individual transceivers designed to support GSM/EDGE, WCDMA and LTE in dedicated or concurrent mode. Each module supports up to six GSM/EDGE carriers in GSM/EDGE dedicated mode, up to four WCDMA carriers in WCDMA dedicated mode and up to four 5 MHz LTE carriers in LTE dedicated mode with one radio branch. In concurrent mode, a combination of all three radio technologies is supported with a single radio branch. Each module is capable to serve three radio branches with multiradio multicarrier radios of up to 60 Watts output power per branch. The transmitter test setup for LTE dedicated mode provided QPSK, 16 QAM and 64 QAM modulation types for single carrier operation only. The transmitter test setup for GSM/EDGE dedicated mode provided GMSK and 8PSK modulation types for both single and multicarrier operation. The transmitter WCDMA dedicated mode provided QPSK and 16QAM modulation types for both single and multicarrier operation. Nemko USA, Inc. CFR 47, PART 24, SUBPART E BROADBAND PCS BASE STATIONS EQUIPMENT: FXFB PROJECT NO.: 10…
