VF2-WPC1WIRELESS CONTROLLER FOR SWIMMING POOL PERIPHERALS

http://www.fiberstars.com 79-15053-00 REV. C Page 1 of 16 Installation Instructions: Read these instructions in their entirety before performing any installation work. Rated for use on 110/120VAC 60Hz and 220/240VAC 60Hz applications WPC-1 ETL LISTED Conforms to UL STD 508; Certified to CSA STD C22.2 No. 14 FOR USE WITH POOL AND SPA PRODUCTS http://www.fiberstars.com 79-15053-00 REV. C Page 2 of 16 18 19 17 16 15 14 13 12 10 10 9 8 7 6 5 4 11 3 2 1 Accessory Items: FP 1/2 Temperature Freeze Device WE-65 65 ft Repeater Cord Extension Kit DL-HUB Direct Light Hub Connection Kit WPC-12V 12V Transformer for Fiberstars Light Streams LED Products The WPC-1 consists of the following parts: Item No. Qty. Component part No. Description 1 1 - WPC-1 Enclosure 2 1 94-15087-00 WPC-1 Enclosure Door 3 1 37-15000-00 Relay 4 1 41-15004-08 8 Position Terminal Block 5 1 42-15032-00 Timer 6 1 02-15268-00 Face Plate 7 2 02-15274-00 WPC-1 Mounting Bracket 8 1 41-15003-00 Grounding Bar 9 1 94-15090-00 WPC Receiver 10 6 10-15086-04 Face Plate and Mounting Bracket Screws 11 2 10-15089-06 Terminal Block Mounting Screw 12 2 10-15060-01 Relay Mounting Screw 13 8 10-15089-03 Timer and Receiver Mounting Screws 14 2 A11526 3-Position Toggle Switch 15 1 94-15092-00 WPC Repeater 16 2 10-15089-02 Freeze Device Mounting Screw (Optional equipment) 17 1 20-15013-00 Strain Relief 18 1 17-15005-00 Latch 19 2 10-15089-01 Latch Mounting Screws http://www.fiberstars.com 79-15053-00 REV. C Page 3 of 16 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by Fiberstars Inc. could void the user's authorit y to operate the equipment. FCC WARNING ELECTRICAL RATINGS Do not exceed the maximum electrical ratings of the WPC-1. A circuit breaker rated at 20Amps at 120VAC must be installed in the breaker panel to connect to the WPC-1 power input. Circuit 1 and Circuit 2 are each rated for use of up to 8Amps @ 120VAC. The Pump Relay is rated at a maximum of 3HP @ 240VAC. Basic safety precautions should be observed when operating the WPC-1 product and other associated equipment. 1. A qualified electrician must install the WPC-1 in accordance to the National and Local Electrical Codes. 2. The WPC-1 must not be less then 5 feet (3 meters in Canada) from inside edge of pool. ONLY USE COPPER CONDUCTORS. 3. Do not exceed the maximum ratings of individual components, wiring devices, and current carrying capacity of conductors. 4. For the bonding, grounding, installing, and wiring of underwater lights to the WPC-1, refer to Article 680 of the National Electrical Code or Article 68 of the Canadian Electrical Code. 5. This device should never operate equipment that could cause property damage, bodily injury, or death should it be activated unexpectedly. 6.NeverallowchildrentooperatetheWPC-1unsupervised. SAVETHESEINSTRUCTIONS! IMPORTANT SAFETY INFORMATION http://www.fiberstars.com 79-15053-00 REV. C Page 4 of 16 HOT NEUTRAL T/C POWER T/C NEUTRAL Power Connections: To wire the WPC-1 use insulate d COPPER wire only, 12 gauge minimum. Run a ½” to ¾” conduit from the main breaker panel to the WPC-1. Pull appropriate wires from the main breake r panel to the WPC-1 unit. To make power connections remove 3/8 inchesof insulation from wire ends. Insert thebare end of wires under the pressure plate o f terminals (Power Input, HOT). Use 1/8- in. flat head screwdriver to tighten terminal screws firmly (4.4 lb-in minimum). Connect the house common to the Power Inputs NEUTRAL terminal. Connect another HOT wire to the Timeclocks T/C POWER terminal. Connect a house common to the Timeclocks T/C NEUTRAL. Install a 20 Amp circuit breaker in the main breake r panel and connect the HOT wiresfrom the WPC-1. LOCATION Install the WPC-1 enclosure using the mounting plates included with each enclosure. The WPC- 1 is housed in a Type 3R rainproof enclosure and can be mounted anywhere between the pool equipment and the breaker panel. WIRING INSTRUCTIONS FOLLOW PROPER WIRING PRACTICES IN ACCORDANCE WITH ALL LOCAL REGULATORY REQUIREMENTS. WARNING • TURN OFF INCOMING POWER BEFORE SERVICING EQUIPMENT. • ALL INSTALLATION AND MAINTENANCE WORK MUST BE PERFORMED BY QUALIFIED ELECTRICAL PERSONELL ONLY. • VERIFY ALL ELECTRICAL RATINGS BEFORE INSTALLATION IS COMPLETE. http://www.fiberstars.com 79-15053-00 REV. C Page 5 of 16 TO NEUTRAL BAR DE GROUND HOT LINE SI T/C NEUTRAL T/C POWER HOT LOAD SIDE NEUTRAL LOAD SIDE GFCI 120VAC 20AMP ERCIRCUIT BREAK Power Connection with GFCI To wire the WPC-1 with the use of a GFCI, punch out the GFCI knockout on the side of the WPC-1 enclosure. Install an outdoor rated GFCI. Using COPPER wire only, 12 gauge minimum, connect the GFCI from the LOAD side to the HOT terminal on the POWER INPUT of the WPC-1. Connect the NEUTRAL from the LOAD side of the GFCI to the NEUTRAL terminal from the WPC-1. Connect the GROUND of the GFCI to the EQUIP. GND. bar. Wire the HOT from the GFCI’s LINE side to the 20Amp circuit breaker in the main breaker panel as discussed earlier. Connect the NEUTRAL from the GFCI’s LINE side to the house common. From the GFCI’s LINE side, connect a wire from the HOTto the Timeclocks T/C POWER terminal. From the NEUTRAL of the LINE side on the GFCI, connect to the T/C NEUTRAL on the terminal block. NOTE: Do not connect the Timecloc k Inputs to the LOAD side of the GFCI. http://www.fiberstars.com 79-15053-00 REV. C Page 6 of 16 If this product is used to connect underwater lights directly, refer to 1999 NEC 680-21(b), 2002 NEC 680-24(b) or CEC 68-060, 062 and 066 for details. Hooking up Lights to Circuit 1 and Circuit 2 To connect a lighting product to the Circuit 1 and Circuit 2 switch, pull wires from the products to the WPC-1 through conduits connected to the bottom of t…

Text truncated - open the document above for the full version.

WPC-1 BLOCK DIAGRAM TIMER PUMP OFF REMOTE REMOTE OFF LIGHT INPUT VOLTAGE RELAY LIGHT BASIC FUNCTION The WPC-1 industrial controller operates on either 120Vac or 240Vac. It may contain one timer that controls pool equipment such as a pool/spa pump and has two remote capable circuits for the control of lighting fixtures such as Sam and Sal underwater lighting fixtures. The remote is also able to synchronize the two circuits.

ITC Engineering Services Over 20 years experience in Compliance Testing and Engineering Consulting Services ———————————————————————————————————————————————————————— ————————————————ISO 17025, NVLAP and VCCI Accredited Laboratory———————————————— 9959 Calaveras Road, Box 543, Sunol, CA 94586-0543 Phone: (925) 862-2944 • (888) 336-7625 • Fax: (925) 862-9013 E-mail: [email protected] • Web: www.itcemc.com Date: Thursday July 19, 2007 Timco Engineering Inc. 849 NW State Road 45 Newberry, Florida 32669 Subject: Request for Confidentiality To Whom It May Concern, Pursuant to 47CFR 0.575(d) of the commissions rules and section 552(b)(4) of the Freedom of Information Act (which authorizes the withholding from public inspection materials which would be privileged as a matter of law, such as trade secrets), we are hereby requesting that the following documents are to be handled with confidentiality and removed from display on the FCC Status Query Form Display of Exhibits: • Transmitter WPC1&2 schematic, layout, BOM.pdf • Repeater schematic.pdf • Receiver schematic.pdf If there are any questions or if further information is needed, please call me at (925) 862-2944. Thank you. Yours sincerely, John Caizzi Compliance Engineer ITC Engineering Services Inc.

External Photos for Fiberstars WPC1 Wireless Pool Controller The WPC1 consists of the WPC transmitter and the WPC1 relay controller with repeater. Figure 1. WPC transmitter, front. Figure 2. WPC transmitter, back.

NOTE: THE SMALL LABEL WILL GO ON THE BACK OF EACH REMOTE. WPC2 WPC-3 WPC-04 WPC1

Internal Photos for Fiberstars WPC1 Wireless Pool Controller The WPC1 consists of the WPC transmitter and WPC1 relay controller with repeater. Figure 1. WPC transmitter, PCB bottom. Figure 2. WPC transmitter, PCB top.

WPC-1 BLOCK DIAGRAM TIMER PUMP OFF REMOTE REMOTE OFF LIGHT INPUT VOLTAGE RELAY LIGHT BASIC FUNCTION The WPC-1 industrial controller operates on either 120Vac or 240Vac. It may contain one timer that controls pool equipment such as a pool/spa pump and has two remote capable circuits for the control of lighting fixtures such as Sam and Sal underwater lighting fixtures. The remote is also able to synchronize the two circuits.

Figure 5. WPC3 transmitter, configured for continuous transmission. Figure 6. WPC3 transmitter test setup. Figure 7. Intentional & spurious radiated emissions, occupied bandwidth setup, 200-1000 MHz. Figure 8. Intentional and spurious radiated emissions setup, 1-3.15 GHz. Figure 9. Unintentional conducted emissions setup.
