VFK-RC-WM-208Remote Control

MOTECK Electric Corp. Version history Version-1.0 1 Date Reason for revision Version 2025/11/25 First edition V1.0 MOTECK Electric Corp. 2 Product Data Sheet TSJ Remote Control Part No. Model No. H1TSJ00001 TSJ 1. Features Communication technology RF 433.92MHz Operating distance 10m Number of actuators 2 Number of button 18 Key lock ✔ Memory positions 2 Massage operation ✔ Standby current ✔ Operating current 4.5V Battery AAA x 3 (not included) Button backlight White Housing material ABS with black leather-texture paint Certified FCC, RoHS MOTECK Electric Corp. 3 2. Dimension Unit: mm 3. Function Operation 3.1 Button definitions MOTECK Electric Corp. 4 3.2 Pairing Press and hold the pairing button on the BB 209 control box until it flashes, then press and hold any button on the remote control until pairing is successful. During pairing, the remote control backlight will flash continuously; once pairing is successful, the remote control backlight will turn off. 3.3 Function operation Button Description ❶ Head up 1. Press and hold the button, the controlled bed will continue to move, and it will stop automatically when it reaches the end. 2. If you release the button during the process, the movement of the bed will stop immediately. ❷ Head down ❸ Foot up ❹ Foot down ❺ Lock 1. Press and hold the head up button, then press and hold the button for 2 seconds, the backlight will flash 3 times, indicating that locking/unlocking is complete. ❻ Torchlight Press and hold the button and the white LED will turns on. Release the button and the white LED will turns off. ❼ Snore Press the button once, the actuator will extend to the specific position preset by factory. The position varies depending on the model. ❽ Flat Press and hold the button to lie flat. Press any button to stop. ❾ Zero G Press the button once, the actuator will extend to the specific position preset by factory. The position varies depending on the model. ❿ Position memory 1 1. Position setting: After moving the actuator to the desired memory position using the up and down buttons, the “1” or “2” button within 2 seconds, the backlight will flash 3 times, indicating that the memory position has been successfully saved. 2. Execution Go to Position: Press the “1” or “2” button to automatically go to the storage position of the bed, press any button to stop. ⓫ Position memory 2 ⓬ Under-bed light Press the button once to switch on/off the under-bed light. ⓭ Increased massage head intensity 1. Press the or button once to activate the massage motor and maintain a constant vibration. 2. Press again to increase the intensity to the next level. The total massage intensity is 10. ⓮ Reduce massage head intensity ⓯ Increased massage foot intensity MOTECK Electric Corp. 5 ⓰ Reduce massage foot intensity ⓱ Vibration mode Press the buttons to activate two massage motors. The massage motor operates according to the default mode. ⓲ Turn off massage Press and hold the button until the head and foot massage stops. Notes: ● Backlight status description: - Function operation: Press any button, the backlight will turn on. After the button is release, the backlight will stay on for 10 seconds and then turn off automatically. - Lock: The backlight is off until the remote control unlocks. - Lock/Unlock: The backlight flashes 3 times after the switch was successful. - Low battery detection: If the remote control voltage is lower than 2.9V, all buttons become inoperative and the backlight turns off ● The specific position is customized according to the customer's bed frame and needs. MOTECK Electric Corp. 6 4. Markings ● TSJ model - Dimension: 44x30.5mm - Material: Silver polyester sticker ● Serial number - Dimension: 26x13mm - Material: Silver polyester sticker MOTECK Electric Corp. 7 5. Safety Declaration  FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.  FCC Radiation Exposure Statement The equipment complies with FCC Radiation exposure limit set forth for uncontrolled environment. The device shall be operated and installed without restriction.

Ascion, LLC 2066 Franklin Road Bloomfield Hills, MI 48302 United States Date: 12/23/2025 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: VFK-RC-WM-208 FRN: 0016634578 US Agent – Attestation Statement / Part 2.911(d)(7) Ascion, LLC certifies, that as of 12/23/2025, we have designated Jeffrey Cuthbertson to accept service of process on our behalf for FCC ID: VFK-RC-WM-208. Martin Rawls-Meehan, accepts to maintain an agent of service of process in the United States for no less than one year after the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Jeffrey Cuthbertson, accepts as of the 12/23/2025 of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Martin Rawls-Meehan for FCC ID:VFK-RC-WM-208. Designated Agent Information: Company Name: Ascion, LLC Address: 2066 Franklin Road, Bloomfield Hills, MI 48302 Contact Person: Jeffrey Cuthbertson Phone: 248-840-6840 Email: [email protected] Sincerely, Company: Ascion, LLC Designated Agent: Ascion, LLC Company Representative: Martin Rawls- Meehan Designated Agent Representative: Jeffrey Cuthbertson Signature: Signature: Docusign Envelope ID: 280BF480-7C77-4A0D-BD59-FEF4BFE306A2

Rev1/26/2023 (Ascion,LLC) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:12-12-2025 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID：VFK-RC-WM-208 [Ascion,LLC](“theapplicant”)certifiesthattheequipmentforwhichauthorizationissoughtisnot “covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903of theFCCrules. [Ascion,LLC](“theapplicant”)certifiesthattheequipmentforwhichauthorizationissoughtdoesnot includecybersecurityoranti-virussoftwareproducedorprovidedbyKasperskyLab,Inc.oranyofits successorsandassignees,includingequipmentwithintegratedKasperskyLab,Inc.(oranyofits successorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB986446 D01CoveredEquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Sincerely, (Applicantsignature) (MartinRawls-Meehan) Docusign Envelope ID: D02B62EE-0C95-4215-822A-C16881BA50CE Rev1/26/2023 (Ascion,LLC) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:12-12-2025 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID：VFK-RC-WM-208 [Ascion,LLC](“theapplicant”)certifiesthat,asofthedateofthefilingoftheapplication,theapplicantis notidentifiedontheCoveredList(asaspecificallynamedentityoranyofitssubsidiariesoraffiliates)as anentityproducing“covered” equipment. Sincerely, (Applicantsignature) (MartinRawls-Meehan) Docusign Envelope ID: D02B62EE-0C95-4215-822A-C16881BA50CE

Ascion,LLC FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:12-12-2025 SUBJECT:FCCID:VFK-RC-WM-208 ToWhomItMayConcern: I,theundersigned,herebystatesthisequipmenthasbeentestedandfoundtocomply withthelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules,and willapplytheSupplier'sDeclarationofConformityproceduretotheclassB computerperipheralportionofthiscompositedevice.IunderstandthefollowingFCC requirements: 1.DevicessubjecttotheSDoCprocedurearerequiredtobetestedtoshow compliancewiththeFCCtechnicalregulationsbyarecognizedaccreditedtesting laboratory.ThetestinglaboratorymustbeaccreditedbyaCommissionapproved accreditationbodyordesignatedunderthetermsofagovernment-to-government MutualRecognitionAgreement(MRA).Alistingofthoseaccreditedtesting laboratoriesthathavebeenrecognizedbytheCommissionispublishedontheFCC Webpage:https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm(Selectthe "accredited"optiontosearchforFCCrecognizedaccreditedtestfirms.) 2.Pt2.1077containsthelistofinformationthatmustbeincludedintheSupplier's DeclarationofConformity,whichmustbesuppliedwitheachproductsold.The SDoCcomplianceinfoshallbeincludedintheUser’sManualorasaseparate sheet.Theinfomustcontainthename,address,andphonenumberofthe responsibleparty,whichmustbelocatedwithintheUnitedStates.Accordingto 2.909(b),theresponsiblepartyiseithertheManufactureroriftheproductis importedtheImporter. Regards, Ascion,LLC ------------------------------- （ MartinRawls-Meehan ） Docusign Envelope ID: D02B62EE-0C95-4215-822A-C16881BA50CE

Ascion,LLC Rev11/20/07 FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:VFK-RC-WM-208 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName BlockDiagram Schematics OperationalDescription BlockDiagram Schematics OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. PursuanttoDA04-1705June15,2004oftheCommission’spublicnotice,Wealsorequestingthe commissiontograntshort-termconfidentialityrequestonthefollowingattachmentsuntil180 daysaftertheGrantDateofEquipmentAuthorizations. ExhibitTypeFileName Sincerely, MartinRawls-Meehan 12-12-2025 Docusign Envelope ID: D02B62EE-0C95-4215-822A-C16881BA50CE

Ascion,LLC Declarationonmodeldifference Wetheundersignedherebyconfirmthatthesemodelsareidentical,andallmodelshavethesame RFmodule,PCBlayout,Antenna,schematicsandcomponent.Onlydifferentonmodelnumber andsurfacestickerpattern. ProductionnameTrademarkFCCIDModelno. RemoteControlHavertys,ReverieVFK-RC-WM-208RC-WM-208-001, RC-WM-214-001, RC-WM-208,RC-WM-214 Confirmedby: MartinRawls-Meehan Ascion,LLC 12-12-2025 Docusign Envelope ID: D02B62EE-0C95-4215-822A-C16881BA50CE

Ascion,LLC FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:12-12-2025 SUBJECT:FCCApplicationforFCCID:VFK-RC-WM-208 ToWhomItMayConcern: We,theundersigned,herebyauthorizeSamLv.atEMTEK(DONGGUAN)CO.,LTD.on ourbehalf,toapplytotheFederalCommunicationsCommissiononourequipment.Any andallactscarriedoutbyEMTEK(DONGGUAN)CO.,LTD.onourbehalfshallhave thesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,the applicant,arenotsubjecttoadenialoffederalbenefitspursuanttoSection5301ofthe Anti-DrugActof1988,21USC853a,andnopartytotheapplicationissubjecttoadenial offederalbenefitspursuanttothatsection. Regards, Sincerely, MartinRawls-Meehan 12-12-2025 Docusign Envelope ID: D02B62EE-0C95-4215-822A-C16881BA50CE

ReportNo.ENS2511180153W003Page1of5Ver.1.0 FCCID:VFK-RC-WM-208 ReportNo.ENS2511180153W003Page2of5Ver.1.0 ReportNo.ENS2511180153W003Page3of5Ver.1.0 ReportNo.ENS2511180153W003Page4of5Ver.1.0 ReportNo.ENS2511180153W003Page5of5Ver.1.0

Report No.: BL-SZ25C0591-AA 1 / 1 EUT PHOTO --BLANK BELOW-- PCB Antenna

ReportNo.ENS2511180153W003Page1of2Ver.1.0 FCCID:VFK-RC-WM-208 ReportNo.ENS2511180153W003Page2of2Ver.1.0 433MHzANT

ReportNo.ENS2511180153W00302RPage1of7Ver.1.0 $二维码$ TESTREPORT ProductName：RemoteControl ModelNumber： RC-WM-208-001,RC-WM-214-001,RC-WM-208, RC-WM-214 FCCID ： VFK-RC-WM-208 Preparedfor:Ascion,LLC Address:2066FranklinRd.,BloomfieldHills,Michigan48302, UnitedStates Preparedby:EMTEK(SHENZHEN)CO.,LTD. Address:Building69,MajialongIndustryZone,NanshanDistrict, Shenzhen,Guangdong,China TEL:(0755)26954280 FAX:(0755)26954282 ReportNumber:ENS2511180153W00302R Dateofsamplereceipt:Nov18,2025 Date(s)ofTests:Nov18,2025toDec05,2025 Dateofissue:Dec08,2025 ReportNo.ENS2511180153W00302RPage2of7Ver.1.0 TableofContents 1.TESTRESULTCERTIFICATION...............................................................................................................................................3 2.EUTSPECIFICATION.................................................................................................................................................................5 3.TESTREQUIREMENT................................................................................................................................................................6 4.MEASUREMENTRESULT.........................................................................................................................................................7 ReportNo.ENS2511180153W00302RPage3of7Ver.1.0 1.TESTRESULTCERTIFICATION Applicant:Ascion,LLC Address:2066FranklinRd.,BloomfieldHills,Michigan48302,UnitedStates Manufacturer:SUZHOUMOTECKELECTRONICS-TECHNOLOGYCO.,LTD Address: NO.500,HUBEIROAD,FENHUECONOMICDEVELOPMENTZONE, WUJIANGCITY,JIANGSUPROVINCE,CHINA Factory:SUZHOUMOTECKELECTRONICS-TECHNOLOGYCO.,LTD Address: NO.500,HUBEIROAD,FENHUECONOMICDEVELOPMENTZONE, WUJIANGCITY,JIANGSUPROVINCE,CHINA EUT:RemoteControl ModelName:RC-WM-208-001,RC-WM-214-001,RC-WM-208,RC-WM-214 Trademark:Havertys,Reverie MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT §15.231,§2.1093 PASS TheaboveequipmentwastestedbyEMTEK(SHENZHEN)CO.,LTD.Thetestdata,dataevaluation,test procedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththeprocedures giveninANSIC63.10(2020)andtheenergyemittedbythesampleEUTtestedasdescribedinthisreportisin compliancewiththerequirementsofFCCRules FCC§15.231,§2.1093 . Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport DateofTest:Nov18,2025toDec04,2025 Preparedby: YuXiaolan/Editor Reviewer: XiaLilu/Supervisor Approve&AuthorizedSigner:WangLi/Manager ReportNo.ENS2511180153W00302RPage4of7Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary ENS2511180153W00302R/OriginalReport ReportNo.ENS2511180153W00302RPage5of7Ver.1.0 2. EUTSpecification CharacteristicsDescription Product:RemoteControl ModelNumber: RC-WM-208-001,RC-WM-214-001,RC-WM-208,RC-WM-214 Allproductsareidenticalexceptthemodelnumberandsurfacesticker pattern.HereweselectedRC-WM-208-001forallthetest. Sample:1# DeviceType: RemoteControl Modulation: FSK OperatingFrequency Range(s): 433.92MHz NumberofChannels: 1channel AntennaType: PCBantenna AntennaGain: 3.87dBi Powersupply: DC4.5Vfrombattery Evaluationapplied:MPEEvaluation SAREvaluation ReportNo.ENS2511180153W00302RPage6of7Ver.1.0 3.TestRequirement SAREvaluation Accordingto447498D01V06,systemsoperatingundertheprovisionsofthissectionshallbeoperatedina mannerthatensuresthatthepublicisnotexposedtoradiofrequencyenergylevelinexcessofthe Commission’sguidelines. RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,usingmeasurementsorcomputer simulation.WhenroutineSARevaluationisnotrequired,portabletransmitterswithoutputpowergreaterthan theapplicablelowthresholdrequireSARevaluationtoqualityforTCBapproval. OneantennaisavailablefortheEUT.Theminimumseparationdistanceis5mm. ReportNo.ENS2511180153W00302RPage7of7Ver.1.0 4. MeasurementResult Antennagain:3.87dBi ***EndofReport*** Channel Freq. (MHz) MaxField Strength (dBuV/m) peak output power (dBm) Tuneup Power (dBm) Maxtune uppower (dBm) Calculation Result Calculation threshold(1-g SAR) 433.9276.14-19.09-19±1-180.00213

Report No.: BL-SZ25C0591-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 12 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: ASCION LLC Address: 701 Seneca St Ste 140 Buffalo, NY, 14210-1361 United States Equipment Type: Remote Control Model Name: RC-WM-208-001 (refer to section 2.3) Brand Name: N/A Test Standard: IEEE Std 149-2021 Sample Arrival Date: Dec. 10, 2025 Test Date: Dec. 10, 2025 Date of Issue: Jan. 04, 2026 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Mai Jintian Checked by: Xia Long Approved by: Tolan Tu (Technical Director) _______________ _______________ _______________ Report No.: BL-SZ25C0591-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 12 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Rev. 01 Jan. 04, 2026 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION ........................................................................................................ 3 1.1 Test Laboratory .................................................................................................................. 3 1.2 Test Location ...................................................................................................................... 3 2 PRODUCT INFORMATION ....................................................................................................... 4 2.1 Applicant Information .......................................................................................................... 4 2.2 Manufacturer Information .................................................................................................... 4 2.3 General Description for Equipment under Test (EUT) ......................................................... 4 2.4 Ancillary Equipment ............................................................................................................ 4 3 SUMMARY OF TEST RESULTS ............................................................................................... 5 3.1 Test Standards ................................................................................................................... 5 3.2 Test Verdict ........................................................................................................................ 5 3.3 Test Uncertainty ................................................................................................................. 5 4 GENERAL TEST CONFIGURATIONS ...................................................................................... 6 4.1 Test Condition .................................................................................................................... 6 4.2 Test Equipment List ............................................................................................................ 6 4.3 Test Setup .......................................................................................................................... 7 4.4 Test Frequencies ................................................................................................................ 7 ANNEX A TEST RESULTS .......................................................................................................... 8 A.1 Gain and Efficiency ............................................................................................................. 8 A.2 VSWR ................................................................................................................................. 8 ANNEX B RADIATION PATTERN ............................................................................................... 9 ANNEX C TEST SETUP PHOTOS ............................................................................................ 11 ANNEX D EUT PHOTO.............................................................................................................. 11 Report No.: BL-SZ25C0591-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 12 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1 GENERAL INFORMATION 1.1 Test Laboratory Name Shenzhen BALUN Technology Co., Ltd. Address Building 2, Intelligent Connected Vehicle Industrial Park, No. 55, Xiangshan Road, Luotian Community, Yanluo Sub-district, Bao'an District, Shenzhen, Guangdong Province, China Phone Number +86 755 6685 0100 1.2 Test Location Name Shenzhen BALUN Technology Co., Ltd. Location Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1/F, Building B, Ganghongji High-tech Intelligent Industrial Park, No. 1008, Songbai Road, Yangguang Community, Xili Sub-district, Nanshan District, Shenzhen, Guangdong Province, P. R. China Building 2, Intelligent Connected Vehicle Industrial Park, No. 55, Xiangshan Road, Luotian Community, Yanluo Sub-district, Bao'an District, Shenzhen, Guangdong Province, China Report No.: BL-SZ25C0591-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 4 / 12 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 2 PRODUCT INFORMATION 2.1 Applicant Information Applicant ASCION LLC Address 701 Seneca St Ste 140 Buffalo, NY, 14210-1361 United States Contact Person White.Wu Telephone Number (0512) 6329 6323 2.2 Manufacturer Information Manufacturer SUZHOU MOTECK ELECTRONICS-TECHNOLOGY CO., LTD Address NO. 500, HUBEI ROAD, FENHU ECONOMIC DEVELOPMENT ZONE,WUJIANG CIT…

Text truncated - open the document above for the full version.

ReportNo.ENS2511180153W00301RPage1of30Ver.1.0 TESTREPORT ProductName ： RemoteControl ModelNumber ： RC-WM-208-001,RC-WM-214-001,RC-WM-208, RC-WM-214 FCCID:VFK-RC-WM-208 Preparedfor:Ascion,LLC Address:2066FranklinRd.,BloomfieldHills,Michigan48302, UnitedStates Preparedby:EMTEK(SHENZHEN)CO.,LTD. Address:Building69,MajialongIndustryZone,NanshanDistrict, Shenzhen,Guangdong,China TEL:(0755)26954280 FAX:(0755)26954282 ReportNumber:ENS2511180153W00301R Dateofsamplereceipt:Nov18,2025 Date(s)ofTests:Nov18,2025toDec05,2025 Dateofissue:Dec08,2025 $二维码$ $二维码$ ReportNo.ENS2511180153W00301RPage2of30Ver.1.0 1TESTRESULTCERTIFICATION Applicant: Ascion,LLC Address： : 2066FranklinRd.,BloomfieldHills,Michigan48302,UnitedStates Manufacturer: SUZHOUMOTECKELECTRONICS-TECHNOLOGYCO.,LTD Address： : NO.500,HUBEIROAD,FENHUECONOMICDEVELOPMENTZONE, WUJIANGCITY,JIANGSUPROVINCE,CHINA Factory: SUZHOUMOTECKELECTRONICS-TECHNOLOGYCO.,LTD Address： : NO.500,HUBEIROAD,FENHUECONOMICDEVELOPMENTZONE, WUJIANGCITY,JIANGSUPROVINCE,CHINA EUT: RemoteControl ModelName: RC-WM-208-001,RC-WM-214-001,RC-WM-208,RC-WM-214 Trademark: Havertys,Reverie MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT FCC47CFRPart2,SubpartJ FCC47CFRPart15,SubpartC PASS TheaboveequipmentwastestedbyEMTEK(SHENZHEN)CO.,LTD.Thetestdata,dataevaluation,testprocedures, andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththeproceduresgiveninANSI C63.10(2020)andtheenergyemittedbythesampleEUTtestedasdescribedinthisreportisincompliancewiththe requirementsofFCCRulesPart2andPart15.231REQUIREMENTS. DateofTest:Nov18,2025toDec04,2025 Preparedby: YuXiaolan/Editor Reviewer: XiaLilu/Supervisor Approve&AuthorizedSigner:WangLi/Manager ReportNo.ENS2511180153W00301RPage3of30Ver.1.0 ModifiedInformation VersionReportNo.RevisionDateSummary ENS2511180153W00301R/OriginalReport ReportNo.ENS2511180153W00301RPage4of30Ver.1.0 TableofContents 1TESTRESULTCERTIFICATION.........................................................................................................2 2EUTTECHNICALDESCRIPTION........................................................................................................5 3SUMMARYOFTESTRESULT..............................................................................................................6 4TESTMETHODOLOGY..........................................................................................................................7 4.1GENERALDESCRIPTIONOFAPPLIEDSTANDARDS............................................................................7 4.2MEASUREMENTEQUIPMENTUSED.........................................................................................................7 4.3DESCRIPTIONOFTESTMODES................................................................................................................8 5FACILITIESANDACCREDITATIONS.................................................................................................9 5.1FACILITIES........................................................................................................................................................9 5.2LABORATORYACCREDITATIONSANDLISTINGS.................................................................................9 6TESTSYSTEMUNCERTAINTY..........................................................................................................10 7SETUPOFEQUIPMENTUNDERTEST............................................................................................11 7.1RADIOFREQUENCYTESTSETUP1............................................................................................................11 7.2RADIOFREQUENCYTESTSETUP2............................................................................................................11 7.3CONDUCTEDEMISSIONTESTSETUP........................................................................................................12 7.4BLOCKDIAGRAMCONFIGURATIONOFTESTSYSTEM.......................................................................13 7.5SUPPORTEQUIPMENT...................................................................................................................................13 8TESTREQUIREMENTS........................................................................................................................14 8.1OCCUPIEDBANDWIDTH.............................................................................................................................14 8.2RADIATEDSPURIOUSEMISSION................................................................................................................16 8.3TRANSMISSIONREQUIREMENT..............................................................................................................26 8.4CONDUCTEDEMISSIONTEST.....................................................................................................................28 8.5ANTENNAAPPLICATION......................................................................................................................................29 ReportNo.ENS2511180153W00301RPage5of30Ver.1.0 2EUTTECHNICALDESCRIPTION CharacteristicsDescription ProductName: RemoteControl ModelNumber: RC-WM-208-001,RC-WM-214-001,RC-WM-208,RC-WM-214 Allproductsareidenticalexceptthemodelnumberandsurfacesticker pattern.HereweselectedRC-WM-208-001forallthetest. Modulation: FSK OperatingFrequency Range(s): 433.92MHz NumberofChannels: 1channel AntennaType: PCBantenna AntennaGain: 3.87dBi Powersupply: DC4.5Vfrombattery Note:formoredetails,pleaserefertotheUser’smanualoftheEUT. TheEUThasbeenassociatedwithperipheralspursuanttoANSIC63.10-2020andconfiguration operatedinamannertendedtomaximizeitsemissioncharacteristicsinatypicalapplication. Frequencyrangeinvestigated:radiation(9KHztothe10thharmonicofthehighestfundamental frequencyorto40GHz,whicheverislower). ReportNo.ENS2511180153W00301RPage6of30Ver.1.0 3SUMMARYOFTESTRESULT FCCPartClauseTestParameterVerdictRemark 15.231(c)OccupiedBandwidthPASS 15.231(b)RadiatedSpuriousEmis…

Text truncated - open the document above for the full version.

Report No.: BL-SZ25C0591-AO 1 / 3 TEST SETUP PHOTOS Report No.: BL-SZ25C0591-AO 2 / 3 Report No.: BL-SZ25C0591-AO 3 / 3 --BLANK BELOW--

ReportNo.ENS2511180153W003Page1of1Ver.1.0 FCCID:VFK-RC-WM-208
