VG8XM031AYYMicrowave Oven

OWNER’S MANUAL Visit our web site at “www.emersonradio.com” UNAUTHORIZED MODIFICATIONS TO THIS DEVICE COULD VOID MANUFACTURER'S WARRANTY. 1000WMICROWAVEOVEN 1 When using electrical appliances, basic safety precautions should be followed, including the following: WARNING–Toreducetheriskofburns,electric shock, fire, injury to persons, or exposure to excessivemicrowaveenergy: 1 Read all instructions before using this appliance. 2 Read and follow the specific “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY” found on page 1. 3 This appliance must be grounded. Connect only to a properly grounded outlet. See “GROUNDING INSTRUCTIONS” found on page 5. 4 Install or locate this appliance only in accordance with the provided installation instructions. 5 Some products such as whole eggs and sealed containers (for example, closed glass jars) may explode and should not be heated in this oven. 6 Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry food. It is not designed for industrial or laboratory use. 7 As with any appliance, close supervision is necessary when used by children. 8 Do not operate this appliance if it has a damaged cord or plug, if it is not working properly,orif it has been damaged or dropped. 9 This appliance should be serviced only by qualified service personnel. Contact the nearest authorized service facility for examination, repair or adjustment. 10 Do not cover or block any openings on this appliance. 11 Do not store or use this appliance outdoors. Do not use this product near water, for example, near a kitchen sink, in a wet basement, or near a swimming pool, or similar location. 12 Do not immerse cord or plug in water. 13 Keep cord away from heated surfaces. 14 Do not let cord hang over edge of table or counter. 15 When cleaning surfaces of door and oven that come together when closing the door, use only mild, non-abrasive soaps or detergents applied with a sponge or soft cloth. 16 To reduce the risk of fire in the oven cavity: (a) Do not overcook food. Carefully attend appliance if paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking. (b) Remove wire twist-ties from paper or plastic bags before placing bag in oven. (c) cord, or shut off power at the fuse or circuit breaker panel. (d) Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils, or food in the cavity when not in use. 17 Do not use this microwave oven to heat corrosive chemicals (for example, sulfides and chlorides). Vapors from such corrosive chemicals may interact with the contact and IMPORTANTSAFETYINSTRUCTIONS 2 If materials inside the oven ignite, keep oven door closed, turn oven off, and disconnect the power SAVETHESEINSTRUCTIONS IMPORTANTSAFETYINSTRUCTIONS SAFETYPRECAUTIONS GeneralUse 1 Do NOT attempt to tamper with or make any adjustments or repairs to door, control panel or any other part of the oven. Do NOT remove outer panel from oven. Repairs should only be done by qualified service personnel. 2 Do NOT operate the oven empty. The microwave energy will reflect continuously throughout the oven if no food or water is present to absorb energy. 3 If a fire occurs in the oven, touch the Stop/Clear button and LEAVE THE DOOR CLOSED. Disconnect the power cord, or shut off power at the fuse or circuit breaker panel. 4 Do NOT attempt to dry clothes, newspapers or other materials in the oven. They may catch on fire. 5 Do NOT use recycled paper products. Recycled paper towels, napkins and waxed paper can contain metal flecks which may cause arcing or ignite. Paper products containing nylon or nylon filaments should be avoided, as they may ignite. 6 Some styrofoam trays (like those that meat is packagedon)have a thin strip of metal embedded on the bottom. When microwaved, the metal can burn the floor of the oven or ignite a paper towel. 7 Avoid inserting nails, wire, etc. through any holes in the unit during operation. Never insert a wire, nail or any other metal objects through the holes on the cavity or any other holes or gaps, because such objects may cause electric shock and microwave leakage. Utensils 1 METAL CONTAINERS or dishes with metallic rims should not be used. Arcing may occur. 2 METAL TWIST-TIES may not be used in the microwave oven. 3 Do NOT use SEALED JARS or NARROW NECK bottles for cooking or reheating. They may shatter. 4 Do NOT use CONVENTIONAL THER- MOMETERS in the microwave oven. They may cause arcing. 5 Remove PLASTIC STORE WRAPS before cooking or defrosting foods in the oven. 6 For FURTHER INFORMATION on proper cooking utensils, refer to theCOOKING GUIDEon page 17. Food 1 Never use your microwave oven for HOME CANNING. The oven is not designed to permit proper canning. Improperly canned food may spoil and be dangerous to consume. 2 COOKING TIMES given in the cooking guide are approximate. Factors that may affect cooking are starting temperature, altitude, volume, size and shape of food and utensils used. As you become familiar with the oven, you will be able to adjust for these factors. 3 springs of the safety interlock switches, thereby rendering them inoperable. 18 Keep the waveguide cover clean at all times. Wipe the oven interior with a soft damp cloth after each use. If you leave grease or fat anywhere in the cavity it may overheat, smoke or even catch fire when next using the oven. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling due to surface tension of the liquid. Visible bubbling or boiling when container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED To reduce the risk of injury to persons: Do not overheat the liquid. Stir the liquid both before and halfway through heatin…

Text truncated - open the document above for the full version.

Web Site: www.midea.com.cn No.6, Yong An Road, Beijiao, Shunde, Foshan E-Mail: [email protected] Guangdong, P.R. China Phone : +86-757-23606480 FAX : +86-757-26656995 AGENCY AUTHORIZATION LETTER FCC ID: VG8XM031AYY Date: 2012-2-2 To whom it may concern: We, the undersigned, hereby authorize ECMG to act on our behalf , as our agent ,in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to the matters. and any other lawful activity necessary to obtain such certification. Any act carried out by ECMG within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date , if you have any question regarding the authorization , please don’t hesitate to contact us , thank you. Sincerely, Xue wenfei Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd Phone : +86-757-26306480 FAX :+86-757- 22607341 E-Mail: [email protected]

Date: 2012-2-2 Federal communications commission Authorization and Evaluation Division FCC ID: VG8XM031AYY Confidentiality Request Pursuant to section 0.457 and 0.459 of the commission’s rules, the applicant hereby requests confidential treatment of information accompanying this application as outline below: 1 Schematics 2 Block diagram 3 Operational description The above materials contain trade secrets and proprietary information not customarily released to the public, the public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, xue wenfei Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd Phone : +86-757-26306480 FAX :+86-757- 22607341 E-Mail: [email protected]

External photos EUT Sample Photos for Model EM031ASJ-X1 EUT Front View EUT Rear View Door Opend View

FCC Label Format&Location: SIZE:160X50mm Label location

Internal photos EUT model: EM031ASJ-X1 EUT Uncovered View Magnetron Front View Power Filter Board Top View Power Filter Board Bottom View Control Board Top View Control Board Bottom View

www.ecmg-global.net FCC EMI TEST REPORT On Model Name: Microwave Oven Model Numbers: XM031AYY, XM031AYY-X1 Brand Name: FCC ID Number: VG8XM031AYY Prepared for Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd According to FCC Part 18(2010) Industrial, Scientific and Medical Equipment FCC/OST MP-5(1986) FCC methods of measurements of radio noise emission from industrial, scientific and medical equipment Test Report#: GUA-1201-10781-FCC Prepared by: Sewen Guo Reviewed by: Jawen Yin QC Manager: Swall Zhang Test Report Released by: February 22, 2012 ⎯⎯⎯⎯⎯⎯⎯⎯ ⎯⎯⎯⎯⎯⎯ Swall Zhang Date Test Location Tests performed in a Certified ANSI Semi-Anechoic Chamber and Shielded Room. Test Site Location : GD WITOL VACUUM ELECTRONIC EMC TEST LABORATORY BeiJiao,ShunDe,FoShan,GuangDong, 528311, China Tel : (86)-757-26326917 Fax : (86)-757- 22607341 Test Facility The test facility was recognized, certified, or accredited by the following organizations: FCC – Registration No.: 910385 GD WITOL VACUUM ELECTRONIC EMC TEST LABORATORY has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC was maintained in our files. Table of Contents GOVERNMENT DISCLAIMER NOTICE _______________________________________________ 2 REPRODUCTION CLAUSE __________________________________________________________ 2 OPINIONS AND INTERPRETATIONS ________________________________________________ 2 STATEMENT OF MEASUREMENT UNCERTAINTY ____________________________________ 2 ADMINISTRATIVE DATA ___________________________________________________________ 3 EUT DESCRIPTION _________________________________________________________________ 4 EUT MODEL DERIVED______________________________________________________________ 4 TEST SUMMARY ___________________________________________________________________ 5 LOAD FOR MICROWAVE OVEN _____________________________________________________ 6 EUT EXERCISE SOFTWARE _________________________________________________________ 6 EQUIPMENT MODIFICATION _______________________________________________________ 6 EUT SAMPLE PHOTOS FOR MODEL EM031ASJ-X1 __________________________________ 7 TEST SYSTEM DETAILS ___________________________________________________________ 11 CONFIGURATION OF TESTED SYSTEM ____________________________________________ 12 ATTACHMENT 1 –RADIATION HAZARD TEST _____________________________________ 13 ATTACHMENT 2 – INPUT POWER MEASUREMENT _________________________________ 15 ATTACHMENT 3 – RF OUTPUT POWER MEASUREMENT ____________________________ 17 ATTACHMENT 4 – OPERATING FREQUENCY MEASUREMENT _______________________ 20 ATTACHMENT 5 – CONDUCTED EMISSION TEST RESULTS_________________________ 23 ATTACHMENT 6 - RADIATED EMISSION TEST RESULTS____________________________ 27 FCC Test Report #: GUA-1202-10781-FCC Prepared for Guangdong Midea Microwave and Electrical Appliances Manufacturing Co., Ltd Prepared by ECMG Electronic Technical Testing Corp (Shenzhen) Page 1 of 30 List Attached Files Exhibit Type File Description File Name Test Report Test Report VG8XM031AYY _Test Report.pdf Operation Description Technical Description VG8XM031AYY _Operation Description.pdf External Photos External Photos VG8XM031AYY _External Photos Internal Photos Internal Photos VG8XM031AYY _Internal Photos Block Diagram Block Diagram VG8XM031AYY _Block Diagram.pdf Schematics Circuit Diagram VG8XM031AYY _Schematics.pdf ID Label/Location Label and Location VG8XM031AYY _Label & Location.pdf User Manual User Manual VG8XM031AYY _User’s Manual.pdf Test set-up photos Test set-up photos VG8XM031AYY _Test Set-up Photos FCC Test Report #: GUA-1202-10781-FCC Prepared for Guangdong Midea Microwave and Electrical Appliances Manufacturing Co., Ltd Prepared by ECMG Electronic Technical Testing Corp (Shenzhen) Page 2 of 30 Government Disclaimer Notice When government drawing, specification, or other data are used for any purpose other than in connection with a definitely related government procurement operation, the United States Government thereby incurs no responsibility nor any obligation whatsoever; and the fact that the Government may have formulated, furnished, or in any way supplied the said drawing, specifications, or other data, is not to be regarded by implication or otherwise in any manner licensing the holder or any other person or corporation, or conveying any rights or permission to manufacture, use, or sell patented invention that may in any way be related thereto. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. Reproduction Clause Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from ECMG Electronic Technical Testing Corp (Shenzhen). Opinions and Interpretations This test report relates to the abovementioned equipment under test (EUT).Without the permission of ECMG Electronic Technical Testing Corp (Shenzhen) Test Lab this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. The manufacturer has sole responsibility of continued compliance of the device. Statement of Measurement Uncertainty The data and results referenced in the document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. FCC Test Report #: GUA-1202-10781-FCC Prepared for Guangdong Midea Microwave and Electrical Appliances Manufacturing Co., Ltd Prepared by ECMG Electronic Technical Testing Corp (Shenzhen) Page 3 of 30 Administrative Data Test Sample : Microwave Oven Model Numbers : XM031AYY, XM031AYY-X1 Model Tested : EM031ASJ-X1 Brand Name : Receipt Date : February 13, 2012 Date Test…

Text truncated - open the document above for the full version.

Test Photos Radiation Hazard Test Set-up: Input Power Test Set-Up : RF Output Power Test Set-Up : Operating Frequency Test Set-up: Conducted Emission Test Set-up: Radiated Emission Test Set-up (30~1000MHz): Radiated Emission Test Set-up (1~25GHz) :
