VG8XM036AYYMicrowave Oven

Questions or forService Call: 1-866-312-2117 Microwave Oven Counter-Top with Sensor Pad READ AND SAVE THESE INSTRUCTIONS Use & Care Manual Welcome & Congratulations......2 Important Safety Instructions...3 Features & Specifications.........7 Before Operating........................8 Manual Operation.......................9 Sensor Operations...................12 Cooking Charts........................14 Care & Cleaning.......................18 Before You Call........................19 Warranty....................................20 E(A)M036A##-P/P1 1000 W Rated Voltage: Rated Input Power(Microwave): Rated Output Power(Microwave): 1450 W AC120V~ 60Hz Welcome & Congratulations Product Registration Be sure to register your product.The self-addressedPRODUCT REGISTRATION CARD should be filled This Use & Care Manual contains general operating instructions for your appliance and feature information for several models. Your microwavemay not have all the described features. The graphics shown are representative. The graphics on your microwave may not look exactly like those shown. Congratulations on your purchase of a new microwave! we are very proud of our product and are completely committed to providing you with the best service possible. Your satisfaction is our number one priority. We know you’ll enjoy your new microwave andThank You for choosing our product. We hope you consider us for future purchases. PLEASE CAREFULLY READ AND SAVE THESE INSTRUCTIONS This Use & Care Manual provides specific operating instructions for your model. Use your microwave only as instructed in this manual. These instructions are not meant to cover every possible condition and situation that may occur. Common sense and caution must be practiced when installing, operating and maintaining any appliance. Be sure to record your model and serial number. The serial plate is located on the back of the microwave oven. Please record your model and serial number and date of purchase in the spaces provided below for future reference in case your microwave should ever require servicing: Model Number: _______________________________________________ Serial Number: _______________________________________________ Purchase Date: _______________________________________________ 2 in completely, signed and returned to us. 3 To avoid personal injury or property damage, observe the following: 1. deep fat fry in oven. Fat could overheat and be hazardous to handle. 2. cook or reheat eggs in shell or with an unbroken yolk using microwave energy. Pressure may build up and erupt. Pierce yolk with fork or knife before cooking. 3. Pierce skin of potatoes, tomatoes, and similar foods before cooking with microwave energy. When skin is pierced, steam escapes evenly. 4. operate oven without load or food in oven cavity. 5. Use only popcorn in packages designed and labeled for microwave use. Popping time varies depending on oven wattage. continue to heat after popping has stopped. Popcorn will scorch or burn. leave oven unattended. 6. use regular cooking thermometers in oven. Most cooking thermometers contain mercury and may cause an electrical arc, malfunction, or damage to oven. 7. use metal utensils in oven. 8. use paper, plastic, or other combustible materials that are not intended for cooking. 9. When cooking with paper, plastic, or other combustible materials, follow manufacturer’s recommendations on product use. 10. use paper towels which contain nylon or other synthetic fibers. Heated synthetics could melt and cause paper to ignite. 11. heat sealed containers or plastic bags in oven. Food or liquid could expand quickly and cause container or bag to break. Pierce or open container or bag before cooking. 12. To avoid pacemaker malfunction, consult physician or pacemaker manufacturer about effects of microwave energy on pacemaker. Warning and Important Safety Instructions appearing in the Use & Care Guide are not meant to cover all possible conditions and situations that may occur. Common sense, caution, and care must be exercised when installing, maintaining or operating a microwave. Always contact your dealer, distributor, service agent or manufacturer about problems or conditions you do not understand. What You Need to Know About Safety Instructions Recognize Safety Symbols, Words, Labels DANGER DANGER - Immediate hazards whichWILLresult in severe personal injury or death. WARNING - Hazards or unsafe practices whichCOULD result in severe personal injury or death. SAVE THESE INSTRUCTIONS WARNING CAUTION - Hazards or unsafe practices whichCOULD result in minor personal injury. CAUTION CAUTION MPORTANT SAFETY INSTRUCTIONS I 4 SAVE THESE INSTRUCTIONS Federal Communications Commission Radio Frequency Interference Statement (U.S.A. Only) WARNING WARNING To avoid risk of electrical shock or death, this oven must be grounded and plug must not be altered. a. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord. their use. 1. The marked electrical rating of the cord set or extension cord set should be at least as great as the electrical rating of the appliance. 2. The extension cord must be a grounding-type 3- wire cord. 3. The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be tripped over, snagged, or pulled on If you use an extension cord, the interior light may flicker and the blower sound may vary when the microwave oven is on. Cooking times may be longer, too. Oven MUST be grounded. Consult a qualified electrician or servicer if grounding instructions are not completely understood, or if doubt exists as to whether the oven is properly grounded. Do not use an extension cord. If the product power cord is too short, have a qualified electrician install a three-slot receptacle. This oven should be plugged into a separate 60 hertz circuit with the electrical ratting as shown in specifications table. When the oven is on a circui…

Text truncated - open the document above for the full version.

Date: 2011-3-8 Federal communications commission Authorization and Evaluation Division FCC ID: VG8XM036AYY Confidentiality Request Pursuant to section 0.457 and 0.459 of the commission’s rules, the applicant hereby requests confidential treatment of information accompanying this application as outline below: 1 Schematics 2 Block diagram 3 Operational description The above materials contain trade secrets and proprietary information not customarily released to the public, the public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, xue wenfei Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd Phone : +86-757-26306480 FAX :+86-757-26656995 E-Mail: [email protected]

Web Site: www.midea.com.cn No.6, Yong An Road, Beijiao, Shunde, Foshan E-Mail: [email protected] Guangdong, P.R. China Phone : +86-757-23606480 FAX : +86-757-26656995 AGENCY AUTHORIZATION LETTER FCC ID: VG8XM036AYY Date: 2011-3-8 To whom it may concern: We, the undersigned, hereby authorize ECMG to act on our behalf , as our agent ,in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to the matters. and any other lawful activity necessary to obtain such certification. Any act carried out by ECMG within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date , if you have any question regarding the authorization , please don’t hesitate to contact us , thank you. Sincerely, Xue wenfei Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd Phone : +86-757-26306480 FAX :+86-757-26656995 E-Mail: [email protected]

External Photos EUT Front View EUT Rear View Door Opened View

Web Site: www.midea.com.cn No.6, Yong An Road, Beijiao, Shunde, Foshan E-Mail: [email protected] Guangdong, P.R. China Phone : +86-757-23606480 FAX : +86-757-26656995 Proposed FCC Label & Label Location z Label Size: 160X50mm z Lable Specifications: Text is Black or white in color and is left justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Label Location

Internal Photos EUT inside View #1 High-voltage Transformer View Magnetron View Power Filter Board Front View Power Filter Board Rear View Control Board Front View Control Board Front View

www.ecmg-global.net EMI TEST REPORT On Model Name: Microwave Oven Model Numbers: XM036AYY-P & XM036AYY-P1 Brand Name: FCC ID: VG8XM036AYY Prepared for Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd According to FCC Part 18(2009) Industrial, Scientific and Medical Equipment FCC/OST MP-5(1986) FCC methods of measurements of radio noise emission from industrial, scientific and medical equipment Test Report#: GUA-1103-10569-FCC Prepared by: May Wang Reviewed by: Jawen Yin QC Manager: Swall Zhang Test Report Released by: March 11, 2011 ⎯⎯⎯⎯⎯⎯⎯⎯ ⎯⎯⎯⎯⎯⎯ Swall Zhang Date List Attached Files Exhibit Type File Description File Name Test Report Test Report VG8XM036AYY_Test report.pdf Operation Description Technical DescriptionVG8XM036AYY_operation description.pdf External Photos External Photos VG8XM036AYY_External Photos Internal Photos Internal Photos VG8XM036AYY_Internal Photos Block Diagram Block Diagram VG8XM036AYY_Block Diagram.pdf Schematics Circuit Diagram VG8XM036AYY_Schematics.pdf ID Label/Location Label and Location VG8XM036AYY_Label & Location.pdf User Manual User Manual VG8XM036AYY _User Manual.pdf Test setup photos Test setup photos VG8XM036AYY_Test Setup Photos Test Location Tests performed in a Certified ANSI Semi-Anechoic Chamber and Shielded Room. Test Site Location: Guangdong Witol Vacuum Electronic Manufacture Co., Ltd No.1, xingye Rd,Beijiao Industry Park,Shunde,Foshan,Guangdong,China Tel : +86- 757-26326917 Fax : +86-757-26656995 Test Facility z FCC – Registration No.: 910385 Guangdong Witol Vacuum Electronic Manufacture Co., Ltd EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC was maintained in our files. Table of Contents GOVERNMENT DISCLAIMER NOTICE ________________________________________________ 1 REPRODUCTION CLAUSE __________________________________________________________ 1 OPINIONS AND INTERPRETATIONS _________________________________________________ 1 STATEMENT OF MEASUREMENT UNCERTAINTY _____________________________________ 1 ADMINISTRATIVE DATA ___________________________________________________________ 2 EUT DESCRIPTION ________________________________________________________________ 3 TYPE OF DERIVED_________________________________________________________________ 4 TEST SUMMARY __________________________________________________________________ 5 LOAD FOR MICROWAVE OVEN____________________________________________________ 6 EQUIPMENT MODIFICATION _______________________________________________________ 6 EUT SAMPLE PHOTOS FOR MODEL EM036AYY-P1___________________________________ 7 TEST SYSTEM DETAILS ___________________________________________________________12 CONFIGURATION OF TESTED SYSTEM _____________________________________________13 ATTACHMENT 1 – RADIATION HAZARD TEST ______________________________________14 ATTACHMENT 2 – INPUT POWER MEASUREMENT___________________________________16 ATTACHMENT 3 – RF OUTPUT POWER MEASUREMENT _____________________________19 ATTACHMENT 4 – OPERATING FREQUENCY MEASUREMENT ________________________22 ATTACHMENT 5 - CONDUCTED EMISSION TEST RESULTS __________________________25 ATTACHMENT 6 - RADIATED EMISSION TEST RESULTS _____________________________29 Report #: GUA-1103-10569-FCC Prepared for Foshan Shunde Midea Microwave and Electrical Appliances Manufacturing Co., Ltd. Prepared by EMC Compliance Management Group. Page 1 of 32 Government Disclaimer Notice When government drawing, specification, or other data are used for any purpose other than in connection with a definitely related government procurement operation, the United States Government thereby incurs no responsibility nor any obligation whatsoever; and the fact that the Government may have formulated, furnished, or in any way supplied the said drawing, specifications, or other data, is not to be regarded by implication or otherwise in any manner licensing the holder or any other person or corporation, or conveying any rights or permission to manufacture, use, or sell patented invention that may in any way be related thereto. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. Reproduction Clause Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from EMC Compliance Management Group. Opinions and Interpretations This test report relates to the above mentioned equipment under test (EUT). Without the permission of EMC Compliance Management Group., this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. The manufacturer has sole responsibility of continued compliance of the device. Statement of Measurement Uncertainty The data and results referenced in the document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. Report #: GUA-1103-10569-FCC Prepared for Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd Prepared by EMC Compliance Management Group. Page 2 of 32 Administrative Data Test Sample : Microwave Oven Model Numbers : XM036AYY-P & XM036AYY-P1 Model Tested : EM036AYY-P1 Brand Name : Receipt Date : March 5, 2011 Date Tested : March 7, 2011 Applicant : Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd. Address : No.6, Yong An Road, Beijiao, Shunde, Foshan. Guangdong, 528311, China. Manufacturer : Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.,Ltd. Address : No.6, Yong An Road, Beijiao, Shunde, Foshan. Guangdong, 528311, China. Factory : Guangdong Midea Microwave and Electrical Appliances Manufacturing Co.…

Text truncated - open the document above for the full version.

EUT Test Set-up Photos Conducted Emission Test Set-up Radiated Emission Test Set-up (30~1000MHz) Radiated Emission Test Set-up (1~25GHz) Radiation Hazard Test Set-up: Input Power Test Set-Up : RF Output Power Test Set-Up : Operating Frequency Test Set-up:
