VGWHEI-25YTOUR de GUIDE 800

Transmitter ＊ ＊＊ ＊ Names of parts Names of partsNames of parts Names of parts ①Power switch ② LCD Ａ Channel display Ｃ Battery indicator Ｄ Save mode display ③ Volume button （Up) ④ Volume button （Down) ⑤ Channel button (Up) ⑥ Channel button (Down) ⑧ Microphone jack ⑨ Battery cap ⑩ External microphone ＊Before to use ＊Before to use＊Before to use ＊Before to use Ｉ ： How to replace battery Power-On Power-OnPower-On Power-On Power-Off Power-OffPower-Off Power-Off Push power switch button ① for more than 1 second -- the power is turned off. ＩI ： Insert the plug of an external microphone all the way into the microphone jack, until you hear "click" sound. While pressing, turn the battery cap 90 degrees int the clockwide direction until it locked. Push power switch button ①, and indication will appears on ② LCD. Lamp is lit on the display for 2 seconds. Turn the battery cap 90 degrees by using coins in the counterclockwise direction, and remove the cap. When open the battery cap, batteries can be seen. Take out batteries by gently tilt the device. (Please note that batteries fall easily.) As shown in the upper right phote, put two AA alkaline batteries in the battery case. Make sure the plus side of batteries (convex) comes to the cap side. *Using the Transmitter *Using the Transmitter*Using the Transmitter *Using the Transmitter Transmitter1 Transmitter * The following operations are performed while the power is on. * The following operations are performed while the power is on.* The following operations are performed while the power is on. * The following operations are performed while the power is on. Change Channels ("A"part of the LCD) Change Channels ("A"part of the LCD)Change Channels ("A"part of the LCD) Change Channels ("A"part of the LCD) ・ Press the channel button ⑤(+CH) once, and one channel up. Goes up to "16" channels, and then will return to "01." ・ Press the channel button ⑥(-CH) once, and one channel down. Battery Indicator ("C"part of the LCD) Battery Indicator ("C"part of the LCD)Battery Indicator ("C"part of the LCD) Battery Indicator ("C"part of the LCD) ・ When lines of the display becomes 0 (None), replace batteries. Full↑Replace batteries Transmission ("D"part of the LCD) Transmission ("D"part of the LCD)Transmission ("D"part of the LCD) Transmission ("D"part of the LCD) Battery Save Mode ("D"part of the LCD) Battery Save Mode ("D"part of the LCD)Battery Save Mode ("D"part of the LCD) Battery Save Mode ("D"part of the LCD) Auto Power Off Auto Power OffAuto Power Off Auto Power Off ・ The device automatically turns off, after 1hour of non use. ・ While in "battery save mode," the device stands up automatically with any operations (such as voice input, button operation). ・ If there is no voice input for 20 seconds, "TX"display of the LCD will blink. Then, the device will enter "battery save mode"-- to prevent battery drain. ・ Accordance with the same transmitter and receiver channels. When speak into the microphone, the device start transmission automatically, and "TX" appears on LCD. ・ 2 seconds after the power turned on, the battery level is displayed in 5 steps below. Blinking = End Transmitter2 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Federal Communications Commission Requirements The equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z Reorient of relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the dealer or an experienced radio/TV technician for help. THE CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le present appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de license. L'exploitation est autorisee aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d'en compromettre le fonctionnement.

RF_160, Issue 03 Declaration of Authorization We Name: BANKEN CO., LTD Address: 1842-10 Kimagase, Noda-shi, Chiba-ken, 270-0222 Japan City: Chiba-ken Country: Japan Declare that: Name Representative of agent: ............. (1) Agent Company name: Neutron Engineering, Inc. Address: B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: TOUR de GUIDE 800 Type designation: HEI-25Y Trademark: BANKEN on our behalf. Date: Jul. 04, 2013 City: Chiba-ken Name: Fumio Nishikawa Function: Managing Director Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: BANKEN CO., LTD Address: 1842-10 Kimagase, Noda-shi, Chiba-ken, 270-0222 Japan City: Chiba-ken Country: Japan To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: VGWHEI-25Y Reference number: HEI-25Y Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: Jul. 04, 2013 Name and signature of applicant: Fumio Nishikawa Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

RV-0000000 Project No.: 1304083 Page 2 of 8 Neutron Engineering Inc. 1304083 1304083 RV-0000000 Project No.: 1304083 Page 3 of 8 Neutron Engineering Inc. 1304083 RV-0000000 Project No.: 1304083 Page 8 of 8 Neutron Engineering Inc. 1304083 1304083

RV-0000000 Project No.: 1304083 Page 4 of 8 Neutron Engineering Inc. 1304083 1304083 RV-0000000 Project No.: 1304083 Page 5 of 8 Neutron Engineering Inc. 1304083 1304083 Antenna RV-0000000 Project No.: 1304083 Page 6 of 8 Neutron Engineering Inc. 1304083 1304083 RV-0000000 Project No.: 1304083 Page 7 of 8 Neutron Engineering Inc. 1304083 1304083

RV-0000000 Report No.: NEI-RSS-1-1304083 Page 1 of 37 Neutron Engineering Inc. Radio Test Report IC ID: 7242A-HEI25Y This report concerns (check one) : Original Grant Class II Change Issued Date : Jun. 26, 2013 Project No. : 1304083 Equipment : TOUR de GUIDE 800 Model Name : HEI-25Y Applicant : BANKEN CO., LTD Address : 1842-10 Kimagase, Noda-shi, Chiba-ken, 270-0222 Japan Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Apr. 11, 2013 Date of Test: Apr. 11, 2013 ~ Apr. 23, 2013 Testing Engineer : (Josh Lin) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 RV-0000000 Report No.: NEI-RSS-1-1304083 Page 2 of 37 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences or generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. RV-0000000 Report No.: NEI-RSS-1-1304083 Page 3 of 37 Neutron Engineering Inc. Table of Contents REPORT ISSUED HISTORY 4 1 CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 9 3.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 3.4 DESCRIPTION OF SUPPORT UNITS 11 4 99% OCCUPIED BANDWIDTH 12 4.1 MEASUREMENT INSTRUMENTS LIST 12 4.2 MEASURING INSTRUMENTS SETTING 12 4.3 TEST PROCEDURES 12 4.4 TEST SETUP LAYOUT 12 4.5 DEVIATION FROM TEST STANDARD 12 4.6 EUT OPERATING CONDITIONS 12 4.7 TEST RESULTS 13 5 RADIATED SPURIOUS EMISSION (9 KHZ TO 1 GHZ) 15 5.1 LIMIT 15 5.2 MEASUREMENT INSTRUMENTS LIST 16 5.3 MEASURING INSTRUMENTS SETTING 16 5.4 TEST PROCEDURES 17 5.5 DEVIATION FROM TEST STANDARD 17 5.6 TEST SETUP LAYOUT 17 5.7 EUT OPERATING CONDITIONS 18 5.8 TEST RESULTS 19 6 RADIATED SPURIOUS EMISSION (ABOVE 1 GHZ) 21 6.1 LIMIT 21 6.2 MEASUREMENT INSTRUMENTS LIST 22 6.3 MEASURING INSTRUMENTS SETTING 22 6.4 TEST PROCEDURES 23 6.5 DEVIATION FROM TEST STANDARD 23 6.6 TEST SETUP LAYOUT 23 6.7 EUT OPERATING CONDITIONS 24 6.8 TEST RESULTS 25 7 EUT TEST PHOTO 37 RV-0000000 Report No.: NEI-RSS-1-1304083 Page 4 of 37 Neutron Engineering Inc. REPORT ISSUED HISTORY Revised Version No. Description Issued Date - Initial Issue. Jun. 26, 2013 RV-0000000 Report No.: NEI-RSS-1-1304083 Page 5 of 37 Neutron Engineering Inc. 1 CERTIFICATION E q u i p m e n t : TOUR de GUIDE 800 Brand Name : BANKEN Model Name : HEI-25Y A p p l i c a n t : BANKEN CO., LTD Date of Test : Apr. 11, 2013 ~ Apr. 23, 2013 Standards : RSS-210, Issue 8, 2010 FCC Part 15, Subpart C: 2012 ANSI C63.4: 2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-RSS-1-1304083) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). RV-0000000 Report No.: NEI-RSS-1-1304083 Page 6 of 37 Neutron Engineering Inc. 2. SUMMARY OF TEST RESULTS RSS-210, Issue 8, 2010; FCC Part 15, Subpart C: 2012 Standard Clause Test Item Result RSS-210 FCC Part 15, Subpart C NOTE (3) 15.207 Conducted Emission N/A NOTE (4) ----- 99% Occupied Bandwidth PASS NOTE (5) 15.249(d) or 15.209 Radiated Spurious Emission PASS NOTE (6) 15.205 Restricted Bands PASS NOTE: (1) N/A: denotes test is not applicable in this Test Report (2) Portable device; SAR report is required. (3) Reference standerads is RSS-GEN 7.2.4 (4) Reference standerads is RSS-GEN 4.6.1 (5) Reference standerads is RSS-GEN 7.2.5 (6) Reference standerads is RSS-GEN 7.2.2 RV-0000000 Report No.: NEI-RSS-1-1304083 Page 7 of 37 Neutron Engineering Inc. 2.1 TEST FACILITY The test facilities used to collect the test data in this report: Radiated emission Test (Below 1 GHz): CB08: (FCC RN: 614388; FCC DN: TW1054; IC Assigned Code: 4428C-1) 1F., No. 61, Ln. 77, Sing-ai Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Radiated emission Test (Above 1 GHz): CB08: (VCCI RN: G-91; FCC RN: 614388; FCC DN: TW1054; IC Assigned Code: 4428C-1) 1F., No. 61, Ln. 77, Sing-ai Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) 2.2 MEASUREMENT UNCERTAINTY The measurement uncertainty is not specified by FCC/Industry Canada rules and for reference only. The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a …

Text truncated - open the document above for the full version.

RV-0000000 Report No.: NEI-FCCP-1-1304083 Page 34 of 34 Neutron Engineering Inc. 6 EUT TEST PHOTO Radiated spurious emission test photos 1304083 1304083
