Instruction manual Model No: MDESLAS7W-E26 1. The compact florescent energy saving lamp fit easily into any socket. But the voltage must be AC120V/60Hz. 2. It uses 5 times less energy than incandescent bulb. 3. Risk of electric shock; use in dry location only. 4. When the line power is applied, don’t touch the glass bulb with your fingers, otherwise the hot blob may burn your fingers. 5. The CFL not for use with dimmer. 6. Not for use in totally enclosed recessed fixture. 7. Please hold the plastic encl sure fit the lamp into any standard lighting socket, because the long bulb may be broken by holding force. 8. Usage environmental temperature :-10°C~50°C 9. Usage Circumstance: Be suitable for family, hotel, restaurant, office, supermarket etc. 10. Warning: This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45–30 MHz. Variations of this language are permitted provided all the points of the statement are addressed and may be presented in any legible font or text style.
Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ110921534-00 FCC Part 18 Page 1 of 1 EXHIBIT B - EUT EXTERNAL PHOTOGRAPH EUT View
EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location (FCC ID: VGZ AS7W) Specifications : Text is Black or white in color and is left justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT.
Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ110921534-00 FCC Part 18 Page 1 of 2 EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Cover off View EUT – Main Board Top View Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ110921534-00 FCC Part 18 Page 2 of 2 EUT – Main Board Bottom View
No. Code Componet Sepcification Qty Unit Manufactory 1 Lamp FluorescentLamp tube Spiral/ φ 6.7/7W/3.5T/OD:30mm/Pin pitch:20mm/2700K/4 Ω /fee lead/Solid mercury/GY02 1 pcs Jiangxi Midea Guiya Lighting Co.,Ltd 2 PCB PCB Signal sided/GY-D32A/H:1.6mm/FR-1/V-0 1 pcs Pan an pcb factory ,China 3 Base E26 type/Copper or copper alloy, plated with nickel 1 pcs Dongguan Casun LampbaseIndustrial Co., Ltd. φ 7/S/E26/PBT/130 °C /V-0 / φ 38/top enclosure 1 pcs φ 7/S/E26/PBT/130 °C /V-0 / φ 38/bottom enclosure 1 pcs Diffuser of class D50/ Φ 35/L55/H59/A shape 1 pcs Jiangxi Midea Guiya Lighting Co.,Ltd 5 Q1 、 Q2 Transistor EB102DL/TO-92/Vceo > 200V/ β :20-25/Ts:1.5-2.0-2.5/1.18*1.18mm 2 pcs Shenzhen SYS semiconductors co.,ltd 6 D1 Bridge Rectifier MB10M/1000V/1A/1.07*1.07 3 pcs Changzhou galaxy electrical co., ltd. 7 D2 Diode 1N4007/1000V/1A/1.07*1.07/DO-41 2 pcs Changzhou galaxy electrical co., ltd. 8 D3 Diode DB3 DB3/28V-36V/2A/0.45*0.45 1 pcs Changzhou galaxy electrical co., ltd. 9 C1 Capacitor CL21-104±5%-400V - 3.5-4MM P8 2 pcs Zhejiang Qixing Capacitor Co.,Ltd. 10 C6 Capacitor CBB28-222±5%-1250V -3.5-4MMP7.5 1 pcs Zhejiang Qixing Capacitor Co.,Ltd. 11 C5 Capacitor CL21-473±5%-250V- 3.5-4MMP7.5 1 pcs Zhejiang Qixing Capacitor Co.,Ltd. 13 C4 Capacitor CL11-102±5%-630V-3.5-4MM P4.2 1 pcs Zhejiang Qixing Capacitor Co.,Ltd. 14 C3 SMD Capacitor 223±5%-100V-1206 1 pcs Zhejiang Qixing Capacitor Co.,Ltd. 15 C2 ( + / - ) ElectrolyticCapacitor 6.8uF±20%-200V-105 °C -8000h- Φ 10*12 1 pcs Yiyang zijiang electronic element co.,ltd 16 R1 、 R2 Resistor RT-510K Ω ±5%-1/2W 2 pcs Guangdong Fenghua AdvancedTechnology (Holding) Co., Ltd. 17 R3 、 R4 Resistor Naked jump line 1 pcs Guangdong Fenghua AdvancedTechnology (Holding) Co., Ltd. 18 R5 、 R6 SMD Resistor 15 Ω ±5%/1/4W-1206 1 pcs Guangdong Fenghua AdvancedTechnology (Holding) Co., Ltd. 19 T1(A,B,C) Ring CoilTransformer XK5 φ 10*6*2.8/S:300-380/L:1.0-1.3 μ H/3:8:3/QA-2/130 °C / Φ 0.35 1 pcs Jiangxi Midea Guiya Lighting Co.,Ltd 20 L2 ChokeTransformer EE10 2.0-2.2mH 224T±5T QA-2/155 °C φ 0.17 1 pcs Jiangxi Midea Guiya Lighting Co.,Ltd 4 NANTONG ZHONGLANENGINEERING PLASTICS COLTD;KINGFA SCI & TECH CO LTD Plasticsenclosure Doc.No. : 2010-12-12 GY02 Model No MDESLAS7W-E26 21 L1 Line Filter φ 6/1mH 1 pcs Zhejiang tongxiang yaorundz Co.,Ltd 22 N Lead wire 24AWG/1015/UL/105 °C /600V/L=60±1.0mm 2 pcs shanghai plastic wire factory 23 Fuse Resistor RXF-1W/0.47 Ω /1W/ φ :3.5mm/L:80mm 1 pcs SHENZHEN GREAT ELECTRONICSCO LTD 24 Fiber glasssleeving φ 2.5*40mm/>1.5KV/190 °C 1 pcs Shenzhen wahchangwei industrialco.,ltd 25 Fiber glassFleeving φ 1*10mm/>1.5KV/190 °C 4 pcs Shenzhen wahchangwei industrialco.,ltd 26 Fiber glasssleeving φ 1*5mm/>1.5KV/190 °C 2 pcs Shenzhen wahchangwei industrialco.,ltd 27 Fiber glasssleeving Φ 1*16mm/>1.5KV/190 °C 2 pcs Shenzhen wahchangwei industrialco.,ltd 28 A , B Steel Pin 0.65*0.65 L=9mm 0.8*0.8 4 pcs Jiangxi Midea Guiya Lighting Co.,Ltd L
Note: This test report is prepared for the customer shown above and for the equipment described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, or any agency of the Federal Government. * This report contains data that are not covered by the NVLAP accreditation and are marked with an asterisk “★” (Rev.2) FCC PART 18 TEST REPORT For Jiangxi Midea Guiya Green Lighting Electrical Co., Ltd. Guixi Industrial District, Guixi, Jiangxi, China FCC ID: VGZAS7W Report Type: Original Report Product Type: CFL Test Engineer: Phase Zhang Report Number: RSZ110921534-00 Report Date: 2011-11-18 Reviewed By: Lisa Zhu EMC Engineer Test Laboratory: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F, the 3rd Phase of WanLi Industrial Building, ShiHua Road, FuTian Free Trade Zone Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ110921534-00 FCC Part 18 Page 2 of 13 TABLE OF CONTENTS GENERAL INFORMATION ...................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .................................................................................... 3 OBJECTIVE................................................................................................................................................................... 3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................ 3 TEST METHODOLOGY.................................................................................................................................................. 3 TEST FACILITY............................................................................................................................................................ 3 SYSTEM TEST CONFIGURATION ......................................................................................................................... 5 JUSTIFICATION............................................................................................................................................................. 5 EUT EXERCISE SOFTWARE.......................................................................................................................................... 5 SPECIAL ACCESSORIES................................................................................................................................................ 5 EQUIPMENT MODIFICATIONS....................................................................................................................................... 5 EXTERNAL I/O CABLE................................................................................................................................................. 5 CONFIGURATION OF TEST SETUP................................................................................................................................. 5 BLOCK DIAGRAM OF TEST SETUP................................................................................................................................6 FCC §18.307 - AC LINE CONDUCTED EMISSIONS ............................................................................................. 7 APPLICABLE STANDARD.............................................................................................................................................. 7 MEASUREMENT UNCERTAINTY................................................................................................................................... 7 EUT SETUP................................................................................................................................................................. 7 EMI TEST RECEIVER SETUP........................................................................................................................................ 8 TEST PROCEDURE........................................................................................................................................................ 8 TEST EQUIPMENT LIST AND DETAILS.......................................................................................................................... 8 TEST RESULTS SUMMARY........................................................................................................................................... 8 TEST DATA.................................................................................................................................................................. 9 FCC §18.305 – FIELD STRENGTH ......................................................................................................................... 11 MEASUREMENT UNCERTAINTY................................................................................................................................. 11 EUT SETUP............................................................................................................................................................... 11 EMI TEST RECEIVER SETUP AND SPECTRUM ANALYZER SETUP............................................................................... 12 TEST PROCEDURE...................................................................................................................................................... 12 TEST EQUIPMENT LIST AND DETAILS........................................................................................................................ 12 CORRECTED AMPLITUDE CALCULATION................................................................................................................... 12 TEST DATA...................…
Text truncated - open the document above for the full version.
Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ110921534-00 FCC Part 18 Page 1 of 2 EXHIBIT D - TEST SETUP PHOTOGRAPHS AC Line Conduction Emissions - Front View AC Line Conduction Emissions - Side View Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ110921534-00 FCC Part 18 Page 2 of 2 Radiated Emissions - Front View Radiated Emissions - Rear View
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 18 | 0.04 MHz - 0.05 MHz | - |
