VIDPMNTLG5Water Meter Pit Unit

© Landis+Gyr 2020 | Proprietary + Confidential Series 5 Water M510 Pit Mount Module User Guide Publication: B 98-2488 Rev AB Limitation on Warranties and Liability Information in this document is subject to change without notice. This manual or any part of it thereof may not be reproduced in any form unless permitted by contract or by written permission of Landis+Gyr. In no event will Landis+Gyr be liable for any incidental, indirect, special, or consequential damages (including lost profits) arising out of or relating to this publication or the information contained in it, even if Landis+Gyr has been advised, knew, or should have known of the possibility of such damages. Covered by both issued and pending patents. For further patent information see: https://www.landisgyr.com/about/patent-notices/ © 2020 Landis+Gyr, Inc. | Proprietary + Confidential Contact Us: To provide feedback about this document, email us at [email protected] Technical Support: 1-888-390-5733 | [email protected] 98-2488 Rev AB | Series 5 Water M510 Pit Mount Module User Guide | 3/17/2020 User Guide98-2488 Rev AB | 3 Series 5 Water M510 Pit Wall Mount Module User Guide Introduction The M510 Pit Mount Water Module is a battery-operated radio module designed for automated water meter reading. The M510 is capable of reading water consumption data from residential and commercial water meters equipped with an Encoded or Solid State Register. It has a 2-way radio that is compatible with electric meters, routers, and mesh extenders for relaying water consumption data to the utility. It also has a low power mode for short distance communications to the Tech Studio field tools. Figure 1. Series 5 Water M510 Pit Wall Mount Federal Communication Commission (FCC) Compliance Notice 1.This device may not cause harmful interference, and 2.This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 4 | 98-2488 Rev ABUser Guide Series 5 Water M510 Pit Wall Mount Module User Guide •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Consult Landis+Gyr or an experienced radio technician for help WARNING: Changes or modifications to this device not expressly approved by Landis+Gyr will void the equipment warranty. Industry Canada (IC) Compliance Notice This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le present appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that necessary for successful communication. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. FCC/IC Label Requirements The text must be clearly visible after the device is installed, and display the module FCC and IC ID in the following format: FCC ID: VIDPMNTLG5 IC: 1023A-PMNTULG5 The following statement must also be clearly visible: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation User Guide98-2488 Rev AB | 5 Series 5 Water M510 Pit Wall Mount Module User Guide RF Exposure Information This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. Cet équipement est conforme aux limites FCC d'exposition aux radiations définies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé à une distance minimale de 20cm entre le radiateur et votre corps. Cet émetteur ne doit pas être co- implantés ou exploi…

Text truncated - open the document above for the full version.

Arad Technologies Ltd. FCC ID:VIDPMNTLG5 IC:10232A-PMNTULG5 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Arad Technologies Ltd. FCC ID:VIDPMNTLG5 IC:10232A-PMNTULG5 Page 2 of 3 Photograph No.1 “PMNTULG5” water meter pit unit general view Arad Technologies Ltd. FCC ID:VIDPMNTLG5 IC:10232A-PMNTULG5 Page 3 of 3 Photograph No.2 “PMNTULG5” water meter pit unit rear side view

Hermon Laboratories Ltd. P.O. Box 23, Binyamina 3055001, Israel Tel. +972 4628 8001 Fax. +972 4628 8277 E-mail: [email protected] Page 1 of 48 Report ID: ARARAD_FCC.33388_Small_Booster_Rev2.docx Date of Issue: 29-Mar-20 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC 47 CFR PART 15 subpart C, section 15.249 and subpart B RSS-210 Issue 9:2016, RSS-Gen Issue 5:2018, ICES-003 Issue 6:2016 FOR: ARAD TECHNOLOGIES Water meter Model: PMNTULG5 FCC ID: VIDPMNTLG5 IC: 10232A-PMNTULG5 This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: ARARAD_FCC.33388_Small_Booster_Rev2.docx Date of Issue: 29-Mar-20 Page 2 of 48 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details .................................................................................................................................................................... 3 5 Tests summary .............................................................................................................................................................. 4 6 EUT description ............................................................................................................................................................. 5 6.1 General information ....................................................................................................................................................... 5 6.2 Test configuration .......................................................................................................................................................... 5 6.3 Transmitter characteristics ............................................................................................................................................ 6 7 Transmitter tests according to 47CFR part 15 subpart C requirements ........................................................................ 7 7.1 Field strength of emissions ............................................................................................................................................ 7 7.2 Occupied bandwidth test ............................................................................................................................................. 23 7.3 Band edge emission .................................................................................................................................................... 32 7.4 Antenna requirements ................................................................................................................................................. 37 8 Unintentional emission tests ........................................................................................................................................ 38 8.1 Radiated emission measurements .............................................................................................................................. 38 9 APPENDIX A Test equipment and ancillaries used for tests ....................................................................................... 41 10 APPENDIX B Test equipment correction factors ......................................................................................................... 42 11 APPENDIX C Measurement uncertainties .................................................................................................................. 45 12 APPENDIX D Test laboratory description ................................................................................................................... 46 13 APPENDIX E Specification references ........................................................................................................................ 47 14 APPENDIX F Abbreviations and acronyms ................................................................................................................. 48 Report ID: ARARAD_FCC.33388_Small_Booster_Rev2.docx Date of Issue: 29-Mar-20 Page 3 of 48 1 Applicant information Client name: ARAD TECHNOLOGIES Address: POB 537, HaMada 4, Yokneam Ind. Zone, Yokneam Ilit 20692, Israel Telephone: 04-9935222 Ext.277 Fax: 04-9935227 E-mail: [email protected] Contact name: Mr.Vily Negreanu 2 Equipment under test attributes Product name: Water meter Product type: Transceiver Model(s): PMNTULG5 Serial number: 18P00A5852 Hardware version: P4 Software release: 07.02/08.02 Receipt date 10-Apr-19 3 Manufacturer information Manufacturer name: ARAD TECHNOLOGIES Address: POB 537, HaMada 4, Yokneam Ind. Zone, Yokneam Ilit 20692, Israel Telephone: 04-9935222 Ext.277 Fax: 04-9935227 E-Mail: [email protected] Contact name: Mr.Vily Negreanu 4 Test details Project ID: 33388 Location: Hermon Laboratories Ltd. P.O. Box 23, Binyamina 3055001, Israel Test started: 19-May-19 Test completed: 10-Jun-19 Test specification(s): FCC 47 CFR PART 15 subpart C, section 15.249 and subpart B RSS-210 Issue 9:2016, RSS-Gen Issue 5:2018, ICES-003 Issue 6:2016 Report ID: ARARAD_FCC.33388_Small_Booster_Rev2.docx Date of Issue: 29-Mar-20 Page 4 of 48 5 Tests summary Test Transmitter characteristics Section 15.249(a)(d) / RSS-210 section B.10, Field strength of emissions Pass Section…

Text truncated - open the document above for the full version.

Arad Technologies Ltd. FCC ID:VIDPMNTLG5 IC:10232A-PMNTULG5 Page 1 of 7 SETUP PHOTOGRAPHS This document contains 6 photographs Arad Technologies Ltd. FCC ID:VIDPMNTLG5 IC:10232A-PMNTULG5 Page 2 of 7 Photograph No.1 Setup for carrier field strength measurements in the anechoic chamber Arad Technologies Ltd. FCC ID:VIDPMNTLG5 IC:10232A-PMNTULG5 Page 3 of 7 Photograph No.2 Setup for spurious emission field strength measurements in the anechoic chamber below 30 MHz Arad Technologies Ltd. FCC ID:VIDPMNTLG5 IC:10232A-PMNTULG5 Page 4 of 7 Photograph No.3 Setup for spurious emission field strength measurements in the anechoic chamber in 30 – 1000 MHz range Arad Technologies Ltd. FCC ID:VIDPMNTLG5 IC:10232A-PMNTULG5 Page 5 of 7 Photograph No.4 Setup for carrier and spurious emission field strength measurements below 1 GHz, EUT close view Arad Technologies Ltd. FCC ID:VIDPMNTLG5 IC:10232A-PMNTULG5 Page 6 of 7 Photograph No.5 Setup for spurious emission field strength measurements in the anechoic chamber above 1000 MHz range Arad Technologies Ltd. FCC ID:VIDPMNTLG5 IC:10232A-PMNTULG5 Page 7 of 7 Photograph No.6 Setup for band edge emissions and hopping parameters measurements
