VIP-DMX5020Mobile DVD Player with FM/AM Tuner

HUIZHOU FORYOU GENERAL ELECTRONICS CO.,LTD.
Mobile DVD Player with FM/AM Tuner - FCC ID VIP-DMX5020 - HUIZHOU FORYOU GENERAL ELECTRONICS CO.,LTD.
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Mar 10, 2014
Application Purpose
Original Equipment
Date of Application
Mar 09, 2014
Equipment Note
Mobile DVD Player with FM/AM Tuner
Frequency Range
2402.00000000 - 2480.00000000
Company
HUIZHOU FORYOU GENERAL ELECTRONICS CO.,LTD.
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

6.2" Double DIN Multimedia Receiver Built-in Bluetooth / Compatible with iPhone / Compatible with iPod / Pandora Link / USB / Aux In DMX5020 4VRMS RCA Output Operating Instructions 2 DMX5020 “Made for iPod” and “Made for iPhone” means that an electronic accessory has been designed to connect specifically to iPod or iPhone, respectively, and has been certified by the developers to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety or regulatory standards. Please note that the use of this accessory with iPod or iPhone may affect wireless performance. Android is a trademark of Google Inc. The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Audiovox is under license. Other trademarks and trade names are those of their respective owners. microSD is a trademark or registered trademark of SD-3C, LLC in the United States, other countries or both. Pandora is a registered trademark of Pandora Media, Inc. 3 DMX5020 CONTENTS FEATURES ���������������������������������������������������������������������������������������������������������������5 CONTROLS AND INDICATORS �������������������������������������������������������������������������������8 REMOTE CONTROL �����������������������������������������������������������������������������������������������10 EXTERNAL DEVICES ���������������������������������������������������������������������������������������������16 QUICK START GUIDE ��������������������������������������������������������������������������������������������18 EQUALIZER CONTROL MENU ������������������������������������������������������������������������������21 SYSTEM SETTINGS �����������������������������������������������������������������������������������������������23 RADIO TUNER OPERATION ����������������������������������������������������������������������������������31 USB AND SDHC OPERATION �������������������������������������������������������������������������������36 iPod®/iPhone® OPERATION ���������������������������������������������������������������������������������41 AV-IN OPERATION ������������������������������������������������������������������������������������������������46 BLUETOOTH OPERATION �������������������������������������������������������������������������������������47 STEERING WHEEL CONTROLS (SWC) OPERATION ���������������������������������������������55 REAR CAMERA OPERATION ���������������������������������������������������������������������������������57 PANDORA RADIO OPERATION ����������������������������������������������������������������������������58 CARE AND MAINTENANCE ����������������������������������������������������������������������������������64 SPECIFICATIONS ��������������������������������������������������������������������������������������������������65 NOTES �������������������������������������������������������������������������������������������������������������������67 4 DMX5020 FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 centimeters between the radiator and your body. 5 DMX5020 Thank you for choosing a Jensen product. We hope you will find the instructions in this owner’s manual clear and easy to follow. If you take a few minutes to look through it, you’ll learn how to use all the features of your new Jensen DMX5020 Media Receiver for maximum enjoyment. Please save this manual for future reference. We recommend having your Jensen DMX5020 Media Receiver installed by a reputable installation shop. FEATURES MP3 / WMA • ID3 Tag Compatible • Directory Search (MP3 / WMA Only) • Random, Repeat and Intro • Play, Pause, Stop, Next Track and Previous Track AM-FM • USA, China, Japan, Europe, Europe (LW) and Orient (OIRT) • 30 Station Presets (18 FM / 12 AM) • Auto Stereo / Mono • Local / Distance • Auto Store / Preview Scan iPod®/iPhone® • iPod®/ iPhone® via USB • High Speed Direct Connect Interface to Access iPod® Playlists, Artists, Albums and Songs. Play music and view video/photo* files from your iPod®. *Video/photo playback requires jLink-USB iPod® interface cable (sold separately). • Power Management Charges iPod® while Connected Chassis • 2.0 DIN (Import / ISO-DIN Mountable) • Fixed Front Panel • 6.2” High Definition TFT LCD • 1,…

Text truncated - open the document above for the full version.

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012

ID Label/Location Info

Label’s Location on EUT

Internal Photos

Antenna

RF Exposure Info

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID:VIP-DMX5020 EUT Specification EUT Mobile DVD Player with FM/AM Tuner Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power -0.97dBm (0.000799W) Antenna gain (Max) 0 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= Antenna Gain (numeric) Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Operating Mode Channel Frequency (MHz) Output Peak power (mW) Antenna Gain (dBi) Antenna Gain (numeric) Power density at 20cm (mW/ cm2 ) Power density Limits (mW/cm 2 ) op-mode 1 2402 0.799 0 1 0.00015896 1 op-mode 2 2441 0.543 0 1 0.00010803 1 op-mode 3 2480 0.434 0 1 0.00008634 1 op-mode 6 2402 0.387 0 1 0.00007699 1 op-mode 7 2441 0.285 0 1 0.00005670 1 op-mode 8 2480 0.220 0 1 0.00004377 1 op-mode 10 2402 0.558 0 1 0.00011101 1 op-mode 11 2441 0.406 0 1 0.00008077 1 op-mode 12 2480 0.327 0 1 0.00006505 1 Signature: Print: Sam Lv Title: Manager Company: DONGGUAN EMTEK CO., LTD. Address: No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China Date: 2014-03-06

Test Report

TRF No. FCC 15.247/A Page 1 of 54 Report No.: KAD140103014E Rev1.0 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Mobile DVD Player with FM/AM Tuner Model No.: DMX5020 Brand Name: JENSEN FCC ID: VIP-DMX5020 Report No.: KAD140103014E Issue Date: March 06, 2014 Prepared for HUIZHOU FORYOU GENERAL ELECTRONICS CO., LTD. Building 2, A Zone, Foryou Industrial Park, 1# North Shangxia Road, Dongjiang Hi-tech Industry Park, Huizhou, Guangdong, China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 TRF No. FCC 15.247/A Page 2 of 54 Report No.: KAD140103014E Rev1.0 VERIFICATION OF COMPLIANCE Applicant: HUIZHOU FORYOU GENERAL ELECTRONICS CO., LTD. Building 2, A Zone, Foryou Industrial Park, 1# North Shangxia Road, Dongjiang Hi-tech Industry Park, Huizhou, Guangdong, China Manufacturer: HUIZHOU FORYOU GENERAL ELECTRONICS CO., LTD. Building 2, A Zone, Foryou Industrial Park, 1# North Shangxia Road, Dongjiang Hi-tech Industry Park, Huizhou, Guangdong, China Product Description: Mobile DVD Player with FM/AM Tuner Brand Name: JENSEN Model Number: DMX5020 Kind of Device: Bluetooth Ver. 2.1+EDR File Number: KAD140103014E Date of Test: January 03, 2014 to January 17, 2014 We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2013). The test results of this report relate only to the tested sample identified in this report. Approved By Sam Lv / Q.A. Manager DONGGUAN EMTEK CO., LTD. TRF No. FCC 15.247/A Page 3 of 54 Report No.: KAD140103014E Rev1.0 Modified History Rev. Summary Date of Rev. Report No. V1.0 Original Report 2014-03-06 KAD140103014E TRF No. FCC 15.247/A Page 4 of 54 Report No.: KAD140103014E Rev1.0 Table of Contents 1. GENERAL INFORMATION ....................................................................................... 6 1.1 PRODUCT DESCRIPTION............................................................................................................... 6 1.2 RELATED SUBMITTAL(S) / GRANT (S)............................................................................................ 6 1.3 TEST METHODOLOGY.................................................................................................................. 6 1.4 SPECIAL ACCESSORIES................................................................................................................ 6 1.5 EQUIPMENT MODIFICATIONS........................................................................................................ 6 1.6 TEST FACILITY............................................................................................................................. 7 2. SYSTEM TEST CONFIGURATION ........................................................................... 8 2.1 EUT CONFIGURATION.................................................................................................................. 8 2.2 EUT EXERCISE............................................................................................................................ 8 2.3 TEST PROCEDURE....................................................................................................................... 8 2.4 LIMITATION.................................................................................................................................. 8 2.5 CONFIGURATION OF TESTED SYSTEM........................................................................................ 12 3. SUMMARY OF TEST RESULTS ............................................................................. 13 4. DESCRIPTION OF TEST MODES........................................................................... 13 5. RADIATED EMISSION TEST .................................................................................. 14 5.1 MEASUREMENT PROCEDURE..................................................................................................... 14 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)............................................................... 15 5.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 16 5.4 MEASUREMENT RESULT............................................................................................................. 16 5.5 RADIATED MEASUREMENT PHOTOS:........................................................................................... 22 6. CHANNEL SEPARATION TEST ............................................................................. 23 6.1 MEASUREMENT PROCEDURE..................................................................................................... 23 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)............................................................... 23 6.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 23 6.4 MEASUREMENT RESULTS:.......................................................................................................... 23 7. 20DB BANDWIDTH TEST ....................................................................................... 29 7.1 MEASUREMENT PROCEDURE..................................................................................................... 29 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION)............................................................... 29 7.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 29 7.4 MEASUREMENT RESULTS:..........…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Joey Zhang(Engineer)
[email protected]86(0)752-2618636Fax: 86(0)752-2616679

Test Firm

EMTEK (DONGGUAN) CO.,LTDSam Lv
[email protected]86-769-2807078Fax: 86-769-2807079

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz799.00 µW
Confidentiality
Long Term
Grant Notes
Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
