VM9725BT Operating Instructions 160 watts peak 40W x 4 2 VM9725BT Thank you for choosing a Jensen product. We hope you will find the instructions in this owner’s manual clear and easy to follow. If you take a few minutes to look through it, you’ll learn how to use all the features of your new Jensen VM9725BT Mobile Multimedia Receiver for maximum enjoyment. CONTENTS Features������������������������������������������������������������������������������������������������������������������3 ControlsandIndicators�����������������������������������������������������������������������������������������6 RemoteControl������������������������������������������������������������������������������������������������������8 Operating Instructions����������������������������������������������������������������������������������������14 SteeringWheelControls�������������������������������������������������������������������������������������22 SettingsMenu������������������������������������������������������������������������������������������������������23 TunerOperation��������������������������������������������������������������������������������������������������31 DVD/VCDVideoOperation���������������������������������������������������������������������������������37 DVD/CD AudioOperation�����������������������������������������������������������������������������������43 MP3/WMAOperation������������������������������������������������������������������������������������������47 iPod®/iPhone®Operation������������������������������������������������������������������������������������53 PandoraOperation����������������������������������������������������������������������������������������������57 BluetoothOperation�������������������������������������������������������������������������������������������61 SiriusXM® RadioOperation���������������������������������������������������������������������������������70 RearCameraOperation���������������������������������������������������������������������������������������80 Troubleshooting��������������������������������������������������������������������������������������������������81 Care andMaintenance����������������������������������������������������������������������������������������85 Specifications�������������������������������������������������������������������������������������������������������86 CommonReplacementParts������������������������������������������������������������������������������87 3 VM9725BT FEATURES Congratulations on your purchase of the Jensen VM9725BT Mobile Multimedia Receiver. It’s a good idea to read all of the instructions before beginning the installation. We recommend having your Jensen VM9725BT installed by a reputable installation shop. DVD • Fast Forward/Reverse - 2X, 4X, 8X, and 20X • Slow Motion Forward/Reverse - 1/2, 1/4, 1/6, and 1/8 • Play, Pause, Stop, Next Chapter, and Previous Chapter CD / MP3 / WMA • CD-Text Compatible • ID3 Tag Compatible • Directory Search (MP3 / WMA Only) • Burn up to 1500 MP3 and WMA Files onto a DVD+R / RW • Audible Forward / Reverse Track Search (CD-DA Only) • Random, Repeat and Intro • Play, Pause, Stop, Next Track, and Previous Track AM-FM • USA / Europe / Latin America / Asia Frequency Spacing • 30 Station Presets (18 FM / 12 AM) • Auto Stereo / Mono • Local / Distance • Auto Store / Preview Scan iPod®/iPhone® • iPod®/ iPhone® via USB • High Speed Direct Connect Interface to Access iPod® Playlists, Artists, Albums and Songs. Play music and view video/photo* files from your iPod®. *Video/photo playback requires jLink-USB iPod® interface cable (sold separately). • Power Management Charges iPod® while Connected SiriusXM® Ready • Satellite Channel Name, Artist, Song and Categories Displayed on Monitor 4 VM9725BT Chassis • 2.0 DIN (Import / ISO-DIN Mountable) • Fixed Front Panel • 6.2” High Definition TFT LCD • 1,152,000 Sub Pixels (800 x 3 X 480) • Beep Tone Confirmation (ON-OFF Option) • Heat Management System - Forced-Air Cooling To Keep The Chip-Sets Operating at Nominal Temperatures General • Built-In Bluetooth® with external microphone, providing Hands-Free operation for safety and convenience and A2DP for streaming music from your smartphone or other Bluetooth® device. • One Composite Video Output for Additional Screens • Front Panel Audio/Video Input • Three-Band Tone control (Bass, Mid and Treble) with Eight Preset EQ Curves • Front Panel A/V Aux Input for Portable Media Devices • Rear Subwoofer Line Output • Programmable Volume Control • Rear Camera Input (Normal and Mirror Image View) • Touch Screen Calibration Mode • 4VRMS Line Output - All Channels • Rotary Encoder Audio Control • Front / Rear / Sub Line Output • Rear USB Input Navigation • TTS Voice Guidance – Street Names Announced • English, French and Spanish TTS Voice • Tele Atlas Map Data • 11 Million Points of Interest • 4GB SD Card with Continental US, Alaska, Hawaii, and Puerto Rico • Latest Map Guarantee (Limited time only - Must be used within 90 days of initial activation) RearCamera The VM9725BT is “camera ready.” Before accessing any camera features, you must purchase and install a rear video camera. Once the camera is connected and operating properly, the CAMERA source mode will become active. While the camera is not installed, the CAMERA option appears gray, indicating the function is not available. 5 VM9725BT WARNING! Never install this unit where operation and viewing could interfere with safe driving conditions. WARNING! To reduce the risk of a traffic accident (except when using for rear view video camera) never use the video display function while driving the vehicle. This is a violation of federal law. WARNING! Never disassemble or adjust the unit. WARNING! To prevent injury from shock or fire, never expose this unit to moisture or water. WARNING! Never use irregular discs. FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Oper…
Text truncated - open the document above for the full version.
SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 FCC ID: VIPVM9725BT FCC ID: VIPVM9725BT
SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 HUIZHOU FORYOU GENERAL ELECTRONICS CO., LTD. (2012-08-29) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: VIPVM9725BT We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application.
General Appearance of the EUT
FCC ID: VIPVM9725BT
Antenna
RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID:VIPVM9725BT EUT Specification EUT Mobile DVD Player with FM/AM Tuner Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 1.42dBm (0.0014W) Antenna gain (Max) -2.34 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Operating Mode Channel Frequency (MHz) Output Peak power (mW) Antenna Gain (dBi) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) op-mode 1 2402 1.250 -2.34 1.45E-04 1 op-mode 2 2441 1.297 -2.34 1.51E-04 1 op-mode 3 2480 1.164 -2.34 1.35E-04 1 op-mode 6 2402 1.291 -2.34 1.50E-04 1 op-mode 7 2441 1.387 -2.34 1.59E-04 1 op-mode 8 2480 1.202 -2.34 1.53E-04 1 op-mode 10 2402 1.143 -2.34 1.33E-04 1 op-mode 11 2441 1.365 -2.34 1.59E-04 1 op-mode 12 2480 1.047 -2.34 1.22E-04 1
DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120529062F FCC ID: VIPVM9725BT DATE: 08/28/2012 Page 1 of 47 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Mobile DVD Player With FM/AM Tuner MODEL No.: VM9725BT BRAND NAME: Jensen, Foryou FCC ID: VIPVM9725BT REPORT NO: KAD120529062F ISSUE DATE: August 28, 2012 Prepared for HUIZHOU FORYOU GENERAL ELECTRONICS CO., LTD. NO.6 Zhongkai Songshan Industrial District, Huizhou, Guangdong, China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120529062F FCC ID: VIPVM9725BT DATE: 08/28/2012 Page 2 of 47 VERIFICATION OF COMPLIANCE Applicant: HUIZHOU FORYOU GENERAL ELECTRONICS CO., LTD. NO.6 Zhongkai Songshan Industrial District, Huizhou, Guangdong, China Manufacturer: HUIZHOU FORYOU GENERAL ELECTRONICS CO., LTD. NO.6, Huifeng 7 Road, Zhongkai Songshan Industrial District, Huizhou, Guangdong, China. Product Description: Mobile DVD Player With FM/AM Tuner Brand Name: Jensen, Foryou Model Number: VM9725BT Serial Number: N/A Kind of Device: Bluetooth Ver. 2.0+EDR File Number: KAD120529062F Date of Test: May 29, 2012 to August 28, 2012 We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Approved By Sam Lv / Q.A. Manager DONGGUAN EMTEK CO., LTD. DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120529062F FCC ID: VIPVM9725BT DATE: 08/28/2012 Page 3 of 47 Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................. 5 1.1 PRODUCT DESCRIPTION........................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 5 1.3 TEST METHODOLOGY.............................................................................................................................. 5 1.4 SPECIAL ACCESSORIES............................................................................................................................ 5 1.5 EQUIPMENT MODIFICATIONS.................................................................................................................. 5 1.6 TEST FACILITY........................................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION .................................................................................... 7 2.1 EUT CONFIGURATION............................................................................................................................. 7 2.2 EUT EXERCISE........................................................................................................................................ 7 2.3 TEST PROCEDURE.................................................................................................................................... 7 2.4 LIMITATION............................................................................................................................................. 7 2.5 CONFIGURATION OF TESTED SYSTEM................................................................................................... 11 3. SUMMARY OF TEST RESULTS ....................................................................................... 12 4. DESCRIPTION OF TEST MODES .................................................................................... 12 5. RADIATED EMISSION TEST ............................................................................................ 13 5.1 MEASUREMENT PROCEDURE................................................................................................................. 13 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 14 5.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 15 5.4 MEASUREMENT RESULT........................................................................................................................ 15 5.5 RADIATED MEASUREMENT PHOTOS: ..................................................................................................... 23 6. CHANNEL SEPARATION TEST ....................................................................................... 24 6.1 MEASUREMENT PROCEDURE................................................................................................................. 24 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 24 6.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 24 6.4 MEASUREMENT RESULTS:..................................................................................................................... 24 7. 20DB BANDWIDTH TEST .................................................................................................. 26 7.1 MEASUREMENT PROCEDURE................................................................................................................. 26 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 26 7.3 MEASUREMENT EQUIPMENT USED: ......…
Text truncated - open the document above for the full version.
Radiated Emission Setup Photos
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 1.40 mW |
