VIQ-ULTIMADT07Emergency Locator Tracker (ELT)

SED beacons SAS SAS au capital social de 2 000 000 euros – 500 055 744 RCS LORIENT ZI des Cinq Chemins – 56520 Guidel, France - FRANCE T +33 (0)2 97 02 49 49 Date: 05-27-2024 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing Re. KDB 986446 D01 FCC ID: VIQ-ULTIMADT07 Dear Sir or Madam, SAFRAN Electronics and Defense Beacons SAS (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please contact us. Sincerely, Contact name: Samuel DAVENEL Company name: SAFRAN Electronics and Defense Beacons SAS Address: ZI des 5 chemins 56520 GUIDEL FRANCE E-mail: [email protected] Tel: +33 2 97 02 49 20

Orolia SAS SAS au capital social de 2 000 000 euros – 500 055 744 RCS LORIENT ZI des Cinq Chemins – 56520 Guidel, France - FRANCE T +33 (0)2 97 02 49 49 F +33 (0)2 97 65 00 20 www.orolia.com Federal Aviation Administration Office of Spectrum Policy and Management ASR-A 8000 Independence Ave., SW Washington, DC 20591 Ref: FAA notification of FCC Equipment Approval under FCC part 87 Model: KANNAD ULTIMA-DT-07 Dear Sir or Madam: In accordance with the Federal Code of Regulation (CFR) Part 87.147(d), Safran Electronics & Defense Beacons SAS – hereby notifies the Federal Aviation Administration of its intention to fill with FCC of an application for certification of: KANNAD ULTIMA-DT-07 S1865501-07 under FCC ID VIQ-ULTIMADT07 These radio equipment meets EUROCAE ED-62B Standard equivalent to RTCA DO- 204B and has an ETSO c126c approval. Technical information: The device is an ELT-DT compliant with Part 87.147(b), 87.141(i), 87.199(a) and following characteristics: Frequencies 406MHz (COSPAS-SARSAT) 121.5MHz Rated power output 5W typical 80mW typical Bandwidth and emission class G1D A3A Designator 16K0G1D 3K20A3A The applicant is: Safran Electronics & Defense Beacons SAS ZI DES 5 CHEMINS 56520 GUIDEL, FRANCE Please send you response to: Samuel DAVENEL Safran Electronics & Defense Beacons SAS Z.I des 5 chemins 56520 GUIDEL FRANCE [email protected] copy to: [email protected] Regards, Samuel DAVENEL Design Authority Safran Electronics & Defense Beacons SAS

800 Independence Ave., S. W. Washington, D. C. 20591 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Dear Mr. Corey Cahill: The Federal Aviation Administration, Spectrum Engineering Services Group received the Safran Electronics & Defense Beacons SAS notification letter of its filing with the Federal Communications Commission (FCC). The application is for certification of the KANNAD ULTIMA-DT-07 S1865501-07 with FCC ID: VIQ-ULTIMADT07. We have completed the review process of the information submitted by Safran Electronics & Defense Beacons SAS and concluded that we have no objection to the FCC granting certification for this equipment. If you require any additional information, please contact Mr. Jae Shin, Electronics Engineer, Spectrum Planning and International Group, at (202) 267-7365 or via e-mail [email protected]. Sincerely, ---- Michael Weiler Group Manager, Spectrum Engineering Services cc: [email protected] [email protected]

Safran Electronics & Defense Beacons SAS Zone Industrielle des Cinq Chemins 56520 GUIDEL - FRANCE Phone: +33 (0)2 97 02 49 49 Page: 1 / 7 DATE: 02/07/2024 EXHIBIT 03 EXTERNAL PHOTOS THIS DOCUMENT IS COPYRIGHT © 2024 SAFRAN ELECTRONICS & DEFENSE BEACONS SAS. ALL RIGHTS ARE STRICTLY RESERVED. THIS DOCUMENT AND ANY ATTACHED MATERIALS CONTAINS PROPRIETARY INFORMATION AND DATA AND IS THE SOLE PROPERTY OF SAFRAN ELECTRONICS & DEFENSE BEACONS SAS AND/OR ITS AFFILIATES. THE DOCUMENTS, ANY ATTACHED MATERIALS AND/OR INFORMATION CONTAINED THEREIN MUST NOT BE USED, DISSEMINATED, OR DISTRIBUTED EXCEPT FOR THE AGREED PURPOSE. UNAUTHORIZED USE, REPRODUCTION, OR ISSUE TO ANY THIRD PARTY IS NOT PERMITTED WITHOUT THE PRIOR WRITTEN CONSENT OF SAFRAN ELECTRONICS & DEFENSE BEACONS SAS. THIS DOCUMENT IS TO BE RETURNED TO SAFRAN ELECTRONICS & DEFENSE BEACONS SAS WHEN THE AGREED PURPOSE IS FULFILLED. Exhibit 03 External Photos FCC DOCUMENTATION © 2023 Safran Electronics & Defense Beacons SAS. All rights reserved. 2 Figure 1 Rear Face Figure 2 Front Face Safran Electronics & Defense Beacons SAS Zone Industrielle des Cinq Chemins 56520 GUIDEL - FRANCE Phone: +33 (0)2 97 02 49 49 Page: 1 / 7 DATE: 02/07/2024 Figure 3 Side face (left) Figure 4 Side face (right) Safran Electronics & Defense Beacons SAS Zone Industrielle des Cinq Chemins 56520 GUIDEL - FRANCE Phone: +33 (0)2 97 02 49 49 Page: 1 / 7 DATE: 02/07/2024 Figure 5 Bottom face Exhibit 03 External Photos FCC DOCUMENTATION © 2023 Safran Electronics & Defense Beacons SAS. All rights reserved. 2 Figure 6 Top cover Exhibit 03 External Photos FCC DOCUMENTATION © 2023 Safran Electronics & Defense Beacons SAS. All rights reserved. 3 Figure 7 Dayton Granger Antenna Exhibit 03 External Photos FCC DOCUMENTATION © 2023 Safran Electronics & Defense Beacons SAS. All rights reserved. 4 Figure 8 Dayton Granger Antenna

Safran Electronics & Defense Beacons SAS Zone Industrielle des Cinq Chemins 56520 GUIDEL - FRANCE Phone: +33 (0)2 97 02 49 49 INDEX: A DATE: 30/11/2023 EXHIBIT 01 – ID LABEL THIS DOCUMENT IS COPYRIGHT © 2023 SAFRAN ELECTRONICS & DEFENSE BEACONS SAS. ALL RIGHTS ARE STRICTLY RESERVED. THIS DOCUMENT AND ANY ATTACHED MATERIALS CONTAINS PROPRIETARY INFORMATION AND DATA AND IS THE SOLE PROPERTY OF SAFRAN ELECTRONICS & DEFENSE BEACONS SAS AND/OR ITS AFFILIATES. THE DOCUMENTS, ANY ATTACHED MATERIALS AND/OR INFORMATION CONTAINED THEREIN MUST NOT BE USED, DISSEMINATED, OR DISTRIBUTED EXCEPT FOR THE AGREED PURPOSE. UNAUTHORIZED USE, REPRODUCTION, OR ISSUE TO ANY THIRD PARTY IS NOT PERMITTED WITHOUT THE PRIOR WRITTEN CONSENT OF SAFRAN ELECTRONICS & DEFENSE BEACONS SAS. THIS DOCUMENT IS TO BE RETURNED TO SAFRAN ELECTRONICS & DEFENSE BEACONS SAS WHEN THE AGREED PURPOSE IS FULFILLED. EXHIBIT 01 – ID LABEL FCC DOCUMENTATION © 2023 Safran Electronics & Defense Beacons SAS. All rights reserved. 2 Label Drawing Set EXHIBIT 01 – ID LABEL FCC DOCUMENTATION © 2023 Safran Electronics & Defense Beacons SAS. All rights reserved. 3 FCC ID: VIQ-ULTIMADT07

TÜV SÜD is a trading name of TUV SUD Ltd Registered in Scotland at East Kilbride, Glasgow G75 0QF, United Kingdom Registered number: SC215164 TUV SUD Ltd is a TÜV SÜD Group Company Phone: +44 (0) 1489 558100 Fax: +44 (0) 1489 558101 www.tuvsud.com/en TÜV SÜD Octagon House Concorde Way Fareham Hampshire PO15 5RL United Kingdom TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Matthew Russell Chief Engineer Authorised Signatory 20 June 2023 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD document control rules. FCC Accreditation 90987 Octagon House, Fareham Test Laboratory EXECUTIVE SUMMARY The wireless devices described within this report are compliant with the exemption criteria related to human exposure to electromagnetic fields laid out in FCC CFR Title 47 Part 1.1307. RF Exposure Exemption Report Safran Electronics & Defence Beacons SAS Model: ULTIMA-DT-05 In accordance with FCC CFR 47 Pt 1.1307 Prepared for: Safran Electronics & Defense Beacon SAS 4 Rue Pierre Fauchard ZI Des Cinq Chemins CS 10028 Le Hirgoat Guidel 56520 France COMMERCIAL-IN-CONFIDENCE FCC ID: VIQ-ULTIMADT Document 75958513-03 Issue: 01 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD. No part of this document may be reproduced without the prior written approval of TÜV SÜD. © 2023 TÜV SÜD. This report relates only to the actual item/items tested. ACCREDITATION Our UKAS Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our UKAS Accreditation. Results of tests not covered by our UKAS Accreditation Schedule are marked NUA (Not UKAS Accredited). Document 75958513-03 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 7 Contents 1 Report Summary .........................................................................................................................2 1.1 Report Modification Record ...........................................................................................................2 1.2 Introduction ....................................................................................................................................2 1.3 Brief Summary of Results .............................................................................................................3 1.4 Product Information .......................................................................................................................4 2 Assessment Details ....................................................................................................................5 2.1 Single RF Source options for determination of exemption............................................................5 2.2 Multiple RF Sources options for determination of exemption. ......................................................6 2.3 Individual Antenna Port Exposure Results ....................................................................................7 Document 75958513-03 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 7 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 20-June-2023 Table 1 1.2 Introduction Applicant Safran Electronics & Defence Beacons SAS Manufacturer Safran Electronics & Defence Beacons SAS Model Number(s) ULTIMA-DT-05 Hardware Version(s) S1865601-01 Software Version(s) YLS1820A Specification/Issue/Date FCC 47 CFR Part 1.1307: 2021 Order Number Date 55317 02 May 2023 Related Document(s) • KDB 447498 D04 v01 Document 75958513-03 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 3 of 7 1.3 Brief Summary of Results The wireless devices described within this report are compliant with the exemption criteria related to human exposure to electromagnetic fields laid out in FCC CFR Title 47 Part 1.1307. The calculations shown in this report were made in accordance with the procedures specified in the applied test specification(s). Document 75958513-03 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 4 of 7 1.4 Product Information 1.4.1 Technical Description Emergency locator beacon with automatic distress tracking functionality. 1.4.2 Transmitter Description The following radio access technologies and frequency bands are supported by the equipment under test. Radio Access Technology Frequency Band (MHz) Minimum Frequency (MHz) Output Power (dBm) Duty Cycle (%) 406 MHz 403.5 – 408.5 403.5 39 9.4 121.5 MHz 120.6 – 122.4 120.6 26 37 Table 2 – Transmitter Description Note: Transmitter power includes upper bounds of uncertainty therefore maximum values are used. 1.4.3 Antenna Description The following antennas are supported by the equipment under test. Radio Access Technology Antenna Model Gain (dBi) Antenna length (cm) Minimum Separation Distance (cm) 406 MHz Dayton Granger Tri- frequency Antenna (406/121.5/GNSS) - ELT10-903 6 20.9 100 121.5 MHz Dayton Granger Tri- frequency Antenna (406/121.5/GNSS) - ELT10-903 -2.5 20.9 100 Table 3 – Antenna description In the case of more than one type of antenna being supported by the equipment, the calculation is based on the maximum of the antenna gains. If other antennas can be used that have greater gains, the minimum separation distances will need to be recalculated. Note: Antenna gain includes upper bounds of uncertainty therefore maximum values are used. 1.4.4 Equipment Configuration No simultaneous transmission is supported Document 75958513-03 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 5 of 7 2 Assessment Details 2.1 Single RF Source options for determination of exemption. Option Reference RF Exposure Test Exemptions for Single Source A (1-mW Test Exemption) FCC 1.1307(b)(3)(i)(A) The avai…

Text truncated - open the document above for the full version.

Document 75959976 Report 01 Issue 3 April 2024 Report On Emergency Beacons Limited Testing of the Safran Electronics & Defense ULTIMA-DT-07 Beacon In accordance with Cospas-Sarsat T.007 TÜV SÜD, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuv-sud.co.uk Document 75959976 Report 01 Issue 3 Page 1 of 62 REPORT ON Emergency Beacons Limited Testing of the Safran Electronics & Defense ULTIMA-DT-07 Beacon Document 75959976 Report 01 Issue 3 April 2024 PREPARED FOR Safran Electronics & Defense Beacon SAS 4 Rue Pierre Fauchard ZI Des Cinq Chemins CS 10028 Le Hirgoat Guidel 56520 France PREPARED BY James Cumming Engineer, Marine APPROVED BY Martin Hardy Authorised Signatory DATED 24 April 2024 Document 75959976 Report 01 Issue 3 Page 2 of 64 CONTENTS Section Page No 1 REPORT SUMMARY .................................................................................................................. 3 1.1 Introduction .................................................................................................................................. 4 1.2 Application Form .......................................................................................................................... 5 1.3 Product Information ................................................................................................................... 15 1.4 Test Locations ........................................................................................................................... 20 1.5 Modifications .............................................................................................................................. 20 1.6 Report Modification Record ....................................................................................................... 20 2 TEST DETAILS ......................................................................................................................... 21 2.1 Power Output ............................................................................................................................. 29 2.2 Digital Message ......................................................................................................................... 31 2.3 Modulation ................................................................................................................................. 33 2.4 406 MHz Transmitted Frequency .............................................................................................. 35 2.5 Spurious Emissions into 50 Ohms ............................................................................................. 38 2.6 406 MHz VSWR Check ............................................................................................................. 40 2.7 satellite qualitative test .............................................................................................................. 43 3 TEST EQUIPMENT USED ........................................................................................................ 52 3.1 Test Equipment.......................................................................................................................... 53 3.2 Measurement Uncertainty ......................................................................................................... 55 4 PHOTOGRAPHS....................................................................................................................... 56 4.1 Photographs of Equipment Under Test (EUT) .......................................................................... 57 5 ACCREDITATION, DISCLAIMERS AND COPYRIGHT........................................................... 61 5.1 Accreditation, Disclaimers and Copyright .................................................................................. 62 6 Annex A – Battery Current Comparison.................................................................................. 63 ANNEX A Battery Current Comparison .................................................................................................... A.2 Document 75959976 Report 01 Issue 3 Page 3 of 64 SECTION 1 REPORT SUMMARY Emergency Beacons Limited Testing of the Safran Electronics & Defense ULTIMA-DT-07 Beacon Document 75959976 Report 01 Issue 3 Page 4 of 64 1.1 INTRODUCTION The information contained in this report is intended to show verification of the Safran Electronics & Defense ULTIMA-DT-07 Beacon to the limited requirements of Cospas-Sarsat T.007. The scope of testing was defined between C/S and the Manufacturer. Objective To perform Emergency Beacon Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Safran Electronics & Defense Beacon Model Number(s) ULTIMA-DT-07 Serial Number(s) KA0040651003 (0075959976-TSR001) Number of Samples Tested 1 Test Specification/Issue/Date Cospas-Sarsat T.007 Issue 5 Rev 10 October 2023 Incoming Release Date Application Form 01 December 2023 Date of Receipt of Test Samples 11 December 2023 Order Number Date Po. 58802 & QAF 31 November 2023 Start of Test 21 December 2023 Finish of Test 28 December 2023 Name of Engineer(s) J Cumming Related Documents Cospas-Sarsat T.001 Issue 4 Revision 11 October 2023 Cospas-Sarsat T.IP (TCXO) Issue 1 Revision 5 October 2013 Document 75959976 Report 01 Issue 3 Page 5 of 64 1.2 APPLICATION FORM G.1 - Beacon Manufacturer and Beacon Model Beacon Manufacturer SAFRAN Electronics & Defense Beacons SAS Beacon Manufacturer's Address ZI des 5 chemins 56520 GUIDEL Beacon Model Name KANNAD ULTIMA-DT-07 Additional Beacon Model Names G.1 - Beacon Type and Operational Configurations Beacon Type Beacon Used While Tick Where Appropriate (X) EPIRB Float Free Floating in water or on deck or in a safety raft EPIRB Non-Float Free (automatic and manual activation) Floating in water or on deck or in a safety raft EPIRB…

Text truncated - open the document above for the full version.
