VK6-IRU600HB2Eclipse IRU600V2

ECLIPSE Rev.002, October 2011 INSTALLATION MANUAL 5.8 GHz Unlicensed Band 260-668066-003 TM Eclipse Microwave Radio Installation Manual For FCC 5.8 GHz Unlicensed Band October 2011 iiAviat Networks Eclipse Installation Manual This manual is specific to Eclipse with IRU 600 for all-indoor operation on the FCC 5.8 GHz unlicensed band. Compliance and Notices 260-668066-003 Rev. 002 October 2011 Copyright © 2011 by Aviat Networks, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Aviat Networks Inc. To request permission, contact [email protected] . Warranty Aviat Networks makes no representation or warranties with respect to the contents hereof and specifically disclaims any implied warranties or merchantability or fitness for any particular purpose. Further, Aviat Networks reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Aviat Networks to notify any person of such revision or changes. Safety Recommendations The following safety recommendations must be considered to avoid injuries to persons and/or damage to the equipment: Installation and Service Personnel: Installation and service must be carried out by authorized personnel who have the technical training and experience necessary to be aware of any hazardous operations during installation and service, and of measures to avoid any danger to themselves, to any other personnel, and to the equipment. Access to the Equipment: Access to the equipment in use must be restricted to service personnel only. Safety Norms: Recommended safety norms are detailed in the Health and Safety sections of this manual. Local safety regulations must be used if mandatory. Safety instructions in this document should be used in addition to the local safety regulations. In the case of conflict between safety instructions stated in this manual and those indicated in local regulations, mandatory local norms will prevail. Should local regulations not be mandatory, then the safety norms in Chapter 2 will prevail. Service Personnel Skill: Service personnel must have received adequate technical training on telecommunications and in particular on the equipment this manual refers to. 260-668066-003 Rev 002 October 2011 iii Eclipse Installation Manual Trademarks All trademarks are the property of their respective owners. Open Source Software The software included in this product contains copyrighted software that is licensed under the GPL. A copy of that license and the complete corresponding source code is included on the CD that is shipped with the product. You may also obtain the complete corresponding source code from us for a period of three years after our last shipment of this product, by contacting us at [email protected]. Product Compliance Notices Eclipse has been tested for and meets EMC Directive 2004/108/EC. The equipment was tested using screened cable; if any other type of cable is used, it may violate compliance. Eclipse is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. This equipment is intended to be used exclusively in telecommunications centers. FCC Notices 1.The IRU600, 5.8GHz must be professionally installed and maintained. 2. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential environment is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. 3. IRU600, 5.8GHz is compliant with FCC CFR47, Part 15.247. 4. To ensure compliance with the FCC RF exposure requirements, a minimum distance of 18 meters must be maintained between the antenna and any persons whilst the unit is operational. This calculation is based on the maximum conducted power and maximum antenna gain. 5. IRU600, 5.8GHz has been certified for use with a parabolic antenna with a maximum gain of 45.4dBi or a flat panel antenna with a maximum gain of 28dBi. 6. The filters and software provided with this product allow for transmission only in the frequency range 5725 - 5850MHz to ensure compliance with Part 15.247. 7. According to the conducted power limit in FCC CFR 47, Part 15.247, the power for this device has been limited to 1W (30dBm) at the antenna port. 8. FCC CFR47, Part 15.247 excludes the use of point-to-multipoint systems, omnidirectional applications and multiple co-located intentional radiators. This system is only for fixed, WARNING Making adjustments and/or modifications to this equipment that are not in accordance with the provisions of this instruction manual or other supplementary documentation may result in personal injury or damage to the equipment, and may void the equipment warranty. ivAviat Networks point-to-point operation. Industry Canada Notices 1.The IRU600, 5.8GHz must be professionally installed and maintained. 2. IRU600, 5.8GHz is compliant with Industry Canada RSS-210. 3. To ensure compliance with the Industry Canada RF exposure requirements in RSS-102, a minimum distance of 18 meters must be maintained between the antenna and any persons whilst the unit is operational. This calculation is based on the maximum conducted power and maximum antenna gain. 4. IRU600, 5.8GHz h…

Text truncated - open the document above for the full version.

Antenna Manufacturer's Name: Andrew Solution Antenna Model No. Antenna Type Low Band Gain–dBi Mid-Band Gain–dBi Top Band Gain–dBi Antenna Diameter–ft Lowest RF Freq– MHz Highest RF Freq– MHz Beam Width–dB Cross Pol Discrimination–dB Front-to-Back Ratio–dB P2F-52 Parabolic 29.4 2 5250 5850 5.4 30 41 P3F-52 Parabolic 33.4 3 5250 5850 3.8 30 42 P4F-52 Parabolic 34.9 4 5250 5850 3.0 30 52 P6F-52 Parabolic 37.6 6 5250 5850 1.8 30 49 PX2F-52 Parabolic 29.4 2 5250 5850 5.4 30 41 PX3F-52 Parabolic 33.4 3 5250 5850 3.8 30 42 PX4F-52 Parabolic 34.9 4 5250 5850 3.0 30 52 PX6F-52 Parabolic 37.6 6 5250 5850 1.8 30 49 HP2F-52 Parabolic 29.0 2 5250 5850 5.4 30 50 HP3F-52 Parabolic 33.0 3 5250 5850 3.8 30 53 HP4F-52 Parabolic 34.5 4 5250 5850 3.0 30 58 HP6F-52 Parabolic 37.2 6 5250 5850 1.8 30 56 HPX2F-52 Parabolic 29.0 2 5250 5850 5.4 30 50 HPX4F-52 Parabolic 34.5 4 5250 5850 3.0 30 58 HPX6F-52 Parabolic 37.2 6 5250 5850 1.8 30 56 P2F-57W Parabolic 29.2 29.3 29.9 2 5725 6425 5.8 30 40 P4F-57W Parabolic 34.5 35.0 35.4 4 5725 6425 2.9 30 40 P6F-57W Parabolic 38.0 38.5 39.0 6 5725 6425 2.0 30 45 P8F-57W Parabolic 40.7 41.2 41.7 8 5725 6425 1.6 30 47 P10F-57W Parabolic 42.5 42.9 43.4 10 5725 6425 1.3 30 50 P2-57W Parabolic 29.2 29.3 29.9 2 5725 6425 5.8 30 40 P4-57W Parabolic 34.5 35.0 35.4 4 5725 6425 2.9 30 40 PL6-57W Parabolic 38.0 38.5 39.0 6 5725 6425 2.0 30 45 PL8-57W Parabolic 40.7 41.2 41.7 8 5725 6425 1.6 30 47 PL10-57W Parabolic 42.5 42.9 43.4 10 5725 6425 1.3 30 50 PL12-57W Parabolic 44.2 44.6 45.0 12 5725 6425 1.0 30 51 HP4F-57W Parabolic 34.6 35.0 35.4 4 5725 6425 2.9 30 52 HP6F-57W Parabolic 38.0 38.5 39.0 6 5725 6425 2.0 30 60 HP8F-57W Parabolic 40.7 41.2 41.7 8 5725 6425 1.6 30 64 HP10F-57W Parabolic 42.5 42.9 43.4 10 5725 6425 1.3 30 65 HP4-57W Parabolic 34.6 35.0 35.4 4 5725 6425 2.9 30 52 HP6-57W Parabolic 38.0 38.5 39.0 6 5725 6425 2.0 30 60 HP8-57W Parabolic 40.7 41.2 41.7 8 5725 6425 1.6 30 64 HP10-57W Parabolic 42.5 42.9 43.4 10 5725 6425 1.3 30 65 Antenna Manufacturer's Name: Andrew Solution Antenna Model No. Antenna Type Estimated Gain at 5.725 to 5.850 GHz Antenna Diameter–ft Lowest RF Freq– MHz Highest RF Freq– MHz Beam Width–dB Cross Pol Discrimination–dB Front-to-Back Ratio–dB HP6-59 Parabolic 37.9 6 5925 6425 1.8 30 62 HP8-59 Parabolic 40.8 8 5925 6425 1.4 30 66 HP10-59 Parabolic 42.3 10 5925 6425 1.1 30 69 HP12-59 Parabolic 44.4 12 5925 6425 0.9 30 71 HP15-59 Parabolic 45.9 15 5925 6425 0.8 30 71 PARX6-59 Parabolic 37.5 6 5725 6425 1.9 30 60 PARX8-59 Parabolic 40.1 8 5725 6425 1.4 30 60 PARX10-59 Parabolic 42.4 10 5925 6425 1.1 30 60 PARX12-59 Parabolic 43.0 12 5925 6425 0.9 30 60 UHX6-59 Parabolic 38.1 6 5925 6425 1.8 33 75 UHX8-59 Parabolic 40.6 8 5925 6425 1.4 33 77 UHX10-59 Parabolic 42.6 10 5925 6425 1.1 34 80 UHX12-59 Parabolic 44.1 12 5925 6425 0.9 35 80 UHX15-59 Parabolic 45.8 15 5925 6425 0.8 34 80 HPX4-59 Parabolic 34.1 4 5925 6425 2.9 30 58 HPX6-59 Parabolic 38.1 6 5925 6425 1.8 30 65 HPX8-59 Parabolic 40.6 8 5925 6425 1.4 30 69 HPX10-59 Parabolic 42.4 10 5925 6425 1.1 30 71 HPX12-59 Parabolic 44.1 12 5925 6425 0.9 30 71 HPX15-59 Parabolic 45.8 15 5925 6425 0.8 30 71 PAR6-59 Parabolic 37.7 6 5725 6425 2.0 30 55 PAR8-59 Parabolic 40.1 8 5725 6425 1.5 30 58 PAR10-59 Parabolic 42.7 10 5925 6425 1.1 30 62 PAR12-59 Parabolic 43.9 12 5925 6425 0.9 30 63

RFS 5.8 GHz antennas for Aviat Networks RFS Model Description Size ft (mtr) gain dB lowband midband highband 5.8 GHz ** -0528 band (5.15 - 5.35 and 5.725 - 5.875 GHz) MA0528-19AN Flat panel, single polarized, N female input 0.5 19.0 MA0528-23AN Flat panel, single polarized, N female input 1 23.0 MA0528-28AN Flat panel, single polarized, N female input 2 28.0 -52 band (5.25 - 5.85 GHz) SPF2-52BN1S Standard performance, single polarized, N female input 2 (0.6) 27.8 28.5 29.1 SPF3-52BN1S Standard performance, single polarized, N female input 3 (0.9) 31.3 32.0 32.6 SPF4-52CN1S Standard performance, single polarized, N female input 4 (1.2) 33.9 34.4 34.9 SPF6-52CN1S Standard performance, single polarized, N female input 6 (1.8) 37.6 38.1 38.6 SDF3-52CN1S1 High performance, single polarized, N female input 3 (0.9) 31.3 32.0 32.6 SDF4-52CN1S1 High performance, single polarized, N female input 4 (1.2) 33.9 34.4 34.9 SDF6-52CN1S1 High performance, single polarized, N female input 6 (1.8) 37.6 38.1 38.6 -59 band ( 5.925-6.425 GHz) PAD6-59BC1S Standard performance, single polarized, CPR137G input 6 (1.8) 38.4 38.7 39.1 38.0 PAD8-59AC1S Standard performance, single polarized, CPR137G input 8 (2.4) 40.9 41.3 41.6 40.7 PAD10-59AC1S Standard performance, single polarized, CPR137G input 10 (3.0) 42.8 43.2 43.5 42.6 SU6-59BC1S1 SlimLine Ultra high performance,single polarized, CPR137G input 6 (1.8) 38.3 38.8 39.1 38.1 SU4-59BC1S1 SlimLine Ultra high performance,single polarized, CPR137G input 4 (1.2) 34.9 35.3 35.6 34.7 DA6-59BC1S1 High Performance, Single Polarized, CPR137G input 6 (1.8) 38.5 39.0 39.3 38.4 DA8-59AC1S1 High Performance, Single Polarized, CPR137G input 8 (2.4) 41.2 41.6 42.0 40.9 DA10-59AC1S1 High Performance, Single Polarized, CPR137G input 10 (3.0) 43.0 43.4 43.7 42.8 DA12-59AC1S1 High Performance, Single Polarized, CPR137G input 12 (3.7) 44.8 45.1 45.4 44.5 DAX4-59AC1S1 High Performance, Dual Polarized, CPR137G input 4 (1.2) 34.1 34.5 34.8 33.8 DAX6-59BC1S1 High Performance, Dual Polarized, CPR137G input 6 (1.8) 38.3 38.7 39.0 38.0 DAX8-59AC1S1 High Performance, Dual Polarized, CPR137G input 8 (2.4) 40.9 41.3 41.7 40.7 DAX10-59AC1S1 High Performance, Dual Polarized, CPR137G input 10 (3.0) 42.9 43.2 43.5 42.6 UXA6-59BC1S1 Ultra high performance Dual Polarized, CPR137G input 6 (1.8) 38.3 38.7 39.0 38.0 UXA8-59AC1S1 Ultra high performance Dual Polarized, CPR137G input 8 (2.4) 40.9 41.3 41.7 40.6 UXA10-59AC1S1 Ultra high performance Dual Polarized, CPR137G input 10 (3.0) 42.9 43.2 43.5 42.6 UXA12-59AC1S1 Ultra high performance Dual Polarized, CPR137G input 12(3.7) 44.6 44.8 45.2 44.1 Page 1 of 2 RFS 5.8 GHz antennas for Aviat Networks -W57 band (5.725 - 6.875 gHz) PA4-W57BC1S1 Standard performance, single polarized, CPR137G input 4 (1.2) 34.7 35.5 36.3 PA6-W57BC1S1 Standard performance, single polarized, CPR137G input 6 (1.8) 38.2 39.0 39.8 PA8-W57AC1S1 Standard performance, single polarized, CPR137G input 8 (2.4) 40.7 41.5 42.3 PA10-W57AC1S Standard performance, single polarized, CPR137G input 10 (3.0) 42.6 43.5 44.2 PAD6-W57BC1S Standard performance, single polarized, CPR137G input 6 (1.8) 38.1 38.9 39.7 PAD8-W57AC1S Standard performance, single polarized, CPR137G input 8 (2.4) 40.6 41.4 42.2 PAD10-W57AC1S Standard performance, single polarized, CPR137G input 10 (3.0) 42.6 43.5 44.2 PADX6-W57AC1S Standard performance, dual polarized, CPR137G input 6 (1.8) 37.9 38.7 39.5 PADX8-W57AC1S Standard performance, dual polarized, CPR137G input 8 (2.4) 40.4 41.2 42.0 PADX10-W57AC1S Standard performance, dual polarized, CPR137G input 10 (3.0) 42.3 43.2 43.9 DA4-W57BC1S1 High Performance, Single Polarized, CPR137G input 4 (1.2) 34.7 35.5 36.3 DA6-W57BC1S1 High Performance, Single Polarized, CPR137G input 6 (1.8) 38.2 39.0 39.8 DA8-W57AC1S1 High Performance, Single Polarized, CPR137G input 8 (2.4) 40.7 41.5 42.3 ** Calculated Value for use at 5.8GHz Page 2 of 2

15 September, 2011 Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality for VK6-IRU600HB2 Aviat Networks requests according to FCC 47 CFR 0.459 that the following items are held permanently confidential and from public view: Block diagrams All schematic diagrams Parts list Operational description These items contain proprietary information that represents considerable investment on the part of Aviat Networks. Public disclosure of this information would be damaging for Aviat Networks due to the competitive nature of our industry. Ruth French Product Compliance Manager

9 November, 2011 IRU600HB External Photographs IRU600 Front B External Photographs 9 November, 2011 IRU600 Back 9 November, 2011 IRU600 Side 1 9 November, 2011 IRU600 Side 2 9 November, 2011 IRU600 Top 9 November, 2011 IRU600 Bottom

Label artwork for VK6-IRU600HB2:

Label location for VK6-IRU600HB2 and 4469A-IRU600HB2 The part number and model label is placed top left on the right hand side of the unit. The Part 15, FCC ID and IC number labels are placed on the right hand side of the right side of the unit.

22 November, 2011 Certification and Engineering Bureau Industry Canada P.O. Box 11490, Station H 3701 Carling Avenue (Building 94) Ottawa, Ontario K2H 8S2 Subject: Transmit Frequency Range: 4469A-IRU600HB2 and 4469A-IRU600LB2 To Whom It May Concern, The product label for 4469A-IRU600LB2 states a frequency range of 5725 – 6200MHz and the product label for 4469A-IRU600HB2 states a frequency range of 5785 – 6450MHz. These ranges represent the full range of the RF components within this radio. The radio can either be configured for use with 5.8GHz spot tuned filters or L6GHz spot tuned frequencies. All of the 5.8GHz filters are within the RSS-210 range of 5725MHz – 5850MHz and ensure compliance with the band edge. All of the L6GHz filters are within the licenced band. Software controls are also in place to ensure that this product can only transmit within the licenced L6GHz band or within the authorised range of the licence-exempt 5.8GHz band. Therefore, it would not be accurate to label these radios only with the range stated on our application. Sincerely, Ruth French Product Compliance Manager

9 November, 2011 IRU600HB Internal Photographs IRU600 Unit IRU600HB Internal Photographs 9 November, 2011 Radio Frequency Unit (lid removed) Radio Frequency Unit (lid removed) 9 November, 2011 Radio Frequency Unit (IF card removed) Radio Frequency Unit (IF card removed) 9 November, 2011 Radio Frequency Unit (internal, Radio Frequency Unit (internal, close up) 9 November, 2011 IF Card (side 1) 9 November, 2011 IF Card (side 2)

Aviat Networks FCC OET 65 & RSS-102 Calculation Page 1 of 3 Page 1 of 3 FCC OET 65 and IC RSS 102 MPE Value Calculations The purpose of this report is to document the Maximum Permissible Exposure (MPE) value for the IRU 600 high band product. Manufacturer: Aviat Networks Equipment Category: Microwave Fixed Link Equipment Name: IRU 600 FCC ID: VK6-IRU600HB2 IC ID: 4469A-IRU600HB2 Report Date: 21-NOV-2011 Aviat Networks FCC OET 65 & RSS-102 Calculation Page 2 of 3 Page 2 of 3 1. Introduction FCC OET Bulletin 65 defines guidelines and limits for Maximum Permissible Exposure (MPE) in terms of electric and magnetic field strength and power density for transmitters operating at frequencies between 300 kHz and 100 GHz. Industry Canada RSS 102 defines the RF exposure compliance requirements for radio communications apparatus in all frequency bands. This report documents the MPE value (distance) for the IRU 600 high band system which is spot tuned to either 5805 or 5835MHz. This product has a FCC ID: VK6-IRU600HB2 This product has an IC ID: 4469A-IRU600HB2 2. References [1] FCC OET Bulletin 65 edition 97-01 [2] IC RSS 102 issue 4 3. Formula and limit. From OET 65 [1] the formula for calculating the maximum permissible exposure is: S = PG/4πR 2 (1) MPE limit for uncontrolled exposure at prediction frequency = 1 mW/cm 2 Re-arranging the above formula to calculate R: R = √(PG/4πS) (2) It should be noted the RSS-102 [2] clause 3.1.1, SAR measurement 3GHz – 6GHz, points the reader towards the FCC published procedures for ensuring compliance and thus this report serves both sets of requirements. Aviat Networks FCC OET 65 & RSS-102 Calculation Page 3 of 3 Page 3 of 3 4. Input values P = power input to antenna = 30dBm or 1000mW G = Antenna gain = 45.9dBi or 38904 numeric S = MPE limit for uncontrolled exposure = 1mW/cm 2 R = Distance to the centre of the antenna (cm) 5. Calculating distance to antenna Using formula (2) from above: R = √((1000x38904)/4π)) R = 1760 cm It should be noted that this distance contains zero margin so the distance cannot be any shorter than this. In order to guarantee some margin a distance of 1800cm is proposed and using formula (1) from above, this gives an exposure level of: S = 1000x38904/4π1800 2 S = 0.956 mW/cm 2 i.e. a compliance margin of 0.0434 mW/cm 2 6. Conclusion The recommended minimum distance from the centre of the antenna to ensure exposure below the limit specified in OET Bulletin 65 [1] and RSS 102 [2] is 1800cm.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Eclipse IRU600V2, 5.8GHz (High Band) FCC ID: VK6-IRU600HB2 IC Certification Number: 4469A-IRU600HB2 To: FCC Part 15.247: 2011 Subpart C, RSS-210 Issue 8 December 2010 & RSS-Gen Issue 3 December 2010 Test Report Serial No: RFI-RPT-RP81852JD03B V3.0 Version 3.0 supersedes all previous versions This Test Report Is Issued Under The Authority Of Chris Guy, Head of Global Approvals: Checked By: Steven White Signature: Date of Issue: 23 November 2011 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI-RPT-RP81852JD03B V3.0 VERSION 3.0 ISSUE DATE: 23 NOVEMBER 2011 Page 2 of 98 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI-RPT-RP81852JD03B V3.0 VERSION 3.0 ISSUE DATE: 23 NOVEMBER 2011 RFI Global Services Ltd Page 3 of 98 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 6 2.4. Deviations from the Test Specification 6 3. Equipment Under Test (EUT) ....................................................................................................... 7 3.1. Identification of Equipment Under Test (EUT) 7 3.2. Description of EUT 7 3.3. Modifications Incorporated in the EUT 7 3.4. Additional Information Related to Testing 8 3.5. Support Equipment 10 4. Operation and Monitoring of the EUT during Testing ............................................................. 11 4.1. Operating Modes 11 4.2. Configuration and Peripherals 11 5. Measurements, Examinations and Derived Results ................................................................ 12 5.1. General Comments 12 5.2. Test Results 13 5.2.1. Transmitter AC Conducted Spurious Emissions 13 5.2.2. Transmitter 6 dB Bandwidth 15 5.2.3. Transmitter 20 dB Bandwidth 33 5.2.4. Transmitter Power Spectral Density 51 5.2.5. Transmitter Maximum Average Output Power 53 5.2.6. Transmitter Radiated Emissions - 4 foot parabolic antenna 72 5.2.7. Transmitter Radiated Emissions - 2 foot flat panel antenna 79 5.2.8. Transmitter Band Edge Conducted Emissions 86 6. Measurement Uncertainty .......................................................................................................... 97 Appendix 1. Test Equipment Used ................................................................................................ 98 TEST REPORT SERIAL NO: RFI-RPT-RP81852JD03B V3.0 VERSION 3.0 ISSUE DATE: 23 NOVEMBER 2011 Page 4 of 98 RFI Global Services Ltd 1. Customer Information Company Name: Aviat Networks Address: 4 Bell Drive, Hamilton Intl Tech Park Blantyre Glasgow Lanarkshire G72 0FB United Kingdom TEST REPORT SERIAL NO: RFI-RPT-RP81852JD03B V3.0 VERSION 3.0 ISSUE DATE: 23 NOVEMBER 2011 RFI Global Services Ltd Page 5 of 98 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.247 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart C (Intentional Radiators) - Section 15.247 Specification Reference: 47CFR15.107 and 47CFR15.109 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart B (Unintentional Radiators) - Sections 15.107 and 15.109 Specification Reference: 47CFR15.207 and 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart C (Intentional Radiators) - Sections 15.207 and 15.209 Specification Reference: RSS-Gen Issue 3 December 2010 Specification Title: General Requirements and Information for the Certification of Radio Apparatus Specification Reference: RSS-210 Issue 8 December 2010 Specification Title: Licence-exempt Radio Apparatus (All Frequency Bands): Category I Equipment. Site Registration: FCC: 209735; Industry Canada: 3245B-2 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 12 July 2011 to 28 October 2011 2.2. Summary of Test Results FCC Reference (47CFR) IC Reference Measurement Result Part 15.207 RSS-Gen 7.2.4 Transmitter AC Conducted Emissions Part 15.247(a)(2) RSS-Gen 4.6.2 RSS-210 A8.2(a) Transmitter 6 dB Bandwidth Part 2.1049 RSS-Gen 4.6.1/4.6.3 Transmitter 20 dB Bandwidth Part 15.247(e) RSS-210 A8.2(b) Transmitter Power Spectral Density Part 15.247(b)(3) RSS-Gen 4.8 RSS-210 A8.4(4) Transmitter Maximum Average Output Power Part 15.247(d)/ 15.209(a) RSS-Gen 4.9 RSS-210 A8.5 Transmitter Radiated Emissions Part 15.247(d) RSS-Gen 4.9 RSS-210 A8.5 Transmitter Band Edge Conducted Emissions Key to Results = Complied = Did not comply Notes: 1. The customer declared that there is no idle mode and that the EUT goes into transceive mode as soon as it is powered up. TEST REPORT SERIAL NO: RFI-RPT-RP81852JD03B V3.0 VERSION 3.0 ISSUE DATE: 23 NOVEMBER 2011 Page 6 of 98 RFI Global Services Ltd 2.3. Methods and Procedures Reference: ANSI C63.4 (2009) Title: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Reference: ANSI C63.10 (2009) Title: American National Standard for Testing Unlicensed Wireless Devices 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or ex…

Text truncated - open the document above for the full version.

VK6-IRU600HB2 and 4469A-IRU600HB2 test set-up photos, flat panel antenna

VK6-IRU600HB2 and 4469A-IRU600HB2 test set-up photos, parabolic antenna
