VK6-ODU600HBEclipse ODU 600

EclipseODU600 InstallationManual 5.8GHzUnlicensedBand ManualRev.001 August2013 ECLIPSEINSTALLATIONMANUAL 260-668066-004AUGUST2013II Copyright&TermsofUse August2013 ThismanualisspecifictoEclipsewithODU600forsplit-mountoperationonthe FCCandIndustryCanada5.8GHzunlicensedband. Copyright©2013byAviatNetworks,Inc. Allrightsreserved. Nopartofthispublicationmaybereproduced,transmitted,transcribed,storedina retrievalsystem,ortranslatedintoanylanguageorcomputerlanguage,inanyform orbyanymeans,electronic,magnetic,optical,chemical,manualorotherwise, withoutthepriorwrittenpermissionofAviatNetworksInc. Torequestpermission,[email protected]. Warranty AviatNetworksmakesnorepresentationorwarrantieswithrespecttothecontents hereofandspecificallydisclaimsanyimpliedwarrantiesormerchantabilityorfitness foranyparticularpurpose. Further,AviatNetworksreservestherighttorevisethispublicationandtomake changesfromtimetotimeinthecontenthereofwithoutobligationofAviatNetworks tonotifyanypersonofsuchrevisionorchanges. SafetyRecommendations Thefollowingsafetyrecommendationsmustbeconsideredtoavoidinjuriestopersons and/ordamagetotheequipment: 1.InstallationandServicePersonnel:Installationandservicemustbecarriedoutby authorizedpersonnelwhohavethetechnicaltrainingandexperiencenecessarytobe awareofanyhazardousoperationsduringinstallationandservice,andofmeasuresto avoidanydangertothemselves,toanyotherpersonnel,andtotheequipment. 2.AccesstotheEquipment:Accesstotheequipmentinusemustberestrictedtoser- vicepersonnelonly. 3.SafetyNorms:RecommendedsafetynormsaredetailedintheHealthandSafety sectionsofthismanual. lLocalsafetyregulationsmustbeusedifmandatory.Safetyinstructionsinthis documentshouldbeusedinadditiontothelocalsafetyregulations. lInthecaseofconflictbetweensafetyinstructionsstatedinthismanualand thoseindicatedinlocalregulations,mandatorylocalnormswillprevail. lShouldlocalregulationsnotbemandatory,thenthesafetynormsinVolume1 willprevail. ECLIPSEINSTALLATIONMANUAL IIIAVIATNETWORKS 4.ServicePersonnelSkill:Servicepersonnelmusthavereceivedadequatetechnical trainingontelecommunicationsandinparticularontheequipmentthismanual refersto. Trademarks Alltrademarksarethepropertyoftheirrespectiveowners. CAUTION:Makingadjustmentsand/ormodificationstothisequipment thatarenotinaccordancewiththeprovisionsofthisinstruction manualorothersupplementarydocumentationmayresultinpersonal injuryordamagetotheequipment,andmayvoidtheequipmentwar- ranty. ECLIPSEINSTALLATIONMANUAL 260-668066-004AUGUST2013IV AviatNetworksSupport ServiceandTechnicalSupport: Forcustomerserviceandtechnicalsupport,contactoneoftheregionalTechnicalHelp Deskslistedbelow,orfor24/7(allday,everydayoftheyear)thereistheGlobalTech- nicalHelpDesk(GTHD). TheGTHDnumberis:+1-210-526-6345,ortollfree1-800-227-8332 withinUSA lFor24/7accessyouwillneedyourSupportAssurancePIN.WithoutaPINyou willstillreceivesupport,butthesupportprocesswillrequireanadditional screeningstep. lAfter-hourscallstoParisareroutedtotheGTHD.TheParisnumberismanned duringbusinesshours. AmericasTechnicalHelp Desk EMEATechnicalHelpDeskAsiaPacificTechnicalHelp Desk AviatNetworks 5200GreatAmericaParkway SantaClaraCA95054 U.S.A. AviatNetworks 4BellDrive HamiltonInternational TechnologyPark Blantyre,Glasgow,Scotland G720FB UnitedKingdom AviatNetworks Bldg10,UnitsA&B PhilexcelIndustrialPark M.RoxasHi-way ClarkFreeportZone Philippines2023 TollFree(Canada/USA):800 2278332 Phone:2105617400 Fax:2105617399 Phone: Hamilton:+44(0)1698717230 Paris:+33(0)177310033 Fax:+44(0)1698717204 Phone:+63455995192 Fax:+63455995196 [email protected]@[email protected] OryoucancontactyourlocalAviatNetworksoffice.Contactinformationisavailable onourwebsiteat:http://www.aviatnetworks.com/services/customer-sup- port/technical-assistance/ ECLIPSEINSTALLATIONMANUAL VAVIATNETWORKS EclipseProductComplianceNotes EclipsehasbeentestedforandmeetsEMCDirective2004/108/EC.Theequipment wastestedusingscreenedcable;ifanyothertypeofcableisused,itmayviolatecom- pliance. EclipseisaClassAproduct.Inadomesticenvironmentthisproductmaycauseradio interferenceinwhichcasetheusermayberequiredtotakeadequatemeasures.This equipmentisintendedtobeusedexclusivelyintelecommunicationscenters. RegulatoryInformationfortheODU600,5.8GHzBand FCCNotices 1.TheODU600,5.8GHzmustbeprofessionallyinstalledandmaintained. 2.Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora ClassAdigitaldevice,pursuanttoPart15oftheFCCrules.Theselimitsare designedtoprovidereasonableprotectionagainstharmfulinterferencewhen theequipmentisoperatedinacommercialenvironment.Thisequipment generates,usesandcanradiateradiofrequencyenergyand,ifnotinstalled andusedinaccordancewiththeinstructionmanual,maycauseharmful interferencetoradiocommunications.Operationofthisequipmentina residentialenvironmentislikelytocauseharmfulinterferenceinwhichcase theuserwillberequiredtocorrecttheinterferenceathisownexpense. 3.ODU600,5.8GHziscompliantwithFCCCFR47,Part15.247. 4.ToensurecompliancewiththeFCCRFexposurerequirements,aminimum distanceof18metersmustbemaintainedbetweentheantennaandany personswhilsttheunitisoperational.Thiscalculationisbasedonthe maximumconductedpowerandmaximumantennagain. 5.ODU600,5.8GHzhasbeencertifiedforusewithaparabolicantennawitha maximumgainof45.9dBioraflatpanelantennawithamaximumgainof 28dBi. 6.Thesoftwareprovidedwiththisproductallowsfortransmissiononlyinthe frequencyrange5725–5850MHztoensurecompliancewithPart15.247. 7.AccordingtotheconductedpowerlimitinFCCCFR47,Part15.247,the powerforthisdevicehasbeenlimitedto1W(30dBm)attheantennaport. 8.FCCCFR47,Part15.247excludestheuseofpoint-to-multipointsystems, omnidirectionalapplicationsandmultipleco-locatedintentionalradiators. Thissystemisonlyforfixed,point-to-pointoperation. IndustryCanadaNoticesAvisd’IndustrieCanada 1.TheODU600,5.8GHzmustbeprofessionallyinstalledandmaintained. 2.ODU600,5.8GHziscompliantwithIndustryCanadaRSS-210. ECLIPSEINSTALLATIONMANUAL 260-668066-004AUGUST2013VI 3.ToensurecompliancewiththeIndustryCanadaRFexposurerequi…

Text truncated - open the document above for the full version.

Request for Confidentiality Date: 15 August 2013 Subject: Confidentiality Request for: VK6-ODU600LB, VK6-ODU600HB and 4469A-ODU600LB, 4469A-ODU600HB Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual Aviat Networks has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, RUTH FRENCH, PRODUCT COMPLIANCE MANAGER

23 rd August, 2013 ODU600, 5.8GHz High Band External Photographs FCC: VK6-ODU600HB Industry Canada: 4469A-ODU600HB ODU600 Unit 23 rd August, 2013 ODU600 Top View 23 rd August, 2013 ODU600 Base View

Label location

IC: 4469A-ODU600HBFCC ID: VK6-ODU600HB 25.0 6.0 001 05-NOV-12 ECO 38573 Dimensions are in Millimeters. Unless otherwise sta ted tolerances are X 0.5 X.X 0.25 X.XX 0.1 Angle 1 Drawing Title / File Name: The information contained in this drawing is the sole property of Aviat Networks. Any reproduction in part or in whole without the written permission of Aviat Networks is prohibited Drawing Number: 007-600301-001 R001 LABEL ODU600 5.8G FCC ID AND IC HB Description Rev 05-NOV-12 Date Sheet 1 of 1 Modeled John Justice Aviat Networks Aviat Networks part number: 007-600301-001 R001Notes: Material: Type: Gloss white UL recoginized Polyes ter. 1. Thickness: 0.05 Adhesive: 0.02 thick permanent acrylic Manufacturer: Fasson, Flexcon or equivalent. 2. Solvent Resistance: (Printed label) Per MIL STD 202F, Notice 12, Method 215J 0.05 matt finished transparent polyester film. 3. Resin based thermal transfer, black on whit e background. 4. Font: Ariel 9 Bold5. Materials used must be RoHS 6 compliant. R efer to Aviat Networks QA_D_004. 5200 Great America Parkway, Santa Clara CA 95054 Tel: 408 567 7000 Motnica 9, 1236 Trzin, Slovenia Tel + 386 1 5887 001 20 Peterkin Street, Lower Hutt, New Zealand Tel: + 64 4 577 8800

22 nd August, 2013 ODU600, 5.8GHz High Band Internal Photographs FCC: VK6-ODU600HB Industry Canada: 4469A-ODU600HB ODU600 Unit 22 nd August, 2013 ODU600 Opened 22 nd August, 2013 ODU600 Lid removed 22 nd August, 2013 Radio Frequency Module (RFM PCB, shield removed) 22 nd August, 2013 Radio Frequency Module removed from ODU casing 22 nd August, 2013 Radio Frequency Module (RFM PCB, side 1) 22 nd August, 2013 Radio Frequency Module (RFM, side 2) 22 nd August, 2013 Radio Frequency Module (RFM, side 2, PCB shield removed)

Aviat Networks FCC OET 65 & RSS-102 Calculation Page 1 of 3 Page 1 of 3 FCC OET 65 and IC RSS 102 MPE Value Calculations The purpose of this report is to document the Maximum Permissible Exposure (MPE) value for the ODU 600 product. Manufacturer: Aviat Networks Equipment Category: Microwave Fixed Link Equipment Name: ODU 600 FCC ID: VK6-ODU600LB and VK6-ODU600HB IC ID: 4469A-ODU600LB and 4469A-ODU600HB Report Date: 15-AUG-2013 Aviat Networks FCC OET 65 & RSS-102 Calculation Page 2 of 3 Page 2 of 3 1. Introduction FCC OET Bulletin 65 defines guidelines and limits for Maximum Permissible Exposure (MPE) in terms of electric and magnetic field strength and power density for transmitters operating at frequencies between 300 kHz and 100 GHz. Industry Canada RSS 102 defines the RF exposure compliance requirements for radio communications apparatus in all frequency bands. This report documents the MPE value (distance) for the ODU 600. This product has a FCC ID: VK6-ODU600LB and VK6-ODU600HB This product has an IC ID: 4469A-ODU600LB and 4469A-ODU600HB 2. References [1] FCC OET Bulletin 65 edition 97-01 [2] IC RSS 102 issue 4 3. Formula and limit. From OET 65 [1] the formula for calculating the maximum permissible exposure is: S = PG/4πR 2 (1) MPE limit for uncontrolled exposure at prediction frequency = 1 mW/cm 2 Re-arranging the above formula to calculate R: R = √(PG/4πS) (2) It should be noted the RSS-102 [2] clause 3.1.1, SAR measurement 3GHz – 6GHz, points the reader towards the FCC published procedures for ensuring compliance and thus this report serves both sets of requirements. Aviat Networks FCC OET 65 & RSS-102 Calculation Page 3 of 3 Page 3 of 3 4. Input values P = power input to antenna = 30dBm or 1000mW G = Antenna gain = 45.9dBi or 38904 numeric S = MPE limit for uncontrolled exposure = 1mW/cm 2 R = Distance to the centre of the antenna (cm) 5. Calculating distance to antenna Using formula (2) from above: R = √((1000x38904)/4π)) R = 1760 cm It should be noted that this distance contains zero margin so the distance cannot be any shorter than this. In order to guarantee some margin a distance of 1800cm is proposed and using formula (1) from above, this gives an exposure level of: S = 1000x38904/4π1800 2 S = 0.956 mW/cm 2 i.e. a compliance margin of 0.0434 mW/cm 2 6. Conclusion The recommended minimum distance from the centre of the antenna to ensure exposure below the limit specified in both OET Bulletin 65 [1] and RSS 102 [2] is 1800cm.

UL VS LTD Pavilion A, Ashwood Park, Ashwood Way, Basingstoke, Hampshire, RG23 8BG, UK Telephone: +44 (0)1256 312000 Facsimile: +44 (0)1256 312001 TEST REPORT Test Report No. : UL-RPT-RP88569JD07B Manufacturer : Aviat Networks Model No. : Eclipse ODU 600, 5.8GHz, EEH-U5-0084-012 FCC ID : VK6-ODU600HB IC Certification No. : 4469A-ODU600HB Test Standard(s) : FCC Parts 15.207, 15.209(a) & 15.247 and Industry Canada RSS- Gen 4.6.1, 4.6.2, 4.8, 4.9, 7.2.4 & RSS-210 A8.2(a), A8.2(b), A8.4(4) & A8.5 1. This test report shall not be reproduced in full or partial, without the written approval of UL VS LTD. 2. The results in this report apply only to the sample(s) tested. 3. This sample tested is in compliance with the above standard(s). 4. The test results in this report are traceable to the national or international standards. 5. Version 1.0 Date of Issue: 29 July 2013 Checked by: Steven White WiSE Project Lead Issued by : pp John Newell Group Quality Manager, WiSE Basingstoke, UL VS LTD This laboratory is accredited by UKAS. The tests reported herein have been performed in accordance with its’ terms of accreditation. TEST REPORT SERIAL NO: UL-RPT-RP88569JD07B VERSION 1.0 ISSUE DATE: 29 JULY 2013 Page 2 of 56 UL VS LTD This page has been left intentionally blank. TEST REPORT SERIAL NO: UL-RPT-RP88569JD07B VERSION 1.0 ISSUE DATE: 29 JULY 2013 UL VS LTD Page 3 of 56 Table of Contents 1. Customer Information .................................................................................................................4 2. Summary of Testing ....................................................................................................................5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 6 2.4. Deviations from the Test Specification 6 3. Equipment Under Test (EUT) .....................................................................................................7 3.1. Identification of Equipment Under Test (EUT) 7 3.2. Description of EUT 7 3.3. Modifications Incorporated in the EUT 7 3.4. Additional Information Related to Testing 8 3.5. Support Equipment 10 4. Operation and Monitoring of the EUT during Testing ............................................................11 4.1. Operating Modes 11 4.2. Configuration and Peripherals 11 5. Measurements, Examinations and Derived Results ...............................................................12 5.1. General Comments 12 5.2. Test Results 13 5.2.1. Transmitter AC Conducted Spurious Emissions 13 5.2.2. Transmitter 6 dB Bandwidth 16 5.2.3. Transmitter Occupied Bandwidth 22 5.2.4. Transmitter Power Spectral Density 28 5.2.5. Transmitter Maximum Average Output Power 34 5.2.6. Transmitter Radiated Emissions - 4 foot parabolic antenna 40 5.2.7. Transmitter Radiated Emissions - 2 foot flat panel antenna 46 5.2.8. Transmitter Band Edge Conducted Emissions 52 6. Measurement Uncertainty ........................................................................................................55 7. Report Revision History ...........................................................................................................56 TEST REPORT SERIAL NO: UL-RPT-RP88569JD07B VERSION 1.0 ISSUE DATE: 29 JULY 2013 Page 4 of 56 UL VS LTD 1. Customer Information Company Name: Aviat Networks Address: 4 Bell Drive, Hamilton International Technology Park Blantyre Glasgow Lanarkshire G72 0FB United Kingdom TEST REPORT SERIAL NO: UL-RPT-RP88569JD07B VERSION 1.0 ISSUE DATE: 29 JULY 2013 UL VS LTD Page 5 of 56 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.247 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2012: Part 15 Subpart C (Intentional Radiators) - Section 15.247 Specification Reference: 47CFR15.207 and 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2012: Part 15 Subpart C (Intentional Radiators) - Sections 15.207 and 15.209 Specification Reference: RSS-Gen Issue 3 December 2010 Specification Title: General Requirements and Information for the Certification of Radio Apparatus Specification Reference: RSS-210 Issue 8 December 2010 Specification Title: Licence-exempt Radio Apparatus (All Frequency Bands): Category I Equipment. Site Registration: FCC: 209735; Industry Canada: 3245B-2 Location of Testing: UL VS LTD, Unit 3 Horizon, Wade Road, Kingsland Business Park, Basingstoke, Hampshire, RG24 8AH, United Kingdom. Test Dates: 04 March to 12 July 2013 2.2. Summary of Test Results FCC Reference (47CFR) IC Reference Measurement Result Part 15.207 RSS-Gen 7.2.4 Transmitter AC Conducted Emissions Part 15.247(a)(2) RSS-Gen 4.6.2 RSS-210 A8.2(a) Transmitter 6 dB Bandwidth N/A RSS-Gen 4.6.1 Transmitter Occupied Bandwidth Part 15.247(e) RSS-210 A8.2(b) Transmitter Power Spectral Density Part 15.247(b)(3) RSS-Gen 4.8 RSS-210 A8.4(4) Transmitter Maximum Average Output Power Part 15.247(d)/ 15.209(a) RSS-Gen 4.9 RSS-210 A8.5 Transmitter Radiated Emissions Part 15.247(d) RSS-Gen 4.9 RSS-210 A8.5 Transmitter Band Edge Conducted Emissions Key to Results = Complied = Did not comply Note(s): 1. The customer declared that there is no idle mode and that the EUT goes into transceive mode as soon as it is powered up. TEST REPORT SERIAL NO: UL-RPT-RP88569JD07B VERSION 1.0 ISSUE DATE: 29 JULY 2013 Page 6 of 56 UL VS LTD 2.3. Methods and Procedures Reference: ANSI C63.4 (2003) Title: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Reference: ANSI C63.10 (2009) Title: American National Standard for Testing Unlicensed Wireless Devices Reference: KDB 558074 D01 v02 10/04/2012 Title: Guidance for Performing Compliance Measurements on Digital Transmission System (DTS) devices operating Under §15.247 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations…

Text truncated - open the document above for the full version.

TCB: As the margin in spurious emission measurements is less than the difference in antenna gains between the antenna used in testing and the antenna supplied with the end product, please confirm that you have verified that there were no emission peaks hiding just below the noise floor. A: We have completed conducted measurements during development that show that the spectrum is clean with the exception of the actual carrier. As the antenna is passive and can only contribute to a genuine emission from the transmitter, we are confident that there is nothing hiding in the noise floor.

VK6-ODU600LB, VK6-ODU600HB and 4469A-ODU600LB, 4469A-ODU600HB test set-up photos
