VK6-IRU600V3Eclipse IRU600V3

Aviat Networks (S) Pte. Ltd

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 07, 2012
Application Purpose: Original Equipment
Date of Application: Dec 06, 2012
Equipment Note: Eclipse IRU600V3
Frequency Range: 5728.00000000 - 5847.00000000
Company: Aviat Networks (S) Pte. Ltd
Country: Singapore

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

ECLIPSE Rev.003 INSTALLATION MANUAL 260-668066-001 TM 5.8 GHZ UNLICENSED BAND EclipseIRU600 InstallationManual 5.8GHzUnlicensedBand ManualRev.003 October2012 ECLIPSEINSTALLATIONMANUAL 260-668066-001OCTOBER2012II Copyright&TermsofUse October2012 ThismanualisspecifictoEclipsewithIRU600forall-indooroperationontheFCC andIndustryCanada5.8GHzunlicensedband. Copyright©2012byAviatNetworks,Inc. Allrightsreserved. Nopartofthispublicationmaybereproduced,transmitted,transcribed,storedina retrievalsystem,ortranslatedintoanylanguageorcomputerlanguage,inanyform orbyanymeans,electronic,magnetic,optical,chemical,manualorotherwise,with- outthepriorwrittenpermissionofAviatNetworksInc. Torequestpermission,[email protected]. Warranty AviatNetworksmakesnorepresentationorwarrantieswithrespecttothecontents hereofandspecificallydisclaimsanyimpliedwarrantiesormerchantabilityorfitness foranyparticularpurpose. Further,AviatNetworksreservestherighttorevisethispublicationandtomake changesfromtimetotimeinthecontenthereofwithoutobligationofAviatNetworks tonotifyanypersonofsuchrevisionorchanges. SafetyRecommendations Thefollowingsafetyrecommendationsmustbeconsideredtoavoidinjuriestopersons and/ordamagetotheequipment: 1.InstallationandServicePersonnel:Installationandservicemustbecarriedoutby authorizedpersonnelwhohavethetechnicaltrainingandexperiencenecessarytobe awareofanyhazardousoperationsduringinstallationandservice,andofmeasuresto avoidanydangertothemselves,toanyotherpersonnel,andtotheequipment. 2.AccesstotheEquipment:Accesstotheequipmentinusemustberestrictedtoserv- icepersonnelonly. 3.SafetyNorms:RecommendedsafetynormsaredetailedintheHealthandSafety sectionsofthismanual. lLocalsafetyregulationsmustbeusedifmandatory.Safetyinstructionsinthis documentshouldbeusedinadditiontothelocalsafetyregulations. lInthecaseofconflictbetweensafetyinstructionsstatedinthismanualand thoseindicatedinlocalregulations,mandatorylocalnormswillprevail. lShouldlocalregulationsnotbemandatory,thenthesafetynormsinVolume1 willprevail. ECLIPSEINSTALLATIONMANUAL IIIAVIATNETWORKS 4.ServicePersonnelSkill:Servicepersonnelmusthavereceivedadequatetechnical trainingontelecommunicationsandinparticularontheequipmentthismanual refersto. Trademarks Alltrademarksarethepropertyoftheirrespectiveowners. OpenSourceSoftware Thesoftwareincludedinthisproductcontainscopyrightedsoftwarethatislicensed undertheGPL.Acopyofthatlicenseandthecompletecorrespondingsourcecodeis includedontheCDthatisshippedwiththeproduct.Youmayalsoobtainthecom- pletecorrespondingsourcecodefromusforaperiodofthreeyearsafterourlastship- mentofthisproduct,[email protected]. CAUTION:Makingadjustmentsand/ormodificationstothisequipment thatarenotinaccordancewiththeprovisionsofthisinstructionman- ualorothersupplementarydocumentationmayresultinpersonal injuryordamagetotheequipment,andmayvoidtheequipmentwar- ranty. ECLIPSEINSTALLATIONMANUAL 260-668066-001OCTOBER2012IV AviatNetworksSupport ServiceandTechnicalSupport: Forcustomerserviceandtechnicalsupport,contactoneoftheregionalTechnicalHelp Deskslistedbelow. AmericasTechnicalHelp Desk EMEATechnicalHelpDeskAsiaPacificTechnicalHelp Desk AviatNetworks 5200GreatAmericaParkway SantaClaraCA95054 U.S.A. AviatNetworks 4BellDrive HamiltonInternational TechnologyPark Blantyre,Glasgow,Scotland G720FB UnitedKingdom AviatNetworks Bldg10,UnitsA&B PhilexcelIndustrialPark M.RoxasHi-way ClarkFreeportZone Philippines2023 TollFree(Canada/USA):800 2278332 Phone:2105617400 Fax:2105617399 Phone: Hamilton:+44(0)1698717230 Paris:+33(0)177310033 Fax:+44(0)1698717204 Phone:+63455995192 Fax:+63455995196 [email protected]@[email protected] OryoucancontactyourlocalAviatNetworksoffice.Contactinformationisavailable onourwebsiteat:http://www.aviatnetworks.com/services/customer-sup- port/technical-assistance/ SalesandSalesSupport: Forsalesinformation,contactoneoftheAviatNetworksheadquarters,orfindyour regionalsalesofficeat:http://www.aviatnetworks.com/contact-us/sales/ CorporateHeadquarters California,USA InternationalHeadquarters Singapore AviatNetworks,Inc. 5200GreatAmericaParkwaySanta ClaraCA95054 U.S.A. Phone:4085677000 Fax:408567 AviatNetworks(S)Pte.Ltd. 17,ChangiBusinessParkCentral1 HoneywellBuilding,#04-01 Singapore486073 Phone:+6564960900 Fax:+6564960999 SalesInquiries: +1-321-674-4252 ECLIPSEINSTALLATIONMANUAL VAVIATNETWORKS EclipseProductComplianceNotes EclipsehasbeentestedforandmeetsEMCDirective2004/108/EC.Theequipment wastestedusingscreenedcable;ifanyothertypeofcableisused,itmayviolate compliance. EclipseisaClassAproduct.Inadomesticenvironmentthisproductmaycauseradio interferenceinwhichcasetheusermayberequiredtotakeadequatemeasures.This equipmentisintendedtobeusedexclusivelyintelecommunicationscenters. FCCNotices 1.IRU600,5.8GHz,mustbeprofessionallyinstalledandmaintained. 2.Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora ClassAdigitaldevice,pursuanttoPart15oftheFCCrules.Theselimitsare designedtoprovidereasonableprotectionagainstharmfulinterferencewhen theequipmentisoperatedinacommercialenvironment.Thisequipment generates,usesandcanradiateradiofrequencyenergyand,ifnotinstalled andusedinaccordancewiththeinstructionmanual,maycauseharmful interferencetoradiocommunications.Operationofthisequipmentina residentialenvironmentislikelytocauseharmfulinterferenceinwhichcase theuserwillberequiredtocorrecttheinterferenceathisownexpense. 3.IRU600,5.8GHz,iscompliantwithFCCCFR47,Part15.247. 4.ToensurecompliancewiththeFCCRFexposurerequirements,aminimum distanceof18metersmustbemaintainedbetweentheantennaandany personswhilsttheunitisoperational.Thiscalculationisbasedonthe maximumconductedpowerandmaximumantennagain. 5.IRU600,5.8GHz,hasbeencertifiedforusewithaparabolicantennawitha maximumgainof45.9dBioraflatpanelantennawithamaximumgainof 28dBi. 6.Thefiltersandsoftwareprovidedwiththisproductallowfortransmission onlyinthefrequencyrange5725–5850MHztoensurecompliancewithPart 15.247. 7.AccordingtotheconductedpowerlimitinFCC…

Text truncated - open the document above for the full version.

Cover Letter(s)

Antenna Manufacturer's Name: Andrew Solution Antenna Model No. Antenna Type Low Band Gain–dBi Mid-Band Gain–dBi Top Band Gain–dBi Antenna Diameter–ft Lowest RF Freq– MHz Highest RF Freq– MHz Beam Width–dB Cross Pol Discrimination (dB) Front-to-Back Ratio–dB P2F-52 Parabolic 29.4 2 5250 5850 5.4 30 41 P3F-52 Parabolic 33.4 3 5250 5850 3.8 30 42 P4F-52 Parabolic 34.9 4 5250 5850 3.0 30 52 P6F-52 Parabolic 37.6 6 5250 5850 1.8 30 49 PX2F-52 Parabolic 29.4 2 5250 5850 5.4 30 41 PX3F-52 Parabolic 33.4 3 5250 5850 3.8 30 42 PX4F-52 Parabolic 34.9 4 5250 5850 3.0 30 52 PX6F-52 Parabolic 37.6 6 5250 5850 1.8 30 49 HP2F-52 Parabolic 29.0 2 5250 5850 5.4 30 50 HP3F-52 Parabolic 33.0 3 5250 5850 3.8 30 53 HP4F-52 Parabolic 34.5 4 5250 5850 3.0 30 58 HP6F-52 Parabolic 37.2 6 5250 5850 1.8 30 56 HPX2F-52 Parabolic 29.0 2 5250 5850 5.4 30 50 HPX4F-52 Parabolic 34.5 4 5250 5850 3.0 30 58 HPX6F-52 Parabolic 37.2 6 5250 5850 1.8 30 56 P2F-57W Parabolic 29.2 29.3 29.9 2 5725 6425 5.8 30 40 P4F-57W Parabolic 34.5 35.0 35.4 4 5725 6425 2.9 30 40 P6F-57W Parabolic 38.0 38.5 39.0 6 5725 6425 2.0 30 45 P8F-57W Parabolic 40.7 41.2 41.7 8 5725 6425 1.6 30 47 P10F-57W Parabolic 42.5 42.9 43.4 10 5725 6425 1.3 30 50 P2-57W Parabolic 29.2 29.3 29.9 2 5725 6425 5.8 30 40 P4-57W Parabolic 34.5 35.0 35.4 4 5725 6425 2.9 30 40 PL6-57W Parabolic 38.0 38.5 39.0 6 5725 6425 2.0 30 45 PL8-57W Parabolic 40.7 41.2 41.7 8 5725 6425 1.6 30 47 PL10-57W Parabolic 42.5 42.9 43.4 10 5725 6425 1.3 30 50 PL12-57W Parabolic 44.2 44.6 45.0 12 5725 6425 1.0 30 51 HP4F-57W Parabolic 34.6 35.0 35.4 4 5725 6425 2.9 30 52 HP6F-57W Parabolic 38.0 38.5 39.0 6 5725 6425 2.0 30 60 HP8F-57W Parabolic 40.7 41.2 41.7 8 5725 6425 1.6 30 64 HP10F-57W Parabolic 42.5 42.9 43.4 10 5725 6425 1.3 30 65 HP4-57W Parabolic 34.6 35.0 35.4 4 5725 6425 2.9 30 52 HP6-57W Parabolic 38.0 38.5 39.0 6 5725 6425 2.0 30 60 HP8-57W Parabolic 40.7 41.2 41.7 8 5725 6425 1.6 30 64 HP10-57W Parabolic 42.5 42.9 43.4 10 5725 6425 1.3 30 65 PAR6-59W Parabolic 37.1 38.7 39 6 5725 7125 1.8 30 59 PAR8-59W Parabolic 39.6 41 41.6 8 5725 7125 1.4 30 59 PARX6-59W Parabolic 37.1 38.3 38.7 6 5725 7125 1.8 30 59 PARX8-59W Parabolic 39.6 40.7 40.9 8 5725 7125 1.6 30 60 PARX10-59W Parabolic 42 43.3 44 10 5725 7125 1.1 30 60 Antenna Manufacturer's Name: Andrew Solution Antenna Model No. Antenna Type Estimated Gain at 5.725 to 5.850 GHz Antenna Diameter–ft Lowest RF Freq– MHz Highest RF Freq– MHz Beam Width–dB Cross Pol Discrimination–dB Front-to-Back Ratio–dB HP6-59 Parabolic 37.9 6 5925 6425 1.8 30 62 HP8-59 Parabolic 40.8 8 5925 6425 1.4 30 66 HP10-59 Parabolic 42.3 10 5925 6425 1.1 30 69 HP12-59 Parabolic 44.4 12 5925 6425 0.9 30 71 HP15-59 Parabolic 45.9 15 5925 6425 0.8 30 71 PARX6-59 Parabolic 37.5 6 5725 6425 1.9 30 60 PARX8-59 Parabolic 40.1 8 5725 6425 1.4 30 60 PARX10-59 Parabolic 42.4 10 5925 6425 1.1 30 60 PARX12-59 Parabolic 43.0 12 5925 6425 0.9 30 60 UHX6-59 Parabolic 38.1 6 5925 6425 1.8 33 75 UHX8-59 Parabolic 40.6 8 5925 6425 1.4 33 77 UHX10-59 Parabolic 42.6 10 5925 6425 1.1 34 80 UHX12-59 Parabolic 44.1 12 5925 6425 0.9 35 80 UHX15-59 Parabolic 45.8 15 5925 6425 0.8 34 80 HPX4-59 Parabolic 34.1 4 5925 6425 2.9 30 58 HPX6-59 Parabolic 38.1 6 5925 6425 1.8 30 65 HPX8-59 Parabolic 40.6 8 5925 6425 1.4 30 69 HPX10-59 Parabolic 42.4 10 5925 6425 1.1 30 71 HPX12-59 Parabolic 44.1 12 5925 6425 0.9 30 71 HPX15-59 Parabolic 45.8 15 5925 6425 0.8 30 71 PAR6-59 Parabolic 37.7 6 5725 6425 2.0 30 55 PAR8-59 Parabolic 40.1 8 5725 6425 1.5 30 58 PAR10-59 Parabolic 42.7 10 5925 6425 1.1 30 62 PAR12-59 Parabolic 43.9 12 5925 6425 0.9 30 63

Cover Letter(s)

RFS 5.8 GHz antennas for Aviat Networks RFS Model Description Size ft (mtr) gain dB lowband midband highband 5.8 GHz ** -0528 band (5.15 - 5.35 and 5.725 - 5.875 GHz) MA0528-19AN Flat panel, single polarized, N female input 0.5 19.0 MA0528-23AN Flat panel, single polarized, N female input 1 23.0 MA0528-28AN Flat panel, single polarized, N female input 2 28.0 -52 band (5.25 - 5.85 GHz) SPF2-52CN1S Standard performance, single polarized, N female input 2 (0.6) 27.8 28.5 29.1 SPF3-52CN1S Standard performance, single polarized, N female input 3 (0.9) 31.3 32.0 32.6 SPF4-52CN1S Standard performance, single polarized, N female input 4 (1.2) 33.9 34.4 34.9 SPF6-52CN1S Standard performance, single polarized, N female input 6 (1.8) 37.6 38.1 38.6 SDF3-52CN1S1 High performance, single polarized, N female input 3 (0.9) 31.3 32.0 32.6 SDF4-52CN1S1 High performance, single polarized, N female input 4 (1.2) 33.9 34.4 34.9 SDF6-52CN1S1 High performance, single polarized, N female input 6 (1.8) 37.6 38.1 38.6 -57 band (5.725 - 7.125 GHz) UXA6-U57AC Ultra high performance, dual polarized 6 (1.8) 38.1 39.0 40.0 UXA8-U57AC Ultra high performance, dual polarized 8 (2.4) 40.6 41.6 42.6 UXA10-U57AC Ultra high performance, dual polarized 10 (3.0) 42.5 43.4 44.4 PADX6-U57AC High performance, dual polarized 6 (1.8) 37.9 38.9 39.8 PADX8-U57AC High performance, dual polarized 8 (2.4) 40.4 41.4 42.3 PADX10-U57AC High performance, dual polarized 10 (3.0) 42.3 43.2 44.2 -59 band ( 5.925-6.425 GHz) PAD6-59BC1S Standard performance, single polarized, CPR137G input 6 (1.8) 38.4 38.7 39.1 38.0 PAD8-59AC1S Standard performance, single polarized, CPR137G input 8 (2.4) 40.9 41.3 41.6 40.7 PAD10-59AC1S Standard performance, single polarized, CPR137G input 10 (3.0) 42.8 43.2 43.5 42.6 SU6-59BC1S1 SlimLine Ultra high performance,single polarized, CPR137G input 6 (1.8) 38.3 38.8 39.1 38.1 SU4-59BC1S1 SlimLine Ultra high performance,single polarized, CPR137G input 4 (1.2) 34.9 35.3 35.6 34.7 DA6-59BC1S1 High Performance, Single Polarized, CPR137G input 6 (1.8) 38.5 39.0 39.3 38.4 DA8-59AC1S1 High Performance, Single Polarized, CPR137G input 8 (2.4) 41.2 41.6 42.0 40.9 DA10-59AC1S1 High Performance, Single Polarized, CPR137G input 10 (3.0) 43.0 43.4 43.7 42.8 DA12-59AC1S1 High Performance, Single Polarized, CPR137G input 12 (3.7) 44.8 45.1 45.4 44.5 DAX4-59AC1S1 High Performance, Dual Polarized, CPR137G input 4 (1.2) 34.1 34.5 34.8 33.8 Page 1 of 2 RFS 5.8 GHz antennas for Aviat Networks DAX6-59BC1S1 High Performance, Dual Polarized, CPR137G input 6 (1.8) 38.3 38.7 39.0 38.0 DAX8-59AC1S1 High Performance, Dual Polarized, CPR137G input 8 (2.4) 40.9 41.3 41.7 40.7 DAX10-59AC1S1 High Performance, Dual Polarized, CPR137G input 10 (3.0) 42.9 43.2 43.5 42.6 UXA6-59CC1S1 Ultra high performance Dual Polarized, CPR137G input 6 (1.8) 38.3 38.7 39.0 38.0 UXA8-59BC1S1 Ultra high performance Dual Polarized, CPR137G input 8 (2.4) 40.9 41.3 41.7 40.6 UXA10-59BC1S1 Ultra high performance Dual Polarized, CPR137G input 10 (3.0) 42.9 43.2 43.5 42.6 UXA12-59AC1S1 Ultra high performance Dual Polarized, CPR137G input 12(3.7) 44.6 44.8 45.2 44.1 5.925 - 7.125GHz SB4-W60 Ultra high performance Single Polarized, CPR137G input 4 (1.2) 34.3 SBX4-W60 Ultra high performance Dual Polarized, CPR137G input 4 (1.2) 34.3 -W57 band (5.725 - 6.875 GHz) PA4-W57BC1S1 Standard performance, single polarized, CPR137G input 4 (1.2) 34.7 35.5 36.3 PA6-W57BC1S1 Standard performance, single polarized, CPR137G input 6 (1.8) 38.2 39.0 39.8 PA8-W57AC1S1 Standard performance, single polarized, CPR137G input 8 (2.4) 40.7 41.5 42.3 PA10-W57AC1S Standard performance, single polarized, CPR137G input 10 (3.0) 42.6 43.5 44.2 PAD6-W57BC1S Standard performance, single polarized, CPR137G input 6 (1.8) 38.1 38.9 39.7 PAD8-W57AC1S Standard performance, single polarized, CPR137G input 8 (2.4) 40.6 41.4 42.2 PAD10-W57AC1S Standard performance, single polarized, CPR137G input 10 (3.0) 42.6 43.5 44.2 PADX6-W57AC1S Standard performance, dual polarized, CPR137G input 6 (1.8) 37.9 38.7 39.5 PADX8-W57AC1S Standard performance, dual polarized, CPR137G input 8 (2.4) 40.4 41.2 42.0 PADX10-W57AC1S Standard performance, dual polarized, CPR137G input 10 (3.0) 42.3 43.2 43.9 DA4-W57BC1S1 High Performance, Single Polarized, CPR137G input 4 (1.2) 34.7 35.5 36.3 DA6-W57BC1S1 High Performance, Single Polarized, CPR137G input 6 (1.8) 38.2 39.0 39.8 DA8-W57AC1S1 High Performance, Single Polarized, CPR137G input 8 (2.4) 40.7 41.5 42.3 ** Calculated Value for use at 5.8GHz Page 2 of 2

Cover Letter(s)

Request for Confidentiality Date: 27 November 2012 Subject: Confidentiality Request for: VK6-IRU600V3 and 4469A-IRU600V3 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual Aviat Networks has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, RUTH FRENCH, PRODUCT COMPLIANCE MANAGER

External Photos

26th November, 2012 IRU600v3 External Photographs FCC: VK6-IRU600V3 Industry Canada: 4469A-IRU600V3 IRU600V3 Front 26th November, 2012 IRU600V3 Back 26th November, 2012 IRU600V3 Side 1 26th November, 2012 IRU600V3 Side 2 26th November, 2012 IRU600V3 Top

ID Label/Location Info

29 November, 2012 Certification and Engineering Bureau Industry Canada P.O. Box 11490, Station H 3701 Carling Avenue (Building 94) Ottawa, Ontario K2H 8S2 Subject: Transmit Frequency Range: 4469A-IRU600V3 To Whom It May Concern, The product label for 4469A-IRU600V3 states a frequency range of 5725 – 6450MHz. These ranges represent the full range of the RF components within this radio. The radio can either be configured for use with 5.8GHz spot tuned filters or L6GHz spot tuned frequencies. All of the 5.8GHz filters are within the RSS-210 range of 5725MHz – 5850MHz and ensure compliance with the band edge. All of the L6GHz filters are within the licenced band. Software controls are also in place to ensure that this product can only transmit within the licenced L6GHz band or within the authorised range of the licence-exempt 5.8GHz band. Therefore, it would not be accurate to label these radios only with the range stated on our application. Sincerely, Ruth French Product Compliance Manager

ID Label/Location Info

IC: 4469A-IRU600V3FCC ID: VK6-IRU600V3 01-NOV-12 001 ECO 38564 Dimensions are in Millimeters. Unless otherwise stated tolerances are X 0.5 X.X 0.25 X.XX 0.1 Angle 1 Drawing Number: 007-600257-003 R001 Sheet 1 of 1 File Name: LABEL IRUv3 5.8G FCC ID AND IC 001 Modeled Drawing Title / File Name: The information contained in this drawing is the sole property of Aviat Networks. Any reproduction in part or in whole without the written permission of Aviat Networks is prohibited Aviat Networks 01-NOV-12 John Justice LABEL IRUv3 5.8G FCC ID AND IC Description Rev Date Aviat Networks part number: 007-600257-003 R001Notes: Material: Type: Gloss white UL recoginized Polyester. 1. Thickness: 0.05 Adhesive: 0.02 thick permanent acrylic Manufacturer: Fasson, Flexcon or equivalent. 2. Solvent Resistance: (Printed label) Per MIL STD 202F, Notice 12, Method 215J 0.05 matt finished transparent polyester film. 3. Resin based thermal transfer, black on white background. 4. Font: Ariel 9 Bold5. Materials used must be RoHS 6 co mpliant. Refer to Aviat Networks QA_D_004. 25.0 6.0 5200 Great America Parkway, Santa Clara CA 9 5 05 4 Te l: 40 8 56 7 70 00 Motnica 9, 1236 Trzin, Slovenia Tel + 386 1 5887 001 20 Peterkin Street, Lower Hutt, New Zealand Tel: + 64 4 577 8800

ID Label/Location Info

Label artwork for 4469A-IRU600V3

ID Label/Location Info

Label location

Internal Photos

5 th December, 2012 IRU600v3 Internal Photographs FCC: VK6-IRU600V3 Industry Canada: 4469A-IRU600V3 IRU600v3 Unit 5 th December, 2012 IRU600v3 Unit Front View 5 th December, 2012 IRU600v3 Unit Front (close up) 5 th December, 2012 Radio Frequency Unit 5 th December, 2012 Radio Frequency Unit (lid removed) 5 th December, 2012 Radio Frequency Module (RFM PCB, shield removed) 5 th December, 2012 Radio Frequency Module (RFM PCB, side 1) 5 th December, 2012 Radio Frequency Module (RFM PCB, side 2) 5 th December, 2012 Fan Interface Card (populated one side only)

RF Exposure Info

Aviat Networks FCC OET 65 & RSS-102 Calculation Page 1 of 3 Page 1 of 3 FCC OET 65 and IC RSS 102 MPE Value Calculations The purpose of this report is to document the Maximum Permissible Exposure (MPE) value for the IRU 600v3 product. Manufacturer: Aviat Networks Equipment Category: Microwave Fixed Link Equipment Name: IRU 600 FCC ID: VK6-IRU600V3 IC ID: 4469A-IRU600V3 Report Date: 23-NOV-2012 Aviat Networks FCC OET 65 & RSS-102 Calculation Page 2 of 3 Page 2 of 3 1. Introduction FCC OET Bulletin 65 defines guidelines and limits for Maximum Permissible Exposure (MPE) in terms of electric and magnetic field strength and power density for transmitters operating at frequencies between 300 kHz and 100 GHz. Industry Canada RSS 102 defines the RF exposure compliance requirements for radio communications apparatus in all frequency bands. This report documents the MPE value (distance) for the IRU 600V3. This product has a FCC ID: VK6-IRU600V3 This product has an IC ID: 4469A-IRU600V3 2. References [1] FCC OET Bulletin 65 edition 97-01 [2] IC RSS 102 issue 4 3. Formula and limit. From OET 65 [1] the formula for calculating the maximum permissible exposure is: S = PG/4πR 2 (1) MPE limit for uncontrolled exposure at prediction frequency = 1 mW/cm 2 Re-arranging the above formula to calculate R: R = √(PG/4πS) (2) It should be noted the RSS-102 [2] clause 3.1.1, SAR measurement 3GHz – 6GHz, points the reader towards the FCC published procedures for ensuring compliance and thus this report serves both sets of requirements. Aviat Networks FCC OET 65 & RSS-102 Calculation Page 3 of 3 Page 3 of 3 4. Input values P = power input to antenna = 30dBm or 1000mW G = Antenna gain = 45.9dBi or 38904 numeric S = MPE limit for uncontrolled exposure = 1mW/cm 2 R = Distance to the centre of the antenna (cm) 5. Calculating distance to antenna Using formula (2) from above: R = √((1000x38904)/4π)) R = 1760 cm It should be noted that this distance contains zero margin so the distance cannot be any shorter than this. In order to guarantee some margin a distance of 1800cm is proposed and using formula (1) from above, this gives an exposure level of: S = 1000x38904/4π1800 2 S = 0.956 mW/cm 2 i.e. a compliance margin of 0.0434 mW/cm 2 6. Conclusion The recommended minimum distance from the centre of the antenna to ensure exposure below the limit specified in both OET Bulletin 65 [1] and RSS 102 [2] is 1800cm.

Test Report

RFI Global Services Ltd trading as UL Pavilion A, Ashwood Park, Ashwood Way, Basingstoke, Hampshire, RG23 8BG, UK Telephone: +44 (0)1256 312000 Facsimile: +44 (0)1256 312001 TEST REPORT Test Report No. : UL-RPT-RP81852JD07A Manufacturer : Aviat Networks Model No. : Eclipse IRU600V3, 5.8GHz, ERM-U53-301 FCC ID : VK6-IRU600v3 IC Certification No. : 4469A-IRU600v3 Test Standard(s) : FCC Parts 15.207, 15.209(a), 15.247 (a)(2), (b)(3), (d) & (e), RSS- 210 A8.2(a), (b), A8.4(4), A8.5 & RSS-Gen 4.6.1, 4.6.2, 4.8, 4.9 & 7.2.4 1. This test report shall not be reproduced in full or partial, without the written approval of RFI Global Services Ltd trading as UL. 2. The results in this report apply only to the sample(s) tested. 3. This sample tested is in compliance with the above standard(s). 4. The test results in this report are traceable to the national or international standards. 5. Version 1.0 Date of Issue: 29 November 2012 Checked by: Steven White WiSE Project Lead Issued by : pp John Newell Group Quality Manager, WiSE Basingstoke, UL Verification Services This laboratory is accredited by UKAS. The tests reported herein have been performed in accordance with its’ terms of accreditation. TEST REPORT SERIAL NO: UL-RPT-RP81852JD07AV1.0 VERSION 1.0 ISSUE DATE: 29 NOVEMBER 2012 Page 2 of 60 RFI Global Services Ltd trading as UL This page has been left intentionally blank. TEST REPORT SERIAL NO: UL-RPT-RP81852JD07AV1.0 VERSION 1.0 ISSUE DATE: 29 NOVEMBER 2012 RFI Global Services Ltd trading as UL Page 3 of 60 Table of Contents 1. Customer Information .................................................................................................................. 4 2. Summary of Testing ..................................................................................................................... 5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 6 2.4. Deviations from the Test Specification 6 3. Equipment Under Test (EUT) ....................................................................................................... 7 3.1. Identification of Equipment Under Test (EUT) 7 3.2. Description of EUT 7 3.3. Modifications Incorporated in the EUT 7 3.4. Additional Information Related to Testing 8 3.5. Support Equipment 10 4. Operation and Monitoring of the EUT during Testing ............................................................. 11 4.1. Operating Modes 11 4.2. Configuration and Peripherals 11 5. Measurements, Examinations and Derived Results ................................................................ 12 5.1. General Comments 12 5.2. Test Results 13 5.2.1. Transmitter AC Conducted Spurious Emissions 13 5.2.2. Transmitter 6 dB Bandwidth 16 5.2.3. Transmitter Occupied Bandwidth 22 5.2.4. Transmitter Power Spectral Density 28 5.2.5. Transmitter Maximum Average Output Power 34 5.2.6. Transmitter Radiated Emissions - 4 foot parabolic antenna 40 5.2.7. Transmitter Radiated Emissions - 2 foot flat panel antenna 47 5.2.8. Transmitter Band Edge Conducted Emissions 54 6. Measurement Uncertainty .......................................................................................................... 59 7. Report Revision History ............................................................................................................. 60 TEST REPORT SERIAL NO: UL-RPT-RP81852JD07AV1.0 VERSION 1.0 ISSUE DATE: 29 NOVEMBER 2012 Page 4 of 60 RFI Global Services Ltd trading as UL 1. Customer Information Company Name: Aviat Networks Address: 4 Bell Drive, Hamilton International Technology Park Blantyre Glasgow Lanarkshire G72 0FB United Kingdom TEST REPORT SERIAL NO: UL-RPT-RP81852JD07AV1.0 VERSION 1.0 ISSUE DATE: 29 NOVEMBER 2012 RFI Global Services Ltd trading as UL Page 5 of 60 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.247 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2012: Part 15 Subpart C (Intentional Radiators) - Section 15.247 Specification Reference: 47CFR15.207 and 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2012: Part 15 Subpart C (Intentional Radiators) - Sections 15.207 and 15.209 Specification Reference: RSS-Gen Issue 3 December 2010 Specification Title: General Requirements and Information for the Certification of Radio Apparatus Specification Reference: RSS-210 Issue 8 December 2010 Specification Title: Licence-exempt Radio Apparatus (All Frequency Bands): Category I Equipment. Site Registration: FCC: 209735; Industry Canada: 3245B-2 Location of Testing: RFI Global Services Ltd trading as UL, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 31 October 2012 to 19 November 2012 2.2. Summary of Test Results FCC Reference (47CFR) IC Reference Measurement Result Part 15.207 RSS-Gen 7.2.4 Transmitter AC Conducted Emissions Part 15.247(a)(2) RSS-Gen 4.6.2 RSS-210 A8.2(a) Transmitter 6 dB Bandwidth N/A RSS-Gen 4.6.1 Transmitter Occupied Bandwidth Part 15.247(e) RSS-210 A8.2(b) Transmitter Power Spectral Density Part 15.247(b)(3) RSS-Gen 4.8 RSS-210 A8.4(4) Transmitter Maximum Average Output Power Part 15.247(d)/ 15.209(a) RSS-Gen 4.9 RSS-210 A8.5 Transmitter Radiated Emissions Part 15.247(d) RSS-Gen 4.9 RSS-210 A8.5 Transmitter Band Edge Conducted Emissions Key to Results = Complied = Did not comply Notes: 1. The customer declared that there is no idle mode and that the EUT goes into transceive mode as soon as it is powered up. TEST REPORT SERIAL NO: UL-RPT-RP81852JD07AV1.0 VERSION 1.0 ISSUE DATE: 29 NOVEMBER 2012 Page 6 of 60 RFI Global Services Ltd trading as UL 2.3. Methods and Procedures Reference: ANSI C63.4 (2009) Title: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Reference: ANSI C63.10 (2009) Title: American National Standard for Testing Unlicensed Wireless Devices Reference: KDB 558074 D01 v02 10/04/20…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ruth French(Product Compliance Manager)

[email protected]011447771978599Fax: 011441698717204

Technical Contact

AVIAT Networks (UK) Ltd.Ruth French

[email protected]

United Kingdom

Test Firm

UL VS LtdDarren Rust

[email protected]+44 1256 31 2119Fax: +44 1256 31 2001

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	5.73 GHz - 5.85 GHz	891.00 mW

Confidentiality

Long Term

Grant Notes

Power Output listed is conducted average. The antenna used for this transmitter must be installed to provide a separation distance of at least 1800 cm from all persons and must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. For professional installation. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 5 MHz, 10 MHz, 20 MHz and 30 MHz bandwidth modes.
