VKF-STORKCStork

User's Manual Stork Camera Smart Home Baby Monitoring Masimo Corporation 1 www.masimo.com There may be information provided in this manual that is not relevant for your system. Do not operate Stork without completely reading and understanding these instructions. If you encounter any serious incident with product, please notify the competent authority in your country and the manufacturer. Wireless Radio: Masimo Stork Camera: - FCC ID:VKF-STORKC - IC: 7362A-STORKC Manufacturer: Masimo Corporation 52 Discovery Irvine, CA 92618, USA www.masimostork.com Patents: www.masimo.com/patents.htm Masimo® and ® are federally registered trademarks of Masimo Corporation. Stork™ is a trademark of Masimo Corporation. Google Play and the Google Play logo are trademarks of Google LLC. App Store and App Store logo are registered trademarks of Apple Inc. The Bluetooth word mark and logo are registered trademarks owned by Bluetooth SIG, Inc. All other trademarks and registered trademarks are property of their respective owners. © 2023 Masimo Corporation Masimo Corporation 3 www.masimo.com Contents About This Manual .......................................................................................... 4 Getting Started Guides ................................................................................... 4 In-App Videos ............................................................................................... 4 Product Description ........................................................................................ 5 Meet the Stork System ..................................................................................... 6 Stork System ................................................................................................ 6 Components of Stork ...................................................................................... 7 Basic Setup and Use of Stork ............................................................................. 8 Getting Started ............................................................................................. 8 Step 1: Smart Phone Setup ............................................................................... 8 Step 2: Setting up the Stork System .................................................................... 9 Step 3: View Live Data ................................................................................... 14 Advanced Use .............................................................................................. 15 Notifications ............................................................................................... 15 Live Controls ............................................................................................... 16 Side Menu .................................................................................................. 17 Bottom Menu .............................................................................................. 19 How to Turn Stork On and Off .......................................................................... 21 Troubleshooting ........................................................................................... 21 Appendix .................................................................................................... 22 Risks and Benefits ........................................................................................ 22 Safety Information ........................................................................................ 23 Specifications .............................................................................................. 28 Service and Maintenance ................................................................................ 32 Masimo Corporation 4 www.masimo.com Stork Camera About This Manual About This Manual Not intended for use as a medical device or to replace a medical device. Do not use it to diagnose, cure, treat, alleviate, or prevent any disease or health condition. This Manual provides an overview of the Stork System and how to set up and use the Stork System. You must read and understand the warnings and precautions to help ensure safe and effective use of the Stork System. See Safety Information on page 23. Please make sure to read the entire manual and notes. A warning is given when there is reasonable evidence of an association of a serious hazard with use of this device that may result in a serious injury, adverse effect, or death to the user. WARNING: This is an example of a warning statement. A caution is given when special care is to be exercised by the user to avoid injury to the user, damage to this device, or damage to other property. CAUTION: This is an example of a caution statement. A note is given when additional information applies. Note: This is an example of a note. Getting Started Guides Use the quick reference guide included for the following:  Basic Setup and starting your first monitoring session. In-App Videos Watch the videos in your app to find out more about:  Setting up your Stork System.  Connecting your Stork Camera to Bluetooth and Wi-Fi. Masimo Corporation 5 www.masimo.com Product Description Masimo Masimo Stork™ Camera is designed for parents to monitor a healthy baby at home. The camera, cloud, and app combine to allow parents to stay connected with their baby via video and 2-way audio on the app. The camera consists of the following:  Stork App: A smart phone application that provides high-resolution video, room conditions, baby health, and audio controls.  Stork Camera: Capable of providing 2K QHD video resolution so that you can see baby in the app regardless of time of day or room lighting. Additionally, the Stork Camera provides 2-way audio, room condition monitoring, and serves as a path to the cloud so that you can get the data on your phone no matter where you are.  Masimo Cloud: A server accessed over the internet that gathers and stores the health data, video and audio communicate…

Text truncated - open the document above for the full version.

2.9 11 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Masimo Corporation Address: Masimo Corporation 52 Discovery Irvine, CA 92618 USA Product Name: Stork FCC ID: VKF-STORKC Model(s): Stork Camera 2.911(d)(5)(i) Equipment Type We, [Masimo Corporation] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Anamidevi Joshi Date: 18-07-2023 Title and Company name: EMC Project Manager Masimo Corporation NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Masimo Corporation Address: Masimo Corporation 52 Discovery Irvine, CA 92618 USA Product Name: Stork FCC ID: VKF-STORKC Model(s): Stork Camera 2.911(d)(5)(ii) Applicant filing We, [Masimo Corporation] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Anamidevi Joshi Date: 18-07-2023 Title and Company name: EMC Project Manager Masimo Corporation NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

2.911 (d)(7)USA Agent v1.4 Section 2.911(d)(7) USA Agent for Service of Process Company name: Masimo Corporation Address Masimo Corporation 52 Discovery Irvine, CA 92618 USA Product Name: Stork FCC ID: VKF-STORKC Model(s): Stork Camera 2.911(d)(7) USA Designated Agent for Service of Process We, [Masimo Corporation] (“the applicant”) designate [Masimo Corporation] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Masimo Corporation USA Address: 52 Discovery Irvine, CA 92618 USA FRN Number: 0016800161 Contact Name: Anamidevi Joshi Telephone No: 949-297-7663 Email: [email protected] Applicant Company name: Masimo Corporation Address: Plot no. 52 Discovery Irvine, CA 92618 USA FCC Grantee Code: VKF Contact Name: Anamidevi Joshi Telephone No: 949-297-7663 Email: [email protected] 2.911 (d)(7)USA Agent v1.4 Signature: Title: Anamidevi Joshi Signature: Title: Anamidevi Joshi Date: July 15 ,2023 Date: July 15 ,2023 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Agent Authorization Company: Masimo Corporation Address: Masimo Corporation 52 Discovery Irvine, CA 92618 USA Product Name: Stork Model Number(s): Stork Camera Product Description: The Stork Baby Monitoring Camera is a high end camera with Wi-Fi and BT connectivity. For precise measurement of the ambient temperature and humidity, it has built-in temperature and humidity sensors. It has a built-in MIC and speaker and a two-way talk feature. Using ALS and IR LEDs, it also supports night vision. It also has analytics-related AI/ML capabilities. We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 14-07-2023 Name: Anamidevi Joshi Title: EMC Project Manager Company: Masimo Corporation

C5266091_X10_Ed.2 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: May 15, 2023 Subject: Request for Confidentiality FCC ID: VKF-STORKC To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐NOTE 1 ☒ Parts List / Tune Up ☒ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☒ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Anamidevi Joshi Title: EMC Project Manager 1/1

External Photos

Label and its Location

RF EXPOSURE EVALUATION 1. PRODUCTINFORMATION Product Description Stork Model Name Stork Camera FCC ID VKF-STORKC 2. EVALUATION METHODANDLIMIT Human exposure to RF emissions from mobile devices(47CFR§2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. The device under test stork is neither a mobile device nor a RF exposure product and it is not closed to 20cm distance from persons LIMITS FOR GENERAL POPULATIONIUNCONTROLLED EXPOSURE Frequency Range (MHz) E-field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density(S) (mW/cm 2 ) Averaging Time IEl 2 IHl 2 or , S(Minutes) 0.3--1.34 614 1.63 (100)* 30 1.34--30 824/f 2.19/f (180/f 2 )* 30 30--300 27.5 0.073 0.2 30 300--1500 -- -- f/1500 30 1500--100,000 -- -- 1.0 30 *Note: 1. f= Frequency in MHz*Plane-wave Equivalent Power Density 2. The averaging time for General Population/Uncontrolled exposure to fixed transmitters is not applicable for mobile and portable transmitters. (operated in BT/ WIFI) See47CFR§§2.1091 and 2.1093 on source-based time-averaging requirement for mobile and portable transmitters. S=PG/4rrR 2 Where: S=power density P=power input toantenna G=power gain of the antenna in the direction of interest relative to anisotropic radiator R=distance to the center of radiation of the antenna 3. CALCULATION A minimum test separation distance 20cm is required between the antenna and radiating structures of the device and nearby persons to apply mobile device exposure limits. The distance must be at least 20cm and fully supported by the operating and installation configurations of the transmitter and its antenna(s), according to the source-based time-averaged maximum power requirements of §2.1091(d)(2). In cases where cable losses or other attenuations are applied to determine compliance, the most conservative operating configurations and exposure conditions must be evaluated. The device under test (IO Wi-Fi 6 Dual Band 2x2:2 Indoor Access Point with Integrated Antenna (5 dBi)) is neither a mobile device nor a RF exposure product and it is not closed to 20cm distance from persons Antenna Gain (2.4GHz Wi-Fi/BT/BLE) = 2.05dBi (Numeric = 1.603), rr = 3.14 Antenna Gain (5GHz) = 5.91dBi (Numeric = 3.899), rr = 3.14 Frequency (MHz) Output Power (dBm) Output Power (mW) Power Density (mW/cm 2) PowerDensity Limit (mW/cm 2) 2441 (BT) 4.28 2.6791683248 0.00085 1 2440 (BLE) 3.88 2.4434305527 0.00077 1 2437 (2.4GHz) 22.33 171.001531509 0.05456 1 5200 (Band 1) 18.89 77.4461797803 0.06010 1 5825 (Band 4) 18.60 72.4435960075 0.05622 1 Note: Only the worst case recorded.

Report No.: AAEMT/RF/230322-03-06 Page | 1 Plot No.174, UdyogVihar Phase 4, Sector -18, Gurgaon -122016, Haryana, India Contact: 0124-4235350, 4145343; e-mail: info @aaemtlabs.com; Website: www.aaemtlabs.com Decision Rule: The result of conformity based on the mentioned standards actual test limits / levels AAEMT/A2LA/TRF/FCC-15C/22_01_REV1 AA Electro Magnetic Test Laboratory Private Limited Certificate#5593.01 FCC Test Report Part 15 Subpart C FCC ID：VKF-STORKC Client Information: Applicant: Masimo Corporation Applicant add.: Masimo Corporation 52 Discovery Irvine, CA 92618 USA Product Information: EUT Name: Stork Model No.: Stork Camera Brand Name: Serial Model: N/A Standards: FCC PART 15 Subpart C: 2015 section 15.247 AA Electro Magnetic Test Laboratory Private Limited Add. : Plot No 174, Udyog Vihar - Phase 4, Sector 18, Gurgaon, Haryana, India Date of Receipt: Mar 22, 2023 Date of Test: Mar. 22 ~ June. 02, 2023 Date of Issue: July. 04, 2023 Test Result: Pass Declaration of Conformity: This device described above has been tested by AA Electro Magnetic Test Laboratory Private Limited, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. *This test report must not be used by the client to claim product endorsement by any agency of the U.S. government. Prepared By (+ signature) Ankur Kumar: Reviewed & Approved by: (+ signature) Dr. Lenin Raja (Authorized Representative) (/ lenin83/) Declaration of conformity of the results is based as per the standard limits Report No.: AAEMT/RF/230322-03-06 Page | 2 Plot No.174, UdyogVihar Phase 4, Sector -18, Gurgaon -122016, Haryana, India Contact: 0124-4235350, 4145343; e-mail: info @aaemtlabs.com; Website: www.aaemtlabs.com Decision Rule: The result of conformity based on the mentioned standards actual test limits / levels AAEMT/A2LA/TRF/FCC-15C/22_01_REV1 AA Electro Magnetic Test Laboratory Private Limited Certificate#5593.01 1 Contents Page COVER PAGE 1 CONTENTS 2 2 VERSION 3 3 TEST SUMMARY 4 3.1 COMPLIANCE WITH FCC PART 15 SUBPART C 4 3.2 MEASUREMENT UNCERTAINTY 5 3.3 TEST LOCATION 5 4 TEST FACILITY 6 4.1 DEVIATION FROM STANDARD 6 4.2 ABNORMALITIES FROM STANDARD CONDITIONS 6 5 GENERAL INFORMATION 7 5.1 GENERAL DESCRIPTION OF EUT 7 5.2 EUT PERIPHERAL LIST 9 5.3 TEST PERIPHERAL LIST 9 6 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 7 TEST RESULT 12 7.1 DESCRIPTION OF TEST CONDITIONS 12 7.2 ANTENNA REQUIREMENT 13 7.3 CONDUCTION EMISSIONS MEASUREMENT 14 7.4 RADIATED EMISSIONS MEASUREMENT 18 7.5 6 DB BANDWIDTH 41 7.6 MAXIMUM PEAK OUTPUT POWER 48 7.7 PEAK POWER SPECTRAL DENSITY 51 7.8 BAND EDGES REQUIREMENT 59 7.9 CONDUCTED SPURIOUS EMISSIONS 64 Report No.: AAEMT/RF/230322-03-06 Page | 3 Plot No.174, UdyogVihar Phase 4, Sector -18, Gurgaon -122016, Haryana, India Contact: 0124-4235350, 4145343; e-mail: info @aaemtlabs.com; Website: www.aaemtlabs.com Decision Rule: The result of conformity based on the mentioned standards actual test limits / levels AAEMT/A2LA/TRF/FCC-15C/22_01_REV1 AA Electro Magnetic Test Laboratory Private Limited Certificate#5593.01 2 Version Revision Record Version Chapter Date Modifier Remark -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- Report No.: AAEMT/RF/230322-03-06 Page | 4 Plot No.174, UdyogVihar Phase 4, Sector -18, Gurgaon -122016, Haryana, India Contact: 0124-4235350, 4145343; e-mail: info @aaemtlabs.com; Website: www.aaemtlabs.com Decision Rule: The result of conformity based on the mentioned standards actual test limits / levels AAEMT/A2LA/TRF/FCC-15C/22_01_REV1 AA Electro Magnetic Test Laboratory Private Limited Certificate#5593.01 3 Test Summary 3.1 Compliance with FCC Part 15 subpart C TEST TEST REQUIREMENT TEST METHOD RESULT Antenna Requirement FCC PART 15 C section 15.247 (c) and Section 15.203 FCC PART 15 C section 15.247 (c) and Section 15.203 PASS Conducted Emissions at Mains Terminals FCC PART 15 C section 15.207 ANSI C63.10: Clause 6.2 PASS Radiated Spurious Emission (30 MHz to 25 GHz) FCC PART 15 C section 15.209 &15.247(d) ANSI C63.10: Clause 6.4, 6.5 and 6.6 PASS 6 dB Bandwidth FCC PART 15 C section 15.247 (a)(2) ANSI C63.10: Clause 6.9.1 PASS Maximum Peak Output Power FCC PART 15 C section 15.247(b)(3) FCC/KDB-558074 D01 v03r01 Clause 9.1.2 PASS Peak Power Spectral Density FCC PART 15 C section 15.247(e) ANSI C63.10: Clause 6.11.2.3 PASS Band Edges Measurement FCC PART 15 C section 15.247 (d) &15.205 FCC/KDB-558074 D01 v03r01 Clause 13.3.1 PASS Conducted Spurious Emission (30MHz to 25GHz) FCC PART 15 C section 15.209 &15.247(d) ANSI C63.10: Clause 6.7 PASS Remark: N/A: not applicable. Refer to the relative section for the details. EUT: In this whole report EUT means Equipment Under Test. Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radio Frequency. ANSI C63.10: the detail version is ANSI C63.10:2013 in the whole report. Report No.: AAEMT/RF/230322-03-06 Page | 5 Plot No.174, UdyogVihar Phase 4, Sector -18, Gurgaon -122016, Haryana, India Contact: 0124-4235350, 4145343; e-mail: info @aaemtlabs.com; Website: www.aaemtlabs.com Decision Rule: The result of conformity based on the mentioned standards actual test limits / levels AAEMT/A2LA/TRF/FCC-15C/22_01_REV1 AA Electro Magnetic Test Laboratory Private Limited Certificate#5593.01 3.2 Measurement Uncertainty All measurements involve certain levels of uncertainties, the following measurements uncertainty Levels have estimated based on standards, the maximum value of the uncertainty as below: No. Item Uncertainty 1 Conducted Emission Test 2.67dB 2 Radiated Emission Test 3.06dB 3.3 Test Location All tests were performed at: AA Electro Magnetic Test Laboratory Private Limited Plot No 174, Udyog Vihar - Phase 4, Sector 18, Gurgaon, Haryana, India Tel.: +91-0124-4235350 Report No.: AAEMT/RF/230322-03-06 Page | 6 Plot No.174, UdyogVihar Phas…

Text truncated - open the document above for the full version.

Report No.: AAEMT/RF/230322-03-07 1 | P a g e Plot No.174, UdyogVihar Phase 4, Sector -18, Gurgaon -122016, Haryana, India Contact: 0124-4235350, 4145343; e-mail: info @aaemtlabs.com; Website: www.aaemtlabs.com Decision Rule: The result of conformity based on the mentioned standards actual test limits / levels AAEMT/A2LA/TRF/FCC-15C/22_01_REV1 AA Electro Magnetic Test Laboratory Private Limited Certificate#5593.01 FCC Test Report Part 15 subpart C FCC ID：VKF-STORKC Client Information: Applicant: Masimo Corporation Applicant add.: Masimo Corporation 52 Discovery Irvine, CA 92618 USA Product Information: EUT Name: Stork Model No.: Stork Camera Brand Name: Standards: FCC PART 15 Subpart C: 2013 section 15.247 Serial Model: N/A AA Electro Magnetic Test Laboratory Private Limited Add. : Plot No 174, Udyog Vihar - Phase 4, Sector 18, Gurgaon, Haryana, India Date of Receipt: Mar 22, 2023 Date of Test: Mar. 22 ~ June. 02, 2023 Date of Issue: July. 04, 2023 Test Result: Pass This device described above has been tested by AA Electro Magnetic Test Laboratory Private Limited, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. *This test report must not be used by the client to claim product endorsement by any agency of the U.S. government. Prepared By (+ signature) Ankur Kumar: Reviewed & Approved by: (+ signature) Dr. Lenin Raja (Authorized Representative)(/ lenin83/) Report No.: AAEMT/RF/230322-03-07 2 | P a g e Plot No.174, UdyogVihar Phase 4, Sector -18, Gurgaon -122016, Haryana, India Contact: 0124-4235350, 4145343; e-mail: info @aaemtlabs.com; Website: www.aaemtlabs.com Decision Rule: The result of conformity based on the mentioned standards actual test limits / levels AAEMT/A2LA/TRF/FCC-15C/22_01_REV1 AA Electro Magnetic Test Laboratory Private Limited Certificate#5593.01 1 Contents Page COVER PAGE 1 CONTENTS ..................................................................................................................................................................... 2 2 TEST SUMMARY ........................................................................................................................................................... 4 2.1 COMPLIANCE WITH FCC PART 15 SUBPART C ..................................................................................................................... 4 2.2 TEST LOCATION ................................................................................................................................................................ 5 2.3 MEASUREMENT UNCERTAINTY .......................................................................................................................................... 5 3 TEST FACILITY ............................................................................................................................................................. 6 3.1 DEVIATION FROM STANDARD ............................................................................................................................................. 6 3.2 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................................. 6 4 GENERAL INFORMATION .......................................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF EUT ........................................................................................................................................ 7 4.2 DESCRIPTION OF TEST CONDITIONS .................................................................................................................................... 9 4.3 TEST PERIPHERAL LIST .................................................................................................................................................... 10 4.4 EUT PERIPHERAL LIST .................................................................................................................................................... 10 5 EQUIPMENTS LIST FOR ALL TEST ITEMS ........................................................................................................... 11 6 TEST RESULT .............................................................................................................................................................. 13 6.1 ANTENNA REQUIREMENT ....................................................................................................................................... 13 6.1.1 Standard requirement ....................................................................................................................................... 13 6.1.2 EUT Antenna ................................................................................................................................................... 13 6.2 CONDUCTION EMISSIONS MEASUREMENT .................................................................................................................. 14 6.2.1 Applied procedures / Limit ...................................................................................................................................... 14 6.2.2 Test procedure ......................................................................................................................................................... 14 6.2.3Test results ............................................................................................................................................................... 15 6.3 RADIATED EMISSIONS MEASUREMENT....................................................................................................................... 17 6.3.1 Applied procedures / Limit ..........................................................................................................................…

Text truncated - open the document above for the full version.

Approval sheet Page 1 of 15 RFFPA451016IMLB301_V01 Dec.2022 FPC ANTENNA 2.4/5.x GHz Working Frequency Halogens Free Product P/N: RFFPA451016IMLB301 Customer： Customer ‘s Part No.： Approval No.： Issue Date： *Contents in this sheet are subject to change without prior notice. Approval sheet Page 2 of 15 RFFPA451016IMLB301_V01 Dec.2022 Version Date Description Author V01 2022 Dec. New Release SHLEE Approval sheet Page 3 of 15 RFFPA451016IMLB301_V01 Dec.2022 ELECTRICAL CHARACTERISTICS Item Specification Working Frequency Range 2.4 ~ 2.5 / 5.15 ~ 5.85 GHz(Note-1) Return Loss -10 dB(Max) Gain(peak) 2.05 [email protected]~2.5 GHz 5.91 [email protected]~5.85 GHz VSWR < 2.0 Impedance 50 Ohm Nominal Radiation Omni-directional Polarization Linear Vertical Operation Temperature －20°C ～ ＋65°C *Note 1. Central Frequency should be defined after customers’ application approval. MATERIAL TABLE Items Description Antenna FPC 0.5oz Double Tape 3M467 Cable Ø1.13 Cable (Black) Connector IPEX Compatible (Gold) ORDERING RULE RF FPA 4510 16 I M L B 3 01 Type Code Product Code PCB Dimension (Unit: mm) Cable Length (unit: cm) Connector Brand Type of Connector Application Project status Wire Diameter Project Walsin RF Device…

Text truncated - open the document above for the full version.
