VLJ-CF85BU5inch Wi-Fi Video Baby Monitor

The features described in this User’s Guide are subject to modifications without prior notice. User’s Guide 5" Wi-Fi ® Video Family Monitor Models: CONNECT40, CONNECT40-2, CONNECT40-3, CONNECT40-4 Welcome... This User's Guide provides you with all the information you need to get the most from your product. Before you can use the Family monitor, we recommend you insert and fully charge the battery in the Parent Unit, so that it continues to work if you disconnect it from the power supply to carry it to another location. Please read the Safety Instructions on pages 7 - 9 before you install the units. Got everything? • 1 x Parent Unit (with built-in Li-ion battery) • 1 x Baby Unit (Camera) • 2 x Power adapters (Parent Unit and Baby Unit) In multi-camera packs, you will find one or more additional baby units with power adapter units. to your new Motorola Video Family Monitor ! Thank you for purchasing the Video Family Monitor. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their playroom. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product related questions, please call: US and Canada 1-888-331-3383 Email: [email protected] On the Web: www.motorolastore.com/support Press to increase speaker volume in camera viewing mode. When in a menu, press to scroll up. While being in remote scan mode, press to tilt up. Overview of the Parent Unit 1.Display (LCD screen) 2.Battery status, Power, Sound level, Pairing indicators a) Lights up in blue when the Parent Unit’s battery is being charged. b) Lights up in green when the Parent Unit is switched on. c) Green-Orange-Red-Red Show the sound level detected by the Baby Unit - the louder the sound detected, the more LEDs light up. Flashes rapidly in green when the Parent Unit is searching for the Baby Unit, or is in pairing mode. 3.Main menu button M Press to enter/exit menu mode. 4.OK/ button When in a menu, press to choose an item, or save a setting. Press to enter remote scan mode. 5.Control key panel UP / VOLUME+ + Press to increase speaker volume in camera viewing mode. When in a menu, press to scroll up. When in remote scan mode, press to tilt up. DOWN / V OLUME - - Press to decrease speaker volume in camera viewing mode. When in a menu, press to scroll down. When in remote scan mode, press to tilt down. LEFT < Decrease brightness in camera viewing mode. When in a menu, press to scroll left. When in remote scan mode, press to pan left. RIGHT > Increase brightness in camera viewing mode. When in a menu, press to scroll right. When in remote scan mode, press to pan right. 6.TALK BACK T Hold down to talk back to the baby unit. 7.Power button 0 Press and hold to switch the unit On/ Off. Press to turn the video screen Off/ On. 8.Power socket 1 2c 2b 2a 3 4 5 6 7 11 12 8 9 10 9.Reset button 10. Support Stand 11. Speaker 12. Antenna Parent Unit display icons Signal Strength Camera Power Mode - AC or Battery Camera Patrol Mode Camera Identification Number Speaker on / off Lullab ies menu / mode Zoom menu / mode Night vision Alarm timer Parent unit battery status Brightness Level Speaker volume Video on timer Add camera Delete camera View camera Talk back function S  . Overview of Your Baby Unit (Camera) Important guidelines for installing your Family Monitor •To use your Video Monitor Baby and the Parent Unit together, you must be able to establish a radio link between them, and the range may be affected by environmental conditions. •Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or reinforced concrete between the Baby and Parent Units may block the radio signal. •The signal strength may also be reduced by other solid structures, like walls or electrical equipment, such as radios, TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. •Use of other 2.4 GHz products, such as wireless networks (Wi-Fi ® routers), Bluetooth ® systems, or microwave ovens, may cause interference with this product, so keep the Family Monitor at least 5 feet from these types of products, or turn them off if they appear to be causing interference. •If the signal is weak, try moving the Parent and/or the Baby Unit to different positions in the rooms. 1. Camera Lens 2. Microphone 3. Mood Light 4. Speaker 5. Light Sensor (Night Vision Mode) 6. Pair button Press and hold to pair with the Parent Unit. 7.Power Adapter Socket 8. Power indicatior Lights up in blue when the Baby Unit is switched on and linked to the Parent Unit. 9.Temperature Sensor 10.P ower ON/OFF switch Slide to switch the Baby Unit on or off. 1 5 2 3 6 7 10 4 8 6Table of contents Table of contents 1.Safety Instructions ..................................................................................... 7 2.Getting Started ........................................................................................ 10 2.1Power up the Baby Unit ............................................................................. 10 2.2Charge the Parent Unit ............................................................................. 11 3. Using the Family Monitor........................................................................... 12 3.1Setting Up .................................................................................................. 12 3.2Power On or Off the Baby Unit ................................................................. 12 3.3Power On or Off the Parent Unit............................................................... 12 3.4Night Vision Mode..................................................................................... 13 4.Parent Unit Menu Options....................................................................... 14 4.1Adjust Speaker Volume ...............…

Text truncated - open the document above for the full version.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States A pplicant Legal Business Name Binatone Eletronics International Limited Address Floor 23A, 9 Des Voeux Road West Sheung Wan, Hong Kong Grantee Code VLJ FCC ID VLJ-CF85BU Authorized Contact Name Karl Heinz Mueller Contact Email [email protected] Contact Phone 852-28027388 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and beli ef. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations ma de in this appli cation, the Applic ant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this a pplication, (2) compliance statement labeling pursuant to the applicable ru les, (3) compliance of the equipment with the applicable technical r ules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to en sure that production u nits of this equipment will continue to comply with the FCC’s tec hnical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the re sponsible part y and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accep ts and agrees to a bide by the post market surveillance requirement s. (1 ) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testi ng. (2 ) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or IS ED. (3 ) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware o r s oftware required for evaluation, review, certification and audit surveillance of products certified by S GS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and con ditions. L ink to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html A pplicant Signature: Date: 23 Oct. 2020 Print Name: Karl Heinz Mueller Title: Chief Technical Officer *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

0RGHO,WHP&RQILUPDWLRQ/HWWHU :H%LQDWRQH(OHFWURQLFV,QWHUQDWLRQDO/LPLWHGGHFODUHWKDWRXUSURGXFW&211(&7%8 DQGLWVEHORZPRGHO V LWHP V ͧ঩ӧֺ՚ͨ   &20)257%8&1%8  DUH LGHQWLFDORQFLUFXLWU\GHVLJQ3&%OD\RXWHOHFWULFDOFRPSRQHQWVXVHGLQWHUQDOZLULQJDQG IXQFWLRQVZLWKWKHPRGHOLWHPQR ՚ֺࡹП   &211(&7%8     ZKLFKZHFKRVHWR EHWHVWHGE\6*6DQGRQO\GLIIHUHQWRQ הФڑٛ 澳&RORU)LQLVKLQJ澳 澳 澳 澳 &RPSDQ\FKRS $XWKRUL]HG6L JQDWXUH .DUO+HLQ]0XHOOHU  3RVLWLRQ   &72     'DWH2FW

To: Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd. Columbia MD 21046 From: Binatone Electronics International Limited Regarding: Confidentiality Request regarding application for FCC ID: VLJ-CF85BU LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Name (Printed): Sam Lee Title: Product Director Signature: On behalf of Company: Binatone Electronics International Limited Telephone: 852-2802 7388 E-mail: [email protected]

Binatone Electronics International Ltd. Date: Oct. 23, 2020 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: VLJ-CF85BU To whom it may concern: We, the undersigned, hereby authorize SGS Hong Kong Limited and YW Yung in SGS Hong Kong Limited to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Binatone Electronics International Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): Sam Lee Title: Product Director Signature: On behalf of Company: Binatone Electronics International Limited Telephone: 852-2802 7388 E-mail: [email protected]

Appendix A: External Photo of HKEM2008000841AT

Part Name: Product Label Set_NA Binatone Labeling File Part Name: Baby Unit Revision History:V1 25-May-2020 Initial release.V2 24-Aug-2020 Updated BU label on SSID. Rating Label1. Size: W37 x H38mm2. Material: PET 50#3. Color: printing black on white background. 434510G000001 SN Label1. Description of Serieal Number.- Model Number: 43451=CONNECT40- Produce date: 0G (July/2020)- Serial no. start from ‘000001’ (6 digits)- Code Format: code 1282. Location: Unit bottom, Gift box and carton (with QR code). SSDID: MODEL: CONNECT40BUINPUT: DC5V 1000mAFCC ID: VLJ-CF85BUIC: 4522A-CF85BUHVIN: CF85BUMADE IN CHINA 434510G000001 Use Only Power Supplies listed in the user’s guide.SSID: CAMERAHD-6085XXXXXX MODEL: CONNECT40BUINPUT: DC5V 1000mAFCC ID: VLJ-CF85BUIC: 4522A-CF85BUHVIN: CF85BUMADE IN CHINA 434510G000001 Use Only Power Supplies listed in the user’s guide.SSID: CAMERAHD-6085XXXXXX CAMERAHD-6085XXXXXX

Appendix B: Internal Photo of HKEM2008000841AT

Report No.: HKEM200800084104 Page: 1 of 12 Law Man Kit EMC Manager This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request and accessible at http://www.sgs.com/en/Terms-and-conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-conditions.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. T he document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. TEST REPORT Application No.: HKEM2008000841AT Applicant: BINATONE ELECTRONIC INTERNATIONAL LIMITED Address of Applicant: Floor 23A, 9 Des Voeux Road West Sheung Wan, Hong Kong Equipment Under Test (EUT): EUT Name: 5” Wi-Fi® Video Baby Monitor Model No.: CONNECT40BU, COMFORT85BU, CN75BU Additional model: Please refer to section 2 of this report which indicates which item was actually tested and which were electrically identical. FCC ID: VLJ-CF85BU IC: 4522A-CF85BU HVIN: CF85BU Standard(s) : 47 CFR Part 1.1307; 47 CFR Part 2.1093 KDB447498D01 General RF Exposure Guidance v06 RSS102 Issue 5 March 2015 Date of Receipt: 2020-08-14 Date of Test: 2020-08-26 to 2020-09-21 Date of Issue: 2020-09-23 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Report No.: HKEM200800084104 Page: 2 of 12 Revision Record Version Chapter Date Modifier Remark 01 2020-09-23 Original Authorized for issue by: Leo Xu /Project Engineer Date: 2020-09-23 Law Man Kit /Reviewer Date: 2020-09-23 Report No.: HKEM200800084104 Page: 3 of 12 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result RF Exposure 47 CFR Part 1.1307, 47 CFR Part 2.1093, KDB 447498 D01 KDB447498D01 KDB447498D01 PASS RF Exposure RSS102 Issue 5 RSS-102 Section 2.5.1 RSS102 Issue 5 PASS Declaration of EUT Family Grouping: Item no.: CONNECT40BU, COMFORT85BU, CN75BU According to the confirmation from the applicant, the above models are identical in all electrical aspects in relating to the circuit design, PCB layout, electrical components used, internal wiring and functions. The difference is only on Color Finishing. Therefore only the model CONNECT40BU was tested in this report. Abbreviation: Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radiated Frequency. CH: In this whole report CH means channel. Volt: In this whole report Volt means Voltage. Temp: In this whole report Temp means Temperature. Humid: In this whole report Humid means humidity. Press: In this whole report Press means Pressure. N/A: In this whole report not application. Report No.: HKEM200800084104 Page: 4 of 12 3 Contents Page 1 COVER PAGE ..................................................................................................................................... 1 2 TEST SUMMARY ................................................................................................................................. 3 3 CONTENTS ......................................................................................................................................... 4 4 GENERAL INFORMATION .................................................................................................................. 5 4.1 D ETAILS OF E.U.T. ......................................................................................................................... 5 4.2 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 6 4.3 T EST LOCATION ............................................................................................................................. 7 4.4 T EST FACILITY ............................................................................................................................... 7 4.5 DEVIATION FROM STANDARDS ......................................................................................................... 7 4.6 A BNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 7 5 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................. 8 5.1 RF EXPOSURE ............................................................................................................................... 8 5.1.1 Test Requirement: ................................................................................................................... 8 5.1.1 IC Radiofrequncy radiation ....................................................................................................... 9 5.1.2 EUT RF Exposure Evaluation ..................................................................................................10 6 PHOTOGRAPHS ................................................................................................................................12 Report No.: HKEM200800084104 Page: 5 of 12 4 General Information 4.1 Details of E.U.T. Power supply: Adaptor model: BQ06A-0501000-U Input: AC 100-240V, 50/60Hz, 300mA Outpu…

Text truncated - open the document above for the full version.

Report No.: HKEM200800084103 Page: 1 of 80 Law Man Kit EMC Manager This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request and accessible at http://www.sgs.com/en/Terms-and-conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-conditions.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. T he document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. TEST REPORT Application No.: HKEM2008000841AT Applicant: BINATONE ELECTRONIC INTERNATIONAL LIMITED Address of Applicant: Floor 23A, 9 Des Voeux Road West Sheung Wan, Hong Kong Equipment Under Test (EUT): EUT Name: 5” Wi-Fi® Video Baby Monitor Model No.: CONNECT40BU, COMFORT85BU, CN75BU Additional model: Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. FCC ID: VLJ-CF85BU IC: 4522A-CF85BU Standard(s) : 47 CFR Part 15, Subpart C 15.247 RSS-247 Issue 2: May 2017 RSS-Gen: Issue 5 Amdt 2019 Date of Receipt: 2020-08-14 Date of Test: 2020-08-26 to 2020-09-21 Date of Issue: 2020-09-23 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Report No.: HKEM200800084103 Page: 2 of 80 Revision Record Version Chapter Date Modifier Remark 01 2020-09-24 Original Authorized for issue by: Leo Xu /Project Engineer Date: 2020-09-22 Law Man Kit /Reviewer Date: 2020-09-22 Report No.: HKEM200800084103 Page: 3 of 80 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Minimum 6dB Bandwidth 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Power Spectrum Density 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.209 & 15.247(d) Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.209 & 15.247(d) Pass Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement RSS-Gen Issue 5, Amdt 2019 N/A RSS-Gen Section 6.8 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) RSS-Gen Issue 5: Amdt 2019 ANSI C63.10 (2013) Section 6.2 RSS-Gen Section 8.8 Pass 99% Bandwidth RSS-Gen Issue 5: Amdt 2019 ANSI C63.10 Section 6.9.3 RSS-Gen Section 6.7 Pass Minimum 6dB Bandwidth RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 11.8.1 RSS-247 Section 5.2(a) Pass Conducted Peak Output Power RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 11.9.1 RSS-247 Section 5.4(d) Pass Power Spectrum Density RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 11.10.2 RSS-247 Clause 5.2(b) Pass Conducted Band Edges Measurement RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 11.12 RSS-247 Section 5.5 Pass Report No.: HKEM200800084103 Page: 4 of 80 Radio Spectrum Matter Part Item Standard Method Requirement Result Spurious Emissions RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 11.11 RSS-247 Section 5.5 Pass Radiated Emissions which fall in the restricted bands RSS-Gen Issue 5: Amdt 2019 ANSI C63.10 (2013) Section 6.4&6.5&6.6 RSS-247 Section Section 3.3 & RSS-Gen Section 8.10 Pass Frequency stability RSS-247 Issue 2, February 2017 RSS-Gen Section 6.11 RSS-Gen Section 8.11 Pass Note: Frequency stability requested in RSS GEN Section 8.1.1 has been complied since the result of band edge can demonstrate. Declaration of EUT Family Grouping: Item no.: CONNECT40BU, COMFORT85BU, CN75BU According to the confirmation from the applicant , the above models are identical in all electrical aspects in relating to the circuit design, PCB layout, electrical components used, internal wiring and functions. The difference is only on Color Finishing. Therefore only the model CONNECT40BU was tested in this report. Abbreviation: Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radiated Frequency. CH: In this whole report CH means channel. Volt: In this whole report Volt means Voltage. Temp: In t…

Text truncated - open the document above for the full version.

Appendix C: Setup Photo of HKEM2008000841AT Conducted Emissions at Mains Terminals Test Setup Radiated Emissions (30MHz-1GHz) Test Setup Radiated Emissions (Above 1GHz) Test Setup Conducted RF Output Power Test Setup
