VLJ-MBP855BU5inch Wi-Fi Video Baby Monitor

User’s Guide 5" Wi-Fi ® Video Baby Monitor Models: MBP855CONNECT The features described in this User’s Guide are subject to modifications without prior notice. Welcome... to your new Motorola Digital Video Baby Monitor! Thank you for purchasing the Digital Video Baby Monitor. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their play room. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product-related questions, please call: This User's Guide provides you with all the information you need to get the most from your product. Before you use the Digital Video Baby Monitor, we recommend that you fully charge the battery that is pre-installed in the Parent Unit, so that it continues to work if you disconnect it from the power supply. Please read the Safety Instructions on pages 8 - 10 before you install the Units. Got everything? • 1 x Parent Unit • 1 x Baby Unit (Camera) •1 x Power adapter for Parent Unit • 1 x Power adapter for Baby Unit • 1 x Stargrip In multi-camera packs, you will find one or more additional Camera Units with power adapters. US and Canada 1-888-331-3383 Email: [email protected] On the Web: www.motorolahome.com/support 1.Display (LCD screen) 2.VIDEO ON/OFF button V Press to turn the LCD screen ON/ OFF (Note: audio is maintained.) 3.TA L K b u t t o n T Press and hold to speak to your baby 4.RESET button (recessed - use small pin) 5.UP button + Normal Mode: Tilt camera Up Menu Mode: Move Up menu options 6.DOWN button - Normal Mode: Tilt camera Down Menu Mode: Move Down menu options 7.MENU button M Press to open / close the Menu options 8.OK button O 9.Micro USB power adapter outlet 10.LEFT button < Normal Mode: Pan camera Left Menu Mode: Move Left along menu options 11.RIGHT button > Normal Mode: Pan camera Right Menu Mode: Move Right along menu options 12.Charging LED: BLUE when mains power connected. 13.Parent Unit ON/OFF LED (Green) 14.Audio Level LEDs (Green, Amber, Red, Red) 15.Volume buttons Press -/+ to decrease/increase Volume level on Parent Unit 16.Power button 0 Press and Hold to turn the Parent Unit ON/OFF 17.Microphone 18.Stand 19.Speaker RESET DC 5V 8 9 7 Overview of the Parent Unit Parent Unit menu icons Signal Level Indication (5 Levels) Night Vision Mode (Video also changes to Black/White) T Ta l k M o d e O n Volume Level Indication (4 Levels) Panning Camera Left Panning Camera Right Tilting Camera Up Tilting Camera Down Zoom Level Control (1X, 2X) Brightness Level Control (8 Levels) Lullaby Control (5 Sound Selections) Alarm Setting (6h, 4h, 2h, OFF) On status bar, indicates alarm set, and when flashing, that alarm time has been reached or missed. Temperature scale select ( o C / o F) Readings display in BLUE, but turn RED if > 29ºC / 84ºF, or < 14ºC / 57ºF Displays HH o C / o F if >36 o C / 97 o F. Displays LL o C / o F if < 1 o C / 34 o F. Camera Control (scan , view , add , delete ) Set Screen Off Timer (Off , 5 min, 30 min, 60 min) Indicates the screen off timer is set Volume Level Control (8 Levels + Off) Indicates volume is off No Baby Unit detected View multiple cameras on screen. Available when you have more than 1 Baby Unit (Camera). + V Overview of Your Baby Unit (Camera) 1.Photo Sensor (Night Vision Mode) 2.Camera Lens 3.Infrared LEDs (x 8, for night vision) 4.Power LED (Blue when on) On when linked to Parent Unit Flashes when searching for Parent Unit 5.Microphone 6.Camera Battery LED On when AC power is connected to camera. Flashes when the battery level of the camera is low. 7.POWER ON/OFF switch 8.Temperature Sensor 9.Micro-USB Power Socket 10.PAIR Button 11.Speaker 12.Star Grip or Tripod Mount 13.Antenna Important guidelines for installing your Baby Monitor • To use your Video Monitor Baby and Parent Units together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions. • Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or reinforced concrete between the Baby and Parent Unit may block the radio signal. • The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. • Use of other 2.4 GHz products, such as wireless networks (Wi-Fi ® routers), Bluetooth™ systems, or microwave ovens, may cause interference with this product, so keep the Baby Monitor at least 5 feet away from these types of products, or turn them off if they appear to be causing interference • If the signal is weak, try moving the Parent and/or the Baby Unit to different positions in the room(s). 6Table of contents Table of contents 1.Safety Instructions .................................................................................... 8 2.Getting Started....................................................................................... 11 2.1Baby Unit Power Supply ........................................................................... 11 2.2Parent Unit Power Supply ........................................................................ 12 2.3Registration (Pairing) ................................................................................ 14 3.Using the Baby Monitor .......................................................................... 15 3.1Setting Up ................................................................................................. 15 3.2Pan and Tilt ............................................................................................... 15 3.3Night Vision Mode .................................................................................... 15 3.4Talk Mode....................................................................…

Text truncated - open the document above for the full version.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Binatone Eletronics International Limited Address 25/F, Guangdong Investment Tower, 148 Connaught Road, Central, Sheung Wan, Hong Kong, China Grantee Code VLJ FCC ID VLJ-MBP855BU Authorized Contact Name Sam Lee Contact Email [email protected] Contact Phone 852-28027388 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 23 Oct. 2020 Print Name: Sam Lee Title: Product Director *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

To: Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd. Columbia MD 21046 From: Binatone Electronics International Limited Regarding: Confidentiality Request regarding application for FCC ID: VLJ-MBP855BU LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Name (Printed): Sam Lee Title: Product Director Signature: On behalf of Company: Binatone Electronics International Limited Telephone: 852-2802 7388 E-mail: [email protected]

Binatone Electronics International Ltd. Date: Oct. 23, 2020 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: VLJ-MBP855BU To whom it may concern: We, the undersigned, hereby authorize SGS Hong Kong Limited and YW Yung in SGS Hong Kong Limited to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Binatone Electronics International Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): Sam Lee Title: Product Director Signature: On behalf of Company: Binatone Electronics International Limited Telephone: 852-2802 7388 E-mail: [email protected]

Appendix A: External Photo of HKEM2005000450AT_BU

Part Name: Product Label Set_NA Binatone Labeling File Part Name: Baby Unit Revision History:V1 Initial release for Anyka platform. Serial Number - Model Number: 42971 = MBP855CONNECT 42972 = MBP855CONNECT-2 - Produce date: 0E= May/2020- Serial no. start from ‘000001’ (6 digits)- Code Format: code 128- Size: 30 x 10 mm (on Gift box and cartoon) Rating Label(BU)Material: 50# PETSize : 31.5 x 31.5 mm 429710E000001 Use Only Power Supplies listed in the user’s guide.SN: 429710E000001CAMERA-6855XXXXXX QR Code MODEL: MBP855CONNECTBUINPUT: DC5V 1500mAFCC ID: VLJ-MBP855BUIC: 4522A-MBP855BUHVIN MBP855BU MADE IN CHINA PIN1(+) PIN5(-) Use Only Power Supplies listed in the user’s guide.SN: 429710E000001CAMERA-6855XXXXXX QR Code MODEL: MBP855CONNECTBUINPUT: DC5V 1500mAFCC ID: VLJ-MBP855BUIC: 4522A-MBP855BUHVIN MBP855BU MADE IN CHINA PIN1(+) PIN5(-) Remark: compliance statement was listed in manual due to surface and interface limitation reason.

Appendix B: Internal Photo of HKEM2005000450AT_BU

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/8003203 Page : 1 of 38 FCC SAR TEST REPORT Application No: ZR/2020/80032 Applicant: BINATONE ELECTRONIC INTERNATIONAL LIMITED Address of Applicant: 25/F, Guangdong Investment Tower, 148 Connaught Road, Central, Sheung Wan, Hong Kong, China Manufacturer: BINATONE ELECTRONICS INTERNATIONAL LIMITED Product Name: 5” Wi-Fi® Video Baby Monitor (Baby Unit) Model No.(EUT): MBP855CONNECTBU Trade Mark: motorola FCC ID: VLJ- MBP855BU Standards: FCC 47CFR §2.1093 Date of Receipt: 2020-08-12 Date of Test: 2020-09-09 to 2020-09-09 Date of Issue: 2020-11-05 Test conclusion: PASS * * In the configuration tested, the EUT detailed in this report complied with the standards specified above. Authorized Signature: Derek Yang Wireless Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/8003203 Page : 2 of 38 REVISION HISTORY Report Number Revision Description Issue Date ZR/2020/8003203 01 Original 2020-11-05 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/8003203 Page : 3 of 38 TEST SUMMARY Frequency Band Maximum Reported SAR(W/kg) Body 2.4G (user-defined) 0.39 WiFi 2.4G 1.39 SAR Limited(W/kg) 1.6 Approved & Released by Simon Ling SAR Manager Tested by Jackson Li SAR Engineer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/8003203 Page : 4 of 38 CONTENTS 1 GENERAL INFORMATION .....................................................................................................................................6 1.1 DETAILS OF CLIENT ...........................................................................................................................................6 1.2 TEST LOCATION.................................................................................................................................................6 1.3 TEST FACILITY ...................................................................................................................................................7 1.4 GENERAL DESCRIPTION OF EUT .......................................................................................................................8 1.4.1 DUT Antenna Locations .............................................................................................................................9 1.5 TEST SPECIFICATION ....................................................................................................................................... 11 1.6 RF EXPOSURE LIMITS ...................................................................................................................................... 12 2 LABORATORY ENVIRONMENT ........................................................................................................................ 13 3 SAR MEASUREMENTS SYSTEM CONFIGURATION ...................................................................................... 14 3.1 THE SAR MEASUREMENT SYSTEM.................................................................................................................. 14 3.2 ISOTROPIC E-FIELD PROBE EX3DV4 .............................................................................................................. 15 3.3 DATA ACQUISITION ELECTRONICS (DAE) ....................................................................................................... 16 3.4 SAM TWIN PHANTOM ...................................................................................................................................... 16 3.5 ELI PHANTOM ................................................................................................................................................. 17 3.6 DEVICE HOLDER FOR TRANSMITTERS .............................................................................................................. 18 3.7 MEASUREMENT PROCEDURE ........................................................................................................................... 19 3.7.1 Scanning procedure ................................................................................................................................. 19 3.7.2 Data Storage ............................................................................................................................................. 21 3.7.3 Data Evaluation by SEMCAD .................................................................................................................. 21 4 SAR MEASUREMENT VARIABILITY AND UNCERTAINTY ............................................................................ 23 4.1 SAR MEASUREMENT VARIABILITY ................................................................................................................... 23 4.2 SAR MEASUREMENT UNCERTAINTY ................................................................................................................. 23 5 DESCRIPTION OF TEST POSITION ................................................................................................................... 24 5.1 BODY EXPOSURE CONDITION .......................................................................................................................... 24 6 SAR SYSTEM VERIFICATION PROCEDURE ............................................................................................…

Text truncated - open the document above for the full version.

Report No.: HKEM200500045004 Page: 1 of 58 Law Man Kit EMC Manager This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request and accessible at http://www.sgs.com/en/Terms-and-conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-conditions.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. T he document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. TEST REPORT Application No.: HKEM2005000450AT Applicant: BINATONE ELECTRONIC INTERNATIONAL LIMITED Address of Applicant: FCC Address 1: 25/F, Guangdong Investment Tower, 148 Connaught Road, Central, Sheung Wan, Hong Kong, China ISED Address 2: Flat 23A, 9 Des Voeux Road West Sheung Wan, Hong Kong, China Equipment Under Test (EUT): EUT Name: 5” Wi-Fi® Video Baby Monitor (Baby Unit) Model No.: MBP855CONNECTBU Additional Model: Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. FCC ID: VLJ-MBP855BU IC: 4522A-MBP855BU HVIN: MBP855BU Standard(s) : 47 CFR Part 15, Subpart C 15.247 RSS-247 Issue 2: May 2017 RSS-Gen: Issue 5 Amdt 2019 Date of Receipt: 2020-07-17 Date of Test: 2020-09-25 to 2020-10-09 Date of Issue: 2020-10-12 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Report No.: HKEM200500045004 Page: 2 of 58 Revision Record Version Chapter Date Modifier Remark 01 2020-10-12 Original Authorized for issue by: Leo Xu /Project Engineer Date: 2020-10-09 Law Man Kit /Reviewer Date: 2020-10-12 Report No.: HKEM200500045004 Page: 3 of 58 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.247(a)(1),(g),(h) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.5 47 CFR Part 15, Subpart C 15.247(b)(1) Pass 20dB Bandwidth 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.7 47 CFR Part 15, Subpart C 15.247(a)(1) Pass Carrier Frequencies Separation 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.2 47 CFR Part 15, Subpart C 15.247a(1) Pass Hopping Channel Number 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.3 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Dwell Time 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.4 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.6 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.8 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement RSS-247 Issue 2, February 2017 N/A RSS-Gen Section 6.8 Pass Pseudorandom Frequency Hopping Sequence RSS-247 Issue 2, February 2017 N/A RSS-247 Section 5.1(a) Pass Report No.: HKEM200500045004 Page: 4 of 58 Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 6.2 RSS-Gen Section 8.8 Pass 99% Bandwidth RSS-247 Issue 2, February 2017 ANSI C63.10 Section 6.9.3 RSS-Gen Section 6.7 Pass Conducted Peak Output Power RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 7.8.5 RSS-247 Section 5.4(b) Pass 20dB Bandwidth RSS-247 Issue 2, February 2017 ANSI C63.10 Section 6.9.2 RSS-247 Section 5.1(a) Pass Carrier Frequencies Separation RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 7.8.2 RSS-247 Section 5.1(b) Pass Hopping Channel Number RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 7.8.3 RSS-247 Section 5.1(d) Pass Dwell Time RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 7.8.4 RSS-247 Section 5.1(d) Pass Conducted Band Edges Measurement RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section7.8.6 RSS-247 Section 5.5 Pass Conducted Spurious Emissions RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 7.8.8 RSS-247 Section 5.5 Pass Radiated Emissions which fall in the restricted bands RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 6.10.5 Section 3.3 & RSS-Gen Section 8.10 Pass Radiated Spurious Emissions RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 6.4&6…

Text truncated - open the document above for the full version.

Appendix C: Setup Photo of HKEM2005000450AT_BU Conducted Emissions at Mains Terminals Test Setup Radiated Emissions (30MHz-1GHz) Test Setup Radiated Emissions (Above 1GHz) Test Setup Conducted RF Output Power Test Setup
