VLJ-FOCUS66Wi-Fi Home Video Camera

Declaration letter for multiple models We, Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong declare that the following product(s): Product Description: Wi-Fi Home Video Camera Model Number:FOCUS66-S utilize the identical circuit design, PCB layout, shielding and interface with (FOCUS66-W, FOCUS66-B, SCOUT66, SCOUT66-S, SCOUT66-W, SCOUT66-B ,FOCUS66-S2, FOCUS66-S3, FOCUS66-S4, FOCUS66-W2, FOCUS66-W3, FOCUS66-W4, FOCUS66-B2, FOCUS66-B3, FOCUS66-B4), only the cosmetic is difference. Therefore this application can be regarded as identical in performance to the submitted test sample. The manufacturer would take all the responsibilities for the above product(s). For and on behalf of Authorized person Location Name:Karl Heinz Mueller Position:Chief Technical Officer Date of issue: 27 – Jun-2014 *I hereby declare that I am entitled to sign on behalf of the applicant and that the information supplied is correct and complet e.

Date (27/06/2014) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We,(Binatone Electronics International Limited),hereby authorize Ray Cheung (TUV SUD HK LTD) to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on(23/12/2014]). Sincerely, Company Officer:Karl Heinz Muller Telephone Number: 852 2802 7388 Email:[email protected]

Date (27/06/2014) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Confidentiality Request FCC ID:VLJ- FOCUS66 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules,(Binatone Electronics International Limited)hereby requests permanent confidential treatment of information accompanying this application as outlined below: [Common exhibits for which confidentiality is requested are: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation] (Binatone Electronics International Limited) alsohereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of(23 Dec, 2014)days: [Common exhibits for which short-term confidentiality is requested are: Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer:Karl Heinz Mueller Telephone Number: 852 2802 7388 Email:852 2802 8138

Appendix B Date: 2014-05-27 Report No.: 60.870.14.006.01F Model No.:FOCUS66-W Page 1 of 3 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix B Date: 2014-05-27 Report No.: 60.870.14.006.01F Model No.:FOCUS66-W Page 2 of 3 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix B Date: 2014-05-27 Report No.: 60.870.14.006.01F Model No.:FOCUS66-W Page 3 of 3 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong.

Label Location

Appendix C Date: 2014-05-27 Report No.: 60.870.14.006.01F Model No.:FOCUS66-W Page 1 of 3 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix C Date: 2014-05-27 Report No.: 60.870.14.006.01F Model No.:FOCUS66-W Page 2 of 3 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix C Date: 2014-05-27 Report No.: 60.870.14.006.01F Model No.:FOCUS66-W Page 3 of 3 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong.

Date: 2014-05-27 Report No.: 60.870.14.006.01F Model No.:FOCUS66-W Page 1 of 1 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. SAR Evaluation Exemption Compliance Information The device has a standalone transmission. According to KDB 447498 section 4.3.1, the 1-g SAR test exclusion thresholds at test separation distances ” 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[ ¥f(GHz)] ” 3.0 The maximum tune-up limit power is 24.43 mW @ 2.462GHz For the head and body SAR, use 50mm as the conservative minimum test separation distance, [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[ ¥f(GHz)] = 0.311 ” 3.0 So standalone SAR measurements are not required for both head and body

TEST REPORT Date: 2014-05-27 Report No.: 60.870.14.006.01F Page 1 of 70 TUV SUD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong Applicant:Binatone Electronics International Limited Floor 23, 9 Des Voeux Road West, Sheung Wan, Hong Kong Description of Samples:Model name: Wi-Fi Home Video Camera Brand name: motorola Model no.:FOCUS66-S,FOCUS66-W, FOCUS66-B, SCOUT 66, SCOUT66-S, SCOUT66-W, SCOUT66-B, FOCUS66-S2, FOCUS66-S3, FOCUS66-S4, FOCUS66-W2, FOCUS66-W3, FOCUS66-W4, FOCUS66-B2, FOCUS66-B3, FOCUS66-B4 FCCID:VLJ-FOCUS66 Date Samples Received:2014-04-14 Date Tested:2014-04-15 to 2014-05-27 Investigation Requested:FCC Part 15 Subpart C, Section 15.247 Conclusions:The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks:--- Checked by:Approved by:- Ray CheungJeff Pong Project EngineerOperation Manager Wireless & Telecom departmentWireless & Telecom department Report No.:60.870.14.006.01F Page 2 of 70 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong CONTENT: Cover Page 1 of 70 Content Page 2-3 of 70 1.0General Details 1.1Test Laboratory Page 4 of 70 1.2Applicant Details Page 4 of 70 1.3Equipment Under Test [EUT] Page 5 of 70 1.4 Related Submittal(s) Grants Page 5 of 70 2.0Technical Details 2.1Investigations Requested Page 6 of 70 2.2Test Standards and Results Summary Page 6 of 70 3.0Test Methodology 3.1Radiated Emission Page 7 of 70 3.2Field Strength Calculation Page 7 of 70 3.3Conducted Emission Page 7 of 70 4.0Test Results 4.1 6dB Bandwidth MeasurementPage 9-16 of 70 4.2 Power Spectral Density Page 17-25 of 70 4.3 Band Edge MeasurementPage 26-28 of 70 4.4 Maximum Output Power Page 29-38 of 70 4.5 Out of Band Emissions and Emissions in Restricted BandsPage 39-66 of 70 4.6 Conducted Emission on AC MainsPage 67-69 of 70 Report No.:60.870.14.006.01F Page 3 of 70 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong 5.0List of Measurement Equipments Page 70 of 70 Appendix A Photos of Test Setup Appendix B External EUT Photos Appendix C Internal EUT Photos Report No.:60.870.14.006.01F Page 4 of 70 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong 1.0General Details 1.1Test Laboratory Attestation of Global Compliance SZ Co Ltd. 2/F, Building 2,No.1-No.4,Chaxi Sanwei, Technical Industrial Park, Gushu, Xixiang, Shenzhen, China. Registration Number: 259865 Tested By: John Zhi 1.2Applicant Details Applicant Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong Manufacturers Dongguan TaoSen Electronic Technology Co. Ltd. No.7 Huanguoshan Road, Xinan Community, Changan Town, Dongguan City, Guangdong, China Report No.:60.870.14.006.01F Page 5 of 70 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong 1.3Equipment Under Test [EUT] Description of EUT Product Description:Wi-Fi Home Video Camera Model No.:FOCUS66-W Multi-listing Model: FOCUS66-S, FOCUS66-B, SCOUT 66, SCOUT66-S, SCOUT66-W, SCOUT66-B, FOCUS66-S2, FOCUS66-S3, FOCUS66-S4, FOCUS66-W2, FOCUS66-W3, FOCUS66-W4, FOCUS66-B2, FOCUS66-B3, FOCUS66-B4 Brand Name: motorola FCCID: VLJ-FOCUS66 Rating:5VDC, 1000mA Powered by AD/DC Switching Adaptor Operated Frequency:2412 – 2462 MHz 2422 – 2452 MHz No. of Operated Channel:11 CH / (802.11b/g/n – HT20) ; 9CH / (802.11n – HT40) Data Rate:802.11b: 1, 2, 5.5, 11Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps 802.11n: MCS0-7, up to 150Mbps Modulation:DSSS (BPSK, QPSK, CCK)and OFDM (BPSK/QPSK/16-QAM/ 64-QAM) Accessories and Auxiliary Equipments: AC/DC power adaptor,ThinkPad Notebook Antenna Type:Integral Antenna Manufacture of Antenna:Cortec Technology Inc. Antenna Gain:1.0dBi Antenna Model:--- General Operation of EUT The Equipment Under Test (EUT) is aWiFi Camera Unitoperated at 2.4GHz,which include of an 802.11b/g/n module. As per Client Declaration, FOCUS66-W & all multi-list models (multi-list model listed on above) have the same technical construction including Software design, RF module, PCB layout, Circuit design, all electrical construction and basic mechanical construction. Only the outlook color and system grouping are different between the models, so we use FOCUS66-W as a representative model to perform all testing. Report No.:60.870.14.006.01F Page 6 of 70 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong Description of Test Modes The EUT has been tested under operating condition. Software used to control the EUT for staying in continuous transmitting and receiving mode is programmed. IEEE802.11b: Channel 1(2412MHz), Channel 6(2437MHz) and Channel 11(2462MHz) with 1Mbps data rate (worst case) are chosen for the final testing. IEEE802.11g: Channel 1(2412MHz), Channel 6(2437MHz) and Channel 11(2462MHz) with 6Mbps data rate (the worst case) are chosen for the final testing. IEEE802.11n – HT20: Channel 1(2412MHz), Channel 6 (2437MHz) and Channel 11 (2462MHz) with MSC0 (worst case) are chosen for the final testing. IEEE802.11n – HT40: Channel 3(2422MHz), Channel 6 (2437MHz) and Channel 9 (2452MHz) with MSC0 (worst case) are chosen for the final testing. 1.4Related Submittal(s) Grants This is a signal application subject to Certificate Authorization. Report No.:60.870.14.006.01F Page 7 of 70 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong 2.0Technical Details 2.1Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.4: 2009 2.2Test Standards and Results Summary Tables Test ConditionTest RequirementTest Result PassN/A Number of Frequency Hopping Section 15.247 ( a1 ) 6dB Bandwidth…
