User’s Guide Digital Audio Baby Monitor Models: MBP160, MBP160-2 The features described in this User’s Guide are subject to modifications without prior notice. Welcome... to your new Motorola Digital Audio Baby Monitor! Thank you for purchasing the Digital Audio Baby Monitor. Now you hear your baby sleeping in another room. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product-related questions, please call: This User's Guide provides you with all the information you need to get the most from your product. Before you use the digital audio baby monitor, we recommend that you insert and fully charge the battery in the parent unit, so that it continues to work if you disconnect it from the electrical outlet to carry it to another location. Please read the Safety Instructions on page 6 before you install the units. Got everything? • 1 x Parent unit with desktop stand • 1 x Baby unit • 1 x Rechargeable Ni-MH battery pack for the Parent unit • 1 x Battery door for Parent unit • 1 x Power adapter for Parent unit • 1 x Power adapter for Baby unit In packs with multi baby units, you will find one or more additional baby units with power adapters. US and Canada 1-888-331-3383 Email: [email protected] Overview of the Parent Unit 1.Sound level indicator It shows the sound level detected by the baby unit and the speaker volume set on the parent unit. Sound level detected by the baby unit: If no LED lights up, no sound is detected. If more LEDs light up, the sound level is high. Speaker volume on the parent unit: If more LEDs light up when adjusting speaker volume, the speaker volume is high. 2.Power/Link indicator On steadily when the parent unit is powered on and linked to the baby unit. Off when the parent unit is powered off. Flashes when it is out of range of the baby unit. 3.UP / VOLUME + Press to increase speaker volume. 4.DOWN / VOLUME - Press to decrease speaker volume. 5.Power ON/OFF button Press and hold to power on or off. 6.Charging indicator On steadily when the parent unit battery is being charged. Flashes when the parent unit battery is low and needs charging. Off when the parent unit battery is fully charged, or when the battery is not installed. 7.Power jack 8.Speaker 9.Battery compartment cover 10.Desktop stand 2 3 4 1 5 6 7 8 9 10 Overview of the Baby Unit 1 2 3 Important guidelines for installing your digital baby monitor • To use your baby unit and parent unit together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions. • Any large metal object, like a refrigerator, a mirror, a filing cabinet, a metallic door or reinforced concrete, between the baby unit and parent unit may block the radio signal. • The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. • If the signal is poor, try moving the parent unit and/or the baby unit to different positions in the rooms. 1.Power/Link indicator On steadily when the baby unit is powered on and linked to the parent unit. Off when the baby unit is powered off. Flashes when it is out of range of the parent unit. 2.Power ON/OFF button 3.Microphone Table of contents5 ENGLISH Table of contents 1.Safety Instructions ..................................................................................... 6 2.Getting Started .......................................................................................... 9 2.1Baby unit power supply ............................................................................... 9 2.2Parent unit battery installation and power supply .................................... 10 2.3Desktop stand on parent unit .................................................................... 11 3.Using Your Digital Audio Baby Monitor.................................................. 12 3.1Power on or off the baby unit.................................................................... 12 3.2Power on or off the parent unit ................................................................. 12 3.3Adjust speaker volume of the parent unit................................................. 12 4.Disposal of the Device (Environment).................................................... 13 5.Cleaning .................................................................................................. 14 6.Troubleshooting ...................................................................................... 15 7.General Information ................................................................................ 17 8.Technical Specifications ......................................................................... 22 6Safety Instructions 1. Safety Instructions WARNING: Strangulation Hazard. Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 3ft (1m) away). Never use extension cords with AC Adapters. Only use the AC Adapters provided. Safety Instructions7 ENGLISH WARNING This Digital Audio Baby Monitor is compliant with all relevant standards regarding electromagnetic fields and is, when handled as described in the User's Guide, safe to use. Therefore, always read the instructions in this User's Guide carefully before using the device. • Adult assembly is required. Keep small parts away from children when assembling. • This product is not a toy. Do not allow children to play with it. • This Digital Audio Baby Monitor is not a substitute for responsible adult supervision. • Keep this user's guide for future reference. • Keep the cords out of reach of children. • Do not cover the Digital Audio Baby Monitor with a towel or blanket. • Test this monitor and all its functions so that you a…

Text truncated - open the document above for the full version.

User’s Guide Digital Audio Baby Monitor Models: MBP161TIMER, MBP161TIMER-2 The features described in this User’s Guide are subject to modifications without prior notice. Welcome... to your new Motorola Digital Audio Baby Monitor! Thank you for purchasing the Digital Audio Baby Monitor. Now you can hear your baby sleeping in another room. The Digital Audio Baby Monitor also comes with a baby care timer that can help you remember important baby- care tasks or maintain your baby's feeding, diaper change and napping schedule when he or she is with other caregivers Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product-related questions, please call: This User's Guide provides you with all the information you need to get the most from your product. Before you use the digital audio baby monitor, we recommend that you insert and fully charge the battery in the parent unit, so that it continues to work if you disconnect it from the electrical outlet to carry it to another location. Please read the Safety Instructions on page 7 before you install the units. Got everything? • 1 x Parent unit with desktop stand • 1 x Baby unit • 1 x Rechargeable Ni-MH battery pack for the Parent unit • 1 x Battery door for Parent unit • 1 x Power adapter for Parent unit • 1 x Power adapter for Baby unit In packs with multi baby units, you will find one or more additional baby units with power adapters. US and Canada 1-888-331-3383 Email: [email protected] Overview of the Parent Unit 1.Sound Level Indicator 2.LCD Display 3.Timer Buttons 4.Control Key Panel UP / VOLUME + Press to increase speaker volume. While in a menu, press to scroll up. DOWN / VOLUME - Press to decrease speaker volume. While in a menu, press to scroll down. POWER ON/OFF Press and hold to power on or off. Press to turn the screen on or off. MENU/SELECT Press to enter the menu. While in a menu, press to choose an option, or save a setting. TALK T Press and hold to talk to the baby unit. 5.Night Light Press to turn nightlight on or off. 6.Microphone 7.Lullaby Press to start or stop lullaby playback. In timer setting: Press to reset timer to 00-00. 8.Power jack 9.Speaker 10.Battery compartment cover 11.Desktop Stand 7 1 4 5 9 10 11 8 2 3 6 Parent Unit display icons Connection status - Displays when the parent unit is linked to the baby unit. - Flashes when the link between the baby unit and the parent unit is lost or the parent unit is out of range of the baby unit. Battery status - scrolls when battery is charging. - displays when battery is fully charged. - displays when battery is low and needs charging. - displays when battery is empty and needs charging. Sound Alert - Displays when sound alert is ON. - Flashes when sound alert is triggered. Vol um e o ff - Displays when speaker volume is turned off. Nightlight - Displays when nightlight is ON. Lullaby - Displays when lullaby is playing. Overview of the Baby Unit 1 2 3 4 5 6 Important guidelines for installing your digital audio baby monitor • To use your baby unit and parent unit together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions. • Any large metal object, like a refrigerator, a mirror, a filing cabinet, a metallic door or reinforced concrete, between the baby unit and parent unit may block the radio signal. • The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. • If the signal is poor, try moving the parent unit and/or the baby unit to different positions in the rooms. 1.Te m p e r a t u r e S e n s o r 2.Speaker 3.Power jack 4.Power/Link indicator On steadily when the baby unit is powered on and linked to the parent unit. Off when the baby unit is powered off. Flashes when the baby unit is out of range of the parent unit. 5.Control Key Panel UP / VOLUME + Press to increase speaker volume. DOWN / VOLUME - Press to decrease speaker volume. POWER/ LULLABY Press and hold to power the baby unit on or off. In idle mode: Press to enter lullaby menu. In lullaby menu: Press to play or select lullaby. PLAY/STOP Press to start or stop lullaby playback. NIGHT LIGHT Press to turn nightlight on or off. 6.Microphone 6Table of contents Table of contents 1.Safety Instructions ..................................................................................... 7 2.Getting Started........................................................................................ 10 2.1Baby unit power supply............................................................................. 10 2.2Parent unit battery installation and power supply .................................... 11 2.3Belt clip/stand on parent unit.................................................................... 12 3.Using Your Digital Audio Baby Monitor.................................................. 13 3.1Power on or off .......................................................................................... 13 3.2Speaker volume ........................................................................................ 13 3.3Nightlight ................................................................................................... 14 3.4Timers ........................................................................................................ 14 3.5Lullaby ....................................................................................................... 17 3.6Select display language for the parent unit .............................................. 17 3.7Turn sound alert on or off .......................................................................... 18 3.8Talk to the baby unit ....................…

Text truncated - open the document above for the full version.
