VLJ-MBP36BXLBU5inch Video Baby Monitor

User’s Guide 5" Video Baby Monitor The features described in this user’s guide are subject to modifications without prior notice. Models: MBP36XL, MBP36XL-2, MBP36XL-3, MBP36XL-4 Welcome... to your new Motorola Digital Video Baby Monitor! Thank you for purchasing your new Motorola Digital Video Baby Monitor. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their playroom. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product related questions, please call: Live Chat: motorolastore.support/en. Email: [email protected] On the Web: www.motorolastore.com/support This User’s Guide provides you with all the information you need to get the most from your product. Before you can use the Baby Monitor, we recommend you fully charge the battery in the Parent Unit, so that it continues to work if you disconnect it from the power supply to carry it to another location. Please read the Safety Instructions on page 8 before you install the units. Got everything? • 1 x Parent Unit • 1 x Baby Unit (Camera) • 1 x Power adapter for the Parent Unit • 1 x Power adapter for the Baby Unit In multi-camera packs, you will find one or more additional camera and power adapter units. Overview of the Parent Unit 1. Display (LCD screen) 2. VIDEO ON/OFF button V Press to turn the LCD screen ON/ OFF 3. TALK button T Press and hold to speak to your baby 4. RESET button (recessed - use small pin) 5. UP button + Normal Mode: Tilt up Up Menu Mode: Up 6. DOWN button - Normal Mode: Tilt Down Menu Mode: Down 7. MENU button M Press to open the Menu options 8. OK button O 9. Power adapter socket 10. LEFT button < Normal Mode: Pan Left Menu Mode: Left 11. RIGHT button > Normal Mode: Pan Right Menu Mode: Right 12. Power Adapter LED: BLUE when mains adapter power on. 13. Unit ON/OFF LEDs (Green) 14. Audio Level LEDs (Green, Orange, Red, Red) 15. Volume buttons Press -/+ to decrease/ increase Volume level on Parent Unit 16. Power button 0 Press and Hold to turn the unit ON/OFF 17. Microphone 18. Stand 19. Speaker 20. Antenna 2 4 5 6 3 1 12 7 8 9 10 11 19 20 13141516 17 18 V Parent Unit menu icons Signal Level (5 Levels) Night Vision Mode (Screen changes to Black/White) Talk Mode Battery Level Indication (4 Levels) Pan Left Pan Right Tilt Up Tilt Down Zoom Level Control (1X, 2X) Brightness Level Control (8 Levels) Lullaby Control (5 Sound Selections) Alarm Setting (6h, 4h, 2h, Off) Temperature scale select ( 0 C / 0 F) Readings display in BLUE, but turn RED > 29 0 C / 84 0 F, or < 14 0 C / 57 0 F Displays HH 0 C / 0 F if >36 0 C / 97 0 F. Displays LL 0 C / 0 F if < 1 0 C / 34 0 F. Camera Control ( del, add, view, scan ) V Set Screen Off Timer (Off , 5 min, 30 min, 60 min) Indicates the screen off timer is set Volume Level Control (8 Levels) No Baby Unit detected View multiple cameras on screen. Available when you have more than 1 Baby Unit (Camera). Overview of the Baby Unit Important guidelines for installing your Baby Monitor • To use your Video Monitor Baby and Parent Units together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions. • Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or reinforced concrete between the Baby and Parent Unit may block the radio signal. • The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. • Use of other 2.4 GHz products, such as wireless networks (Wi- Fi ® routers), Bluetooth™ systems, or microwave ovens, may cause interference with this product, so keep the Baby Monitor away at least 1 metre(3ft) from these types of products, or turn them off if they appear to be causing interference. • If the signal is weak, try moving the Parent and/or the Baby Unit to different positions in the room(s). 1. Photo Sensor (Night Vision Mode) 2. Camera Lens 3. Infrared LEDs (x8, for night vision) 4. Power LED 5. Microphone 6. Camera Battery LED Flashes when AC power is connected to the camera. 7. POWER ON/OFF switch 8. Temperature Sensor 9. Power Adapter Socket 10. PAIR button 11. Speaker 12. Star Grip or Tripod Mount 6 7 1 2 3 4 5 9 10 12 8 11 6 Table of contents Table of contents 1. Safety Instructions ..........................................................................7 2. Getting Started ..............................................................................10 2.1 Baby Unit Power Supply ......................................................................10 2.2 Parent Unit Power Supply ....................................................................11 2.3 Registration (Pairing)............................................................................12 3. Using the Baby Monitor ...............................................................13 3.1 Setting up ..................................................................................................13 3.2 Pan and Tilt ...............................................................................................13 3.3 Night Vision Mode ..................................................................................13 3.4 Talk Mode ...................................................................................................13 3.5 Video ON/OFF ........................................................................................13 3.6 Temperature Display (HH °C / °F or LL °C / °F) ........................14 4. Parent Unit Menu Options ...........................................................15 4.1 Volume ........................................................................................................1…

Text truncated - open the document above for the full version.

Binatone Electronics International Ltd. Date: Oct. 23, 2020 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: VLJ-MBP36BXLBU To whom it may concern: We, the undersigned, hereby authorize SGS Hong Kong Limited and YW Yung in SGS Hong Kong Limited to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Binatone Electronics International Ltd. This authorization is valid until further written notice from the applicant. Name (Printed): Sam Lee Title: Product Director Signature: On behalf of Company: Binatone Electronics International Limited Telephone: 852-2802 7388 E-mail: [email protected]

Appendix A: External Photo of HKEM2005000448AT For model: MBP50BU For model: MBP36XLBU

Part Name: Product Label Set_NA Binatone Labeling File Part Name: Baby Unit Revision History:V1 20200507 Initial release.V2 20200513 Add sticker to pull out antenna. Serial Number - Model Number: 43641 = MBP36BXL - Produce date: 0E= May/2020- Serial no. start from ‘000001’ (6 digits)- Code Format: code 128- Size: 30 x 10 mm (on Gift box and cartoon) Rating Label(BU)Material: 50# PETSize : 31.5 x 31.5 mm 436410E000001 Use Only Power Supplies listed in the user’s guide. SN: 436410E000001 QR Code MODEL: MBP36XLBUINPUT: DC5V 1000mAFCC ID: VLJ-MBP36BXLBUIC: 4522A-MBP36BXLBUHVIN MBP36BXLBU MADE IN CHINA PIN1(+) PIN5(-) Use Only Power Supplies listed in the user’s guide. SN: 436410E000001 QR Code MODEL: MBP36XLBUINPUT: DC5V 1000mAFCC ID: VLJ-MBP36BXLBUIC: 4522A-MBP36BXLBUHVIN MBP36BXLBU MADE IN CHINA PIN1(+) PIN5(-) Remark: compliance statement was listed in manual due to surface and interface limitation reason.

Appendix B: Internal Photo of HKEM2005000448AT For model: MBP50BU For model: MBP36XLBU

Report No.: HKEM200500044802 Page: 1 of 60 Law Man Kit EMC Manager This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request and accessible at http://www.sgs.com/en/Terms-and-conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-conditions.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. T he document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. TEST REPORT Application No.: HKEM2005000448AT Applicant: BINATONE ELECTRONIC INTERNATIONAL LIMITED Address of Applicant: FCC Address 1: 25/F, Guangdong Investment Tower, 148 Connaught Road, Central, Sheung Wan, Hong Kong, China ISED Address 2: Flat 23A, 9 Des Voeux Road West Sheung Wan, Hong Kong, China Equipment Under Test (EUT): EUT Name: 5” Video Baby Monitor (Baby Unit) Model No.: MBP50BU, MBP36XLBU Additional model: Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. FCC ID: VLJ-MBP36BXLBU IC: 4522A- MBP36BXLBU HVIN: MBP36BXLBU Standard(s) : 47 CFR Part 15, Subpart C 15.247 RSS-247 Issue 2: May 2017 RSS-Gen: Issue 5 Amdt 2019 Date of Receipt: 2020-05-15 Date of Test: 2020-09-01 to 2020-09-20 Date of Issue: 2020-10-12 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Report No.: HKEM200500044802 Page: 2 of 60 Revision Record Version Chapter Date Modifier Remark 01 2020-09-07 Original Authorized for issue by: Leo Xu /Project Engineer Date: 2020-09-07 Law Man Kit /Reviewer Date: 2020-09-07 Report No.: HKEM200500044802 Page: 3 of 60 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.247(a)(1),(g),(h) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.5 47 CFR Part 15, Subpart C 15.247(b)(1) Pass 20dB Bandwidth 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.7 47 CFR Part 15, Subpart C 15.247(a)(1) Pass Carrier Frequencies Separation 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.2 47 CFR Part 15, Subpart C 15.247a(1) Pass Hopping Channel Number 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.3 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Dwell Time 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.4 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Conducted Band Edges Measurement 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.6 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 7.8.8 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement RSS-247 Issue 2, February 2017 N/A RSS-Gen Section 6.8 Pass Pseudorandom Frequency Hopping Sequence RSS-247 Issue 2, February 2017 N/A RSS-247 Section 5.1(a) Pass Report No.: HKEM200500044802 Page: 4 of 60 Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 6.2 RSS-Gen Section 8.8 Pass 99% Bandwidth RSS-247 Issue 2, February 2017 ANSI C63.10 Section 6.9.3 RSS-Gen Section 6.7 Pass Conducted Peak Output Power RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 7.8.5 RSS-247 Section 5.4(b) Pass 20dB Bandwidth RSS-247 Issue 2, February 2017 ANSI C63.10 Section 6.9.2 RSS-247 Section 5.1(a) Pass Carrier Frequencies Separation RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 7.8.2 RSS-247 Section 5.1(b) Pass Hopping Channel Number RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 7.8.3 RSS-247 Section 5.1(d) Pass Dwell Time RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 7.8.4 RSS-247 Section 5.1(d) Pass Conducted Band Edges Measurement RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section7.8.6 RSS-247 Section 5.5 Pass Conducted Spurious Emissions RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 7.8.8 RSS-247 Section 5.5 Pass Radiated Emissions which fall in the restricted bands RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 6.10.5 Section 3.3 & RSS-Gen Section 8.10 Pass Radiated Spurious Emissions RSS-247 Issue 2, February 2017 ANSI C63.10 (2013) Section 6.…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/8003201 Page : 1 of 34 FCC SAR TEST REPORT Application No: ZR/2020/80032 Applicant: BINATONE ELECTRONIC INTERNATIONAL LIMITED Address of Applicant: 25/F, Guangdong Investment Tower, 148 Connaught Road, Central, Sheung Wan, Hong Kong, China Manufacturer: BINATONE ELECTRONICS INTERNATIONAL LIMITED Product Name: 5” Video Baby Monitor (Baby Unit) Model No.(EUT): MBP50BU, MBP36XLBU Trade Mark: motorola FCC ID: VLJ- MBP36BXLBU Standards: FCC 47CFR §2.1093 Date of Receipt: 2020-08-12 Date of Test: 2020-09-09 to 2020-09-09 Date of Issue: 2020-11-05 Test conclusion: PASS * * In the configuration tested, the EUT detailed in this report complied with the standards specified above. Authorized Signature: Derek Yang Wireless Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/8003201 Page : 2 of 34 REVISION HISTORY Report Number Revision Description Issue Date ZR/2020/8003201 01 Original 2020-11-05 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/8003201 Page : 3 of 34 TEST SUMMARY Frequency Band Maximum Reported SAR(W/kg) Body 2.4G (user-defined) 0.24 SAR Limited(W/kg) 1.6 Approved & Released by Simon Ling SAR Manager Tested by Jackson Li SAR Engineer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/8003201 Page : 4 of 34 CONTENTS 1 GENERAL INFORMATION .....................................................................................................................................6 1.1 DETAILS OF CLIENT ...........................................................................................................................................6 1.2 TEST LOCATION.................................................................................................................................................6 1.3 TEST FACILITY ...................................................................................................................................................7 1.4 GENERAL DESCRIPTION OF EUT .......................................................................................................................8 1.4.1 DUT Antenna Locations .............................................................................................................................9 1.5 TEST SPECIFICATION ....................................................................................................................................... 10 1.6 RF EXPOSURE LIMITS ...................................................................................................................................... 11 2 LABORATORY ENVIRONMENT ........................................................................................................................ 12 3 SAR MEASUREMENTS SYSTEM CONFIGURATION ...................................................................................... 13 3.1 THE SAR MEASUREMENT SYSTEM.................................................................................................................. 13 3.2 ISOTROPIC E-FIELD PROBE EX3DV4 .............................................................................................................. 14 3.3 DATA ACQUISITION ELECTRONICS (DAE) ....................................................................................................... 15 3.4 SAM TWIN PHANTOM ...................................................................................................................................... 15 3.5 ELI PHANTOM ................................................................................................................................................. 16 3.6 DEVICE HOLDER FOR TRANSMITTERS .............................................................................................................. 17 3.7 MEASUREMENT PROCEDURE ........................................................................................................................... 18 3.7.1 Scanning procedure ................................................................................................................................. 18 3.7.2 Data Storage ............................................................................................................................................. 20 3.7.3 Data Evaluation by SEMCAD .................................................................................................................. 20 4 SAR MEASUREMENT VARIABILITY AND UNCERTAINTY ............................................................................ 22 4.1 SAR MEASUREMENT VARIABILITY ................................................................................................................... 22 4.2 SAR MEASUREMENT UNCERTAINTY ................................................................................................................. 22 5 DESCRIPTION OF TEST POSITION ................................................................................................................... 23 5.1 BODY EXPOSURE CONDITION .......................................................................................................................... 23 6 SAR SYSTEM VERIFICATION PROCEDURE ................................................................................................... 24 6.1 TI…

Text truncated - open the document above for the full version.

Appendix C: Setup Photo of HKEM2005000448AT Conducted Emissions at Mains Terminals Test Setup For model: MBP50BU For mode: MBP36XLBU Radiated Emissions (30MHz-1GHz) Test Setup For model: MBP50BU For mode: MBP36XLBU Radiated Emissions (Above 1GHz) Test Setup For model: MBP50BU For mode: MBP36XLBU Conducted RF Output Power Test Setup For mode: MBP36XLBU
