VLJ-MBP622BU2.4GHz Baby Monitor - Baby Unit

User’s Guide Digital Video Baby Monitor Models: MBP622, MBP622-2, MBP622-3, MBP622-4 The features described in this User’s Guide are subject to modifications without prior notice. Welcome... to your new Motorola Digital Video Baby Monitor! Thank you for purchasing this Baby Monitor. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their playroom. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product related questions, please call: This User's Guide provides you with all the information you need to get the most from your product. Before you can use the baby monitor, we recommend you insert and fully charge the battery in the Parent Unit, so that it continues to work if you disconnect it from the power supply to carry it to another location. Please read the Safety Instructions on pages 7 - 9 before you install the units. Got everything? • 1 x Parent Unit • 1 x Baby Unit (camera) • 1 x Rechargeable Ni-MH battery pack for the Parent Unit • 1 x Power adapter for the Parent Unit • 1 x Power adapter for the Baby Unit In multi-camera packs, you will find one or more additional camera units with power adapter units. US and Canada 1-888-331-3383 Email: [email protected] On the Web: www.motorolamonitors.com POWER 1 10 14 13 12 11 15 9 2 7 5 34 6 8 Overview of the Parent Unit 1.Display (LCD screen) 2.Up/Volume+ Button Press to increase sound volume. Press to scroll up menu options/ settings. Press to tilt up in zoom mode. 3.Down/Volume- Button Press to decrease sound volume. Press to scroll down menu options/ settings. Press to tilt down in zoom mode. 4.Return Button Press to return to previous menu level. Press to pan left in zoom mode. 5.Switch Camera Button Press to switch between Camera Units. (If paired with more than one Camera) Press to pan right in zoom mode. 6.Zoom Button Press once to switch to 2X Zoom mode. Press again to return to normal mode (1X). 7.Menu/OK Button Press to open the menu options. Press to confirm a selection. 8.Power indicator LED (Blue) when mains adapter power is ON. 9.Unit ON/OFF LED (Green) 10.Audio Level LED (Green, Orange, Red, Red) 11.Power / Video On-Off Button P Press and hold to switch the Unit ON or OFF. In monitor mode, press to turn the LCD screen ON/OFF. 12.Battery compartment cover 13.Stand 14.Speaker 15.Power Adapter Socket Parent Unit menu icons Signal Level Indication (3 Levels) No signal from the Baby Unit - out of range or turned off Night Vision Mode (Video also changes to Black/White) Battery Level Indication (4 Levels) Volume Level Control (8 Levels + Off) Brightness Level Control (8 Levels) Alarm Setting (6h, 4h, 2h, OFF) Select Camera to view Add Camera Delete Camera Camera scan mode set Zoom Select - icon displays when in Zoom (2X) mode. N * Overview of Your Baby Unit Important guidelines for installing your Baby Monitor • To use your Video Monitor Baby and the Parent Unit together, you must be able to establish a radio link between them, and the range may be affected by environmental conditions. • Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or reinforced concrete between the Baby and Parent Units may block the radio signal. • The signal strength may also be reduced by other solid structures, like walls or electrical equipment, such as radios, TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. • Use of other 2.4 GHz products, such as wireless networks (Wi-Fi ® routers), Bluetooth ® systems, or microwave ovens, may cause interference with this product, so keep the Baby Monitor at least 5 feet (1.5 meters) from these types of products, or turn them off if they appear to be causing interference. • If the signal is weak, try moving the Parent and/or the Baby Unit to different positions in the rooms. 1. Photo Sensor (Night Vision Mode)6. Power Adapter Socket 2. Camera Lens7. Pair Key 3. Infrared LEDs (8)8. Microphone 4. Power LED 5. ON/OFF Switch 5 1 2 4 3 6 7 8 Table of contents6 ENGLISH Table of contents 1.Safety Instructions ..................................................................................... 7 2.Getting Started ........................................................................................ 10 2.1Baby Unit Power Supply ............................................................................ 10 2.2Parent Unit Battery Installation .................................................................. 10 2.3Parent Unit Power Supply ......................................................................... 11 2.4Registration (Pairing)................................................................................. 13 3.Using the Baby Monitor ........................................................................... 14 3.1Setting Up .................................................................................................. 14 3.2Night Vision Mode..................................................................................... 14 3.3Video ON/OFF.......................................................................................... 14 4.Parent Unit Menu Options....................................................................... 15 4.1Volume....................................................................................................... 15 4.2Brightness .................................................................................................. 15 4.3Zoom, Pan and Tilt..................................................................................... 15 4.4Alarm.......................................................................................................... 15 4.5Camera Control ......................................................................…

Text truncated - open the document above for the full version.

Appendix B1 Letter of Agency for FCC Certification 26 Jun 2015 To whom it may concern, Letter of Agency I, an officer of Binatone Electronics International Ltd do hereby authorize Intertek Testing Services (Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Karl Heinz Mueller, CTO

26 Jun 2015 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: VLJ-MBP622PU, VLJ-MBP622BU Request is hereby submitted by Binatone Electronics International Limited to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and Binatone Electronics International Limited reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of Binatone Electronics International Limited and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Karl Heinz Mueller, CTO

MBP622_NA(TRU)_LABEL SET 3) Size : 35 x 5mm(On Unit/Gift box), 60x25mm(On Carton) 15=Year (2015), 03=Month(March) Your factory code is ‘A’ Serial no. start from ‘000001’ (6 digits) Serial Number label on Gift box/Carton box Code Format: code 128 Produce date: 1) Colour: White background black letters 2) Material: adhesive label with plastic lamination on top Checking digit: Z Use only Power Supplies listed in the user’s guide. Made in China Model: MBP622BU Input: DC6V 500mA FCC ID: VLJ-MBP622BU IC: 4522A-MBP622BU A1503Z000001 MBP622 BABY UNIT please call at: To obtain servic e or information, Or Email: [email protected] US and Canada 1-888-331-3383 Helpline Label on BU 3) Size : 30 x 10mm(or fit to the unit). 1) Colour: White background black letters. 2) Material: adhesive label with plastic lamination on top. Rating Label on BU 3) Size : 35 x 20mm(or fit to the unit). 1) Colour: White background black letters. 2) Material: adhesive label with plastic lamination on top. MBP662_NA(TRU)_LABEL SET 3) Scale: 1:1, size:40 x 20mm 1) Colour: White background black letters 2) Material: label paper with plastic lamination on top Rating Label ( Parent Unit) listed in the user’s guide. Use only Batteries and Power Supplies Made in China Model: MBP622PU Input: DC6V 500mA Ni-MH Battery pack 3.6V, 900mAh Rechargeable Batteries only RED BLACK A1503Z000001 Produce date: 15=Year (2015), 03=Month (March) Your factory code is ‘A’ Serial Number Label 3) Size:40 x 10mm(on Unit and Gift box), 60x25mm(on Carton box). Stick on Camera bottom, Gift box and Carton box. Serial no. start from ‘000001’ (6 digits) 1) Colour: White background black letters. 2) Material: adhesive label with plastic lamination on top. Checking digit: Z Code Format: code 128 MBP622 PARENT UNIT FCC ID: VLJ-MBP622PU IC: 4522A-MBP622PU A 1503Z000001 listed in the user’s guide.Use only Batteries and Power Supplies Made in China Model: MBP622PUInput: DC5V 600mANi-MH Battery pack 3.6V, 900mAhRechargeable Batteries only RED BLA CK FCC ID: VLJ-MBP622PUIC: 4522A-MBP622PU WARNING TAG on Power Adapter Warning Tag (for NA) 3) Size: 40 x 250 MM 2) Material: 50# Polyester Matte, PP COATING. 1) Printing: Orange PANTONE 151C. WARNING TAG Model: MBP622 www.motorola.com Model/Modèle: MBP622Model/Modèle: MBP622Modèle: MBP622 watch them dream Digital Video Baby Monitor Moniteur vidéo bébé numérique Contenu de la boîte Unité parents avec écran couleur diagonal de 2,4 pouces Unité bébé (Audio/Vidéo) Mode d’emploi Guide de démarrage rapide Batterie rechargeable (l’unité parents) Adaptateur d’alimentation (l’unité parents) Adaptateur d’alimentation (l’unité bébé) Veuillez contacter le service clientèle pour les questions/commentaires, garantie, soutien ou d’un service lié au produit: 1-888-331-3383 (US/Canada) Email: [email protected] Features Wireless Technology: 2.4 GHz FHSS 2.4" Diagonal Color Screen High Sensitivity Microphone Infrared Night Vision Up to 520ft Range * Out-of-Range Alert Support Stand Volume Control Sound Level Indicator Low Battery Alert Rechargeable Battery (Parent Unit) Digital Video Baby Monitor Moniteur vidéo bébé numérique 2.4" Diagonal Color Screen Écran d’affichage couleur diagonal de 2,4 pouces watch them dream regardez-les rêver High Sensitivity Microphone Microphone à haute sensibilité Infrared Night Vision Vision nocturne infrarouge High Sensitivity Microphone Microphone à haute sensibilité Infrared Night Vision Vision nocturne infrarouge Monitéur vidéo bébé numérique Caractéristiques Écran d’affichage couleur diagonal de 2,4 pouces Microphone à haute sensibilité Vision nocturne infrarouge Portée jusqu’à 160m * Fonction d’alerte hors de portée Support Contrôle de volume Indicateur de volume Avertisseur de batterie faible Batterie rechargeable (l’unité parents) * Quand il y a une ligne de vue dégagée entre l’unité parents et l’unité bébé. Tout obstacle entre l’unité parents et l’unité bébé réduira sensiblement la portée. Quand les deux unités sont à l’intérieur, la portée typique est de 30 mètres. Digital Video Baby Monitor * When there is a clear line of sight between parent and baby units. Any obstruction between parent and baby units will reduce the r With parent and baby units indoors, the typical range is up to 100 feet. Inside the Box Parent Unit with 2.4" Diagonal Color Screen Baby Unit (Audio/Video) User’s Guide Quick Start Guide Rechargeable Battery Pack (Parent Unit) Power Adapter (Parent Unit) Power Adapter (Baby Unit) Please contact customer service for questions/comments, warranty, support or service related to the product at: 1-888-331-3383 (US/Canada) Email: [email protected] AVERTISSEMENT: Risque d'étranglement : des enfants ont été ÉTRANGLÉS dans des cordons. Garder ce cordon hors de portée des enfants (plus de 1 métre d'écart). Ne jamais utiliser de rallonges avec des adaptateurs CA. Utiliser les adaptateurs CA fournis seulement. WARNING: Strangulation Hazard: Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 3ft (1m) away). Never use extension cords with AC Adapters. Only use the AC Adapters provided. SERIAL NUMBER Manufactured, distributed or sold by Binatone Electronics International LTD., official licensee for this product. MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license. All other trademarks are the property of their respective owners. © 2015 Motorola Mobility LLC. All rights reserved. The actual product may vary slightly from the photograph. Screen images are simulated. Fabriqué, distribué et vendu par Binatone Electronics International LTD., licencié officiel pour ce produit. Motorola et le logo M stylisé sont des marques de commerce ou des marques de commerce déposées de Motorola Trademark Holdings, LLC. et sont utilisées sous licence. Toutes les autres marques déposées sont la propriété de leurs propriétaires respectifs. © 2015 Motorola Mobility L…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES FCC ID: VLJ-MBP622BU RF exposure - 1 of 1 For Maximum Permissible Exposure (MPE) evaluation of the base unit, the maximum power density at 20 cm from this mobile transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65 and meet the requirement listed in KDB447498. For the 2.4GHz Baby Monitor - Baby Unit of tested model: MBP622BU, the measured powers among all the measured channels were within its production tolerance: +16 dBm (Minimum) and +20 dBm (Maximum).The antenna gain of MBP622BU is 0 dBi = 1.00 (num gain) and its maximum source-based time- averaging duty factor is 26.7% (125/468 x100%). From these data and its operating configuration – Mobile device, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The Conducted Power = 20 dBm = 100.0 mW The Conducted Power source-based time-averaging output power = (100.0 * 0.267) mW = 26.7 mW The power density at 20cm = 26.7 *1.00/ 4πR 2 = 0.0053 mW cm -2 In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm -2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the base unit at least 20cm from nearby persons.”

- Intertek’s standard Terms and Conditions can be obtained at our website: http://www.intertek.com/terms/. - The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report Number: 15060142HKG-001R2 Application for Original Grant of 47 CFR Part 15 Certification New Family of RSS-210 Issue 8 Equipment Certification 2.4GHz Frequency Hopping Spread Spectrum Baby Monitor - Baby Unit FCC ID: VLJ-MBP622BU IC: 4522A-MBP622BU This report supersedes previous report with report number(s) 15060142HKG-001R1 dated July 14, 2015. Please refer TC-SP1091 Letter issued on July 22, 2015 for the detail Amendment Summary. Prepared and Checked by: Approved by: Signed on File _______________________ Tang Kwan Mo, Jess Chan Chi Hung, Terry Lead Engineer Senior Supervisor July 22, 2015 INTERTEK TESTING SERVICES Test Report Number: 15060142HKG-001R2 Page 1 of 47 FCC ID: VLJ-MBP622BU IC: 4522A-MBP622BU GENERAL INFORMATION Applicant Name: Binatone Electronics International Limited Applicant Address: Floor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2013 Edition FCC ID: VLJ-MBP622BU FCC Model(s): MBP622BU, MBP622-2BU, MBP622-3BU, MBP622-4BU, MBP25SBU, MBP25S-2BU, MBP25S-3BU, MBP25S-4BU, MBP26SBU, MBP26S-2BU, MBP26S-3BU, MBP26S-4BU IC Specification Standard: RSS-210 Issue 8, December 2010 RSS-Gen Issue 3, December 2010 IC: 4522A-MBP622BU IC Model(s): MBP622BU, MBP622-2BU, MBP622-3BU, MBP622-4BU, MBP25SBU, MBP25S-2BU, MBP25S-3BU, MBP25S-4BU, MBP26SBU, MBP26S-2BU, MBP26S-3BU, MBP26S-4BU Type of EUT: Spread Spectrum Transmitter Description of EUT: 2.4GHz Frequency Hopping Spread Spectrum Baby Monitor - Baby Unit Serial Number: N/A Sample Receipt Date: June 02, 2015 Date of Test: June 09, 2015 to July 08, 2015 Report Date: July 22, 2015 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Test Report Number: 15060142HKG-001R2 Page 2 of 47 FCC ID: VLJ-MBP622BU IC: 4522A-MBP622BU Table of Contents 1.0 Test Results Summary & Statement of Compliance............................................... 4 1.1 Summary of Test Results.......................................................................................... 4 1.2 Statement of Compliance .......................................................................................... 4 2.0 General Description................................................................................................... 6 2.1 Product Description ................................................................................................... 6 2.2 Test Methodology...................................................................................................... 6 2.3 Test Facility ...............................................................................................................6 3.0 System Test Configuration........................................................................................ 8 3.1 Justification ...............................................................................................................8 3.2 EUT Exercising Software .......................................................................................... 9 3.3 Details of EUT and Description of Accessories ....................................................... 10 3.4 Measurement Uncertainty ....................................................................................... 10 4.0 Test Results.............................................................................................................. 12 4.1 Maximum Conducted Output Power at Antenna Terminals ..................................... 12 4.2 Maximum 20 dB RF Bandwidth............................................................................... 15 4.3 Minimum Number of Hopping Frequencies ............................................................. 18 4.4 Minimum Hopping Channel Carrier Frequency Separation ..................................... 20 4.5 Average Channel Occupancy Time......................................................................... 23 4.6 Out of Band Conducted Emissions.......................................................................... 26 4.7 Field Strength Calculation ....................................................................................... 31 4.8 Transmitter Radiated Emissions in Restricted Bands and Spurious Emissions ....... 32 4.8.1 Radiated Emission Configuration Photograph ...................................................... 33 4.8.2 Radiated Emission Data....................................................................................... 33 4.8.3 Transmitter Duty Cycle Calculation ...................................................................... 39 4.9 AC Power Line Conducted Emission...................…
