VLJ-MBP854HDSPUDigital Baby Monitor (Parent Unit)

UserDs Guide Digital Video Baby Monitor With Wi-Fi ® Internet Viewing Models: MBP854CONNECT, MBP854CONNECT-2, MBP854CONNECT-3, MBP854CONNECT-4 The features described in this UserCs Guide are subject to modifications without prior notice. Welcome... to your new Motorola Digital Video Baby Monitor! Thank you for purchasing your new Motorola Digital Video Baby Monitor. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their playroom. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product related questions, please call: This User's Guide provides you with all the information you need to get the most from your product. Before you can use the Baby Monit or, we re comme nd you f ully ch arge t he battery in the Parent Unit, so that it continues to work if you disconnect it from the power supply to carry it to another location. Please read the Safety Instructions on page 8 before you install the units. Got everything? ʻ 1 x Parent Unit ʻ 1 x Baby Unit (Camera) ʻ 1 x Power adapter for the Parent Unit ʻ 1 x Power adapter(s) for the Baby Unit In multi-camera packs, you will find one or more additional camera units with power adapter units and battery packs. US and Canada 1-888-331-3383 Email: [email protected] Overview of the Parent Unit 1.Display (LCD screen) 2.Video ON/OFF KeyV Press to turn the LCD display ON/ OFF 3.Talk KeyT Press and hold to speak to your baby 4.Up Key+ Normal Mode: Tilt Up Menu Mode: Up 5.Down Key- Normal Mode: Tilt Down Menu Mode: Down 6.Microphone 7.Menu KeyM Press to open the Menu options 8.OK KeyO 9.Left Key< Normal Mode: Pan Left Menu Mode: Left 10.Right Key> Normal Mode: Pan Right Menu Mode: Right 11.Power Adapter / Battery LED BLUE when connected to an electrical outlet. RED when battery low. 12.Unit ON/OFF LED (Green) 13.Audio Level LED (Green, Orange, Red) 14.Power Key0 Press and Hold to turn the unit ON/ OFF 15.Volume Key Press -/+ to decrease/increase Volume level on Parent Unit 16.Reset Key 17.SD Card socket 18.Micro USB Socket 19.Stand 20.Speaker 21.Antenna Raise the antenna for optimal reception Parent Unit menu icons Signal Level (4 Levels) Night Vision Mode (Screen changes to Black/White) Talk Mode Battery Level Control (4 Levels) Pan Left Pan Right Tilt Up Tilt Down Zoom Level Control (1X, 2X) Brightness Level Control (8 Levels) Lullaby Control (5 Song Selections) Alarm Setting (6h, 4h, 2h, Off) Temperature Reading (HH ºC / ºF or LL ºC / ºF) Icon & readings turn RED> 29ºC / 84ºF, and reading display HH ºC / ºF> 36ºC / 97 ºF Icon & readings turn RED< 14ºC / 57ºF, and reading display LL ºC / ºF< 1ºC / 34 ºF Camera Control (scan, view, add, delete) Local Recording (Record, Play) Set Video On Timer (5 min, 30 min, 60 min) Time Setting (Date, Time format 12/24 Hour and Time) Volume Level Control (8 Levels) SD Card detection No Baby Unit detected Important guidelines for installing your Baby Monitor ʻ To use your Video Monitor Baby and Parent Units together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions. ʻ Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or reinforced concrete between the Baby and Parent Unit may block the radio signal. ʻ The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. ʻ Use of other 2.4 GHz products, such as wireless networks (Wi-Fi ® routers), Bluetooth ® systems, or microwave ovens, may cause interference with this product, so keep the Baby Monitor away at least 3ft from these types of products, or turn them off if they appear to be causing interference. ʻ If the signal is weak, try raising the Parent Unit's Antenna, moving the Parent and/or the Baby Unit to different positions in the room(s). 1. Light Sensor (for night mode detection)7. Speaker 2. Camera Lens8. Antenna 3. Infrared LEDs (for night vision)9. Micro USB socket 4. Power / Status indicator10. ON/OFF Switch 5. Microphone11. Temperature Sensor 6. PAIR Button Overview of Your Baby Unit :% 6Table of contents Table of contents 1.Safety Instructions ..................................................................................... 8 2.Getting Started........................................................................................ 11 2.1Baby Unit Power Supply............................................................................ 11 2.2Parent Unit Power Supply ......................................................................... 11 2.3Registration (Pairing) ................................................................................ 13 3.Using the Baby Monitor ........................................................................... 14 3.1Setting up .................................................................................................. 14 3.2Pan and Tilt ................................................................................................ 14 3.3Night Vision Mode .................................................................................... 14 3.4Talk Mode .................................................................................................. 14 3.5Video ON/OFF ......................................................................................... 14 3.6Temperature Display (HH °C / °F or LL °C / °F)...................................... 15 4.Parent Unit Menu Options ...................................................................... 16 4.1Volume ...................................................................................................... 16 4.2Brightness ...........................…

Text truncated - open the document above for the full version.

54Wi-Fi Internet Viewing 5.7Camera Functions: Working with PC/Notebook ʻ Go to https://app.hubbleconnected.com/#login ʻ Enter your User Name and Password andthen click Login if you have already created an account. ʻ Click on the Camera list paired in your account via Androidž device or iPhone ® /iPad ® , and the Camera view will appear on screen. You can easily stay connected with your favorite people, places and pets with live video streaming. ʻ On the website, you can change the Settings by following the Menu instructions. 5.8Procedure for Resetting the Camera Note: If your Camera is moved from one router (e.g. home) to another (e.g. office) or you have Camera setup issues, then the Camera must be reset. Please reset the Camera with the following procedures: 1.Slide the ON/OFF switch to OFF. 2.Press and hold the PAIR button then slide the ON/OFF switch to ON. 3.Release the PAIR button when you hear a confirmation beep and wait for Camera to compete internal reset procedure, the LED indicator will be red and flashes slowly when Camera is reset successfully. 4.You can add your Camera again by following the steps in section 5.3.4 for Android devices or in section 5.4.4 for iOS devices. Disposal of The Device (environment)55 6. Disposal of The Device (environment) At the end of the product lifecycle, you should not dispose of this product with normal household waste. Take this product to a collection point for the recycling of electrical and electronic equipment. The symbol on the product, user's guide and/or box indicates this. Some of the product materials can be reused if you take them to a recycling point. By reusing some parts or raw materials from used products you make an important contribution to the protection of the environment. Please contact your local authorities in case you need more information on the collection points in your area. Dispose of the battery pack in an environmentally-friendly manner according to your local regulations. 56Cleaning 7. Cleaning Clean the Baby Monitor with a slightly damp cloth or with an anti-static cloth. Never use cleaning agents or abrasive solvents. Cleaning and care ʻ Do not clean any part of the product with thinners or other solvents and chemicals F- this may cause permanentdamage to the product which is not covered by the warranty. ʻ Keep the Baby Monitor away from hot, humid areas or strong sunlight, and don't let it get wet. ʻ Every effort has been made to ensure high standards of reliability for your Baby Monitor. However, if something does go wrong, please do not try to repair it yourself F- contact Customer Service for assistance. Help57 8. Help Display No display ʻ Try recharging or replacing the battery pack. ʻ Reset the units. Disconnect the battery pack of the Parent Unit and unplug both the units' electrical power, then plug them back in. ʻ Is the unit turned on? Press and hold the ON/OFF button0 on the Parent Unit to turn it ON. ʻ Is the correct camera selected? Change the camera number, if necessary. ʻ Is the video display turned on? Press the VIDEO ON/OFF buttonV to turn it on. ʻ When operating using batteries only, the Display will go blank after 5 minutes or 30 minutes or 60 minutes to save power (depending on video settings). The unit is still active and will give you audio alerts. You can reactivate the screen by pressing any button. Registration If the Baby Unit has lost its link with the Parent Unit ʻ Try recharging or replacing the battery pack. ʻ If the Baby Unit is too far away it may be going out of range, so move the Baby Unit closer to the Parent Unit. ʻ Reset the units by disconnecting themfrom the battery and electrical power. Wait about 15 seconds before reconnecting. Allow up to one minute for the Baby Unit and the Parent Unit to synchronize. ʻ See 2.3 Registration (Pairing), if there is a need to re-register the units. 58Help Interference Noise interference on your Parent Unit ʻ Your Baby and Parent Units may be too close. Move them farther apart. ʻ Make sure there is at least 3 to 6ft (1 to 2m) between the 2 units to avoid audio feedback. ʻ lf the Baby Unit is too far away it may be out of range, so move the Baby Unit closer to the Parent Unit. ʻ Make sure the Baby and Parent Units are not near other electrical equipment, such as a television, computer or cordless/mobile telephone. ʻ Use of other 2.4 GHz products, such as wireless networks (Wi-Fi ® routers), Bluetooth ® systems, or microwave ovens, may cause interference with this product, so keep the Baby Monitor away at least 5ft (1.5m) from these types of products, or turn them off if they appear to be causing interference. ʻ If the signal is weak, try moving the Parent and/or Baby Unit to different positions in the rooms. Noise interference on your device To avoid background noise or echoes, ensure that there is enough distance between your device and the Wi-Fi ® Camera Unit. Use of other 2.4 GHz products, such as Bluetooth ® systems or microwave ovens, may cause interference with this product. Keep the Wi-Fi ® Camera Unit at least 3ft away from these types of products, or turn them off if they appear to be causing interference. Lost connection Check your Wi-Fi ® settings. If necessary reconnect your Wi-Fi ® . Ensure the Wi-Fi ® Camera Unit is switched ON. Wait a few minutes to make the connection with the Wi-Fi ® system. Help59 If you forgot your password If you do not remember your password, tap Forgot password and submit your e-mail address. A new password will be sent to your e-mail address immediately. Troubleshooting for Wi-Fi ® Internet Viewing CategoryProblem Description / Error Solution AccountI am unable to login even after registration. Please check your user name and password. AccountI receive an error message saying: "Email ID is not registered". Please ensure that you have registered with us. TapCreate Account to create an account to be able to use the Wi-Fi ® Home Video Baby Monitor Camera. AccountWhat do I do if I forgot my password? Clic…

Text truncated - open the document above for the full version.

Date (22/06/2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We, (Binatone Electronics International Limited), hereby authorize Ray Cheung (TUV SUD HK LTD) to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on (22/12/2015]). Sincerely, _______________________________(signature) Company Officer: Karl Heinz Muller Telephone Number: 852 2802 7388 Email: [email protected]

Date (22/06/2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Confidentiality Request FCC ID: VLJ-MBP854HDSPU, VLJ-FOCUS85 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, (Binatone Electronics International Limited) hereby requests permanent confidential treatment of information accompanying this application as outlined below: << List of Exhibits either by name or type e.g. “Schematics” [exhibit type] or “Design Drawings” [description of data which must be uploaded ] >> [Common exhibits for which confidentiality is requested are: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation] (Binatone Electronics International Limited) also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of (22 December, 2015) days: << List of Exhibits either by name or type e.g. “Internal Photos” [exhibit type]>> [Common exhibits for which short-term confidentiality is requested are: Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Karl Heinz Mueller (signed by FCC listed Grantee contact) Telephone Number: 852 2802 7388 Email: 852 2802 8138

Report Number: 60.870.15.005.01F TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 1 of 3 External Photos Report Number: 60.870.15.005.01F TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 2 of 3 Report Number: 60.870.15.005.01F TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 3 of 3

Produce date: 14=Year (2014), 03=Month (March) Serial Number Label Baby Unit Serial Number Label Your factory code is ‘VT’ MBP854S North America Label Set Parent Unit Label 3) Size: 24 x 10mm(on Gift box and Unit), 60 x 25mm (On Carton box) Stick on PU bottom, Gift box and Carton box. Baby Unit Rating Label PIN1(+) PIN 5(-) MBP854S BU MBP854S PU 3) Scale: 1:1, size: 35 x 24mm 1) Colour: White background black letters 2) Material: adhesive label with plastic lamination 3) Scale: 1:1, size: 24 x 23mm 1) Colour: White background black letters 2) Material: label paper with plastic lamination on top Serial no. start from ‘000001’ (6 digits) Code Format: code 128 1) Colour: White background black letters 2) Material: adhesive label with plastic lamination on top Label Area Checking digit: Z Model: MBP854CONNECTPU 3.7V, 1880mAh, Li-ion Battery IC: 4522A-MBP854HDSPU MADE IN CHINA FCC ID: VLJ-MBP854HDSPU VT1403Z005531 Model: MBP854CONNECTPU 3.7V, 1880mAh, Li-ion Battery IC: 4522A-MBP854HDSPU MADE IN CHINA FCC ID: VLJ-MBP854HDSPU VT1403Z005531 IC: 4522A-FOCUS85 MADE IN CHINA FCC ID: VLJ-FOCUS85 Model: MBP85CONNECT Use only Power Supplies listed in the user’s guide. Input: DC5V 1500mA Camera HD-0854000001 Camera UDID Label 92-004676-002-100 SIZE: 24X5MM Camera HD-0854000001 VT 1403Z005531 VT1403Z005531 PIN1(+) PIN 5(-) IC: 4522A-FOCUS85MADE IN CHINAFCC ID: VLJ-FOCUS85 M odel: MBP85CONNECT Use o nly Power Supplies listed in the user’ s guide. Input: DC5V 1500mA Produce date: 14=Year (2014), 03=Month (March) Your factory code is ‘VT’ 3) Size:20 x 11mm. Stick on Baby Unit bottom. Serial no. start from ‘000001’ (6 digits) 1) Colour: White background black letters 2) Material: adhesive label with plastic lamination on top Checking digit: Z Code Format: code 128 Warning Tag (for NA) 3) Size: 40 x 250 MM 2) Material: 50# Polyester Matte, PP COATING. 1) Printing: Orange PANTONE 151C. WARNING TAG WARNING TAG on Power Adapter(North America)

Report Number: 60.870.15.005.01F TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 1 of 4 Internal Photos Report Number: 60.870.15.005.01F TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 2 of 4 Report Number: 60.870.15.005.01F TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 3 of 4 Report Number: 60.870.15.005.01F TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 4 of 4

Report No.: 60.870.15.005.01S Page 2 of 53 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Hong Kong Science Park, Shatin, Hong Kong. Test Report Certification Applicant NameBinatone Elctronics International Limited Applicant AddressFloor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong Manufacturer NameVtech (Dongguan) Telecommunication Limited Manufacturer Address VTech Science Park, Xia Ling Bei Management Zone, Liaobu Dongguan, Guangdong, China Product DesignationDigital Video Baby Monitor (Parent Unit) Brand Name motorola Model NameMBP854CONNECTPU Different DescriptionN/A EUT VoltageDC3.7V by battery Applicable Standard IEEE Std. 1528:2003 IEEE Std. 1528a:2005 FCC 47CFR § 2.1093 IEEE/ANSI C95.1:1992 Test DateMay 25,2015 Performed Location Attestation of Global Compliance(Shenzhen) Co., Ltd. 2 F, Building 2, No.1-No.4, Chaxi Sanwei Technical Industrial Park, Gushu, Xixiang Street, Bao'an District, Shenzhen, China Report No.: 60.870.15.005.01S Page 3 of 53 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Hong Kong Science Park, Shatin, Hong Kong. TABLE OF CONTENTS 1. SUMMARY OF MAXIMUM SAR VALUE ......................................................................................................... 4 2. GENERAL INFORMATION............................................................................................................................... 5 2.1.EUTDESCRIPTION......................................................................................................................................... 5 3. SAR MEASUREMENT SYSTEM ........................................................................................................................ 6 3.1.THESATIMO SYSTEM USED FOR PERFORMING COMPLIANCE TESTS CONSISTS OF FOLLOWING ITEMS .................. 6 3.2.COMOSARE-FIELDPROBE .......................................................................................................................... 7 3.3.ROBOT .......................................................................................................................................................... 7 3.4.VIDEOPOSITIONINGSYSTEM .......................................................................................................................... 8 3.5.DEVICEHOLDER ............................................................................................................................................ 8 3.6.SAMTW INPHANTOM ..................................................................................................................................... 9 4. SAR MEASUREMENT PROCEDURE .............................................................................................................. 10 4.1.SPECIFICABSORPTIONRATE(SAR) .............................................................................................................. 10 4.2.SARMEASUREMENTPROCEDURE .................................................................................................................11 5. TISSUE SIMULATING LIQUID ......................................................................................................................... 13 5.1.THE COMPOSITION OF THE TISSUE SIMULATING LIQUID..................................................................................... 13 5.2.TISSUEDIELECTRICPARAMETERS FORHEAD ANDBODYPHANTOMS ............................................................... 13 5.3.TISSUECALIBRATIONRESULT ....................................................................................................................... 14 6. SAR SYSTEM CHECK PROCEDURE ........................................................................................................... 15 6.1.SARSYSTEMCHECKPROCEDURES ............................................................................................................. 15 6.2.SARSYSTEMCHECK ................................................................................................................................... 16 7. EUT TEST POSITION ...................................................................................................................................... 17 7.1.BODYWORNPOSITION ................................................................................................................................ 17 8. SAR EXPOSURE LIMITS ............................................................................................................................... 18 9. TEST EQUIPMENT LIST ................................................................................................................................ 19 10. MEASUREMENT UNCERTAINTY ................................................................................................................ 20 11. CONDUCTED POWER MEASUREMENT ..................................................................................................... 22 12. TEST RESULTS ........................................................................................................................................... 23 12.1.SARTESTRESULTSSUMMARY................................................................................................................... 23 APPENDIX A. SAR SYSTEM CHECK DATA ..................................................................................................... 25 APPENDIX B. SAR MEASUREMENT DATA ...................................................................................................... 27 APPENDIX C. TEST SETUP PHOTOGRAPHS &EUT PHOTOGRAPHS .......................................................... 53 APPENDIX D. CALIBRATION DATA ................................................................................................................. 53 Report No.: 60.870.15.005.01S Page 4 of 53 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Hong Kong Science Park, Shatin, Hong Kong. 1. SUMMARY OF MAXIMUM SA…

Text truncated - open the document above for the full version.

CALIBRATION DATA PROBE CALIBRATION DATA DIPOLE CALIBRATION DATA

Report Number: 60.870.15.005.01F EMC_SZ_FR_21.00 FCC Release 2014-03-20 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 1 of 39 FCC/IC - TEST REPORT Report Number: 68.850.15.005.01F Date of Issue: May 8, 2015 Model: MBP854CONNECTPU Product Type: Digital Video Baby Monitor (Parent Unit) Applicant: Binatone Electronics International Limited Address: Floor 23A, 9 Des Voeux Road West, Sheung Wan Production Facility: Vtech (Dongguan) Telecommunication Limited Address: VTech Science Park, Xia Ling Bei Management Zone, Liaobu, Dongguan, Guangdong, China Test Result: „Positive†Negative Total pages including Appendices: 39 TÜV SÜD Hong Kong Co., Ltd is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Hong Kong Co., Ltd reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Hong Kong Co., Ltd shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Hong Kong Co., Ltd issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval Report Number: 60.870.15.005.01F EMC_SZ_FR_21.00 FCC Release 2014-03-20 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 2 of 39 1 Table of Contents 1 Table of Contents ............................................................................................................................................ 2 2 Details about the Test Laboratory .................................................................................................................... 3 3 Description of the Equipment Under Test ......................................................................................................... 4 4 Summary of Test Standards ............................................................................................................................ 5 5 Summary of Test Results ................................................................................................................................ 6 6 General Remarks ............................................................................................................................................ 7 7 Test Setups ..................................................................................................................................................... 8 8 Systems test configuration ............................................................................................................................... 9 9 Technical Requirement .................................................................................................................................. 10 9.1Conducted Emission............................................................................................................................... 10 9.2Conducted peak output power ................................................................................................................ 13 9.320 dB bandwidth..................................................................................................................................... 16 9.4Carrier Frequency Separation ................................................................................................................. 19 9.5Number of hopping frequencies .............................................................................................................. 22 9.6Dwell Time ............................................................................................................................................. 24 9.7Spurious RF conducted emissions .......................................................................................................... 27 9.8Band edge testing .................................................................................................................................. 30 9.9Spurious radiated emissions for transmitter ............................................................................................ 32 10Test Equipment List ................................................................................................................................... 38 11System Measurement Uncertainty .............................................................................................................. 39 Report Number: 60.870.15.005.01F EMC_SZ_FR_21.00 FCC Release 2014-03-20 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 3 of 39 2 Details about the Test Laboratory Detailsabout the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Telephone:86 755 8828 6998 Fax:86 755 8828 5299 Report Number: 60.870.15.005.01F EMC_SZ_FR_21.00 FCC Release 2014-03-20 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 4 of 39 3 Description of the Equipment Under Test Product:Digital Video Baby Monitor (Parent Unit) Model no.:MBP854CONNECTPU FCC ID:VLJ-MBP854HDSPU IC:4522A-MBP854HDSPU Options and accessories:Adapter Rating:DC5V, 1500mA powered by AC/DC power adaptor OR DC 3.7V, 1880mAh (Li-ion package rechargeable batt…

Text truncated - open the document above for the full version.

Report Number: 60.870.15.005.01F TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin Hong Kong Page 1 of 1 Test Setup Photos

APPENDIX C. TEST SETUP PHOTOGRAPHS &EUT PHOTOGRAPHS Test Setup Photographs Body Back 0mm (Antenna Open) Body Left Body Right Body Bottom Body Back 0mm (Antenna Closed) Body Left Body Right Body Bottom Body Top . DEPTH OF THE LIQUID IN THE PHANTOM—ZOOM IN Note：The position used in the measurement were according to IEEE 1528 EUT PHOTOGRAPHS TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT OPEN VIEW OF EUT-1 OPEN VIEW OF EUT-2 OPEN VIEW OF EUT-3 INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 INTERNAL V…

Text truncated - open the document above for the full version.
