VLJ-MBP867PUDigital Video Baby Monitor (Parent Unit)

User’s Guide Digital Video Baby Monitor Models: MBP867, MBP867-2, MBP867-3, MBP867-4 The features described in this User’s Guide are subject to modifications without prior notice. Welcome... to your new Motorola Video Baby Monitor! Thank you for purchasing the Motorola Video Baby Monitor. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their playroom. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product related questions, please call: This User's Guide provides you with all the information you need to get the most from your product. Before you can use the baby monitor, we recommend you fully charge the battery in the parent unit, so that it continues to work if you disconnect it from the power supply to carry it to another location. Please read the Safety Instructions on page 6 before you install the units. Got everything? • 1 x Parent unit • 1 x Baby unit (Camera) • 1 x Power adapter for the Parent unit • 1 x Power adapter(s) for the Baby unit In multi-camera packs, you will find one or more additional camera units with power adapter units. US and Canada 1-888-331-3383 Email: [email protected] Overview of the Parent Unit 1.Display (LCD screen) 2.Vol + Key Normal Mode: Vol Up Menu Mode: Up 3.Vol - Key Normal Mode: Vol Down Menu Mode: Down 4.Menu Key M Press to open the Menu options 5.OK Key O Long press OK key for 4 seconds, snap shot display photo. Save image to Micro SD card, photos inside DCIM folder. 6.Video ON/OFF Key V Press to turn OFF the LCD display Press again to turn ON the LCD display 7.Ta l k K e y T Press and hold to speak to your baby 8.Microphone 9.Power Key P Press and Hold to turn the unit ON/OFF 10.Stand 11.Speaker 12.USB power adapter socket 13.Reset Key Use a pin to reset device, if any frozen screen or unstable problem occur. 14.Micro SD Card Slot SD 10 11 4 8 5 6 7 1 9 13 2 3 12 14 Parent unit menu icons Signal Level (4 Levels) Night Vision Mode (Screen changes to Black/White) Ta l k M o d e Battery Level Control (4 Levels) Volume Level Control (8 Levels) Zoom Level Control (1X, 2X) Brightness Level Control (8 Levels) Lullaby Control (5 Song Selections) Alarm Setting (6h, 4h, 2h, Off ) Important guidelines for installing your Baby Monitor • To use your Video Monitor Baby and Parent Units together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions. • Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or reinforced concrete between the Baby and Parent Unit may block the radio signal. • The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. • Use of other 2.4 GHz products, such as wireless networks (Wi-Fi ® routers), Bluetooth ® systems, or microwave ovens, may cause interference with this product, so keep the baby monitor away at least 5ft (1.5m) from these types of products, or turn them off if they appear to be causing interference. • If the signal is weak, try lifting up the Parent Unit Antenna, moving the Parent and/or the Baby Unit to different positions in the rooms. 1. Light Sensor (Night Vision Mode)6. Speaker 2. Camera Lens7. ON/OFF Switch 3. Infrared LEDs8. Power Adapter Socket 4. Power LED9. Temperature Sensor 5. Microphone 10. Pair Key Parent unit menu icons (cont’d) Overview of Your Baby Unit Temperature Reading (HH ºC / ºF or LL ºC / ºF) Icon & readings turn RED > 29ºC / 84ºF, and reading display HH ºC / ºF > 36ºC / 97 ºF Icon & readings turn RED < 14ºC / 57ºF, and reading display LL ºC / ºF < 1ºC / 34 ºF Cam Control (scan, view, add, delete) Screen viewing mode control (Single Screen, 4-split Screen) Set Video On Timer (5 min, 30 min, 60 min) 7 8 1 2 5 10 9 6 34 Table of contents5 ENGLISH Table of contents 1.Safety Instructions ..................................................................................... 6 2.Getting Started .......................................................................................... 9 2.1Baby Unit Power Supply .............................................................................. 9 2.2Parent Unit Power Supply ........................................................................... 9 2.3Registration (Pairing)................................................................................. 10 3.Using the Baby Monitor ........................................................................... 11 3.1Setting up................................................................................................... 11 3.2Night Vision Mode..................................................................................... 11 3.3Talk Mode .................................................................................................. 11 3.4Video ON/OFF.......................................................................................... 11 3.5Temperature Display (HH °C / °F or LL °C / °F) ...................................... 11 4.Parent Unit Menu Options....................................................................... 12 4.1Volume....................................................................................................... 12 4.2Brightness .................................................................................................. 12 4.3Lullaby........................................................................................................ 12 4.4Zoom.......................................................................................................... 12 4.5Alarm................................................................................................…

Text truncated - open the document above for the full version.

Date (09/01/2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We,(Binatone Electronics International Limited),hereby authorize Ray Cheung (TUV SUD HK LTD) to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on(09/07/2015]). Sincerely, Company Officer:Karl Heinz Muller Telephone Number: 852 2802 7388 Email:[email protected]

Date (09/01/2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Confidentiality Request FCC ID:VLJ-MBP867BU, VLJ-MBP867PU Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules,(Binatone Electronics International Limited)hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Block Diagrams Theory of Operation (Binatone Electronics International Limited) alsohereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of(9 JULY, 2015)days: Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer:Karl Heinz Mueller Telephone Number: 852 2802 7388 Email:852 2802 8138

Appendix B Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 1 of 4 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix B Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 2 of 4 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix B Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 3 of 4 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix B Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 4 of 4 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong.

材質: 50#特多龍, , Material: 50# polyester, Background:white Text:black,matting coating. MBP867_安規貼紙(PU) Mingwei Wu Mingwei Wu Sam Chen Sam Chen 2014.12.08 2014.12.08 2014.12.08 2014.12.08 1/1mm1:1 01 MBP867(PU) 3C DABU Customer Model Name Position: Camera unit rating label 1) Colour: White background black letters 2) Material: label paper with plastic lamination on top 3) Scale: 1:1, size:40 x 15mm 40 15

Appendix C Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 1 of 9 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix C Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 2 of 9 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix C Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 3 of 9 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix C Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 4 of 9 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix C Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 5 of 9 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix C Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 6 of 9 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix C Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 7 of 9 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix C Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 8 of 9 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Appendix C Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.: MBP867 PU Page 9 of 9 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS,All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No: STS1503010H01 Issued for Binatone Electronics International Ltd. Floor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong. Product Name: Digital Video Baby Monitor (Parent Unit) Brand Name: Motorola Model No.: MBP867 PU Series Model:N/A FCC ID:VLJ-MBP867PU Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2003 Max. SAR (1g):Body:0.698W/kg S T L A B S Page 2 of 42 Report No.: STS1503010H01 Test Report Certification Applicant’s name ................. : Binatone Electronics International Ltd. Address ................................. : Floor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong. Manufacture's Name ............ : Dongguan TaoSen Electronic Technology Co. Ltd. Address ................................. : No.7 Huanguoshan Road, Xinan Community, Changan Town, Dongguan City, Guangdong, China Product description Product name ........................ : Digital Video Baby Monitor (Parent Unit) Trademark ........................... : Motorola Model and/or type reference : MBP867 PU Serial Model烉 N/A Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2003 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test .......................................... : Date (s) of performance of tests ............. : Mar. 04,2015 Date of Issue ........................................ : Mar. 04,2015 Test Result ............................................ : Pass Testing Engineer : (Allen Chen) Technical Manager : (John Zou) Authorized Signatory : (Bovey Yang) Page 3 of 42 Report No.: STS1503010H01 TABLE OF CONTENS 1. General Information4 1.1 EUT Description4 1.2 Test Environment5 1.3 Test Facility5 2. Test Standards And Limits6 3. SAR Measurement System7 3.1 Definition Of Specific Absorption Rate (SAR)7 3.2 SAR System7 3.2.1 Probe8 3.2.2 Phantom9 3.2.3 Device Holder9 4. Tissue Simulating Liquids10 4.1 Simulating Liquids Parameter Check10 5. SAR System Validation11 5.1 Validation System11 5.2 Validation Result11 6. SAR Evaluation Procedures12 7. EUT Test Position13 7.1 Body-worn Position Conditions13 8. Uncertainty14 8.1 Measurement Uncertainty14 8.2 System cheek Uncertainty16 9. Conducted Power Measurement18 10. Test Setup Photo19 11. SAR Result Summary24 12. Equipment List25 Appendix A. System Validation Plots26 Appendix B. SAR Test Plots28 Appendix C. Probe Calibration And Dipole Calibration Report42 Page 4 of 42 Report No.: STS1503010H01 1. General Information 1.1 EUT Description Equipment Digital Video Baby Monitor (Parent Unit) Brand Name Motorola Model No. MBP867 PU Serial Model N/A FCC ID VLJ-MBP867PU Model Difference N/A Hardware Version NIL Software Version NIL Frequency Range 2400-2483.5MHz Transmit Power(MAX): 16.00dBm Max. Reported SAR(1g): Body: 2.4GHz: 0.698W/kg Antenna Specification: Internal Page 5 of 42 Report No.: STS1503010H01 1.2 Test Environment Ambient conditions in the SAR laboratory: ItemsRequiredActual Temperature (°C)18-2522~23 Humidity (%RH)30-7055~65 1.3 Test Facility Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building 2, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China FCC Registration No.: 842334;IC Registration No.: 12108A-1 Page 6 of 42 Report No.: STS1503010H01 2. Test Standards And Limits No.IdentityDocument Title 147 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4FCC KDB 447498 D01 v05r02 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5FCC KDB 865664 D01 v01r03 SAR Measurement 100 MHz to 6 GHz 6FCC KDB 648474Handset SAR This device belongs to portable device category because its radiating structure is allowed to be used within 20 centimeters of the body of the user. According to EN 50360 and 1999/519/EC the limit for General Population/Uncontrolled exposure should be applied for this device, it is 2.0 W/kg as averaged over any 10 gram of tissue. (A). Limits for Occupational/Controlled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.4 8.0 20.0 (B). Limits for General Population/Uncontrolled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.08 1.6 4.0 NOTE: Whole-Body SAR is averaged over the entire body, partial-body SAR is averaged over any 10 gram of tissue defined as a tissue volume in the shape of a cube. SAR for hands, wrists, feet and ankles is averaged over any 10 grams of tissue defined as a tissue volume in the shape of a cube. Population/Uncontrolled Environments : are defined as locations where there is the exposure of individuals who have no knowledge or control of their exposure. Occupational/Controlled Environments : are defined as locations where there is exposure that may be incurred by people who are aware of the potential for exposure, (i.e. as a result of employment or occupation). NOTE GENERAL POPULATION/UNCO…

Text truncated - open the document above for the full version.

TEST REPORT Date: 2014-12-22 Report No.: 60.870.14.025.02F Page 1 of 29 TUV SUD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong Applicant:Binatone Electronics International Ltd. Floor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong Description of Samples:Model name: Digital Video Baby Monitor(ParentUnit) Brand name: Motorola Model no.:MBP867 PU FCCID:VLJ-MBP867PU Date Samples Received:2014-12-12 Date Tested:2014-12-13 to 2014-12-19 Investigation Requested:FCC Part 15 Subpart C, Section 15.247 Conclusions:The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks:--- Checked by:Approved by:- Ray CheungJeff Pong Project EngineerManager Wireless & Telecom DepartmentWireless & Telecom Department ReportNo.: 60.870.14.025.02F Page 2 of 29 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong CONTENT: Cover Page 1 of 29 Content Page 2-3 of 29 1.0General Details 1.1Test Laboratory Page 4 of 29 1.2Applicant Details Page 4 of 29 1.3Equipment Under Test [EUT] Page 5 of 29 1.4 Related Submittal(s) Grants Page 5 of 29 2.0Technical Details 2.1Investigations Requested Page 6 of 29 2.2Test Standards and Results Summary Page 6 of 29 3.0Test Methodology 3.1Radiated Emission Page 7 of 29 3.2Field Strength Calculation Page 7 of 29 3.3Conducted Emission Page 7 of 29 4.0Test Results 4.1 Number of Frequency Hopping Page 8 of 29 4.2 20dB Bandwidth Measurement Page 9-10 of 29 4.3 Hopping Channel Carrier Frequency Separation Page 11 of 29 4.4 Average Time of Occupancy Page 12-14 of 29 4.5 Pseudorandom Hopping Algorithm Page 15 of 29 4.6 Band Edge Measurement Page 16-17 of 29 4.7 Maximum Output Power Page 18-20 of 29 4.8 Out ofBand Emissionsand Emissions in Restricted Bands Page 21-25 of 29 4.9 Conducted Emission on AC Mains Page 26-28 of 29 ReportNo.: 60.870.14.025.02F Page 3 of 29 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong 5.0List of Measurement Equipments Page 29 of 29 Appendix A Photos of Test Setup Appendix B External EUT Photos Appendix C Internal EUT Photos ReportNo.: 60.870.14.025.02F Page 4 of 29 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong 1.0General Details 1.1Test Laboratory Attestation of Global ComplianceSZCoLtd. 2/F, Building 2,No.1-No.4,Chaxi Sanwei, Technical Industrial Park, Gushu, Xixiang, Shenzhen, China. Registration Number: 259865 Tested by: John Zhi 1.2Applicant Details Applicant Binatone Electronics International Ltd. Floor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong Manufacturer Dongguan TaoSen Electronic Technology Co. Ltd. No.7 Huanguoshan Road, Xinan Community, Changan Town, Dongguan City, Guangdong, China ReportNo.: 60.870.14.025.02F Page 5 of 29 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong 1.3Equipment Under Test [EUT] Description of EUT Product Description:Digital Video Baby Monitor(Parent Unit) ModelNo.:MBP867PU Brand Name: Motorola FCCID:VLJ-MBP867PU Rating:DC5.0V,1000mApowered by AC/DC power adaptor Or DC 3.7V 1880mAh Li-ion rechargeable battery Operated Frequency:2402 – 2479 MHz No. of Operated Channel:23 Accessories and Auxiliary Equipments:AC/DC Switching Adaptor Antenna Type:Integral Manufacture of Antenna:CVISION HK LTD Antenna Gain:0 dBi Antenna Model:N/A General Operation of EUT The Equipment Under Test (EUT) is aMonitorofWireless Monitoring System,which include of a FHSS Module. FHSS Operation Principle: This module is controlled by microchip to generate Pseudorandom Frequency Hopping Sequence, this module support 23 hopping channels. Refer to section 4.5 of this report to have more detail of Pseudorandom Hopping Algorithm. 1.4Related Submittal(s) Grants This is a signal application subjected to Certificate Authorization. ReportNo.: 60.870.14.025.02F Page 6 of 29 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong 2.0Technical Details 2.1Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15:2012 and ANSI C63.4: 2009 2.2Test Standards and Results Summary Tables Test ConditionTest RequirementTest Result PassN/A Number of Frequency Hopping Section 15.247 ( a1 ) 20dB Bandwidth Measurement Section 15.247 ( a1 ) Hopping Channel Carrier Frequency Separation Section 15.247 ( a1 ) Average Time of Occupancy Section 15.247 ( a1 ) Pseudorandom Hopping Algorithm Section 15.247 ( a1 ) Band Edge Measurement Section 15.247 Maximum Output PowerSection 15.247 ( b1 ) Out of Band EmissionSection 15.247 ( d ) Radiated Emission in Restricted Band Section 15.247 ( d ) Conducted Emission on AC MainsSection 15.207 Antenna RequirementSection 15.203 See note 1 Note 1 :The EUT uses a permanently attached antenna, which in accordance to Section 15.203, is considered sufficient to comply with the provisions of this section. Remark: N/A - Not Applicable ReportNo.: 60.870.14.025.02F Page 7 of 29 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong 3.0Test Methodology 3.1Radiated Emission The sample was placed 0.8m above the ground plane on a standard emission test site *. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. 3.2Field Strength Calculation The field stre…

Text truncated - open the document above for the full version.

Appendix A Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.:MBP867 PU Page 1 of 2 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Radiated Emission Appendix A Date: 2014-12-22 Report No.: 60.870.14.025.02F Model No.:MBP867 PU Page 2 of 2 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Conducted Emission
