User’s Guide Wearable Pet Tracker with GPS and mobile network Model: SCOUT2500 The features described in this User's Guide are subject to modifications without prior notice. Welcome... to your new Motorola Pet Tracker! Thank you for purchasing the Motorola Pet Tracker. With SCOUT2500 you will always see where your dog or cat is located, safely around the house or patrolling the streets. Set a Geo fence for your pet, and receive alerts on your smart device if he or she leaves the defined perimeter. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product related questions, please call: This User Guide provides you with all the information you need to get the most from the product and is accurate at the time it was completed. As part of our ongoing effort to improve our products, features and on-screen displays may change from time to time. We recommend you to visit our website www.motorolahome.com to get the latest User Guide. Before using this product: • Visit our website www.motorolahome.com to get the latest User Guide. • Read and follow the instructions in the User Guide along with the Safety Instructions on page 6. • Upgrade the product’s app and firmware (see page 29). Got everything? • 1 x Pet Tracker (with integrated battery) • 2 x Silicone Cover • 1 x Power Adapter for the Pet Tracker • 1 x User Guide +44 (0) 844 557 0890 (UK only) +44 (0) 8187 62092 (ROI) On the Web: www.motorolahome.com Overview of the Pet Tracker 1.LED indicator 2.Temperature sensor 3.Power On/Off button (with waterproof cover) 4.Micro USB Charging Socket (with waterproof cover) 1 2 3 4 How the Pet Tracker works The mobile network enabled Pet Tracker is integrated with GPS and temperature sensor. It offers a quick and easy way for you to track the location of your dog and receive notifications when they escape from the virtual fence. The Pet Tracker sends alerts to your smart device through an App called "Hubble for Motorola Petcam". Free 1-year Subscription for Mobile Network Connection The Pet Tracker comes with a free 1-year subscription for mobile network connection. Important guidelines when using the Pet Tracker • Do not make your dog wear the Pet Tracker for more than 12 hours continuously to avoid skin irritation. • Do not connect a leash to the Pet Tracker. • When connecting a separate collar for the leash, make sure that it does not add pressure on the Pet Tracker. • Check the contact area on your dog’s neck for signs of irritation. If there is a rash or sore, discontinue use until the skin is completely healed. See a veterinarian if the condition persists. • Use of other 2.4 GHz products, such as other wireless networks, Bluetooth ® systems or microwave ovens may cause interference with this product. Keep the Pet Tracker away from these types of products, or turn them OFF if they appear to be causing interference. • Always ensure that you have a mobile connection available. Table of contents5 ENGLISH Table of contents 1.Safety Instructions ..................................................................................... 6 2.System Requirements ............................................................................... 7 3.Basic Setup ................................................................................................ 8 3.1Charge the Pet Tracker............................................................................... 8 3.2Fit the Silicone Cover Over the Pet Tracker .............................................. 8 3.3Fit the Pet Tracker on your Dog’s Neck ..................................................... 9 3.4Power On/Off the Pet Tracker.................................................................. 10 3.5Behaviour of the Status Indicator LED ...................................................... 10 4.Connecting Devices................................................................................ 11 4.1User Account and Pet Tracker Setup on Android™ Devices.................. 12 4.2Connect the Pet Tracker to another Android™ Device.......................... 13 4.3Add another Pet Tracker to your Hubble Account .................................. 13 4.4User Account and Pet Tracker Setup on iOS ® Devices........................... 14 4.5Connect the Pet Tracker to another iOS ® Device................................... 15 4.6Add another Pet Tracker to your Hubble Account .................................. 15 5.Overview of the Features in Hubble App ............................................... 16 5.1Using the Pet Tracker when connected to the Mobile Network ............. 17 5.2Pet Tracker Settings .................................................................................. 19 5.3Account Settings ....................................................................................... 21 5.4Reset or remove a Pet Tracker from your Hubble Account..................... 22 6.App and Firmware Upgrades .................................................................. 23 6.1App Upgrade ............................................................................................. 23 6.2Firmware Upgrade .................................................................................... 23 7.Disposal of the Device (Environment).................................................... 24 8.Cleaning and Care .................................................................................. 25 9.Help.......................................................................................................... 25 10. Troubleshooting ...................................................................................... 26 11. General Information ................................................................................ 30 12. Technical Specifications .................................…
