VLJ-T25CPet Training System (Collar)

User’s Guide REMOTE TRAINING SYSTEM Model: SCOUTTRAINER25 The features described in this User's Guide are subject to modifications without prior notice. Welcome... to your new Motorola Remote Training System! Thank you for purchasing the Motorola SCOUTTRAINER25. Your new Remote Training System will provide a quick and effective means of solving common problem behaviors and reinforcing basic obedience commands your pet already knows. You can choose from two training modes - warning tone only or 9 levels of static correction from gentle to firm. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product related questions, please call: This User's Guide provides you with all the information you need to get the most from the product. Please read and follow the instructions in this User’s Guide along with the Safety Instructions on page 8 before you using this product. Got everything? • 1 x Pet Collar Unit • 1 x Collar Strap • 1 x Remote Control Unit • 1 x Test Light for Collar Contacts • 2 Pairs of Collar Contacts - Long & Short (For Pet Collar Unit) In multi-collar packs, you will find one or more additional Pet Collar Units with power adapter units. US and Canada 1-888-331-3383 Email: [email protected] Overview of the Pet Collar Unit 1.Pair Key 2.Indicator LED Lights up in green for 3 seconds when the unit is powered on and flashes slowly during standby. Lights up in red when battery is low. Flashes quickly in green and red when delivering static correction. 3.Power Key Press once to power the unit On/ Off. Indicator LED lights up in green for 3 seconds when the unit is powered on. 4.Battery Cover 5.Collar Contacts 1 2 3 5 4 Overview of the Remote Control Unit 1.Display (LCD screen) 2.Up Key Correction Mode: Increase level Menu Mode: Move up 3.Down Key Correction Mode: Decrease level Menu Mode: Move down 4.To n e K e y Press to send a tone to the Pet Collar Unit. Press to confirm and pair with the Pet Collar Unit. 5.Static Correction Key Press and hold to deliver static correction to the Pet Collar Unit. 6.Antenna 7.Power Key Press and hold to power ON/OFF. 8.Battery Cover 9.Leash Clip 1 2 3 4 5 6 7 8 9 Symbols on the Remote Control Unit Battery level on Remote Control Unit. Pet Collar Number. Displays the selected STATIC CORRECTION LEVEL (Level 0 to 9). When 0 is displayed, only tone alerts are sent to the Pet Collar Unit. Displays when TONE KEY is pressed. How the Remote Training System works The Training System comes with a Remote Control Unit that is paired with the Pet Collar Unit. At the push of the STATIC CORRECTION KEY on the Remote Control Unit, a signal is sent to the Pet Collar Unit, which delivers static correction to your dog to assist you with shaping and modifying its behavior. The Remote Control Unit is also designed with a TONE KEY . At the push of the key, a tone is sent to the Pet Collar Unit. The tone function is good for giving your dog an opportunity to respond to your commands prior to pressing the STATIC CORRECTION KEY . Important guidelines when using the Remote Training System • Included in the Training System are Collar Contacts in three different lengths (short, medium and long) that deliver static correction to your dog. Choose the appropriate length for your dog’s hair coat. The Pet Collar Unit was shipped with medium Collar Contacts that are suitable for dogs with medium hair coats. If your dog has dense coats or undercoats, use one of the longer Collar Contacts included with the product. • Proper fit of the Pet Collar Unit is critical to the performance and effectiveness of the Training System. If the fit is too loose, the collar will not be able to get sufficient contact with the skin to deliver static correction. If the fit is too tight, it will irritate your dog’s skin. • Tighten the collar high on your dog’s neck, tight enough that you can get two fingers between the collar strap and your dog. It should not be able to rotate around the neck. • Do not make your dog wear the Pet Collar Unit for more than 12 hours continuously to avoid skin irritation. • Do not connect a leash to the Pet Collar Unit as this might pull the Collar Contacts too tight against your dog’s neck. • When connecting a separate collar for the leash, make sure that it does not add pressure on the Pet Collar Unit. • Check the contact area on your dog’s neck for signs of irritation. If there is a rash or sore, discontinue use until the skin is completely healed. See a veterinarian if the condition persists. 7 ENGLISH Table of contents 1.Safety Instructions .................................................................................... 8 2.Getting Started ......................................................................................... 9 2.1Insert Batteries on the Remote Control Unit .............................................. 9 2.2Attach the Adjustable Strap to the Pet Collar Unit .................................. 10 2.3Insert and Remove Battery on the Pet Collar Unit ................................... 10 2.4Fit the Pet Collar Unit on your Dog’s Neck .............................................. 12 2.5Trim Away Excess Strap Length ............................................................... 13 2.6Change Collar Contacts .......................................................................... 14 2.7Using the Test Light .................................................................................. 15 3.Using the Pet Collar Unit ........................................................................ 16 3.1Powering On/Off the Pet Collar Unit ...................................................... 16 3.2Pairing with the Remote Control Unit ...................................................... 16 4.Training Your Dog with the Remote Training System .....…

Text truncated - open the document above for the full version.

Appendix B1 Letter of Agency for FCC Certification 09-Oct-14 To whom it may concern, Letter of Agency I, an officer of Binatone Electronics International Ltd do hereby authorize Intertek Testing Services (Mr. Terry Chan) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Karl Heinz Mueller Chief Technical Officer

Attention: Application Examiner Re: Request for confidentiality Applicant: Binatone Electronics International Limited FCC ID: VLJ-T25C To whom it may concern, Permanent Confidentiality Request is hereby submitted by Binatone Electronics International Limited to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description Rationale for request for confidentiality: Binatone Electronics International Limited has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Sincerely, Chief Technical Officer Binatone Electronics International Limited

INTERTEK TESTING SERVICES External Photos FCC ID: VLJ-T25C IC:4522A-T25C external photos - 1 of 1

INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ-T25C IC: 4522A-T25C internal photos - 1 of 3 INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ-T25C IC: 4522A-T25C internal photos - 2 of 3 INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ-T25C IC: 4522A-T25C internal photos - 3 of 3

lntertek valued Quality, D€livelEd. TEST REPORT Report No.: 14091 179HKG-002 Binatone Electronics lnternational Ltd. Application For Certification (Original Grant) (FCC lD: VLJ-T25G) Receiver Prepared and Checked by: Wong Kwok Yeung, Kenneth Lead Engineer ( lntertek's standard Terms snd Cond¡t¡ons en b€ obtsined at our webs¡t6 httpj/ vw lnterl€k.com/torms/. This r€port shall not be roproduæd, except ¡n lull This report is lor the exclusivo usô of lnt€rlek's Client ånd is providôd pursuant to tho âgreêmônt betwoen lntertek and its Client lnt8rteKs responsibility and l¡abil¡ty aro limited to th6 tôms and condit¡ons of lho agr€sm€nt. lntêrtôk assumes no l¡âb¡lity to any party, oth€r then to ths Cli€nt ¡n 8@rdancê wilh the agr€em€nt, for any loss, expenss or damage oæsioned by thô use of th¡s report, Only the Cl¡ent ls authorized to permit øpying or d¡stribut¡on of th¡s report snd then only ¡n its entir€ty Any use of ths lnlerlek namo or ono of lts marks lor th€ sale or sdverlisement of lhe lested material, product or seruiæ must lìrsl bô approved in writing by lnt€l€k The obseryat¡ons ând t6st rosults ¡n th¡s ßporl are relovant only to the sâmple tested. This report by its8lf do8s not imply thât tho måterial, producl, or señ¡æ is or has ev€r be€n und€r sn lntertok cert¡fletion progrsm. lntertek Testing Services Hong Kong Ltd. ZF., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fex: (852) 2785 5487 Website: www.hk.interlek-otlsemko.com Approved by: ,r'" A /Ø;( Chan Chi Hung, Terry Supervisor Date: December 01 ,2014 INTERTEK TESTING SERVICES Report No.: 14091179HKG-002 i FCC ID: VLJ-T25C GENERAL INFORMATION Grantee: Binatone Electronics International Ltd. Grantee Address: Floor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong. Contact Person: Karl Heinz Mueller Tel: (852) 2802-2738 Fax: (852) 2802-8138 e-mail: [email protected] Manufacturer: Foshan Shunde Alford Electronics Co. Ltd Manufacturer Address: Xinjiao Industrial Park, DaLiang, ShunDe, Foshan City, Guangdong Province, China Brand Name: Motorola Model: SCOUTTRAINER25CU Type of EUT: Superheterodyne Receiver Description of EUT: Pet Training Product Serial Number: N/A FCC ID: VLJ-T25C Date of Sample Submitted: September 29, 2014 Date of Test: September 30, 2014 to November 12, 2014 Report No.: 14091179HKG-002 Report Date: December 01, 2014 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Report No.: 14091179HKG-002 ii FCC ID: VLJ-T25C SUMMARY OF TEST RESULT TEST SPECIFICATION REFERENCE RESULTS Receiver / Digital Device Radiated Emissions 15.109 Pass The equipment under test is found to be complying with the following standards: FCC Part 15, October 1, 2012 Edition INTERTEK TESTING SERVICES Report No.: 14091179HKG-002 iii FCC ID: VLJ-T25C Table of Contents 1.0 General Description ............................................................................................ 1 1.1 Product Description ........................................................................................... 1 1.2 Related Submittal(s) Grants ............................................................................... 1 1.3 Test Methodology .............................................................................................. 1 1.4 Test Facility ....................................................................................................... 1 2.0 System Test Configuration ................................................................................. 2 2.1 Justification........................................................................................................ 2 2.2 EUT Exercising Software ................................................................................... 2 2.3 Special Accessories........................................................................................... 2 2.4 Measurement Uncertainty .................................................................................. 2 2.5 Support Equipment List and Description............................................................. 2 3.0 Emission Results ................................................................................................ 3 3.1 Field Strength Calculation .................................................................................. 3 3.2 Radiated Emission Configuration Photograph .................................................... 4 3.3 Radiated Emission Data .................................................................................... 4 4.0 Equipment Photographs ..................................................................................... 6 5.0 Product Labelling................................................................................................ 6 6.0 Technical Specifications ..................................................................................... 6 7.0 Instruction Manual.............................................................................................. 6 8.0 Miscellaneous Information ................................................................................. 7 8.1 Discussion of Pulse Desensitization ................................................................... 7 8.2 Calculation of Average Factor ............................................................................ 7 8.3 Emissions Test Procedures ............................................................................... 7 9.0 Equipment List .................................................................................................... 9 INTERTEK TESTING SERVICES Report No.: 14091179HKG-002 1 FCC ID: VLJ-T25C 1.0 General Description 1.1 Product Description The Equipment Under Test (EUT) is a wireless collar unit of pet training system. It operates at frequency of 434MHz. The device was powered by a new 3.0V CR2032 battery. Antenna Type: Internal, Integral For electronic filing, the brief circuit description is…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs – Mode: Transmission FCC ID: VLJ-T25C IC: 4522A-T25C config photos ( radiated emission) - 1 of 1 Radiated Emission
