VLJ80-8231-011.9GHz Digital Modulation Video Baby Monitor - Parent Unit

Userís Guide MBP20 Baby Monitor The features described in this user's guide are subject to modifications without prior notice. Welcome... to your new Motorola Baby Monitor! Thank you for purchasing the MBP20. Now you can see and hear your baby sleeping in the other room or you can monitor your older children in their play room. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product-related questions, please call: US and Canada1-888-331-3383 On the Web: www.motorola.com This User's Guide provides you with all the information you need to get the most from your product. Before you can use the baby monitor, we recommend you insert and fully charge the battery in the parent unit, so that it continues to work if you disconnect it from the mains power to carry it to another location. Please read the Safety Instructions on page 8 before you install the units. Got everything? ï 1 x Parent unit (MBP20PU) ï 1 x Baby unit (MBP20BU) ï 1 x Rechargeable Ni-MH battery pack for the Parent unit ï 1 x Belt clip for parent unit ï 1 x Battery door for parent unit ï 1 x Power adapter for the parent unit ï 1 x Power adapter for the baby unit Overview of your Parent unit 1 LCD Display 2 Link Indicator On when the parent unit is powered on and linked to the baby unit. Flashes when the parent unit is out of range from baby unit. Off when the parent unit is powered off. 7 8 9 6 5 4 3 2 1 3 UP / Volume + In idle mode: Press to increase the speaker volume. In menu mode: Press to view the previous menu item. 4Menu / OK In idle mode: Press to access the main menu. In menu mode: Press to access the sub-menu, or confirm the settings. 5 DOWN / Volume - In idle mode: Press to decrease the speaker volume. In menu mode: Press to view the next menu item. 6Talk In idle or menu mode: Press and hold to talk back with baby unit. Release to quit the talk mode. 7 Video On / Off In monitoring mode: Press to deactivate/activate the video feed or turn on/off the LCD display. In menu mode: Press to go to the monitoring mode. 8 Power / Back In idle or menu mode: Press and hold to power on/off the parent unit. In menu mode: Press to cancel settings and back to the previous level. Parent Unit Display Menu Structure of Parent Unit 9 Charging Indicator On steadily when in charging mode. Flashes when low battery is detected. NOTE Off even if connected with power adapter but without battery pack installed. Icons Behaviors Description Indicates the signal strength between baby unit and parent unit. The more blocks, the stronger connection signal. Flashes when parent unit is out of range. Indicates no connection between the baby unit and parent unit. Indicates when speaker of parent unit is muted. Indicates the speaker volume level of parent unit. Indicates when parent unit or baby unit is playing lullaby. Indicates when timer alarm is activated. Indicates when the sound alert is set on. Low battery, needs charging. 1/2 battery level. More internal bars mean high battery level. Full battery level. Animation in cycle. Battery is in charging. MAIN MENULANGUAGETIMERBRIGHTNESSSOUND ALERTALERT TONESRESET SUB MENUEnglish FranÁais EspaÒol Deutsch Italiano PortuguÍs Activation Set Timer Level 1 ~ 5On Off Low Battery No Link Overview of your Baby unit 6 5 4 8 9 2 7 3 1 1 Infrared Light 2Camera 3 Power Indicator On when the baby unit is switched on. Off when the baby unit is switched off. 4 UP / Volume + Press to increase the speaker volume. 5Power Press and hold to power on/off the baby unit. 6DOWN / Volume - Press to decrease the speaker volume. 7Stop Press to stop the lullaby playing. 8Play Press to play the lullaby. 9 Lullaby Press to select the lullaby and start playing the selected lullaby. During lullaby playing, press to select and play the other lullabies. Important guidelines for installing our Baby Monitor ï To use your baby unit and parent unit together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions. ï Any large metal object, like a refrigerator, a mirror, a filing cabinet, a metallic doors or reinforced concrete, between the baby and parent unit may block the radio signal. ï The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TV's, computers, cordless or mobile phones, fluorescent lights or dimmer switches. ï If the signal is poor, try moving the parent and/or the baby unit to different positions in the rooms. 7 1. SAFETY INSTRUCTIONS ................................... 8 2. GETTING STARTED............................................ 9 2.1 Baby unit power supply .......................................9 2.2 Parent unit battery installation.............................9 2.3 Belt clip on parent unit ......................................10 3. USING YOUR BABY MONITOR........................ 11 3.1 Power on/off the parent unit..............................11 3.2 Power on/off the baby unit ................................11 3.3 Adjust speaker volume of parent unit and baby unit ...........................................................11 3.4 Talk Back ..........................................................11 3.4.1 Adjust talk back volume .........................12 3.5 Temperature .....................................................12 3.6 Lullaby...............................................................12 3.7 Video on/off and video transfer .........................12 4. Parent unit settings .......................................... 13 4.1 Set the language...............................................13 4.2 Timer.................................................................13 4.2.1 Turn on the timer ...................................13 4.2.2 Set the timer ..............................…

Text truncated - open the document above for the full version.

Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . June 28, 2011 To whom it may concern, Declarations FCC ID: VLJ80-8231-01 IC: 4522A-80823101 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the parent unit will act as the initiating device, which will initiate the establishment of the duplex connection. 4. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Parent Unit 1 Switch-off companion device A 2 On hook by companion device NA 3 Remove power from companion device A 4 Switch-off device C 5 On hook device NA 6 Remove power from device C A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. NA – Not applicable represents the device does not contain a hook switch or a power off switch. If you have questions or need further information, please contact the undersigned. Regards, Paul Tsui Product Operation Director

[Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . June 28, 2011 To whom it may concern, Label Location Justification FCC ID: VLJ80-8231-01 Request is hereby submitted by Binatone Electronics International Limited to request an alternative method of positively identifying the equipment, pursuant to 47 CFR § 2.925(f) of the FCC Rules. The FCC identifier for Parent Unit will be placed in the battery compartment and the following requirements are confirmed to meet: a) The FCC identifier will visible at the time of purchase, by either of the following approaches:  Marketing the device without the battery installed, or  Providing instruction (stated on the box, user manual, or additional documentation) directing the user as to where to find the FCC label. b) The user accessible area will not require any special tools for access and the FCC label will not be placed on a removable part. The user manual has already included the FCC statements, pursuant to 47 CFR § 15.19(a)(3), 15.21 and 15.105(b). If you have questions or need further information, please contact the undersigned. Sincerely, Paul Tsui Product Operation Director

Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . Appendix B1 Letter of Agency for FCC Certification June 28, 2011 To whom it may concern, Letter of Agency I, an officer of Binatone Electronics International Limited do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Paul Tsui Product Operation Director

Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . June 28, 2011 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: VLJ80-8231-01 Request is hereby submitted by Binatone Electronics International Limited to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and Binatone Electronics International Limited reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of Binatone Electronics International Limited and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Paul Tsui Product Operation Director

INTERTEK TESTING SERVICES External Photos FCC ID: VLJ80-8231-01 IC: 4522A-80823101 external photos - 1 of 2 INTERTEK TESTING SERVICES External Photos FCC ID: VLJ80-8231-01 IC: 4522A-80823101 external photos - 2 of 2

Lable paper : 24X20 mm MBP20 PU Engraving Raised 0.2mm m   MBP20PU-(UK/EU) S/N : Use only battery and power supplies listed in the user manual Model : MBP20 Made in China Input : DC6V 600mA S/N : Use only battery and power supplies listed in the user manual Model : MBP20 Made in China Input : DC6V 600mA MBP20PU-(US/CA) S/N : Model : MBP20PU DC 6V 600mA Made in China IC : 4522A-80823101 FCC ID : VLJ80-8231-01

INTERTEK TESTING SERVICES Internal Photos FCC ID: VLJ80-8231-01 IC: 4522A-80823101 Internal photos - 1 of 3 Internal Photo - 1 Internal Photo - 2 INTERTEK TESTING SERVICES Internal Photos FCC ID: VLJ80-8231-01 IC: 4522A-80823101 Internal photos - 2 of 3 Internal Photo - 3 Internal Photo - 4 INTERTEK TESTING SERVICES Internal Photos FCC ID: VLJ80-8231-01 IC: 4522A-80823101 Internal photos - 3 of 3 Internal Photo - 5 Internal Photo - 6

A Test Lab Techno Corp. Changan Lab：No. 140 -1, Changan Street, Bade City, Taoyuan County, Taiwan R.O.C. Te l：886-3-271-0188 / Fax：886-3-271-0190 SAR EVALUATION REPORT Test Report No. ： 1107FS22 Applicant ： Binatone Electronics International Limited EUT Type ： 1.9GHz DECT 6.0 Baby Monitor FCC ID ： VLJ80-8231-01 Trade Name ： MOTOROLA Model Number ： MBP20PU Dates of Test ： Jul. 12, 2011 Date of Issued ： Jul. 15, 2011 Test Environment ： Ambient Temperature： 22 ±2 ° C Relative Humidity：40 - 70 % Test Specification ： Standard C95.1-1992 IEEE Std. 1528-2003 2.1093;FCC/OET Bulletin 65 Supplement C [July 2001] Max. SAR ： 0.122 W/kg UPCS Brain SAR 0.099 W/kg UPCS Muscle SAR Test Lab Location ： Chang-an Lab 1. The test operations have to be performed with cautious behavior, the test results are as attached. 2. The test results are under chamber environment of A Test Lab Techno Corp. A Test Lab Techno Corp. does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples. 3. The measurement report has to be written approval of A Test Lab Techno Corp. It may only be reproduced or published in full. This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. 4. This document may be altered or revised by A Test Lab Techno. Corp. personnel only, and shall be noted in the revision section of the document. Approved By ： Tested By ： (Sam Chuang ) (Alex Wu) ©2011 A Test Lab Techno Corp. Report Number: 1107DS22Page 1 of 70 Contents 1. Description of Equipment under Test (EUT) .................................................................................................. 3 2. Introduction .................................................................................................................................................... 4 3. SAR Definition ............................................................................................................................................... 5 4. SAR Measurement Setup .............................................................................................................................. 6 5. System Components ..................................................................................................................................... 8 5.1 DASY4 E-Field Probe System ........................................................................................................... 8 5.2 Data Acquisition Electronic (DAE) System .....................................................................................11 5.3 Robot ..................................................................................................................................................11 5.4 Measurement Server .........................................................................................................................11 5.5 Device Holder for Transmitters ....................................................................................................... 12 5.6 Phantom - SAM v4.0 ......................................................................................................................... 12 5.7 Data Storage and Evaluation........................................................................................................... 13 6. Test Equipment List ..................................................................................................................................... 16 7. Tissue Simulating Liquids ............................................................................................................................ 17 7.1 Ingredients ........................................................................................................................................ 18 7.2 Recipes .............................................................................................................................................. 18 7.3 Liquid Confirmation ......................................................................................................................... 19 8. Measurement Process................................................................................................................................. 20 8.1 Device and Test Conditions ............................................................................................................ 20 8.2 System Performance Check............................................................................................................ 21 8.3 Dosimetric Assessment Setup........................................................................................................ 24 8.4 Spatial Peak SAR Evaluation........................................................................................................... 26 9. Measurement Uncertainty............................................................................................................................ 27 10. SAR Test Results Summary ........................................................................................................................ 30 10.1 Brain SAR.......................................................................................................................................... 30 10.2 Muscle SAR....................................................................................................................................... 31 10.3 Std. C95.1-1992 RF Exposure Limit ................................................................................................ 32 11. Conclusion ................................................................................................................................................... 33 12. References .................................................................................................................................................. 33 Appendix A - System Performance Check.................…

Text truncated - open the document above for the full version.

SAR EUT Photographs EUT Photo ( 1 ) EUT Photo ( 2 ) ©2011 A Test Lab Techno Corp. Report Number: 1107FS22Page 1 of 4 EUT Photo ( 3 ) EUT Photo ( 4 ) ©2011 A Test Lab Techno Corp. Report Number: 1107FS22Page 2 of 4 EUT Photo ( 5 ) EUT Photo ( 6 ) ©2011 A Test Lab Techno Corp. Report Number: 1107FS22Page 3 of 4 EUT Photo ( 7 ) EUT Photo ( 8 ) ©2011 A Test Lab Techno Corp. Report Number: 1107FS22Page 4 of 4

SAR Test Setup Photographs EUT Back side EUT Front side EUT Top side ©2011 A Test Lab Techno Corp. Report Number: 1107FS22Page 1 of 4 Body Setup (Front surface to phantom 0mm) Figure 2. Body SAR Test Setup (Flat Section) EUT Front side EUT Top side EUT Back side ©2011 A Test Lab Techno Corp. Report Number: 1107FS22Page 2 of 4 Body Setup (EUT with belt-clip, Front surface to phantom 0mm) Figure 3. Body SAR Test Setup (Flat Section) EUT Front side EUT Top side EUT Back side ©2011 A Test Lab Techno Corp. Report Number: 1107FS22Page 3 of 4 Body Setup (EUT with belt-clip, Back surface to phantom 0mm) Figure 4. Body SAR Test Setup (Flat Section) EUT Front side EUT Top side EUT Back side ©2011 A Test Lab Techno Corp. Report Number: 1107FS22Page 4 of 4

INTERTEK TESTING SERVICES 26dB Emission Bandwidth Plots FCC ID: VLJ80-8231-01 bw - 1 of 1 A0 Parent unit, Lowest channel, Traffic carrier Parent unit, Highest channel, Traffic carrier

INTERTEK TESTING SERVICES Unwanted Emission Inside The Sub-Band Plots FCC ID:VLJ80-8231-01 inband - 1 of 1 A0 Parent unit, Lowest channel, Traffic carrier Parent unit, Highest channel, Traffic carrier

INTERTEK TESTING SERVICES Peak Transmit Power Plots FCC ID:VLJ80-8231-01 IC: 4522A-80823101 peaktp - 1 of 2 A0 Parent unit, Lowest channel, Traffic carrier Parent unit, Middle channel, Traffic carrier INTERTEK TESTING SERVICES Peak Transmit Power Plots FCC ID:VLJ80-8231-01 IC: 4522A-80823101 peaktp - 2 of 2 A0 Parent unit, Highest channel, Traffic carrier

INTERTEK TESTING SERVICES Power Spectral Density Plots FCC ID:VLJ80-8231-01 psd - 1 of 1 A0 Parent unit, Lowest channel, Traffic carrier Parent unit, Highest channel, Traffic carrier

- The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Binatone Electronics International Limited Application For 47 CFR Part 15 Certification RSS-213 Issue 2 Equipment Certification Unlicensed Personal Communication Service Devices/ 2 GHz License-exempt Personal Communications Service Devices (Parent Unit) FCC ID: VLJ80-8231-01 Model: MBP20PU IC: 4522A-80823101 Model: MBP20PU Test Report Number: HK11061060-2 Issue Date: July 22, 2011 MN/ cl INTERTEK TESTING SERVICES Test Report Number: HK11061060-2 Page 1 of 48 FCC ID: VLJ80-8231-01 IC: 4522A-80823101 Table of Contents 1.0 Summary of Test Results........................................................................................ 4 2.0 General Description................................................................................................. 7 2.1 Product Description ................................................................................................. 7 2.2 Technical Description .............................................................................................. 7 2.3 Test Methodology.................................................................................................... 7 2.4 Test Facility............................................................................................................. 7 3.0 System Test Configuration...................................................................................... 9 3.1 Justification ............................................................................................................. 9 3.2 Conducted Emission Test Configuration ................................................................ 10 3.3 Conducted Monitoring and Operational Test Configuration.................................... 10 3.4 EUT Exercising Software....................................................................................... 10 3.5 Details of EUT and Description of Peripherals....................................................... 11 3.6 Measurement Uncertainty ..................................................................................... 11 4.0 Measurement Results............................................................................................ 13 4.1 Antenna Requirement........................................................................................... 13 4.2 Digital Modulation Techniques............................................................................... 13 4.3 Emission Bandwidth.............................................................................................. 14 4.4 Directional Gain of the Antenna ............................................................................. 14 4.5 Peak Transmit Power ............................................................................................ 15 4.6 Power Spectral Density ......................................................................................... 16 4.7 Automatic Discontinuation of Transmission............................................................ 16 4.8 Unwanted Emission Inside the Sub-Band .............................................................. 17 4.9 Emissions Outside the Sub-Band .......................................................................... 18 4.9.1 Radiated Emissions Configuration Photographs ................................................. 19 4.9.2 Radiated Emissions Data ................................................................................... 19 4.9.3 Field Strength Calculation................................................................................... 23 4.9.4 Average Factor Calculation and Transmitter ON Time Measurements ................ 24 4.10 Radiated Emissions from Receiver ...................................................................... 24 4.10.1 Radiated Emission Configuration Photographs ................................................. 25 4.10.2 Radiated Emissions Data ................................................................................. 25 4.11 AC Power Line Conducted Emissions ................................................................. 27 4.11.1 AC Power Line Conducted Emissions Configuration Photographs .................... 28 4.11.2 AC Power Line Conducted Emissions Data ...................................................... 28 4.12 Radio Frequency Radiation Exposure.................................................................. 29 4.13 Radio Frequency Exposure Compliance.............................................................. 29 4.14 Frame Repetition Stability .................................................................................. 30 4.15 Frame Period and Jitter ...................................................................................... 31 4.16 Carrier Frequency Stability ....…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs – Mode: Transmission FCC ID: VLJ80-8231-01 IC: 4522A-80823101 config photos (radiated emission – parent unit) - 1 of 1 Radiated Emission – Parent Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs – Mode: Talk FCC ID: VLJ80-8230-01 IC: 4522A-80823001 config photos (conducted emission) - 1 of 2 Conducted Emission Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs – Mode: Talk FCC ID: VLJ80-8230-01 IC: 4522A-80823001 config photos (conducted emission) - 2 of 2 Conducted Emission Left Side View
