Doc Title : Product Data – User’s Guide Revision : R.00 Model : MFV700 Page(s) : 1 of 25 This document contains confidential and proprietary information of VTech Telecommunications Ltd MFV700 Digital Photo Frame with Video-in-Picture The features described in this user’s guide are subject to modifications without prior notice. Doc Title : Product Data – User’s Guide Revision : R.00 Model : MFV700 Page(s) : 2 of 25 This document contains confidential and proprietary information of VTech Telecommunications Ltd Welcome... to your new Motorola Digital Photo Frame with Video-In-Picture! Thank you for purchasing the MFV700 - the Digital Photo Frame with video-In-Picture is more than just a Photo Frame. It’s a multimedia trip down memory lane, and with the addition of the Wireless Camera and Live Video Feed, it’s also a way of protecting what matters most. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product-related questions, please call: US and Canada 1-888-331-3383 (FOR US VERSION) UK 0845 218 0890 (FOR UK VERSION) ROI 08187 62092 (FOR UK VERSION) On the Web: www.motorola.com This User’s Guide provides you with all the information you need to get the most from your product. Before you can use the digital photo frame, please read the Safety Instructions on page xx before you install the units. Got everything? • 1 x Digital photo frame (MFV700PU for US version) • 1 x Camera unit (MFV700BU for US version) • 1 x Remote control • 1 x Power adapter for the Digital photo frame • 1 x Power adapter for the Camera unit Doc Title : Product Data – User’s Guide Revision : R.00 Model : MFV700 Page(s) : 3 of 25 This document contains confidential and proprietary information of VTech Telecommunications Ltd Overview of your Digital photo frame (also digital photo frame) Front panel <Front panel diagram> Rear panel Doc Title : Product Data – User’s Guide Revision : R.00 Model : MFV700 Page(s) : 4 of 25 This document contains confidential and proprietary information of VTech Telecommunications Ltd 1. ON/OFF button 2. Navigation and buttons 3. Video ON/OFF button 4. Remote control for remote control functions, please refer to page xx 5. Memory card slot for inserting an SD, SDHC, MMC memory card that contains the photos you want to play or record. 6. USB connector Doc Title : Product Data – User’s Guide Revision : R.00 Model : MFV700 Page(s) : 5 of 25 This document contains confidential and proprietary information of VTech Telecommunications Ltd Overview of your Camera unit 1 Infrared Light 6 d / Volume – Press to decrease the speaker volume. 2 Camera 7 Stop During lullaby playback, press to stop the lullaby playback. 3 Power Indicator On when the digital photo frame is switched on. Off when the digital photo frame is switched off. 8 Play Press to play the lullaby. 4 c / Volume + Press to increase the speaker volume. 9 Lullaby Press to recall the current lullaby and start playback. During lullaby playback, press to select and play the other lullabies. 5 Power Press and hold to power on/off the camera unit. Important guidelines for installing our Digital photo frame z To use your camera unit and digital photo frame together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions. z Any large metal object, like a refrigerator, a mirror, a filing cabinet, a metallic doors or reinforced concrete, between the baby and digital photo frame may block the radio signal. z The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. z If the signal is poor, try moving the parent and/or the camera unit to different positions in the rooms. 5 3 9 6 7 1 2 4 8 Doc Title : Product Data – User’s Guide Revision : R.00 Model : MFV700 Page(s) : 6 of 25 This document contains confidential and proprietary information of VTech Telecommunications Ltd TABLE OF CONTENTS 1 SAFETY INSTRUCTIONS.................................................................................................................................................7 2 GETTING STARTED .........................................................................................................................................................8 2.1 CONNECTING CAMERA UNIT TO POWER..........................................................................................................................8 2.2 CONNECTING DIGITAL PHOTO FRAME TO POWER...........................................................................................................8 2.3 INSERTING A MEMORY CARD...........................................................................................................................................9 2.4 REMOVING A MEMORY CARD..........................................................................................................................................9 2.5 CONNECTING A USB DEVICE..........................................................................................................................................9 3 USING YOUR DIGITAL PHOTO FRAME............................................................................................................11 3.1 USING THE CONTROL BUTTONS.....................................................................................................................................11 3.2 USING THE REMOTE CONTROL.................................................................................................................................13 4. USING THE MENUS...............................................................................................................................................15 4.1 Usi…

Text truncated - open the document above for the full version.

Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . Jul. 13, 2011 To whom it may concern, Declarations FCC ID: VLJ80-8402-01 IC: 4522A-80840201 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the parent unit will act as the initiating device, which will initiate the establishment of the duplex connection. 4. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Parent Unit 1 Switch-off companion device A 2 On hook by companion device NA 3 Remove power from companion device A 4 Switch-off device C 5 On hook device NA 6 Remove power from device C A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. NA – Not applicable represents the device does not contain a hook switch or a power off switch. If you have questions or need further information, please contact the undersigned. Regards, Paul Tsui Product Operation Director

Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . Appendix B1 Letter of Agency for FCC Certification Jul. 13, 2011 To whom it may concern, Letter of Agency I, an officer of Binatone Electronics International Limited do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Paul Tsui Product Operation Director

[Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . Jul. 13, 2011 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: VLJ80-8402-01 Request is hereby submitted by Binatone Electronics International Limited to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and Binatone Electronics International Limited reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of Binatone Electronics International Limited and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Paul Tsui Product Operation Director

INTERTEK TESTING SERVICES External Photos FCC ID: VLJ80-8402-01 IC: 4522A-80840201 external photos - 1 of 2 INTERTEK TESTING SERVICES External Photos FCC ID: VLJ80-8402-01 IC: 4522A-80840201 external photos - 2 of 2

Engraved in glossyRaised 0.2mm Engraved in glossyRaised 0.2mm MFV700 PU MFV700PU-(UK/EU) MFV700PU-(US/CA) S/N : Model : MFV700PU DC 5V 1A Made in China IC : 4522A-80840201 FCC ID : VLJ80-8402-01 Dimension: 40*20 mmMaterial: 80g art paper 92-0xxxxx-010-100 Fram label Fram label Dimension: 40*20 mmMaterial: 80g art paper 92-0xxxxx-010-100 S/N : Use only power supplies listed in the user manual Model : MFV700 Made in China Input : DC 5V 1A S/N : Use only power supplies listed in the user manual Model : MFV700 Made in China Input : DC 5V 1A Frame Rear This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:1) This device may not cause harmful interference; and2) This device must accept any interference received, including interference that may cause undesired operation. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:1) This device may not cause harmful interference; and2) This device must accept any interference received, including interference that may cause undesired operation. Dimension: 40*30 mmMaterial: 80g art paper92-019994-010-100FCC LBL TEXT TYPE: Arial TEXT SIZE: Point 6

INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8402-01 IC: 4522A-80840201 internal photos - 1 of 5 Digital Photo Frame Unit assembly (View 1) Digital Photo Frame Unit assembly (View 2) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8402-01 IC: 4522A-80840201 internal photos - 2 of 5 Digital Photo Frame Unit Main PCB comp side Digital Photo Frame Unit Main PCB solder side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8402-01 IC: 4522A-80840201 internal photos - 3 of 5 Digital Photo Frame Unit Antenna front side Digital Photo Frame Unit Antenna rear side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8402-01 IC: 4522A-80840201 internal photos - 4 of 5 Digital Photo Frame Unit LED front side Digital Photo Frame Unit LED rear side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8402-01 IC: 4522A-80840201 internal photos - 5 of 5 Digital Photo Frame Unit Oscillator PCB comp side

INTERTEK TESTING SERVICES FCC ID: VLJ80-8402-01 RF exposure info - 1 of 1 For Maximum Permissible Exposure (MPE) evaluation of the digital photo frame unit, the maximum power density at 20 cm from this mobile transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65. For the digital photo frame unit of tested model of MFV700PU, the maximum field strength measured (FS) was 119.7 dBμV/m. The distance (D) between the antenna and the equipment under test (EUT) was 3 meters. And the maximum source-based time-averaging duty factor in one digital photo frame unit operation is 37.5%. From these data, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The radiated power (EIRP) = (FS*D) 2 / 30 = 279.98 mW The radiated (EIRP) source-based time-averaging output power = (279.98 * 0.375) mW = 104.99 mW The power density at 20 cm from the antenna = EIRP / 4πR 2 = 0.0209 mW cm -2 In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm -2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “ FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the digital photo frame unit at least 20cm from nearby persons.”

INTERTEK TESTING SERVICES 26dB Emission Bandwidth Plots FCC ID: VLJ80-8402-01 bw - 1 of 1 A0 Digital Photo Frame unit, Lowest channel, Traffic carrier Digital Photo Frame unit, Highest channel, Traffic carrier

Report no.: HK11071265-1 SD Card Slideshow with Music Playing AC Mains Ctrl No.: N/A 150 kHz30 MHz 6DB AC dBμV dBμV 1 PK CLRWR 2 AV CLRWR SGL TDS RBW 9 kHz MT 1 s PREAMP OFFAtt 10 dB AUTO 1 MHz10 MHz 0 10 20 30 40 50 60 70 80 90 100 CF15MAV CF15MQP Date: 13.JUL.2011 19:30:15 Report no.: HK11071265-1 SD Card Slideshow with Music Playing AC Mains Ctrl No.: N/A EDIT PEAK LIST (Final Measurement Results) Trace1: CF15MQP Trace2: CF15MAV Trace3: --- TRACE FREQUENCY LEVEL dBμV DELTA LIMIT dB 1 Quasi Peak 159 kHz 42.73 N -22.78 1 Quasi Peak 384 kHz 35.38 N -22.80 1 Quasi Peak 537 kHz 32.68 L1 -23.31 1 Quasi Peak 10.0005 MHz 40.57 L1 -19.43 2 CISPR Average10.0005 MHz 35.90 L1 -14.09 1 Quasi Peak 30 MHz 42.54 N -17.45 2 CISPR Average30 MHz 38.23 L1 -11.76 Date: 13.JUL.2011 19:30:05 Report no.: HK11071265-1 Standby Mode AC Mains Ctrl No.: N/A 6DB AC 150 kHz30 MHz dBμV dBμV 1 PK CLRWR 2 AV CLRWR SGL TDS RBW 9 kHz MT 1 s PREAMP OFFAtt 10 dB AUTO 1 MHz10 MHz 0 10 20 30 40 50 60 70 80 90 100 CF15MAV CF15MQP Date: 13.JUL.2011 19:43:52 Report no.: HK11071265-1 Standby Mode AC Mains Ctrl No.: N/A EDIT PEAK LIST (Final Measurement Results) Trace1: CF15MQP Trace2: CF15MAV Trace3: --- TRACE FREQUENCY LEVEL dBμV DELTA LIMIT dB 2 CISPR Average348 kHz 23.95 L1 -25.05 1 Quasi Peak 4.047 MHz 26.31 N -29.68 1 Quasi Peak 10.0005 MHz 40.04 N -19.95 2 CISPR Average10.0005 MHz 35.61 N -14.38 1 Quasi Peak 30 MHz 41.79 N -18.20 2 CISPR Average30 MHz 37.85 L1 -12.14 Date: 13.JUL.2011 19:43:43 Report no.: HK11071265-1 USB Slideshow with Music Playing AC Mains Ctrl No.: N/A 6DB AC 150 kHz30 MHz dBμV dBμV 1 PK CLRWR 2 AV CLRWR SGL TDS RBW 9 kHz MT 1 s PREAMP OFFAtt 10 dB AUTO 1 MHz10 MHz 0 10 20 30 40 50 60 70 80 90 100 CF15MAV CF15MQP Date: 13.JUL.2011 19:38:23 Report no.: HK11071265-1 USB Slideshow with Music Playing AC Mains Ctrl No.: N/A EDIT PEAK LIST (Final Measurement Results) Trace1: CF15MQP Trace2: CF15MAV Trace3: --- TRACE FREQUENCY LEVEL dBμV DELTA LIMIT dB 1 Quasi Peak 159 kHz 40.42 L1 -25.09 1 Quasi Peak 424.5 kHz 30.50 L1 -26.86 1 Quasi Peak 784.5 kHz 30.33 L1 -25.66 1 Quasi Peak 829.5 kHz 30.71 L1 -25.28 1 Quasi Peak 1.194 MHz 29.90 L1 -26.09 1 Quasi Peak 2.0985 MHz 28.35 N -27.64 1 Quasi Peak 2.949 MHz 27.65 N -28.34 1 Quasi Peak 3.561 MHz 28.14 L1 -27.85 1 Quasi Peak 4.8795 MHz 27.47 N -28.52 1 Quasi Peak 10.0005 MHz 40.35 N -19.65 2 CISPR Average10.0005 MHz 35.82 N -14.17 1 Quasi Peak 30 MHz 42.39 N -17.61 2 CISPR Average30 MHz 38.15 L1 -11.84 Date: 13.JUL.2011 19:38:15

INTERTEK TESTING SERVICES Unwanted Emission Inside The Sub-Band Plots FCC ID: VLJ80-8402-01 inband - 1 of 1 A0 Digital Photo Frame unit, Lowest channel, Traffic carrier Digital Photo Frame unit, Highest channel, Traffic carrier

INTERTEK TESTING SERVICES Peak Transmit Power Plots FCC ID: VLJ80-8402-01 IC: 4522A-80840201 peaktp - 1 of 2 A0 Digital Photo Frame unit, Lowest channel, Traffic carrier Digital Photo Frame unit, Middle channel, Traffic carrier INTERTEK TESTING SERVICES Peak Transmit Power Plots FCC ID: VLJ80-8402-01 IC: 4522A-80840201 peaktp - 2 of 2 A0 Digital Photo Frame unit, Highest channel, Traffic carrier

INTERTEK TESTING SERVICES Power Spectral Density Plots FCC ID: VLJ80-8402-01 psd - 1 of 1 A0 Digital Photo Frame unit, Lowest channel, Traffic carrier Digital Photo Frame unit, Highest channel, Traffic carrier

- The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Binatone Electronics International Limited Application For 47 CFR Part 15 Certification RSS-213 Issue 2 Equipment Certification Unlicensed Personal Communication Service Devices/ 2 GHz License-exempt Personal Communications Service Devices (Digital Photo Frame Unit) FCC ID: VLJ80-8402-01 Model: MFV700PU IC: 4522A-80840201 Model: MFV700PU Test Report Number: HK11071265-1 Issue Date: July 29, 2011 MN/ cl INTERTEK TESTING SERVICES Test Report Number: HK11071265-1 Page 1 of 48 FCC ID: VLJ80-8402-01 IC: 4522A-80840201 Table of Contents 1.0 Summary of Test Results........................................................................................ 4 2.0 General Description................................................................................................. 7 2.1 Product Description ................................................................................................. 7 2.2 Technical Description .............................................................................................. 7 2.3 Test Methodology.................................................................................................... 7 2.4 Test Facility............................................................................................................. 7 3.0 System Test Configuration...................................................................................... 9 3.1 Justification ............................................................................................................. 9 3.2 Conducted Emission Test Configuration ................................................................ 10 3.3 Conducted Monitoring and Operational Test Configuration.................................... 10 3.4 EUT Exercising Software....................................................................................... 10 3.5 Details of EUT and Description of Peripherals....................................................... 11 3.6 Measurement Uncertainty ..................................................................................... 11 4.0 Measurement Results............................................................................................ 13 4.1 Antenna Requirement........................................................................................... 13 4.2 Digital Modulation Techniques............................................................................... 13 4.3 Emission Bandwidth.............................................................................................. 14 4.4 Directional Gain of the Antenna ............................................................................. 14 4.5 Peak Transmit Power ............................................................................................ 15 4.6 Power Spectral Density ......................................................................................... 16 4.7 Automatic Discontinuation of Transmission............................................................ 16 4.8 Unwanted Emission Inside the Sub-Band .............................................................. 17 4.9 Emissions Outside the Sub-Band .......................................................................... 18 4.9.1 Radiated Emissions Configuration Photographs ................................................. 19 4.9.2 Radiated Emissions Data ................................................................................... 19 4.9.3 Field Strength Calculation................................................................................... 23 4.9.4 Average Factor Calculation and Transmitter ON Time Measurements ................ 24 4.10 Radiated Emissions from Receiver ...................................................................... 24 4.10.1 Radiated Emission Configuration Photographs ................................................. 25 4.10.2 Radiated Emissions Data ................................................................................. 25 4.11 AC Power Line Conducted Emissions ................................................................. 27 4.11.1 AC Power Line Conducted Emissions Configuration Photographs .................... 28 4.11.2 AC Power Line Conducted Emissions Data ...................................................... 28 4.12 Radio Frequency Radiation Exposure.................................................................. 29 4.13 Radio Frequency Exposure Compliance.............................................................. 29 4.14 Frame Repetition Stability .................................................................................. 30 4.15 Frame Period and Jitter ...................................................................................... 31 4.16 Carrier Frequency…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: VLJ80-8402-01 IC: 4522A-80840201 config photos (radiated emission - digital photo frame unit) - 1 of 1 Radiated Emission – Digital Photo Frame Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Receiving IC: 4522A-80840201 config photos (radiated emission – digital photo frame unit) - 1 of 1 Radiated Emission - Digital Photo Frame Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: SD Card Slideshow with Music Playing FCC ID: VLJ80-8402-01 IC: 4522A-80840201 config photos (conducted emission) - 1 of 2 Conducted Emission Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: SD Card Slideshow with Music Playing FCC ID: VLJ80-8402-01 IC: 4522A-80840201 config photos (conducted emission) - 2 of 2 Conducted Emission Left Side View
