Doc Title : User’s Guide Revision : 1.0 Model : Motorola L70×CBT Page(s) : 1 of 40 This document contains confidential and proprietary information of VTech Telecommunications Ltd User’s Guide L702CBT / L703CBT / L704CBT / L705CBT DECT 6.0 Digital Cordless/Corded Phones with Bluetooth ® Wireless Technology and Answering Machine Warning Use only the adapter and telephone line cord provided in the box. Doc Title : User’s Guide Revision : 1.0 Model : Motorola L70×CBT Page(s) : 2 of 40 This document contains confidential and proprietary information of VTech Telecommunications Ltd Welcome to your new Motorola Phone! Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product-related questions, please call: US and Canada: 1-888-331-3383 On the Web: www.motorola.com .200 name and number phonebook for cordless handset and corded base totally. .Answering machine with up to 15 minutes digital recording time. * .Caller ID shows you who is calling and includes details of the last 30 callers in a calls list for cordless handset, and 28 callers in a calls list for the corded base. ** .Register up to 5 cordless handsets to the corded base. .Make internal calls, transfer external home calls, hold 3-way conversation between two internal callers and an external caller. *The recording time includes the pre-recorded voice menu and outgoing announcements. **You must subscribe to your network provider’s Caller ID or Call Waiting service for these features to work. Please note that only the corded phone operates during power outage (with limited functions). Doc Title : User’s Guide Revision : 1.0 Model : Motorola L70×CBT Page(s) : 3 of 40 This document contains confidential and proprietary information of VTech Telecommunications Ltd This User’s Guide provides you with all the information you need to get the most from your phone. Before you make your first call you will need to set up your phone. Follow the simple instructions in ‘Getting Started’, on the next few pages. IMPORTANT Use only the supplied telephone line cord. Got everything? . Cordless Handset .Cordless Charger .NiMH Rechargeable Battery Pack .Power Adapter for the Cordless Charger .Corded Base .Corded Handset .Power Adapter for the Corded Base .Wall-mount Bracket .Telephone Line Cords (one for connecting the corded base and handset) .User’s Guide .Quick Start Guide In multi-handset packs, you will find one or more additional cordless handsets, cordless chargers with power adapters, additional rechargeable battery packs and battery doors. Doc Title : User’s Guide Revision : 1.0 Model : Motorola L70×CBT Page(s) : 4 of 40 This document contains confidential and proprietary information of VTech Telecommunications Ltd TABLE OF CONTENTS 1 GETTING STARTED......................................................................................................................................... 7 1.1 INSTALLING AND CHARGING THE CORDLESS HANDSET BATTERY PACK....................................................... 7 1.2 INSTALLING THE CORDLESS CHARGER............................................................................................................ 8 1.3 CONNECTING THE CORDED BASE..................................................................................................................... 8 1.4 WALL MOUNTING ON CORDED BASE................................................................................................................ 8 1.5 SETTING THE DISPLAY LANGUAGE.................................................................................................................. 9 1.6 SETTING DATE AND TIME.................................................................................................................................. 9 2 GETTING TO KNOW YOUR PHONE .......................................................................................................... 10 2.1 OVERVIEW OF YOUR CORDED BASE............................................................................................................... 10 2.2 CORDED BASE LCD DISPLAY.......................................................................................................................... 11 2.3 OVERVIEW OF YOUR CORDLESS HANDSET.................................................................................................... 12 2.4 CORDLESS HANDSET LCD DISPLAY............................................................................................................... 14 ENJOY YOUR CORDED BASE PHONE ............................................................................................................ 14 3 BLUETOOTH ® ................................................................................................................................................. 14 3.1 INTRODUCING BLUETOOTH............................................................................................................................ 14 3.2 SETUP CELLULAR............................................................................................................................................ 15 3.3 PAIRED DEVICES.............................................................................................................................................. 15 3.3.1 CONNECTING/REMOVING A PAIRED DEVICE................................................................................................... 15 3.3.2 REPLACING A PAIRED DEVICE........................................................................................................................ 16 3.4 ACTIVE DEVICES............................................................................................................................................. 16 3.4.1 ADDING AN ACTIVE DEVICE................................................…

Text truncated - open the document above for the full version.

Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . Appendix B1 Letter of Agency for FCC Certification January 24, 2012 To whom it may concern, Letter of Agency I, an officer of Binatone Electronics International Limited do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Paul Tsui Product Operation Director

March 7, 2012 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: VLJ80-8620-00 Request is hereby submitted by Binatone Electronics International Limited to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and Binatone Electronics International Limited reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of Binatone Electronics International Limited and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards,

INTERTEK TESTING SERVICES External Photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 external photos - 1 of 2 HK12010461 Job Number HK12010461 Job Number INTERTEK TESTING SERVICES External Photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 external photos - 2 of 2

L70XCBT Base engraving 30-013860-002-100 for American Version L70XCBT Charger engraving 10.00 AC 6V 300mA MADE IN CHINA CORDLESS TELEPHONE 4H20 Accessory 30-011812-000-120 for American Version 24.00 AC 6V Engraving Text Raised 0.3mm 21.00 40.00 Background: Textured AC 6V Model : L702CBT S/N: XXXXXXXXXXX 30-012590-000-130 10.00 13.00 21.00 20.00 FCC ID:VLJ80-8619-00 IC:4522A-80862000 Engraving BATT-LABLE S/N-LABLE Raised 0.3mm Model : L702CBT S/N: XXXXXXXXXXX S/N-LABLE Model : L703CBT S/N: XXXXXXXXXXX Model : L702CBT S/N: XXXXXXXXXXX L70XCBT Handset engraving Recess 0.3mm,glossy FCC ID: VLJ80-8620-00 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,AND 2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. CORDLESS TELEPHONE DC 6V 450mA/300mA MADE IN CHINA L70XCBT FCC ID: VLJ80-8620-00 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,AND 2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. Engraving A Recess 0.3mm,glossy S/N Label 23.4mmX9.40mm CORDLESS TELEPHONE DC 6V 450mA/300mA MADE IN CHINA Engraving C 42.00 26.50 42.00 42.00 23.00 23.00 10.00 24.00 Engraving D Raised 0.3mm Model : L702CBT S/N: XXXXXXXXXXX Model : L703CBT S/N: XXXXXXXXXXX Model : L704CBT S/N: XXXXXXXXXXX Model : L705CBT S/N: XXXXXXXXXXX 4H20 IC: 4522A-80862000 COMPLIES WITH 47 CFR PART 68 REGISTRATION NO.:US: BINW401B80-862000 RINGER EQUIVALENCE: 0.1B USOC JACK: RJ11C/W HAC Customer service number: US and Canada: 1-888-331-3383 Web: www.motorola.com Engraving B Recess 0.3mm,glossy TELEPHONE EQUIPMENT 4H20 IC: 4522A-80862000 COMPLIES WITH 47 CFR PART 68 REGISTRATION NO.:US: BINW401B80-862000 RINGER EQUIVALENCE: 0.1B USOC JACK: RJ11C/W HAC Customer service number: US and Canada: 1-888-331-3383 Web: www.motorola.com TELEPHONE EQUIPMENT TEL. LINE Engraving E Raised 0.3mm DC 6V USB TEL. LINE DC 6V USB Model : L704CBT S/N: XXXXXXXXXXX Model : L705CBT S/N: XXXXXXXXXXX Model : L702CBT S/N: XXXXXXXXXXX Model : L703CBT S/N: XXXXXXXXXXX Model : L704CBT S/N: XXXXXXXXXXX Model : L705CBT S/N: XXXXXXXXXXX

INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 internal photos - 1 of 9 Base Unit assembly Base Unit Main PCB comp side (View 1) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 internal photos - 2 of 9 Base Unit Main PCB comp side (View 2) Base Unit Main PCB solder side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 internal photos - 3 of 9 Base Unit Antenna 1 Base Unit Antenna 2 INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 internal photos - 4 of 9 Base Unit Keypad front side Base Unit Keypad rear side (View 1) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 internal photos - 5 of 9 Base Unit Keypad rear side (View 2) Base Unit Display front side (View 1) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 internal photos - 6 of 9 Base Unit Display front side (View 2) Base Unit Display rear side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 internal photos - 7 of 9 Base Unit On/Off Hook front side Base Unit On/Off Hook rear side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 internal photos - 8 of 9 Base Unit Bluetooth Module comp side Base Unit Bluetooth Module solder side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-8620-00 IC: 4522A-80862000 internal photos - 9 of 9 Base Unit Oscillator PCB comp side

- The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report Number: HK12010461-2 Application for Original Grant of 47 CFR Part 15 Certification New Family of RSS-210 Issue 8 Equipment Certification 1.9GHz Digital Modulation Cordless/Corded Phone with Caller ID, Digital Answering Machine and Bluetooth - Base Unit Bluetooth Portion FCC ID: VLJ80-8620-00 IC: 4522A-80862000 Prepared and Checked by: Approved by: Signed on File Koo Wai Ip Nip Ming Fung, Melvin Senior Lead Engineer Senior Supervisor March 12, 2012 INTERTEK TESTING SERVICES Test Report Number: HK12010461-2 Page 1 of 28 FCC ID: VLJ80-8620-00 IC: 4522A-80862000 GENERAL INFORMATION Applicant Name: Binatone Electronics International Ltd. Applicant Address: Floor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2010 Edition FCC ID: VLJ80-8620-00 FCC Model(s): L702CBT, L703CBT, L704CBT, L705CBT, L70XCBT IC Specification Standard: RSS-210 Issue 8, December 2010 RSS-Gen Issue 3, December 2010 RSS-102 Issue 4, March 2010 RSS-310 Issue 3, December 2010 IC: 4522A-80862000 IC Model(s): L702CBT, L703CBT, L704CBT, L705CBT Type of EUT: Transceiver Description of EUT: 1.9GHz Digital Modulation Cordless/Corded Phone with Caller ID, Digital Answering Machine and Bluetooth - Base Unit Bluetooth Portion Serial Number: N/A Sample Receipt Date: January 12, 2012 Date of Test: Jan 16 - Feb 02, 2012 Report Date: March 12, 2012 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Test Report Number: HK12010461-2 Page 2 of 28 FCC ID: VLJ80-8620-00 IC: 4522A-80862000 Table of Contents 1.0 Test Results Summary & Statement of Compliance.............................................. 4 1.1 Summary of Test Results ........................................................................................ 4 1.2 Statement of Compliance ........................................................................................ 4 2.0 General Description................................................................................................. 6 2.1 Product Description ................................................................................................. 6 2.2 Test Methodology.................................................................................................... 7 2.3 Test Facility............................................................................................................. 7 3.0 System Test Configuration...................................................................................... 9 3.1 Justification ............................................................................................................. 9 3.2 EUT Exercising Software....................................................................................... 10 3.3 Details of EUT and Description of Accessories...................................................... 11 3.4 Measurement Uncertainty ..................................................................................... 11 4.0 Test Results............................................................................................................ 13 4.1 Field Strength Calculation...................................................................................... 13 4.2 Radiated Emissions............................................................................................... 14 4.2.1 Radiated Emission Configuration Photograph ..................................................... 14 4.2.2 Radiated Emission Data ..................................................................................... 14 4.2.3 Transmitter Duty Cycle Calculation ..................................................................... 15 4.3 Radiated Emissions from Receiver ........................................................................ 20 4.3.1 Radiated Emission Configuration Photograph ..................................................... 20 4.3.2 Radiated Emission Data ..................................................................................... 20 4.4 Radiated Emission on the Bandedge..................................................................... 22 4.5 AC Power Line Conducted Emission ..................................................................... 23 4.5.1 AC Power Line Conducted Emission Configuration Photograph.......................... 23 4.5.2 AC Power Line Conducted Emission Data .......................................................... 23 4.6 Radio Frequency Exposure Compliance................................................................ 26 5.0 Equipment List...................................................................................................... 28 INTERTEK TESTING SERVICES Test Report Number: HK12010461-…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES Radiated Emission on the Bandedge Plots FCC ID: VLJ80-8620-00 be - 1 of 1 Base unit, Lowest channel Base unit, Highest channel

Report No.:HK12010461-2 Model: L702CBT Mode: Talk (DECT + BT) + USB Charging AC Mains Ctrl No.: 150 kHz30 MHz 1 PK CLRWR 2 AV CLRWR SGL TDS 6DB dBμV dBμV AC RBW 9 kHz MT 1 s PREAMP OFFAtt 10 dB AUTO 1 MHz10 MHz 0 10 20 30 40 50 60 70 80 90 100 CF15MAV CF15MQP Date: 16.JAN.2012 22:04:38 Report No.:HK12010461-2 Model: L702CBT Mode: Talk (DECT + BT) + USB Charging AC Mains Ctrl No.: EDIT PEAK LIST (Final Measurement Results) Trace1: CF15MQP Trace2: CF15MAV Trace3: --- TRACE FREQUENCY LEVEL dBμV DELTA LIMIT dB 2 CISPR Average6.585 MHz 34.92 N gnd -15.08 1 Quasi Peak 6.6075 MHz 48.42 N gnd -11.57 1 Quasi Peak 8.025 MHz 41.33 L1 gnd -18.67 2 CISPR Average8.2095 MHz 35.77 L1 gnd -14.22 Date: 16.JAN.2012 22:03:50

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: EW780-8620-00 IC: 4522A-80862000 config photos (radiated emission - base unit) - 1 of 1 Radiated Emission - Base Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Receiving IC: 4522A-80862000 config photos (radiated emission - base unit) - 1 of 1 Radiated Emission - Base Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk (DECT+BT) + USB Charging FCC ID: VLJ80-8620-00 IC: 4522A-80862000 config photos (conducted emission) - 1 of 2 Conducted Emission Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk (DECT+BT) + USB Charging FCC ID: VLJ80-8620-00 IC: 4522A-80862000 config photos (conducted emission) - 2 of 2 Conducted Emission Left Side View
