VLJ80-9185-001.9GHz Digital Modulation Cordless Phone

User’s Guide K701/ K702/ K703/ K704/ K705 DECT 6.0 Digital Cordless Phone with Answering Machine Warning Use only the adapter and telephone line cord provided in the box. Welcome... to your new Motorola phone! Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product-related questions, please call or visit us online: US and Canada: 1-888-331-3383 On the Web: www.motorola.com • 30 name and number phonebook. • Caller ID shows you who is calling and includes details of the last 30 callers in a calls list.** • Register up to 5 cordless handsets to a single base. • Make internal calls, transfer external calls, hold 3-way conversations between two internal callers and an external caller. **You must subscribe to your network provider’s Caller ID or Call Waiting service for these features to work. Please note that this equipment is not designed for making emergency telephone calls when the power fails. Alternative arrangements should be made if an emergency telephone call is necessary. This ENERGY STAR ® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR ® label indicating it meets the latest energy efficiency guidelines. This User’s Guide provides you with all the information you need to get the most from your phone. Before you make your first call you will need to set up your phone. Follow the simple instructions in ‘Getting Started’, on the next few pages. IMPORTANT Only use the telephone line cord supplied. This equipment is not designed to make emergency telephone calls during power failures. Alternative arrangements should be made for access to emergency services. Got everything? • Handsets • Base • NiMH Rechargeable Battery Pack • Battery Door • Power Adapter • Charger • Telephone Line Cord • User’s Guide • Quick Start Guide In multi-handset packs, you will find one or more additional handsets, chargers with power adapter units, additional rechargeable battery packs and battery doors. 4 Contents 1. Getting started ..................................................8 1.1 Connecting the base ................................9 1.2 Connecting the charger ............................9 1.3 Installing and charging the handset battery pack ............................................10 1.4 Setting the display language ..................10 1.5 Setting the date and time .......................10 2. Getting to know your phone .........................11 2.1 Overview of your handset ......................11 2.2 Cordless handset LCD display ...............15 2.3 Overview of the base .............................16 2.4 Overview of the charger .........................19 3. Using the phone .............................................19 3.1 Making a call ..........................................19 3.1.1 Preparatory dialing ....................19 3.1.2 Direct dialing .............................19 3.1.3 Dialing from the phonebook ......19 3.1.4 Dialing from the redial list .........19 3.1.5 Dialing from the calls list ...........20 3.1.6 Dialing from the speed dial location .....................................20 3.2 Muting a call ...........................................20 3.3 Answering a call .....................................20 3.4 Ending a call ...........................................20 3.5 Adjusting the volume ..............................20 3.6 Call waiting .............................................20 3.7 Redialing the last number ......................21 3.7.1 Redialing a number from the redial list ....................................21 3.7.2 Storing a redial number into the phonebook ..................................21 3.7.3 Deleting a redial number ...........21 3.7.4 Deleting the entire redial list .....22 3.10 Phonebook .............................................22 3.10.1 Reviewing an entry in the phonebook ................................22 3.10.2 Adding an entry to the phonebook ................................22 45 3.10.3 Storing a phonebook entry to a speed dial location .................23 3.10.4 Dialing from the phonebook ......23 3.11 Speed dial ..............................................24 3.11.1 Reviewing the entry in a speed dial location ....................24 3.11.2 Storing an entry to a speed dial location ...............................24 3.11.4 Deleting an entry in a speed dial location ...............................25 3.12 Memory ..................................................25 3.12.1 Storing a memory number ........25 3.12.2 Reviewing a memory number ... 26 3.12.3 Dialing from the memory ...........26 3.12.4 Editing a memory number .........26 3.12.5 Deleting a memory number ......27 3.13 Caller ID .................................................27 3.13.1 Calls List ...................................27 3.13.2 Viewing the calls list ..................28 3.13.3 Saving a number from the calls list to the phonebook ........28 3.13.4 Deleting a calls list entry ...........29 3.13.5 Deleting the entire calls list .......29 3.14 Personal settings ....................................30 3.15 Intercom .................................................31 3.15.1 Calling another handset ............31 3.15.2 Transferring a call to another handset .....................................32 3.15.3 Three-party conference calls ....32 3.16 Handset settings ....................................32 3.16.1 Setting the ringer tone ..............32 3.16.2 Setting the ringer volume ..........33 3.16.3 Setting the alert tone .................33 3.16.4 Renaming the handset ..............34 3.16.5 Setting the language .................34 3.16.6 Setting the contrast ...................34 3.16.7 Setting the equalizer .................34 3.16.8 Setting th…

Text truncated - open the document above for the full version.

Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . Appendix B1 Letter of Agency for FCC Certification April 8, 2013 To whom it may concern, Letter of Agency I, an officer of Binatone Electronics International Limited do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and/or Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards,

Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . April 8, 2013 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: VLJ80-9185-00 Request is hereby submitted by Binatone Electronics International Limited to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and Binatone Electronics International Limited reserves the right to discern which parties can obtain access to these information:  Schematics  Detailed Block diagrams  Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of Binatone Electronics International Limited and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ .

Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . April 8, 2013 To whom it may concern, Declarations FCC ID: VLJ80-9185-00 IC: 4522A-80918500 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the handset will act as the initiating device, which will initiate the establishment of the duplex connection. 4. For FCC, Upper Monitoring Threshold of base unit and handset unit declared by manufacturer are -60.6 dBm and -60.6 dBm respectively 5. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Base Unit Reaction of Handset unit 1 Switch-off companion device NA NA 2 On hook by companion device B NA 3 Remove power from companion device B A 4 Switch-off device NA NA 5 On hook device NA C 6 Remove power from device A C A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. N/A – Not applicable represents the device does not contain a hook switch or a power off switch. If you have questions or need further information, please contact the undersigned. Regards,

Binatone Electronics International Limited Floor 23A, 9 Des Voeux Road West, Hong Kong Tel: (852) 2802 7388 Fax: (852) 2802 8138 _______________________________________ . April 8, 2012 To whom it may concern, Label Location Justification FCC ID: VLJ80-9185-00 Request is hereby submitted by Binatone Electronics International Limited to request an alternative method of positively identifying the equipment, pursuant to 47 CFR § 2.925(f) of the FCC Rules. The FCC identifier for Handset and Speaker Pod will be placed in the battery compartment and the following requirements are confirmed to meet: a) The FCC identifier will visible at the time of purchase, by either of the following approaches:  Marketing the device without the battery installed, or  Providing instruction (stated on the box, user manual or additional documentation) directing the user as to where to find the FCC label. b) The user accessible area will not require any special tools for access and the FCC label will not be placed on a removable part. The user manual has already included the FCC statements, pursuant to 47 CFR § 15.19(a)(3), 15.21 and 15.105(b). If you have questions or need further information, please contact the undersigned. Sincerely,

INTERTEK TESTING SERVICES External Photos FCC ID: VLJ80-9185-00 IC: 4522A-80918500 external photos - 1 of 2 HK13031173 Job Number HK13031173 Job Number INTERTEK TESTING SERVICES External Photos FCC ID: VLJ80-9185-00 IC: 4522A-80918500 external photos - 2 of 2

K70X Tam base engraving Background: Textured K70X Charger engraving THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE; AND 2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. DC 5V 450mA CORDLESS TELEPHONE Customer service number: US and Canada: 1-888-331-3383 Web:www.motorola.com 4H20 MADE IN CHINA FCC ID: VLJ80-9185-00 IC: 4522A-80918500 COMPLIES WITH 47 CFR PART 68 REGISTRATION NO.: US: BINW401B80-918500 RINGER EQUIVALENCE: 0.1B USOC JACK: RJ11C HAC Model:K702 S/N: XXXXXXXXXXX 118.0mm 59.0mm 1.5mm 28.0mm 10.00 DC 6V 300mA MADE IN CHINA CORDLESS TELEPHONE 4H20 Accessory 24.00 21.00 40.00 Background: Textured Model : K702 S/N: XXXXXXXXXXX K70X Hs engraving FCC ID:VLJ80-9185-00 IC:4522A- 80918500 Background: Textured BC BC Model : K7 S/N: XXXXXXXXXXX BC Model : K702 S/N: XXXXXXXXXXX BC Model : K703 S/N: XXXXXXXXXXX BC Model : K7 S/N: XXXXXXXXXXX Model : K704 S/N: XXXXXXXXXXX BC Model : K705 S/N: XXXXXXXXXXX BC Model:K702 S/N: XXXXXXXXXXX BC Model:K703 S/N: XXXXXXXXXXX BC Model:K704 S/N: XXXXXXXXXXX BC Model:K705 S/N: XXXXXXXXXXX BC Model:K701 S/N: XXXXXXXXXXX BC Model : K701 S/N: XXXXXXXXXXX Model : K702 S/N: XXXXXXXXXXX Model : K703 S/N: XXXXXXXXXXX Model : K704 S/N: XXXXXXXXXXX Model : K705 S/N: XXXXXXXXXXX Model : K702 S/N: XXXXXXXXXXX 28.0mm 8.0mm 20 10

INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-9185-00 IC: 4522A-80918500 internal photos - 1 of 8 Base Unit assembly Base Unit Main PCB comp side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-9185-00 IC: 4522A-80918500 internal photos - 2 of 8 Base Unit Main PCB solder side Base Unit Antenna INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-9185-00 IC: 4522A-80918500 internal photos - 3 of 8 Base Unit DAM front side Base Unit DAM rear side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-9185-00 IC: 4522A-80918500 internal photos - 4 of 8 Base Unit Oscillator PCB comp side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-9185-00 IC: 4522A-80918500 internal photos - 5 of 8 Handset assembly Handset Main PCB comp side (View 1) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-9185-00 IC: 4522A-80918500 internal photos - 6 of 8 Handset Main PCB comp side (View 2) Handset Main PCB comp side (View 3) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-9185-00 IC: 4522A-80918500 internal photos - 7 of 8 Handset Main PCB display side (View 1) Handset Main PCB display side (View 2) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJ80-9185-00 IC: 4522A-80918500 internal photos - 8 of 8 Handset Oscillator PCB comp side

A Test Lab Techno Corp. Changan Lab：No. 140 -1, Changan Street, Bade City, Taoyuan County, Taiwan R.O.C. Te l：886-3-271-0188 / Fax：886-3-271-0190 SAR EVALUATION REPORT Test Report No. ： 1305FS11-01 Applicant ： Binatone Electronics International Limited EUT Type ： 1.9GHz DECT6.0 Cordless Phone FCC ID ： VLJ80-9185-00 Trade Name ： Motorola Model Number ： K701, K702, K703, K704, K705, K70X, K7 Dates of Receive ： Apr. 23, 2013 Dates of Test ： Apr. 25 ~ Apr. 26, 2013 Date of Issued ： May 22, 2013 Test Environment ： Ambient Temperature： 22 ±2 ° C Relative Humidity：40 - 70 % Test Specification ： Standard C95.1-1992 IEEE Std. 1528-2003 IEEE Std. 1528a-2005 2.1093;FCC/OET Bulletin 65 Supplement C [July 2001] Max. Reported SAR ： 0.03 W/kg UPCS Head SAR Test Lab Location ： Chang-an Lab 1. The test operations have to be performed with cautious behavior, the test results are as attached. 2. The test results are under chamber environment of A Test Lab Techno Corp. A Test Lab Techno Corp. does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples. 3. The measurement report has to be written approval of A Test Lab Techno Corp. It may only be reproduced or published in full. This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. The test results in the report only apply to the tested sample. Approved By ： Tested By ： (Yung Tan Tsai ) (Bill Hu) ©2013 A Test Lab Techno Corp. Report Number: 1305FS11-01Page 1 of 63 Contents 1. Description of Equipment under Test (EUT) .................................................................................................. 3 2. Introduction .................................................................................................................................................... 4 3. SAR Definition ............................................................................................................................................... 4 4. SAR Measurement Setup .............................................................................................................................. 5 5. System Components ..................................................................................................................................... 6 5.1 DASY5 E-Field Probe System......................................................................................................... 6 5.2 Data Acquisition Electronic (DAE) System ...................................................................................... 9 5.3 Robot ............................................................................................................................................... 9 5.4 Measurement Server ....................................................................................................................... 9 5.5 Device Holder for Transmitters ...................................................................................................... 10 5.6 Phantom - SAM v4.0 ..................................................................................................................... 10 5.7 Data Storage and Evaluation..........................................................................................................11 6. Test Equipment List ..................................................................................................................................... 14 7. Tissue Simulating Liquids ............................................................................................................................ 15 7.1 Ingredients ..................................................................................................................................... 16 7.2 Recipes.......................................................................................................................................... 16 7.3 Liquid Depth................................................................................................................................... 17 8. Measurement Process................................................................................................................................. 18 8.1 Device and Test Conditions ........................................................................................................... 18 8.2 Conducted power .......................................................................................................................... 18 8.3 SAR Testing with RF Transmitters................................................................................................. 19 8.4 System Performance Check.......................................................................................................... 21 8.5 Dosimetric Assessment Setup....................................................................................................... 23 8.6 Spatial Peak SAR Evaluation ........................................................................................................ 25 9. Measurement Uncertainty............................................................................................................................ 26 10. SAR Test Results Summary ........................................................................................................................ 29 10.1 Head SAR...................................................................................................................................... 29 10.2 Std. C95.1-1992 RF Exposure Limit .............................................................................................. 30 11. Conclusion ................................................................................................................................................... 31 12. SAR Measurement Guidance .............................................................................................…

Text truncated - open the document above for the full version.

SAR EUT Photographs EUT Photo 1 ) EUT Photo 2 ) ©2013 A Test Lab Techno Corp. Report Number: 1305FS11-01Page 1 of 6 EUT Photo 3 ) EUT Photo 4 ) ©2013 A Test Lab Techno Corp. Report Number: 1305FS11-01Page 2 of 6 ©2013 A Test Lab Techno Corp. EUT Photo 5 ) EUT Photo 6 ) Report Number: 1305FS11-01Page 3 of 6 ©2013 A Test Lab Techno Corp. EUT Photo 7 ) EUT Photo 8 ) Report Number: 1305FS11-01Page 4 of 6 EUT Photo 9 ) EUT Photo 10 ) ©2013 A Test Lab Techno Corp. Report Number: 1305FS11-01Page 5 of 6 EUT Photo 11 ) EUT Photo 12 ) ©2013 A Test Lab Techno Corp. Report Number: 1305FS11-01Page 6 of 6

SAR Test Setup Photographs EUT Side Definition Item Side 1 EUT Top side 2 EUT Front side 3 EUT Back side n p o ©2013 A Test Lab Techno Corp. Report Number: 1305FS11-01Page 1 of 3 Right Head Setup Figure 2. Right Head SAR Test Setup (Cheek)Figure 3. Right Head SAR Test Setup (Tilted) n p o ©2013 A Test Lab Techno Corp. Report Number: 1305FS11-01Page 2 of 3 Left Head Setup Figure 4. Left Head SAR Test Setup (Cheek) Figure 5. Left Head SAR Test Setup (Tilted) o p n ©2013 A Test Lab Techno Corp. Report Number: 1305FS11-01Page 3 of 3

Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Test Report Number: 13031173HKG-001Page 1 of 83 FCC ID: VLJ-80-9185-00 IC: 4522A-80918500 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com GENERAL INFORMATION Applicant Name: Binatone Electronics International Limited Applicant Address: Floor 23A, 9 Des Voeux Road West, Sheung Wan, Hong Kong. FCC Specification Standard: FCC Part 15, October 1, 2011 Edition and 77 FR 43013, July 23, 2012 FCC ID: VLJ80-9185-00 FCC Model(s): K701, K702, K703, K704, K705, K70X, K7 IC Specification Standard: RSS-213 Issue 2, December 2005 RSS-Gen Issue 3, December 2010 IC: 4522A-80918500 IC Model(s): K701, K702, K703, K704, K705; K7 Type of EUT: Unlicensed Personal Communications Service Devices Description of EUT: 1.9GHz Digital Modulation Cordless Phone with Caller ID, Speakerphone and Digital Answering Machine Serial Number: N/A Sample Receipt Date: March 25, 2013 Date of Test: April 18-24, 2013 Report Date: May 24, 2013 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% Issuing Laboratory: Intertek Testing Services Hong Kong Limited Hong Kong Accreditation Service (HKAS) has accredited this laboratory under the Hong Kong Laboratory Accreditation Scheme (HOKLAS) for specific laboratory activities as listed in the HOKLAS directory of accredited laboratories. The results shown in this report were determined by this laboratory in accordance with its terms of accreditation. Test Report Number: 13031173HKG-001Page 2 of 83 FCC ID: VLJ-80-9185-00 IC: 4522A-80918500 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Table of Contents 1.0 Test Results Summary & Statement of Compliance....................................................5 1.1 Summary of Test Results...................................................................................................5 1.2 Statement of Compliance...................................................................................................7 2.0 General Description..............................................................................................................9 2.1 Product Description..............................................................................................................9 2.2 Technical Description...........................................................................................................9 2.3 Test Methodology...............................................................................................................10 2.4 Test Facility.........................................................................................................................10 3.0 System Test Configuration...............................................................................................12 3.1 Justification.........................................................................................................................12 3.2 Conducted Emission Test Configuration.........................................................................13 3.3 Conducted Monitoring and Operational Test Configuration..........................................13 3.4 EUT Exercising Software..................................................................................................13 3.5 Details of EUT and Description of Accessories..............................................................14 3.6 Measurement Uncertainty.................................................................................................14 4.0 Measurement Results.........................................................................................................16 4.1 Antenna Requirement........................................................................................................16 4.2 Digital Modulation Techniques..........................................................................................16 4.3 Emission Bandwidth...........................................................................................................17 4.4 Directional Gain of the Antenna........................................................................................22 4.5 Peak Transmit Power........................................................................................................23 4.6 Power Spectral Density.....................................................................................................28 4.7 Automatic Discontinuation of Transmission....................................................................32 4.8 Unwanted Emission Inside the Sub-Band.......................................................................33 4.9 Emissions Outside the Sub-Band.....................................................................................40 4.9.1 Radiated Emissions Configuration Photographs.........................................................41 4.9.2 Radiated Emissions Data...............................................................................................41 4.9.3 Field Strength Calculation..............................................................................................51 4.9.4 Average Factor Calculation and Transmitter ON Time Measurements....................52 4.10 AC Power Line Conducted Emissions...........................................................................53 4.10.1 AC Power Line Conducted Emissions …

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: VLJ80-9185-00 IC: 4522A-80918500 config photos (radiated emission - base unit) - 1 of 2 Radiated Emission - Base Unit (with adaptor “Ten Pao”) Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: VLJ80-9185-00 IC: 4522A-80918500 config photos (radiated emission - base unit) - 2 of 2 Radiated Emission - Base Unit (with adaptor “Sunstrong”) Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Transmission FCC ID: VLJ80-9185-00 IC: 4522A-80918500 config photos (radiated emission - handset) - 1 of 1 Radiated Emission - Handset Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk FCC ID: VLJ80-9185-00 IC: 4522A-80918500 config photos (conducted emission) - 1 of 4 Conducted Emission (with adaptor “Sunstrong”) Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk FCC ID: VLJ80-9185-00 IC: 4522A-80918500 config photos (conducted emission) - 2 of 4 Conducted Emission Left Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk FCC ID: VLJ80-9185-00 IC: 4522A-80918500 config photos (conducted emission) - 3 of 4 Conducted Emission (with adaptor “Ten Pao”) Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs - Mode: Talk FCC ID: VLJ80-9185-00 IC: 4522A-80918500 config photos (conducted emission) - 4 of 4 Conducted Emission Left Side View
