VLJVEVA12101.9GHZ CORDLESS PHONE

USER GUIDE THIS EQUIPMENT IS NOT DESIGNED FOR MAKING EMERGENCY TELEPHONE CALLS WHEN THE POWER FAILS. ALTERNATIVE ARRANGEMENTS SHOULD BE MADE FOR ACCESS TO DIAL EMERGENCY SERVICES. Before operating this set, please read these instructions carefully. DIGITAL CORDLESS TELEPHONE WITH ANSWERING MACHINE Veva1210 CANCEL MENU TALK PHONE BOOK ON/OFF MUTE FLASH R E D I A L CID P A U S E IMPORTANTES MESURES DE SÉCURITÉ Certaines mesures de sécurité doivent être prises pendant l’utilisation de matérial téléphonique afin de réduire les risques d’incendie, de choc électrique et de blessures. En voici quelquesunes: 1.Ne pas utiliser l’appareil près de l’eau, p.ex., près d’une baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à laver, dans un sous-sol humide ou près d’une piscine. 2.Éviter d’utiliser le téléphone (sauf s’il s’agit d’un appareil sans fil) pendant un orage électrique. Ceci peut présenter un risque de choc électrique causé par la foudre. 3.Ne pas utiliser l’appareil téléphonique pour signaler une fuite de gaz s’il est situé près de la fuite. 4.Utiliser seulement le cordon d’alimentation et le type de piles indiqués dans ce manuel. Ne pas jeter les piles dans le feu: elles peuvent exploser. Se conformer aux règlements pertinents quant à l’élimination des piles. 5.la socklet-sortie sera installée près de l'équipement et serafacilement accessible 6.ATTENTION- Il y a danger d’explosion s’il y a remplacement incorrect de la batterie. Remplacer uniquement avec une batterie du même type ou d’un type équivalent recommandé par le constructeur. Mettre au rebut les batteries usagées conformément aux instructions du fabricant. CONSERVER CES INSTRUCTIONS ================================================ uniquement avec les piles rechargeables ’ ’ A utiliser SANIK 2SN AAA 6 0H-S-J P 2, NiMH 6 00mAh ,2.4V . IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. 2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. 3. Do not use the telephone to report a gas leak in the vicinity of the leak. 4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions. 5. Plug the adaptor to the socket-outlet that near the equipment and shall be easily accessible. 6. CAUTION Risk of explosion if battery is replaced by an Incorrect type. Dispose of used batteries according to the instructions. Use only with SANIK SAVE THESE INSTRUCTIONS ================================================ rechargeable battery pack . 2SN AAA 6 0H-S-J P 2, NiMH 6 00mAh ,2.4V . This equipment is approved for connection to the Public Switched Telephone Network and complies with Part 15 and 68 of the FCC rules and the requirements adopted by the ACTA. Notification to Local Telephone Company On the bottom of this equipment is a label that contains, among other information, BINW400BVEVA1210 and Ringer Equivalence Number (REN) for the equipment. If requested, this number must be provided to the telephone company. The REN is used to determine the number of devices that may be connected to a telephone line. Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most but not all areas, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone company. [For products approved after July 23, 2001, the REN for this product is part of the product identifier that has the format US:AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is separately shown on the label.] A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See installation instructions for details. NOTICE: xIf your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this product does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer. Equipment Approval Information xConnection to a party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information. xAC electrical surges, typically resulting from lightning strikes, are very destructive to the telephone equipment connected to AC power sources. To minimize damage from these types of surges, a surge arrestor is recommended Rights of the Telephone Company If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required or may request that you disconnect the equipment until the problem is resolved. But if advance notice isn't practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary. The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the operation of the equipment. If this happens the telephone company will provide advance notice in order for you to make necessary modifications…

Text truncated - open the document above for the full version.

BINATONE ELECTRONICS INTERNATIONAL LTD. ******************************************************************************************************************** [Date] 17 Dec 2007 To whom it may concern, Let ter of Agency I, an officer of Binatone Electronics International Ltd. do hereby authorize Intertek Testing Services (Mr. Ken Sit/ Mr. Tommy Leung) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and Part 95 of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, . [Signature] Paul Tsui . [Name] Product Operation Director . [Title]

BINATONE ELECTRONICS INTERNATIONAL LTD. ***************************************************************************************************** Date: 18 Feb 2008 To whom it may concern, Declarations FCC ID:VLJVEVA1210 I, the undersigned, hereby declare that 1. The device does not use the provisions of 47CFR 15.323 (c) (6), random waiting mechanism is not used in this system. 2. The provisions of 47CFR 15.323 (c) (10) and 47CFR 15.323 (c) (11) are not used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. 3. Only the handset will act as the initiating device, which will initiate the establishment of the duplex connection. 4. The device complies with the provisions of 47CFR 15.319(f). The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude transmission of control and signaling information or use of repetitive codes used by certain digital technologies to complete frame or burst intervals. The following table explains the reaction of device in case of either absence of information to transmit or operational failure after a connection of its companion device is established. Circumstances Reaction of Base Unit Reaction of Handset 1 Switch-off companion device B N/A 2 On Hook by companion device B N/A 3 Switch-off device C 4 On Hook on device side NA C 5 Remove power from device A C 6 Remove power from companion device B A A – Connection is terminated and, transmission ceases. B – Connection is terminated but device transmits control or signaling information. C – Connection is terminated but companion device transmits control or signaling information. NA – Not applicable If you have questions or need further information, please contact the undersigned. Regards, . Name:Paul Tsui Title:Product Operation Director

BINATONE ELECTRONICS INTERNATIONAL LTD. *********************************************************************************** [Date] 18 Feb 2008 To whom it may concern, Label Location Justification FCC ID: VLJVEVA1210 Request is hereby submitted by Binatone Electronics International Ltd. to request an alternative method of positively identifying the equipment, pursuant to 47 CFR § 2.925(f) of the FCC Rules. The FCC identifier for handset will be placed in the battery compartment and the following requirements are confirmed to meet: a) The FCC identifier will visible at the time of purchase, by either of the following approaches: • Marketing the device without the battery installed, or • Providing instruction (stated on the box, user manual, or additional documentation) directing the user as to where to find the FCC label. b) The user accessible area will not require any special tools for access and the FCC label will not be placed on a removable part. The user manual has already included the FCC statements, pursuant to 47 CFR § 15.19(a)(3), 15.21 and 15.105(b). If you have questions or need further information, please contact the undersigned. Sincerely, . [Signature] Paul Tsui . [Name] Product Operation Director . [Title]

BINATONE ELECTRONICS INTERNATIONAL LTD. ******************************************************************************************************************** [Date] 18 Feb 2008 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: VLJVEVA1210 Request is hereby submitted by Binatone Electronics International Ltd. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and Binatone Electronics International Ltd. reserves the right to discern which parties can obtain access to these information: • Schematics[FILENAME:VLJVEVA1210_circuit.pdf] • Detailed Block diagrams [FILENAME:VLJVEVA1210_block.pdf] • Detailed Operational/Functional Description [FILENAME:VLJVEVA1210_descri.pdf] The rationale for request for confidentiality is as followings: This information represents intellectual property of Binatone Electronics International Ltd. and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, . [Signature] Paul Tsui . [Name] Product Operation Director . [Title]

INTERTEK TESTING SERVICES External Photos FCC ID: VLJVEVA1210 external photos - 1 of 2 INTERTEK TESTING SERVICES External Photos FCC ID: VLJVEVA1210 external photos - 2 of 2

K0712 000001G 1 2 3 4 5 6 7 8 9 K07 012 00001G 23.4mm 35.8mm 37.0mm 35.4mm 26.8mm VEVA 1210 VEVA 1210 3133379 3 VLJVEVA1210 BINW400BVEVA1210 IC: 4522A-VEVA1210 FCC REN = 0.0B and IC REN = 0.0 PRIVACY OF COMMUNICATION MAY NOT BE ENSURED WHEN WHEN USING THIS PHONE. RED BLACK VEVA 1210 VLJVEVA1210 IC: 4522A-VEVA1210

INTERTEK TESTING SERVICES Internal photos FCC ID: VLJVEVA1210 internal photos - 1 of 7 Base Unit assembly Base Unit Main PCB comp side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJVEVA1210 internal photos - 2 of 7 Base Unit Main PCB solder side Base Unit Oscillator PCB comp side (View 1) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJVEVA1210 internal photos - 3 of 7 Base Unit Oscillator PCB comp side (View 2) Base Unit Oscillator PCB comp side (View 3) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJVEVA1210 internal photos - 4 of 7 Handset assembly Handset Main PCB comp side INTERTEK TESTING SERVICES Internal photos FCC ID: VLJVEVA1210 internal photos - 5 of 7 Handset Main PCB display side (View 1) Handset Main PCB display side (View 2) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJVEVA1210 internal photos - 6 of 7 Handset Oscillator PCB comp side (View 1) Handset Oscillator PCB comp side (View 2) INTERTEK TESTING SERVICES Internal photos FCC ID: VLJVEVA1210 internal photos - 7 of 7 Handset Oscillator PCB comp side (View 3)

©2008 A Test Lab Techno Corp. Page 1 of 37 This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. R e v. 0 1 This document may be altered or revised by A Test Lab Techno. Corp. personnel only, and shall be noted in the revision section of the document A Test Lab Techno Corp. Changan Lab：No. 140 -1, Changan Street, Bade City, Taoyuan County, Taiwan R.O.C. Te l：886-3-271-0188 / Fax：886-3-271-0190 SAR EVALUATION REPORT Test Report No. ： 0802FS23 Applicant ： Binatone Electronics International Ltd. FCC ID ： VLJVEVA1210 Trade Name ： Binatone Model Name ： Veva 1210 Twin Battery Type ： Ni-MH Battery (2.4V，600mAh) EUT Type ： 1.9GHz DECT6.0 Cordless Phone Dates of Test ： Mar. 01~02 , 2008 Test Environment ： Ambient Temperature： 22 ±3 °C Relative Humidity：40 - 70 % Test Specification ： Standard C95.1-1999 IEEE Std. 1528-2003 Max. SAR ： 0.024 W/kg UPCS Head SAR 0.025 W/kg UPCS Body SAR Test Lab ： Changan Lab 1. The test operations have to be performed with cautious behavior, the test results are as attached. 2. The test results are under chamber environment of A Test Lab Techno Corp. A Test Lab Techno Corp. does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples. 3. The measurement report has to be written approval of A Test Lab Techno Corp. It may only be reproduced or published in full. Country Huang 20080403 Sam Chuang 20080403 Measurement Center Manager Testing Engineer Test Report No：0802FS23 Page 2 of 37 ©2008 A Test Lab Techno Corp. Rev.01 Contents 1. Description of Equipment Under Test (EUT) ................................................................ 3 2. Other Accessories .......................................................................................................... 5 3. Introduction..................................................................................................................... 6 4. SAR Definition ................................................................................................................ 7 5. SAR Measurement Setup ............................................................................................... 8 6. System Components .................................................................................................... 10 6.1 DASY5 E-Field Probe System .............................................................................................10 6.2 Data Acquisition Electronic (DAE) System ..........................................................................12 6.3 Robot ...................................................................................................................................13 6.4 Measurement Server ...........................................................................................................13 6.5 Device Holder for Transmitters ............................................................................................13 6.6 Phantom - SAM v4.0............................................................................................................14 6.7 Data Storage and Evaluation ...............................................................................................14 7. Test Equipment List...................................................................................................... 17 8. Tissue Simulating Liquids ........................................................................................... 18 8.1 Liquid Confirmation..............................................................................................................19 9. Measurement Process.................................................................................................. 21 9.1 Device and Test Conditions .................................................................................................21 9.2 System Performance Check ................................................................................................22 9.3 Dosimetric Assessment Setup .............................................................................................25 9.4 Spatial Peak SAR Evaluation...............................................................................................27 10. Measurement Uncertainty ............................................................................................ 28 11. SAR Test Results Summary......................................................................................... 30 11.1 UPCS Head SAR.................................................................................................................30 11.2 UPCS Body SAR .................................................................................................................32 11.3 EUT Steup Up Phote ...........................................................................................................33 11.4 Std. C95.1-1999 RF Exposure Limit ....................................................................................35 12. Conclusion .................................................................................................................... 36 13. References .................................................................................................................... 37 Test Report No：0802FS23 Page 3 of 37 ©2008 A Test Lab Techno Corp. Rev.01 1. Description of Equipment Under Test (EUT) Applicant： Manufacturer ： Founder Telecommunication Corp.Ltd. Manufacturer Address ： Founder High-Tech Zone, No.2 LongSheng Road, New Town District, Shilong Town,Dongguan,P.R.C. EUT Type ： 1.9GHz DECT6.0 Cordless Phone FCC ID ： VLJVEVA1210 Trade Name ： Binatone Model Name ： Veva 1210 Twin Battery Type ： Ni-MH Battery (2.4V，600mAh) Test Device ： Production Unit Tx Frequency ： 1921.536 -1928.448 MHz ( UPCS ) Max. RF Conducted Power ： 0.109 W (20.39 dBm ) UPCS Max. SAR Measurement ： 0.024 W/kg UPCS Head SAR 0.025 W/kg UPCS …

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES 26dB Emission Bandwidth Plots FCC ID: VLJVEVA1210 26bw - 1 of 3 Plot B1A Plot B1D A0 INTERTEK TESTING SERVICES 26dB Emission Bandwidth Plots FCC ID: VLJVEVA1210 26bw - 2 of 3 Plot B1G Plot B1J A0 INTERTEK TESTING SERVICES 26dB Emission Bandwidth Plots FCC ID: VLJVEVA1210 26bw - 3 of 3 Plot H1A Plot H1D A0

Report No.: HK08020963-1 Talk Mode AC Mains “L” Ctrl No.: N/A PAGE 1 Report No.: HK08020963-1 Scan Settings (1 Range) |--------- Frequencies -----------||----------- Receiver Settings ------------| Start Stop Step IF BW Detector M-Time Atten Preamp OpRge 150k 30M 5k 10k PK+AV 10ms AUTO LN OFF 60dB Final Measurement: x QP / + AV Meas Time: 1 s Subranges: 16 Acc Margin: 20dB Transducer No. Start Stop Name 2 1 9k 30M EW0699 12 9k 30M EW1449 0 10 20 30 40 50 60 70 80 90 dBuV 100 0.15 MHz 30 110 F15Q F15A Report No.: HK08020963-1 Talk Mode AC Mains “L” Ctrl No.: N/A Report No.:HK08020963-1 Scan Settin gs (1 Range) |--------- Frequencies -----------||----------- Receiver Settings ------------| Start Stop Step IF BW Detector M-Time Atten Preamp OpRge 150k 30M 5k 10k PK+AV 10ms AUTO LN OFF 60dB Final Measurement Results: Frequency QP Level QP Limit Delta MHz dBuV dBuV dB 2.93500 34.2 56.0 -21.8 3.00500 34.9 56.0 -21.1 Frequency AV Level AV Limit Delta MHz dBuV dBuV dB no Results * limit exceed

INTERTEK TESTING SERVICES Unwanted Emission Inside The Sub-Band Plots FCC ID: VLJVEVA1210 inband - 1 of 3 Plot B4A Plot B4B A0 INTERTEK TESTING SERVICES Unwanted Emission Inside The Sub-Band Plots FCC ID: VLJVEVA1210 inband - 2 of 3 Plot B4C Plot B4D A0 INTERTEK TESTING SERVICES Unwanted Emission Inside The Sub-Band Plots FCC ID: VLJVEVA1210 inband - 3 of 3 Plot H4A Plot H4B A0

INTERTEK TESTING SERVICES Peak Transmit Power Plots FCC ID: VLJVEVA1210 peaktp - 1 of 3 Plot B2A Plot B2B A0 INTERTEK TESTING SERVICES Peak Transmit Power Plots FCC ID: VLJVEVA1210 peaktp - 2 of 3 Plot B2C Plot B2D A0 INTERTEK TESTING SERVICES Peak Transmit Power Plots FCC ID: VLJVEVA1210 peaktp - 3 of 3 Plot H2A Plot H2B A0

INTERTEK TESTING SERVICES Power Spectral Density Plots FCC ID: VLJVEVA1210 psd - 1 of 3 Plot B3A Plot B3B A0 INTERTEK TESTING SERVICES Power Spectral Density Plots FCC ID: VLJVEVA1210 psd - 2 of 3 Plot B3C Plot B3D A0 INTERTEK TESTING SERVICES Power Spectral Density Plots FCC ID: VLJVEVA1210 psd - 3 of 3 Plot H3A Plot H3B A0

Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com March 14, 2008 Binatone Electronics International Ltd. Floor 23A, No. 9 Des Voeux Road West, Sheung Wan, Hong Kong. Tel. : 86-755-83778332 Fax. : 86-755-83690653 Dear Henry Leung: Enclosed you will find your file copy of a Part 15 Certification (FCC ID: VLJVEVA1210). For your reference, TCB will normally take another 15 to 20 days for reviewing the report. Approval will then be granted when no query is sorted. Please contact me if you have any questions regarding the enclosed material. Sincerely, Leung Wai Leung, Tommy Senior Manager Enclosure - The test report only allows to be revised within three years from its original issued date unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Binatone Electronics International Ltd. Application For 47 CFR Part 15 Certification Unlicensed Personal Communication Service Devices FCC ID: VLJVEVA1210 Test Report Number: HK08020963-1 Issue Date: March 14, 2008 TL/ ac INTERTEK TESTING SERVICES Test Report Number: HK08020963-1 Page 1 of 84 FCC ID: VLJVEVA1210 LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: Summary of Tests EXHIBIT 2: General Description EXHIBIT 3: System Test Configuration EXHIBIT 4: Measurement Results EXHIBIT 5: Equipment Photographs EXHIBIT 6: Product Labelling EXHIBIT 7: Technical Specifications EXHIBIT 8: Instruction Manual EXHIBIT 9: UTAM Affidavit EXHIBIT 10: Letter of Agency EXHIBIT 11: Confidentiality Request INTERTEK TESTING SERVICES Test Report Number: HK08020963-1 Page 2 of 84 FCC ID: VLJVEVA1210 MEASUREMENT/TECHNICAL REPORT Binatone Electronics International Ltd. Model: Veva 1200, Veva 1200 Twin, Veva 1200 Triple, Veva 1200 Quad, Veva 1200 Quin, Veva 1210, Veva 1210 Twin, Veva 1210 Triple, Veva 1210 Quad, Veva 1210 Quin FCC ID: VLJVEVA1210 This report concerns (check one:) Original Grant X Class II Change Equipment Type : PUB - Part 15 Unlicensed PCS Base Station PUE - Part 15 Unlicensed PCS portable Tx held to ear Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until : __________________ Date Company Name agrees to notify the Commission by: Date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart D for Unlicensed Personal Communication Service Device - the new 47 CFR [05-04-07 Edition] Provision. Report prepared by: Leung Wai Leung, Tommy Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone : 852-2173-8538 Fax: 852-2741-1693 INTERTEK TESTING SERVICES Test Report Number: HK08020963-1 Page 3 of 84 FCC ID: VLJVEVA1210 Table of Contents 1.0 Summary of Test Results........................................................................................ 7 2.0 General Description................................................................................................ 10 2.1 Product Description ............................................................................................... 10 2.2 Technical Description ............................................................................................ 10 2.3 Related Submittal(s) Grants................................................................................... 11 2.4 Test Methodology.................................................................................................. 11 2.5 Test Facility ........................................................................................................... 11 3.0 System Test Configuration.................................................................................... 13 3.1 Justification............................................................................................................ 13 3.2 Conducted Emission Test Configuration ................................................................ 14 3.3 Conducted Monitoring and Operational Test Configuration..................................... 14 3.4 EUT Exercising Software ....................................................................................... 14 3.5 Details of EUT and Description of Peripherals........................................................ 15 3.6 Measurement Uncertainty...................................................................................... 16 3.7 Equipment Modification ......................................................................................... 16 4.0 Measurement Results............................................................................................. 18 4.1 Antenna Requirement............................................................................................ 18 4.2 Digital Modulation Techniques .......................…

Text truncated - open the document above for the full version.

INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: VLJVEVA1210 config photos (radiated emission – base unit) - 1 of 1 Radiated Emission – Base Unit Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: VLJVEVA1210 config photos (radiated emission - handset) - 1 of 1 Radiated Emission – Handset Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: VLJVEVA1210 config photos (conducted emission) - 1 of 2 Conducted Emission Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: VLJVEVA1210 config photos (conducted emission) - 2 of 2 Conducted Emission Left Side View
