VMICOREPROCoreCam Pro 2K Wire-Free Security Camera with Spotlight

1 EN CoreCam Pro Spotlight Camera Cámara con Foco CoreCam Pro Caméra de Projecteur CoreCam Pro Telecamera con illuminazione CoreCam Pro CoreCam Pro Scheinwerfer Kamera EN Quick Start Guide ES Guía de inicio rápido FR Guide de démarrage rapide IT Guida rapida DE Schnellstartanleitung Model: SWIFI-COREPRO 2 EN CAMERA OVERVIEW Threaded screw hole (attaches to the included wall-mount bracket) Pull rubber cap gently from the bottom to access: • ON/OFF switch • MicroSD card slot 32GB card pre-installed, Max. 128GB card supported • Micro USB charging port • Reset button — Press and hold for 5 seconds to enter pairing mode — Press and hold for 10 seconds to factory reset the camera Microphone Speaker QR code (for device pairing) Rubber cap Passive infrared motion sensor LED indicator Night detection sensor Infrared LEDs (for night vision) Spotlight Threaded mounting post Bracket screw hole (x3) Locking knob 3 EN GETTING STARTED Before using the camera for the first time, fully charge it with the included micro USB charging cable. 1 Pull open the rubber cap on the bottom of the camera. 2 Slide the ON/OFF switch to the ON position. Note: You can also charge the camera with the switch OFF but you won’t be able to check the LED indicator for the charging status. 3 Insert the smaller end of the micro USB charging cable into the micro USB port on the camera. 4 Insert the other end of the micro USB charging cable into a USB wall charger such as the USB power adapter for your smartphone. 5 The LED indicator on the front of the camera will turn solid blue indicating that the camera is charging. When the camera is fully charged, the LED indicator will turn off. Actual charging times may vary depending on the USB power supply (DC5V 2.1A is recommended for faster charging) and the remaining battery level. A full charge may take up to 6 hours. 6 After charging is finished, unplug the micro USB charging cable from the camera and make sure to close the rubber cap tightly to keep out water and dust. The camera comes with a 32GB microSD card pre-installed for recording events and performing firmware updates. You can easily replace the microSD card with a new one (max. 128GB card supported), if needed in the future. Simply open the rubber cap on the bottom of the camera, eject the current microSD card (push in until it clicks) from the microSD card slot, and then insert the new microSD card (with the label side facing the front of the camera) into the slot until it clicks into place. You should format the microSD card the first time it is used. From the Swann Security app, go to Device Settings > [your camera] > Advanced Settings and tap Format. Charging the camera Replacing the microSD card 4 EN GET THE SWANN SECURITY APP 1 Download the latest version of the Swann Security app from the Apple App Store® or Google Play™ Store on your iOS or Android device. Simply search for "Swann Security". 2 Open the app and create your Swann Security account by tapping “Not yet registered? Sign Up” at the bottom of the screen. Then, activate your Swann Security account by confirming the verification email that is sent to the registered email address. 5 EN Launch the Swann Security app and sign in. Tap the Pair Device button on the screen (or tap the menu icon in the top left and select “Pair Device”). The app will now guide you through the pairing process to set up the camera with your Wi-Fi network. Before you begin, have the camera with you and be close to your router. Please note that the camera is only compatible with the 2.4GHz network. If your router is using the 5GHz band, please ensure it is operating in mixed mode. SET UP THE CORECAM 6 EN The camera can be conveniently placed on a table or shelf, or mounted on a flat surface using the included bracket. Because the camera is completely wire-free, you’ll have a lot of flexibility on where you can install it. Choose a location with strong, reliable Wi-Fi reception to ensure best video streaming and battery performance. The easiest way to check is to use your smartphone. Connect your smartphone to your Wi-Fi network at the spot you have chosen and see if you get 2 bars of Wi-Fi signal or more. As a general rule, the nearer the camera is to your router, the better the wireless connection quality. If you’re finding the wireless signal is too weak or out of range, consider installing a Wi-Fi range extender. CAMERA PLACEMENT Mounting the bracket If mounting to a wooden surface, screw bracket directly to the surface. If mounting to a masonry surface (brick, concrete), mark and drill holes, insert wall plugs, and screw bracket to the surface. Attaching the camera to the bracket Screw the threaded hole at the bottom of the camera onto the threaded post of the bracket by turning the locking knob clockwise until the camera is securely attached. After installation, make sure to remove the protective plastic film covering the camera lens. Adjusting the viewing angle Loosen the adjustment ring slightly by turning counter-clockwise. Swivel or tilt the camera as needed then tighten the adjustment ring to lock the position. 7 EN Download the Swann Security app manual for Android/iOS via the App Menu > User Manual to learn more about using the Swann Security app to view camera live video, use 2-way talk, playback and download motion recordings, check battery level, configure various camera settings including spotlight duration, motion detection sensitivity, modes, and more. Screens may vary slightly depending on the Swann Security app version (Android version shown above) THE SWANN SECURITY APP MANUAL 8 EN MOTION DETECTION TIPS Optimizing motion detection • The camera’s passive infrared motion sensor detects heat signatures of moving objects. • You’ll generally get good detection results by pointing the camera at an angle where people will be moving across the coverage area (i.e., from left to right or right to left, see figure on the right) as the motion sensor is less sensitive to movem…

Text truncated - open the document above for the full version.

Swann Communications Pty Ltd Agent Authorization Company: Swann Communications Pty Ltd Address: Unit 5B, 706 Lorimer Street Port Melbourne, Victoria, Australia 3207 Product Name: CoreCam Pro 2K Wire-Free Security Camera with Spotlight Model Number(s): SWIFI-COREPRO Product Description: CoreCam Pro 2K Wire-Free Security Camera with Spotlight with 2.4G WIFI We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022.07.28 Name: JIANKUAI LI Title: PM Company: Shenzhen STS Test Services Co., Ltd.

Swann Communications Pty Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022-07-28 Subject; Request for Confidentiality FCC ID: VMICOREPRO To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES Part List In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Swann Communications Pty Ltd Signature: Date: 2022.07.28 Name: JIANKUAI LI Title: PM Company: Shenzhen STS Test Services Co., Ltd.

2022.06.18 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO.,LTD./ A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District,Bao’an District, Shenzhen, Guang Dong, China/Jiankuai Li(Name of Agent company name and address, Name of Agent) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. Name: Jiankuai Li Title: PM E- mail:[email protected] This appointment is valid until further until December 31, 2023 Sincerely, Name: James Cain Title: VP Quality Assurance E- mail: [email protected] Company: Swann Communications Pty Ltd Address: Unit 5B, 706 Lorimer Street Port Melbourne, Victoria, Australia 3207

Page 1 of 4 Report No.: STS2206021 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: SWIFI-COREPRO Photo 1 Photo 2 Page 2 of 4 Report No.: STS2206021 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2206021 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2206021 Photo 7 Photo 8

Label

Page 1 of 5 Report No.: STS2206021 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: SWIFI-COREPRO Photo 1 Photo 2 2.4G WIFI Antenna Page 2 of 5 Report No.: STS2206021 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2206021 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2206021 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2206021 Photo 9 Photo 10

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2206021H02 Issued for Swann Communications Pty Ltd Unit 5B, 706 Lorimer Street Port Melbourne, Victoria, Australia 3207 Product Name: CoreCam Pro 2K Wire-Free Security Camera with Spotlight Brand Name: Swann Model Name: SWIFI-COREPRO Series Model: N/A FCC ID: VMICOREPRO Test Standard: FCC 47CFR §2.1091 S T L A B S Page 2 of 9 Report No.: STS2206021H02 Test Report Certification Applicant’s Name ................. : Swann Communications Pty Ltd Address .................................. : Unit 5B, 706 Lorimer Street Port Melbourne, Victoria, Australia 3207 Manufacturer's Name ........... : Swann Communications Pty Ltd Address .................................. : Unit 5B, 706 Lorimer Street Port Melbourne, Victoria, Australia 3207 Product Description Product Name ........................ : CoreCam Pro 2K Wire-Free Security Camera with Spotlight Brand Name ......................... : Swann Model Name ........................... :... : SWIFI-COREPRO Series Model .......................... : N/A Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item ..................... : 06 June 2022 Date (s) of performance of tests............. : 06 June 2022 ~ 23 June 2022 Date of Issue ......................................... : 23 June 2022 Test Result ............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2206021H02 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2206021H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 23 June 2022 STS2206021H02 ALL Initial Issue Page 5 of 9 Report No.: STS2206021H02 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name CoreCam Pro 2K Wire-Free Security Camera with Spotlight Brand Name Swann Model Name SWIFI-COREPRO Series Model N/A Model Difference N/A Product Description The EUT is CoreCam Pro 2K Wire-Free Security Camera with Spotlight Operation Frequency: 802.11b/g/n 20: 2412~2462 MHz 802.11n(40MHz):2422~2452MHz Modulation Type: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK,QPSK,16-QAM,64-QAM Antenna gain: 2dBi Antenna Designation: FPC Rating Input: DC 5V 2A Battery Rated Voltage:3.65V Charge Limit Voltage:4.2V MAX Capacity: 6000mAh Hardware version number V1.0 Software version number V1.0.41 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2206021H02 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2206021H02 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2206021H02 For multiple RF sources: Multiple RF sources are exempt if: (…

Text truncated - open the document above for the full version.

ShenzhenMayacommunicationequipmentCo.,LTD Model:E93JJ32 Date：2022.9.9 -1- Productspecificationacknowledgment. ShenzhenMayaantennalab R&DcenterinShenZhen Themobilecommunicationterminalantenna PRODUCTNAMEE93JJ3218600E93J0002 CUSTOMERNAME奥尼科技 ShenzhenMayacommunicationequipmentCo.,LTD Site：Asecondfloor,minqingroad,minqingroad,longhuastreet,baoandistrict,shenzhencity. Tel:86-755-82916162Fax:86-755-82916227 accountpartyDevelopmentparty Customeracknowledges Quality Department R&DDepartmentapprovedby 夏兵 ME:黎文明 RF：朱强清 冯国军 Date：年月日Date：2022年9月9日 ShenzhenMayacommunicationequipmentCo.,LTD Model:E93JJ32 Date：2022.9.9 -2- 1.aim FortheProductionfromshenzhenmayacommunicationequipmentco.,LTD.Thatmobile communicationterminalantennaproductspecificationsandtestmethodsforspecification, avoidthetestconditions,theerrorcausedbydifferentmethods 2.Antennadebugdesignrequirementfrequencyband. frequency frequencyband WIFIWIFI2.4G other / 3.Productcellphoneandskychart. Theantenna ShenzhenMayacommunicationequipmentCo.,LTD Model:E93JJ32 Date：2022.9.9 -3- 4.electrical 4.1Testmethoddescriptionanddata. Devicenameuse VectorNetworkAnalyzerS11/Impedance/PassiveTest Agilent8960 SP6010 R&SCMU200 GSM,GPRS,EDGE,CDMA2000,1xev-do, td-scdma,WCDMA,HSDPAmobilephonemobile communicationequipmenttest. R&SCMW500 MT8820C Includingtd-scdma,WCDMA, HSDPA,LTE,WIFI,GPSmobilephonemobile communicationequipmenttest. SP9500E Contains5G,SA,NSA AgilentE4438C TestactiveGPS MVGChamber PassiveTest/OTAactiveTest/Efficiency/Gain 4.2PassiveTestReport Testequipment:networkanalyzer. Testmethod:witha50ohmCABLECABLEfromtheinstrumenttestportisderived,usingthe calibrationafteracalibrationmechanismofSMAconnector,connectinghandrecordsrelatedtothe frequencypointscorrespondingreturnlossandstandingwaveratiodata. ShenzhenMayacommunicationequipmentCo.,LTD Model:E93JJ32 Date：2022.9.9 -4- 4.3ActiveTestReport TRP/TIS Fromtestingtools,measuring,networkanalyzer,fullwavesfarfieldETS,FrenchMVGSG24LT (Satmio)nearfield3dmicrowavedarkroom,thehighprecisionpositioningsystemandits controllerandthecomputerwithautomatictestproceduretestenvironment:thetemperatureof 22°C+3°C,humidity60%plusorminus60%testmethods:UsingESTor24ltSatimosystem softwareTestmethodandcalculationofTRPwhentestedTRP,DUT(DeviceUnderTest)isina stateofmaximumtransmittedpower,includingthreetochoosechannelTest,bypositioningsystem controlthelocationoftheDUT,with15degreesforsteplength,measuringthreedimensional space,theeffectiveradiatedpower(EIRP)atvariouspointsthroughtheaverageoftheintegral sphere,computationformulaisasfollows InTIStest,theDUTatthemaximumtransmissionpowerofthestate,includingthreetochoose channeltest,bycontrollingthelocationoftheDUT,at30degreesforthesteplength,measuring thethreedimensionalspaceeachpointreceivingsensitivity,theaverageofthespherebyintegral calculation,calculationformulaisasfollows: ShenzhenMayacommunicationequipmentCo.,LTD Model:E93JJ32 Date：2022.9.9 -6- Directionalpattern ShenzhenMayacommunicationequipmentCo.,LTD Model:E93JJ32 Date：2022.9.9 -7- ShenzhenMayacommunicationequipmentCo.,LTD Model:E93JJ32 Date：2022.9.9 -8- 5.Matchingcircuitdescription Note:wedonotdebugtheantennamatchingcircuit. 6.Environmentaltreatment ShenzhenMayacommunicationequipmentCo.,LTD Model:E93JJ32 Date：2022.9.9 -9- 7.structuraldrawings ShenzhenMayacommunicationequipmentCo.,LTD Model:E93JJ32 Date：2022.9.9 -10- 8.WarningSign 1.Thesectiononperformanceandstructurevalidation ★Pleaseconfirmtheappearanceandperformanceoftheproductbeforeyousign theacknowledgement. ★Pleasebesuretoprovidethefinalmassproductiontrialproductionmachine toourcompanyortakebackourcompanyverificationbeforemassproduction ★Astheproductofthisacknowledgementisahighlysensitiveobject,please besuretokeepthetestingmachineforfollow-up ★Asthisproductisacustom-madeobject,theuseofthetargeted,customers inmaterialreplacementorfornon-designateditems,pleasebesuretochange thematerialornon-designateditemsofthemachinesenttoourcompanytoverify theradio-frequencyperformance,otherwise,maycausetheusestateandthe designstateinconsistentserioushiddendanger,toourcompanysealeddebugging samplefunctionconfirmation,ensureourcompanydebuggingsamplefunction completelynormal,preventfunctionabnormaltotheantennaperformanceerror causedbytheantennaperformance 2.Aboutproductstorage ★Asthisproducthasprintinginkonthesurface,adhesiveonthebackand electroplate,pleasemakesurethetemperatureisbetween23°c-27°Candthe relativehumidityisbelow60%duringstorageortransportation,nostrongacid, nosulfur,nooxygenstorageortransportenvironment ★Astheproductbackglueontheenvironmentrequirementsaremorestringent, pleasecustomersmustbereceivedaftertheproduct,intheproductquality guaranteeperiodtoensurethereliabilityoftheproduct 3.Tipsforusingtheproduct ★Duetothespecialstructureofthisproduct,pleaseusethisproductmustbe infullcontactwiththepastedobjects,andpastedobjectsmustnotberesidual chemicals(releaseagent,etc.)orasfaraspossibledonotusetherawmaterials withreleaseagent,toensurethattheproductisingoodworkingcondition, pleasecleanthesurfaceofthepastedarticlebeforeusingtheproducttoensure thatthereisnochemicalresidueonthesurfaceofthepastedarticle 4.StatementofQualityAssuranceforthisproduct ★Thisproductqualityguaranteeperiodis12months,ifyouruseandstorage environmenttomeettheaboverequirements,inthevalidguaranteeperiodofany qualityproblems,anddeterminedthatourproductsareabnormal,ourcompanycan providefreereplacementservices,after12months,ourproductsprovide life-longconsultationandpaidreplacementservices ★Thisproductisaspecialcustomdevice,pleasereceivetheproductmustwithin 3workingdaysoftheproductquantityconfirmation

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.:STS2206021W02 Issued for Swann Communications Pty Ltd Unit 5B, 706 Lorimer Street Port Melbourne, Victoria, Australi a 3207 Product Name: CoreCam Pro 2K Wire-Free Security Camera with Spotlight Brand Name: Swann Model Name: SWIFI-COREPRO Series Model: N/A FCC ID: VMICOREPRO IC: 12494A-COREPRO Test Standard: FCC Part 15.247 RSS-247 Issue 2, February 2017 RSS-Gen Issue 5, Amendment 2, February 2021 S T L A B S Page 2 of 102 Report No.:STS2206021W02 TEST RESULT CERTIFICATION Applicant’s Name ................. : Swann Communications Pty Ltd Address ................................. : Unit 5B, 706 Lorimer Street Port Melbourne, Victoria, Australia 3207 Manufacturer's Name ........... : Swann Communications Pty Ltd Address ................................. : Unit 5B, 706 Lorimer Street Port Melbourne, Victoria, Australia 3207 Product Description Product Name ........................ : CoreCam Pro 2K Wire-Free Security Camera with Spotlight Brand Name ........................... : Swann Model Name .......................... : SWIFI-COREPRO Series Model .......................... : N/A Test Standards ..................... : FCC Part 15.247 RSS-247 Issue 2, February 2017 RSS-Gen Issue 5, Amendment 2, February 2021 Test Procedure........................: ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC/IC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item ...................... : 06 June 2022 Date (s) of performance of tests ............. : 06 June 2022 ~ 23 June 2022 Date of Issue .......................................... : 23 June 2022 Test Result .............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 102 Report No.:STS2206021W02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION MEASUREMENT 19 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 32 4.1 LIMIT 32 4.2 TEST PROCEDURE 32 4.3 DEVIATION FROM STANDARD 32 4.4 TEST SETUP 32 4.5 EUT OPERATION CONDITIONS 32 4.6 TEST RESULTS 32 5. POWER SPECTRAL DENSITY TEST 33 5.1 LIMIT 33 FCC PART15.247 , SUBPART C 33 RSS-247 ISSUE 2 33 5.2 TEST PROCEDURE 33 5.3 DEVIATION FROM STANDARD 33 5.4 TEST SETUP 33 5.5 EUT OPERATION CONDITIONS 33 5.6 TEST RESULTS 33 6. BANDWIDTH TEST 34 6.1 LIMIT 34 6.2 TEST PROCEDURE 34 6.3 DEVIATION FROM STANDARD 34 Page 4 of 102 Report No.:STS2206021W02 Table of Contents Page 6.4 TEST SETUP 34 6.5 EUT OPERATION CONDITIONS 34 6.6 TEST RESULTS 34 7. PEAK OUTPUT POWER TEST 35 7.1 LIMIT 35 7.2 TEST PROCEDURE 35 7.3 DEVIATION FROM STANDARD 35 7.4 TEST SETUP 36 7.5 EUT OPERATION CONDITIONS 36 7.6 TEST RESULTS 36 8. ANTENNA REQUIREMENT 37 8.1 STANDARD REQUIREMENT 37 8.2 EUT ANTENNA 37 9. FREQUENCY STABILITY 38 9.1 LIMITS OF FREQUENCY STABILITY MEASUREMENT 38 9.2 TEST PROCEDURE 38 9.3 TEST RESULT 38 APPENDIX 1-TEST DATA 39 1. DUTY CYCLE 39 2. MAXIMUM AVERAGE CONDUCTED OUTPUT POWER 46 3. MAXIMUM PEAK CONDUCTED OUTPUT POWER 53 4. BANDWIDTH 60 5. MAXIMUM POWER SPECTRAL DENSITY LEVEL 73 6. BAND EDGE 80 7. CONDUCTED RF SPURIOUS EMISSION 89 APPENDIX 2-PHOTOS OF TEST SETUP 102 Page 5 of 102 Report No.:STS2206021W02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 23 June 2022 STS2206021W02 ALL Initial Issue Page 6 of 102 Report No.:STS2206021W02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C RSS-247 Issue 2 Standard Section Test Item Judgment Remark 15.207 RSS-Gen 8.8 Conducted Emission PASS -- 15.247 (a)(2) RSS-Gen 6.7 RSS-247 5.2 a) 6dB&99% Bandwidth PASS -- 15.247 (b)(3) RSS-247 5.4 d) Output Power PASS -- 15.209 RSS-Gen 8.9/8.10 Radiated Spurious Emission PASS -- 15.247 (d) RSS-247 5.5 RSS-Gen 8.9/8.10 Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) RSS-247 5.2 b) Power Spectral Density PASS -- 15.205 RSS-Gen 8.9/8.10 Restricted Band Edge Emission PASS -- 15.203 RSS-Gen 6.8 Antenna Requirement PASS -- RSS-Gen 6.11/8.11 Frequency Stability PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 102 Report No.:STS2206021W02 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverag…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: VMICOREPRO IC: 12494A-COREPRO DTS Setup photo Model name: SWIFI-2KOCAM DTS conduction DTS radiation L Page 2 of 2 FCC ID: VMICOREPRO IC: 12494A-COREPRO DTS radiation H
