VMISE2KPTEVO 2K Indoor Pan Tilt Camera

English 2K Indoor Pan Tilt Wi-Fi Camera Quick Start Guide evo 123 4 5What’s IncludedCamera OverviewPower the Camera Install a microSD card Get the App Camera Drill Template Reset Tool USB-C Cable Microphone Infrared LEDs (for night vision) Keyhole mounting slots Reset Button Speaker USB-C Power Por t QR Code (for device pairing) LED Indicator microSD Card Slot (microSD card not included) Screw Pack USB Power Adapter * Images are for illustrative purposes only and may differ slightly from the actual product Connect the USB-C cable to the USB power adapter and the USB-C power port on the back of the camera, then plug the USB power adapter into a wall outlet. a. Download the latest version of the Swann Security app fr om the Google Play™ St ore or Apple App St ore® on your Android or iOS mobile device. Simply search for “Swann Security”. Or , you can scan the QR code below to get the app. b. Open the Swann Security app and sign in, or tap “Not yet registered? Sign Up” to create your Swann Security account. Activate your Swann email sent to your registered email address. A microSD card (not included) is necessary for the camera to record and st ore event clips locally. Manually rotate the camera up then insert a microSD card (up to 128GB supported), with the gold contacts facing up by push- ing it into the slot until you hear a click. For other languages scan 65Camera PlacementSet Up the Camera Initiating the camera’s pairing mode Help & More PSTI STATEMENT OF COMPLIANCE Swann Communications declares that this product complies with the applicable security requirements in Schedule 2 of the Product Security and Telecommunications Infrastructure (Security Requirements for Relevant Connectable Products) Regulations 2023. The full text of the PSTI Statement of Compliance can be obtained at uk.swann.com/psti QSGSE2KPTVER1E © 2024 Swann Communications SUPPORT.SWANN.COM — FAQs & Help Articles — Manuals, Guides & Videos — Technical Support In the Swann Security app, tap the Pair Device button on the screen (or tap the menu icon in the top left and select Pair Device). The app will now guide you through the pairing pr ocess to set up the camera with your Wi-Fi network. The camera can be placed on a table or shelf, or of pan and tilt operations using the app, you can freely rotate the camera ar ound and monitor your home from any angle that you need. The bottom of the camera has two keyhole slots that pr ovide a convenient method for you to securely hang the camera on the wall or ceiling. Motion Detection Whenever motion is detected, the camera records the event to the local st or age. Event clips can range fr om 10 seconds to 1 minute in length, depending on how long the motion activity lasts. You can adjust the motion detection sensitivity settings in the app. If you’re receiving too many false alerts, try reducing the sensitivity. In addition, you can also customize the camera detection zone to reduce unnecessary detections. Swann Security App Manual To learn more about using the Swann Security app, you can download the manual fr om the App Menu > User Manual. The app manual pr ovides detailed information on how to view live video, operating pan and tilt controls, playback and download event clips, adjust camera settings, and more. LED Status Guide Wall/Ceiling Mounting Freestanding Please note that the camera is only compatible with the 2.4GHz network. If your router is using the 5GHz band, ensure that it is operating in mixed mode. Use the Reset tool to press the Reset button on the side of the camera for 5 seconds until the camera LED blinks blue. Slow Blinking BluePairing mode Solid RedLive streaming / Motion recording Fast Blinking Blue Connecting to Wi-Fi IR LEDs BlinkingFirmware update in pr ogress For optimal performance, ensure the camera location has strong Wi-Fi reception. You can check the Wi-Fi signal strength in the app. As a general rule, the nearer your camera is to your Wi-Fi router, the better the wireless connection quality. Drill template Install screws and anchors using the drill template. Leave screw heads protruding slightly Hang camera over the screw heads through the keyhole slots A B This products installation height is < 2M FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. IC Warning This device complies with Industry Canada licence-…

Text truncated - open the document above for the full version.

Swann Communications U.S.A. lnc. (2024.07.31) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:VMISE2KPT) [Swann Communications U.S.A. lnc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Raymond Chan Swann Communications U.S.A. lnc. (2024.07.31) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:VMISE2KPT) [Swann Communications U.S.A. lnc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Raymond Chan

Attestation Statements (2024.07.31) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID:VMISE2KPT) (Swann Communications U.S.A. lnc.), the undersigned, hereby authorize (Swann Communications U.S.A. lnc.) to act as our designated U.S. agent for service of process, (Swann Communications U.S.A. lnc.) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (Swann Communications U.S.A. lnc.) accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Swann Communications U.S.A. lnc. Contact Name: Raymond Chan Address: 12636 Clark Street Santa Fe Springs California United States 90670 Telephone No: 5627772551 Email: [email protected] Signature Raymond Chan U.S. Agent Information: Company Name: Swann Communications U.S.A. lnc. Address: 12636 Clark Street Santa Fe Springs California United States 90670 FRN: 0024573800 Contact Name: Raymond Chan Telephone No: 5627772551 Email: [email protected] Signature Raymond Chan

Swann Communications U.S.A. lnc. Agent Authorization Company: Swann Communications U.S.A. lnc. Address: 12636 Clark Street Santa Fe Springs California United States 90670 Product Name: EVO 2K Indoor Pan Tilt Camera Model Number(s): SWIFI-SE2KPT Product Description: EVO 2K Indoor Pan Tilt Camera with 2.4G WIFI We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2024.08.03 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO., LTD.

Swann Communications U.S.A. lnc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024.08.08 Subject; Request for Confidentiality FCC ID: VMISE2KPT To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES Part List In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Swann Communications U.S.A. lnc. Signature: Date: 2024.08.08 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO., LTD.

2024.07.31 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO.,LTD./ 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China /Jiankuai Li(Name of Agent company name and address, Name of Agent) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. Name: Jiankuai Li Title: PM E-mail:[email protected] This appointment is valid until further until July 30, 2025 Sincerely, Name: Raymond Chan Title: Compliance Manager E-mail: [email protected] Company: Swann Communications U.S.A. lnc. Signature:

Page 1 of 5 ReportNo.:STS2407133 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 5 ReportNo.:STS2407133 Photo3 Photo4 Page 3 of 5 ReportNo.:STS2407133 Photo5 Photo6 Page 4 of 5 ReportNo.:STS2407133 Photo7 Photo8 Page 5 of 5 ReportNo.:STS2407133 Photo9 Photo10

Label

Page 1 of 5 ReportNo.:STS2407133 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 2.4GWIFIAntenna Page 2 of 5 ReportNo.:STS2407133 Photo3 Photo4 Page 3 of 5 ReportNo.:STS2407133 Photo5 Photo6 Page 4 of 5 ReportNo.:STS2407133 Photo7 Photo8 Page 5 of 5 ReportNo.:STS2407133 Photo9 Photo10

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Radio Test Report Report No.: STS2407133H03 Issued for Swann Communications U.S.A. lnc. 12636 Clark Street Santa Fe Springs California United States 90670 Product Name: EVO 2K Indoor Pan Tilt Camera Brand Name: Swann Model Name: SWIFI-SE2KPT Series Model(s): N/A FCC ID: VMISE2KPT Test Standard: FCC 47CFR §2.1091 Page 2 of 10 Report No.: STS2407133H03 TEST REPORT Applicant’s Name ................. : Swann Communications U.S.A. lnc. Address ................................. : 12636 Clark Street Santa Fe Springs California United States 90670 Manufacturer's Name ........... : Swann Communications U.S.A. lnc. Address ................................. : 12636 Clark Street Santa Fe Springs California United States 90670 Product Description Product Name ........................ : EVO 2K Indoor Pan Tilt Camera Brand Name .......................... : Swann Model Name .......................... : SWIFI-SE2KPT Series Model(s) ...................... : N/A Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 22 July 2024 Date (s) of performance of tests ............. : 22 July 2024~30 July 2024 Date of Issue .......................................... : 30 July 2024 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Chris Chen) Authorized Signatory : (Bovey Yang) Page 3 of 10 Report No.: STS2407133H03 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 7 2.1 TEST STANDARDS 7 2.2 LIMIT 7 2.3 TEST RESULT 10 Page 4 of 10 Report No.: STS2407133H03 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 July 2024 STS2407133H03 ALL Initial Issue Page 5 of 10 Report No.: STS2407133H03 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name EVO 2K Indoor Pan Tilt Camera Brand Name Swann Model Name SWIFI-SE2KPT Series Model(s) N/A Model Difference N/A Product Description The EUT is EVO 2K Indoor Pan Tilt Camera Operation Frequency: 802.11b/g/n 20: 2412~2462 MHz Modulation Type: 802.11b(DSSS): CCK,DQPSK,DBPSK 802.11g(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK,QPSK,16-QAM,64-QAM Antenna gain: 4.19 dBi Antenna Designation: FPC Adapter Model:BS05A-0501000US Input: AC 100-240V 50/60Hz 0.25A Output: DC 5V 1A Rating Input: DC 5V 1A Hardware Version V1.3 Software Version V2.0.12 Page 6 of 10 Report No.: STS2407133H03 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 7 of 10 Report No.: STS2407133H03 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 8 of 10 Report No.: STS2407133H03 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 9 of 10 Report No.: STS2407133H03 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may …

Text truncated - open the document above for the full version.

SPECIFICATIONFORAPPROVAL CUSTOMERNAME: SHENZHENAONIELECTRONICCO.,LTD CUSTOMERP/N: PRODUCT P/N:H1C65F3D222A PRODUCTNAME:built-inantenna/EP12301 Description:H1C65F3D222A/2.4Gbuilt-inFPCantenna REV:A 出厂签章 S I G N APPROVEDBYCHECKEDBYDRAMN 客户签章 S I G N QER&DPE Contents 一、RevisionHistory 二、SpecificationTable 三、ProductDrawing 四、PackagingSpecifications 五、TestReport 六、Schematicdiagramoftheentiremachine 一、RevisionHistory： Reversio n Revisio n page Change date Revised by Reason and content for revision Remarks A-2024.7.10VictorInitial release 二、SpecificationTable： Maintechnicalspecifications FrequencyRange (MHZ) 2400-2500 Impedance(Ω)50 Gain(dBi) 4±1 VSWR ≤2.0 PolarizationLinear RadiationOmni-directional ConnectorType Cable+IPEX PhysicalProperties AntennacoverFPC OperatingTemp-20°C~+70°C StorageTemp-20°C~+60°C 三、Productdrawing： G F E D C A 3 4 2 G F 56 D C B A 15634 B 1 2 E F R O N T S i d e V i e w 四、Packagingspecifications： G F E D C A 342 G F 56 D C B A 15634 B 1 2 E 五、Testreport： 5.1 ： antennaS11parameters 5.2 ： Passivepatternofantenna 5.3 ： Passiveefficiencyofantenna 5.4 ： Activetestreport 六、Schematicdiagramoftheentiremachine：

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2407133W03 Issued for Swann Communications U.S.A. lnc. 12636 Clark Street Santa Fe Springs California United States 90670 Product Name: EVO 2K Indoor Pan Tilt Camera Brand Name: Swann Model Name: SWIFI-SE2KPT Series Model(s): N/A FCC ID: VMISE2KPT Test Standards: FCC Part15.247 Page 2 of 77 Report No.: STS2407133W03 TEST REPORT Applicant’s Name ................. : Swann Communications U.S.A. lnc. Address ................................. : 12636 Clark Street Santa Fe Springs California United States 90670 Manufacturer's Name ........... : Swann Communications U.S.A. lnc. Address ................................. : 12636 Clark Street Santa Fe Springs California United States 90670 Product Description Product Name ........................ : EVO 2K Indoor Pan Tilt Camera Brand Name ........................... : Swann Model Name .......................... : .. : SWIFI-SE2KPT Series Model(s) .................... : N/A Test Standards ..................... : FCC Part 15.247 Test Procedure........................: ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 22 July 2024 Date (s) of performance of tests ............. : 22 July 2024~30 July 2024 Date of Issue .......................................... : 30 July 2024 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Chris Chen) Authorized Signatory : (Bovey Yang) Page 3 of 77 Report No.: STS2407133W03 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 RADIATED EMISSION MEASUREMENT 17 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 29 4.1 LIMIT 29 4.2 TEST PROCEDURE 29 4.3 DEVIATION FROM STANDARD 29 4.4 TEST SETUP 29 4.5 EUT OPERATION CONDITIONS 29 4.6 TEST RESULTS 29 5. POWER SPECTRAL DENSITY TEST 30 5.1 LIMIT 30 5.2 TEST PROCEDURE 30 5.3 DEVIATION FROM STANDARD 30 5.4 TEST SETUP 30 5.5 EUT OPERATION CONDITIONS 30 5.6 TEST RESULTS 30 6. BANDWIDTH TEST 31 6.1 LIMIT 31 6.2 TEST PROCEDURE 31 6.3 DEVIATION FROM STANDARD 31 6.4 TEST SETUP 31 6.5 EUT OPERATION CONDITIONS 31 Page 4 of 77 Report No.: STS2407133W03 Table of Contents Page 6.6 TEST RESULTS 31 7. PEAK OUTPUT POWER TEST 32 7.1 LIMIT 32 7.2 TEST PROCEDURE 32 7.3 DEVIATION FROM STANDARD 32 7.4 TEST SETUP 33 7.5 EUT OPERATION CONDITIONS 33 7.6 TEST RESULTS 33 8. ANTENNA REQUIREMENT 34 8.1 STANDARD REQUIREMENT 34 8.2 EUT ANTENNA 34 APPENDIX 1-TEST DATA 35 1. DUTY CYCLE 35 2. MAXIMUM AVERAGE CONDUCTED OUTPUT POWER 41 3. MAXIMUM PEAK CONDUCTED OUTPUT POWER 47 4. -6DB BANDWIDTH 48 5. MAXIMUM POWER SPECTRAL DENSITY LEVEL 54 6. BAND EDGE 60 7. CONDUCTED RF SPURIOUS EMISSION 67 APPENDIX 2-PHOTOS OF TEST SETUP 77 Page 5 of 77 Report No.: STS2407133W03 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 July 2024 STS2407133W03 ALL Initial Issue Page 6 of 77 Report No.: STS2407133W03 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 77 Report No.: STS2407133W03 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.755dB 2 Unwanted Emissions, conducted ±2.874dB 3 All emissions, radiated 9K-30MHz ±3.80dB 4 All emissions, radiated 30M-1GHz ±4.18dB 5 All emissions, radiated 1G-6GHz ±4.90dB 6 All emissions, radiated>6G ±5.24dB 7 Conducted Emission (9KHz-150KHz) ±2.19dB 8 Conducted Emission (150KHz-30MHz) ±2.53dB 9 Occupied Channel Bandwidth ±3.5% 10 Power Spectral Density, conducted ±1.245dB 11 Duty Cycle ±3.2% Page 8 of 77 Report No.: STS2407133W03 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name EVO 2K Indoor Pan Tilt Camera Brand Name Swann Model Name SWIFI-SE2KPT Series Model(s) N/A Model Difference N/A Product Description The EUT is a EVO 2K Indoor Pan Tilt Camera Operation Frequ…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: VMISE2KPT DTS Setup photo Model Number: SWIFI-SE2KPT DTS conduction DTS radiation L Page 2 of 2 FCC ID: VMISE2KPT DTS radiation H
