VNH-IK-CSRBC05Bluetooth module

[IK-CSRBC05] Bluetooth Module for Audio OEM / Integrators Installation Manual Device Overview Dimensions 28mm 44mm DMAIN B'D BLUETOOTH B'D Antenna DMAINBD IK‐CSRBC05 VNH‐IK‐CSRBC05VNH‐IK‐CSRBC05 This device is intended only for OEM integrators under the following conditions: The antenna must be installed such that 20 cm is maintained between the antenna and users, and The transmitter module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID:VNH-IK-CSRBC05”, “contains IC: 10581A-IKCSRBC05”. The grantee's FCC ID can be used only when all FCC/ IC compliance requirements are met. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The Grantee must instruct the OEM/Integrator to include statements as required per Parts 15.19 and 15.21. An attestation that the Grantee will provide guidance to the host manufacturer for compliance to Part 15, subpart B requirements. The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirement. 10581A‐IKCSRBC05 IK‐CSRBC05

Inkel Corporation. 93, Cheongjung-Ro, Bupyeong-Gu, Incheon, 403-853, Republic of Korea Date: September 18, 2014 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Timco Engineering, Inc. Certification Division 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA To whom it may concern: I, the undersigned, hereby authorize Technical Manager Issac Jin of MOVON CORPORATION and here after referred to as MOVON CORPORATION , to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these m atters. Any and all acts carried out by Technical Manager Issac Jin of MOVON CORPORATION on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing MOVON CORPORATION as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; Inkel Corporation. 93, Cheongjung-Ro, Bupyeong-Gu, Incheon, 403-853, Republic of Korea e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Eun-HWan, Shim / R&D Strategy Team Principal Research Engineer Inkel Corporation. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Inkel Corporation. 93, Cheongjung-Ro, Bupyeong-Gu, Incheon, 403-853, Republic of Korea Subject: Request for Modular Transmitter Approval In accordance with Part 15.212 Modular Transmitters approval FCC ID: VNH-IK-CSRBC05 Inkel Corporation. Requests single modular transmitter approval for the IK-CSRBC05 module. This letter addresses the numbered requirements below. Modular approval requirement Yes No (i) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly; ✔ (ii) The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal; ✔ (iii) The module must contain power supply regulation on the module; ✔ (iv) The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b); ✔ (v) The module must demonstrate compliance in a stand-alone configuration; ✔ (vi) The module must be labelled with its permanently affixed FCC ID label, or use an electronic display ✔ (vii) The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee; ✔ (viii) The module must comply with RF exposure requirements ✔ Sincerely Yours, Eun-HWan, Shim / R&D Strategy Team Principal Research Engineer Inkel Corporation.

Inkel Corporation. 93, Cheongjung-Ro, Bupyeong-Gu, Incheon, 403-853, Republic of Korea Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: VNH-IK-CSRBC05 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Parts List Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely Yours, Eun-HWan, Shim / R&D Strategy Team Principal Research Engineer Inkel Corporation.

External photos of EUT Front view of EUT Rear view of EUT Antenna (FPCB type antenna)

Internal photos of EUT Internal photo (Front) Internal photo (Rear) Internal photo Removed Shield RF part

(주)인켈 귀중 승 인 원 [Approval Sheet] 결 재 Person in Charge Q.A R&D Approved by S.J.Y J.B.H J.H.J L.S.H 09/03 09/03 09/03 09/03 BUYER Inkel MODEL solo Soundbar Part Name - Part Code - Arro Code AT98-0069A 공급 업체명 PLATEL Corp. 사장 김 근 하 대표전화( Tel ) 031-290-4700 FAX 031-291-0095 주소 경기도 수원시 권선구 산업로 97 (고색동) 승인원 목차 List ` Part No - Maker Code - Date (제출일) 2014.09.03 Model Type Rev PLATEL Corporation A solo Soundbar Bluetooth ANTENNA Inkel A Contents 1. 제품사양 변경 이력 ------------------------------------------------- 3/10 1.1 승인원 이력 List ----------------------------------------------- 4/10 2. 기술적 사항 ------------------------------------------------------ 4/10 2.1 일반적 사양 --------------------------------------------------- 4/10 2.2 기구적 사양 --------------------------------------------------- 4/10 3. 회로 사항 -------------------------------------------------------- 5/10 3.1 전기적 요구 사항 ---------------------------------------------- 5/10 3.1.1 Set 전기적 사양(정재파비 포함) ---------------------------------- 5/10 3.1.2 Set 안테나 이득---------------------------------------------- 6/10 3.1.3 Cable loss ------------------------------------------------ 7/10 3.2 시험 조건 ---------------------------------------------------- 8/10 3.1.1 시험 환경(조건/방법) ------------------------------------------ 8/10 4. 기구 사항 ------------------------------------------------------- 10/10 4.1기구적 요구 사항 --------------------------------------------- 10/10 4.2.1 기구도면 -------------------------------------------------- 10/10 승인원 목차 List ` Part No - Maker Code - Date (제출일) 2014.09.03 Model Type Rev PLATEL Corporation A solo Soundbar Bluetooth ANTENNA Inkel A 1. 제품사양 변경 이력 1.1 승인원 이력List 승인원 이력 List No Rev 개정 날짜 (제출 날짜) 상세개정 및 변경내용 수량 요청부서 진행 단계 고객사 PLATEL 1 0 A 2014.09.03 New REVISION - R&D 2 3 4 5 승인원 목차 List ` Part No - Maker Code - Date (제출일) 2014.09.03 Model Type Rev PLATEL Corporation A solo Soundbar Bluetooth ANTENNA Inkel A 2. 기술적사항 MODEL ANTENNA ANTENNA TYPE Bluetooth ANTENNA APPLICATIONS Bluetooth ANTENNA 2.2 전기적 사양 FREQUENCY RANGE 2,400~2485 MHz V.S.W.R LESS TNEN 3.5:1 Cable Loss (dB) -5 AVERAGE.GAIN(dBi) -6.31 (3D MEASUREMENT) INPUT IMPEDANCE(Ω) 50 Ohm POLARIZATION LINEAR RADIATION PATTERN OMNIDIRECTIONAL 2.3 기구적 사양 3. 회로사항 CONNECTOR N/A LENGTH REF DRAWING (No 4.1) TEMPERATURE -20 ~ 70(°C) WEIGHT 0.53(g) 승인원 목차 List ` Part No - Maker Code - Date (제출일) 2014.09.03 Model Type Rev PLATEL Corporation A solo Soundbar Bluetooth ANTENNA Inkel A 3.1 전기적 요구 사항 3.1.1 Set 전기적 사양(정재파비 포함) [그림 3-1] VSWR 승인원 목차 List ` Part No - Maker Code - Date (제출일) 2014.09.03 Model Type Rev PLATEL Corporation A solo Soundbar Bluetooth ANTENNA Inkel A 3.1.2 Set 안테나 이득 12345 24002421244224632484 -7.24-6.71-6.37-5.96-5.48 18.8921.3523.0625.3828.34 -7.24-6.71-6.37-5.96-5.48 -8.35 -7.83 -7.49 -7.07 -6.54 -3.95 -3.67 -3.85 -3.97 -2.80 -17.70 -16.81 -16.11 -15.65 -15.52 -13.70 -13.13 -12.80 -12.42 -12.12 -7.62 -6.98 -6.42 -5.93 -5.75 -29.67 -28.19 -27.70 -27.84 -33.57 -10.33 -9.93 -9.68 -9.38 -9.03 49.04 47.60 46.68 45.49 44.09 -6.20 -5.78 -6.09 -6.52 -6.25 -9.00 -8.58 -8.27 -7.81 -7.29 -9.21 -8.63 -8.22 -7.70 -7.15 -3.72 -3.39 -3.56 -3.38 -2.49 3.523.322.812.572.99 -13.92 -13.23 -12.90 -12.58 -12.46 FS=Free Space, BHR=Beside Head Right Side, BHL=Besid e -6.31 dB,23.40% TRG φ [dB] UHRG [dB] UHRG/TRG [%] Gain θPeak [dB] Gain θMin [dB] Gain φPeak [dB] Gain φMin [dB] Fr e qu e nc y [ M Hz ] TRG [dB] H-Pla ne E1-Plane, AVG [dB] Efficiency [dB] Efficiency [%] E2-Plane, AVG [dB] TR G θ [dB] Peak Gain [dB] Dir ec tivity [dB] Minimum Gain [dB] Average Efficiency Antenna Type FS Test Condition 승인원 목차 List ` Part No - Maker Code - Date (제출일) 2014.09.03 Model Type Rev PLATEL Corporation A solo Soundbar Bluetooth ANTENNA Inkel A 3.1.3 Cable loss 승인원 목차 List ` Part No - Maker Code - Date (제출일) 2014.09.03 Model Type Rev PLATEL Corporation A solo Soundbar Bluetooth ANTENNA Inkel A 3.2 시험 조건 3.2.1 시험 환경(조건/방법) 정재파비 측정 방법: [그림3-3]와 같이 장비를 연결하고 NETWORK ANALYZER의 REFLECTION POINT에 안테나가 장착된 시료를 연결하여 사용주파수 대역 내에서의 정재파비를 측정한다. [그림 3-3]정재파비 측정 조건 승인원 목차 List ` Part No - Maker Code - Date (제출일) 2014.09.03 Model Type Rev PLATEL Corporation A solo Soundbar Bluetooth ANTENNA Inkel A 이득 측정 방법 : [그림 3-4]과 같이 혼 안테나를 표준 안테나로 설정하여 [dBi]로 나타내었다 [그림3-4]이득 측정 조건 승인원 목차 List ` Part No - Maker Code - Date (제출일) 2014.09.03 Model Type Rev PLATEL Corporation A solo Soundbar Bluetooth ANTENNA Inkel A 4. 기구 사항 4.1 기구적 요구 사항 4.1.1 기구 도면

MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (1) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. FCC Part 15 Subpart C §15.247 RSS-210 ISSUE No. :8 Test Report Equipment Under Test Bluetooth module Model Name IK-CSRBC05 FCC ID VNH-IK-CSRBC05 IC 10581A-IKCSRBC05 Applicant Inkel Corporation. Manufacturer Inkel Vietnam Co., Ltd. Date of Test(s) 2014. 09. 10 ~ 2014. 09. 18 Date of Issue 2014. 09. 22 In the configuration tested, the EUT complied with the standards specified above. Issue to Issue by Inkel Corporation. 93, Cheongjung-ro, Bupyeong-Gu, Incheon, 403-853, Korea Tel.: +82-32-650-6141 Fax: +82-32-650-6466 MOVON CORPORATION 498-2, Geumeo-ro, Pogok-eup, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea, 449-812 Tel.: +82-31-338-8837 Fax: +82-31-338-8847 MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (2) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Revision history Revision Date of issue Description Revised by -- Sep. 22, 2014 Initial -- MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (3) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Table of contents 1. ATTESTATION OF TEST RESULTS ............................................................................. 4 2. EUT DESCRIPTION ........................................................................................................ 6 3. FREQUENCY HOPPING SYSTEM REQUIREMENTS ................................................... 6 4. MEASUREMENT EQUIPMENT ...................................................................................... 8 5. TRANSMITTER RADIATED SPURIOUS EMISSIONS AND CONDUCTED SPURIOUS EMISSIONS .................................................................................................................. 9 6. CONDUCTED POWER LINE TEST .............................................................................. 33 7. RECEIVER RADIATED SPURIOUS EMISSIONS ........................................................ 36 8. 20 ㏈ BANDWIDTH MEASUREMENT & 99 % BANDWIDTH MEASUREMENT ........ 40 9. MAXIMUM PEAK OUTPUT POWER MEASUREMENT ............................................... 47 10. HOPPING CHANNEL SEPARATION ......................................................................... 52 11. NUMBER OF HOPPING FREQUENCY ...................................................................... 54 12. TIME OF OCCUPANCY (DWELL TIME) .................................................................... 56 13. ANTENNA REQUIREMENT ....................................................................................... 62 14. RF EXPOSURE EVALUATION .................................................................................. 63 15. TEST SETUP PHOTO OF EUT .................................................................................. 65 MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (4) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 1. Attestation of test results 1.1. Details of applicant Applicant : Inkel Corporation Address : 93, Cheongjung-ro, Bupyeong-Gu, Incheon, 403-853, Korea Contact Person : Eun-HWan, Shim Telephone : + 82-2-850-6295 Fax : + 82-2-850-6478 1.2. Manufacturer Information Manufacturer : Inkel Vietnam Co.,Ltd. Address : Block 26, Quang Minh Industrial Zone, Quang Minh Town, Me Linh District, Hanoi City, 100000, Vietnam. MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (6) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 2. EUT Description Kind of product Bluetooth module Model Name IK-CSRBC05 Power supply DC 1.8V / 3.3V (simultaneously) Frequency range 2 402 ㎒ ~ 2 480 ㎒ Modulation technique GFSK, Pi/4DQPSK, 8DPSK Number of channels 79 Antenna gain -2.49㏈i (Max.) TEST SITE REGISTRATION NUMBER FCC(670686) , IC(6432B-1) 2.1. Declarations by the manufacturer Power supply :DC 1.8V for core (simultaneously) DC 3.3V for Memory, USB, UART, GPIO 2.2. Details of modification None 3. Frequency Hopping System Requirements 3.1. Standard Applicable According to FCC Part 15.247(a)(1), The system shall hop to channel frequencies that are selected at the system hopping rate from a pseudo randomly ordered list of hopping frequencies. Each frequency must be used equally on the average by each transmitter. The system receivers shall have input bandwidths that match the hopping channel bandwidths of their corresponding transmitters and shall shift frequencies in synchronization with the transmitted signals. (g) Frequency hopping spread spectrum systems are not required to employ all available hopping channels during each transmission. However, the system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this section should the transmitter be presented with a continuous data (or information) stream. In addition, a system employing short transmission bursts must comply with the definition of a frequency hopping system and must distribute its transmissions over the minimum number of hopping channels specified in this section. (h) The incorporation of intelligence within a frequency hopping spread spectrum system that permits the system to recognize other users within the spectrum band so that it individually and independently chooses…

Text truncated - open the document above for the full version.

MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (40) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 8. 20 ㏈ bandwidth measurement & 99 % bandwidth measurement 8.1. Test setup EUT Spectrum analyzer 8.2. Limit Not applicable 8.3. Test procedure 1. The 20 ㏈ band width was measured with a spectrum analyzer connected to RF antenna connector (conducted measurement) while EUT was operating in transmit mode at the appropriate center frequency. The analyzer center frequency was set to the EUT carrier frequency, using the analyzer. Display Line and Marker Delta functions, the 20 ㏈ band width of the emission was determined. 2. The bandwidth of the fundamental frequency was measured with the spectrum analyzer using RBW ≥ 10 ㎑, VBW ≥ 10 ㎑, Span = 5 ㎒. 8.4. Test results Ambient temperature: 22 °C Relative humidity: 55 % R.H. Operation mode Frequency(㎒) 20 ㏈ bandwidth(㎒) 99 % bandwidth(㎒) BDR mode 2 402 0.764 0.855 2 441 0.760 0.851 2 480 0.764 0.855 EDR mode 2 402 1.216 1.190 2 441 1.242 1.172 2 480 1.263 1.177 MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (41) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Operation mode: BDR mode A. Low channel (2 402 ㎒) – 20 ㏈ bandwidth A. Low channel (2 402 ㎒) – 99 % bandwidth MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (42) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. B. Middle channel (2 441 ㎒) – 20 ㏈ bandwidth B. Middle channel (2 441 ㎒) – 99 % bandwidth MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (43) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. C. High channel (2 480 ㎒) – 20 ㏈ bandwidth C. High channel (2 480 ㎒) – 99 % bandwidth MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (44) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Operation mode: EDR mode A. Low channel (2 402 ㎒)– 20 ㏈ bandwidth & 99 % bandwidth MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (45) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. B. Middle channel (2 441㎒)– 20 ㏈ bandwidth & 99 % bandwidth MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (46) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. C. High channel (2 480㎒)– 20 ㏈ bandwidth & 99 % bandwidth MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (47) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 9. Maximum peak output power measurement 9.1. Test setup. EUT Spectrum analyzer 9.2. Limit The maximum peak output power of the intentional radiator shall not exceed the following: 1. §15.247(a)(1), Frequency hopping systems shall have hopping channel carrier frequencies separated by a minimum of 25 ㎑ or the 20 ㏈ bandwidth of the hopping channel, whichever is greater, provided the systems operate with an output power no greater than 125 ㎽ 2. §15.247(b)(1), For frequency hopping systems operating in the 2 400 – 2 483.5 ㎒ employing at least 75 non-overlapping hopping channels, and all frequency hopping systems in the 5 725 – 5 805 ㎒ band: 1 Watt. 9.3. Test procedure 1. The RF power output was measured with a Spectrum analyzer connected to the RF Antenna connector(conducted measurement) while EUT was operating in transmit mode at the appropriate center frequency, A spectrum analyzer was used to record the shape of the transmit signal. 2. The bandwidth of the fundamental frequency was measured with the spectrum analyzer using; Span = approximately 5 times the 20 ㏈ bandwidth, centered on a hopping channel RBW ≥ 20 ㏈ BW, VBW ≥ RBW, Sweep = auto, Detector function = peak, Trace = max hold 9.4. Test results Ambient temperature: 22 °C Relative humidity: 55 % R.H. Operation mode Frequency(㎒) Peak output power(㏈m) Limit(㏈m) BDR mode 2 402 -2.81 30 2 441 -1.41 30 2 480 -1.05 30 EDR mode 2 402 -3.87 30 2 441 -2.82 30 2 480 -2.53 30 MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (48) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Operation mode: BDR mode A. Low channel (2 402 ㎒) B. Middle channel (2 441 ㎒) MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (49) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. C. High channel (2 480 ㎒) MOVON CORPORATION Report Number: MOV-14-RF-I051 Page : (50) of (67) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Operation mode: EDR mode A. Low channel (2 402 ㎒) B. Middle ch…

Text truncated - open the document above for the full version.

Test setup photo of EUT A. Setup photo of EUT Photo of radiated spurious emission at below 30 ㎒ Photo of radiated spurious emission at 30 ㎒ ~ 1 000 ㎒ Photo of radiated spurious emission at above 1 000 ㎒ Photo of Conducted emission at below 30 ㎒
