Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
User Guide TCL 100 Contents Analog Alarm Clock Features........ 3 Cordless Vibration Pad Features .. 4 Important Safety Instructions ...... 5 Included Equipment ....................... 6 Set Up .............................................. 6 LED Display Notifi cation ................ 8 Clock Functions .............................. 9 Help and Support ......................... 12 Troubleshooting Guide ................ 12 Maintenance and Warranty ......... 13 Technical Details ........................... 15 Instructions available in other languages at www.amplicomusa.com. 1 FCC Compliance 33 Clock Features 1 Snooze button/ Alarm light/ incoming call light/Stop alarm 2 LED: Power ON/ OFF/Battery ON/OFF 3 Alarm ON/OFF 4 5 6 7 8 9 10 11 12 14 13 15 16 TCL 100 Analog Alarm Clock Features 1 2 3 2 3 1 4 5 6 7 8 9 10 11 12 13 14 15 16 4 Volume control 5 Set one of 5 acoustic signals 6 Pitch 7 Vibration and Acoustics 8 Flashing lamp ON/OFF 9 Snooze delay 10 Clock illumination 11 Telephone line socket 12 Power adapter socket 13 Vibration pad socket 14 Set alarm time 15 Set time 16 Battery compartment (on underside) Service Center 4 Clock Features TCL100 Cordless Vibration Pad Features 1 2 3 4 5 1 2 3 4 5 1 LED: Alarm ON/ OFF/Battery charge low 2 Vibration pad ON/OFF 3 Battery compartment 4 Screws for battery compartment 5 Connection cable socket Service Center 6 Getting Started — Included Equipment Set up 1. Connecting the alarm clock i. Insert the supplied batteries in the clock’s battery compartment. Getting started Important: Pay attention to correct polarity when inserting the batteries. • 1 Analog Alarm Clock • 1 Power Adapter • 1 Vibration Pad • 1 Connector Cable for Vibration Pad • 2XAAA, 500mA Ni-MH Rechargable Battery for Alarm Clock • 3XAAA, 800mA Ni-MH Rechargeable Battery Pack for Vibration Pad • Telephone Cord • Operating Instructions • Battery Compartment Cover Service Center 8 LED Display Notifi cation Alarm Clock Face The following functions are on the alarm clock face: Red: Alarm function is activated. Flashing Orange: Alarm function is activated, and battery charge is low. Vibration Pad The following functions are on the vibration pad: Flashing Green Every 2 Seconds: Vibration pad is on. Red: Vibration pad is charging. Flashing Red: Battery charge is low. Getting startedGetting started Getting started 1-866-AMPLICOM (267-5426) 9 Clock Functions Setting the clock Turn the set time rotary knob until the clock shows the correct time. Setting the alarm Turn the alarm time rotary knob until the clock shows the correct time for the alarm to trigger. Turning the alarm on/off Turn the alarm on/off rotary knob clockwise for On. Counterclockwise for Off. Setting the volume Caution: The volume/acoustic signal/pitch can only be modifi ed if the alarm is on. If the alarm is off, those settings cannot be adjusted. Caution: The alarm and telephone ringer begin sounding at a low volume. The volume will then increase to the set maximum until the alarm is turned off or the telephone is answered. Turn the volume rotary knob to set the maximum volume for the alarm and telephone ringer. Set the volume to a quiet setting to start and increase it slowly to the desired maximum volume. Clock functions Service Center 10 Clock functions Caution: Exposure to the alarm at full volume for a long period could cause ear damage. Selecting the acoustic signal Turn the acoustic signal rotary knob to required acoustic signal. Setting the pitch Turn the pitch rotary knob to set the pitch. It may be possible to detect higher or lower pitch tones even at low volumes. Setting the clock face illumination Slide the illumination switch to set clock face illumination. The following settings are available: (From left to right) bright, medium or off. Selecting the alarm mode MODE Slide the alarm mode switch to set the type of alarm. There are three settings available: (from left to right) vibration only, acoustic signal only or acoustic signal and vibration. 1-866-AMPLICOM (267-5426) 11 Setting the fl ashing light ON OFF Slide the switch to set the light in the snooze button to fl ash during an alarm. There are two settings available: (from left to right) On and Off. Setting the snooze delay SNOOZE 0m 5m 15m Slide the snooze delay switch to set the snooze delay. There are three settings available: (from left to right) 0 min, 5 min, or 15 min. Activating the snooze delay Important: if the Snooze button is pressed when the light is switched off, the clock face will illuminate for 30 seconds to allow the user to see the time. After 30 seconds the illumination will go out. SNOOZE Press the snooze button to stop the alarm for a specifi ed time before it resumes. To activate the snooze function, see “Setting the snooze delay”. Activating the vibration pad After connecting the vibration pad, use the switch on the vibration pad to turn the vibration function on and off. There are two settings available: (from left to right) On and Off. Clock functions Service Center 12 Help and support If you have problems with your device, please refer to the following information before calling for support. If you continue to have problems, please call the Service Center at 1-866-AMPLICOM (267-5426) for further assistance. Troubleshooting guide My clock does not work 1. The battery charge may be too low or no batteries have been inserted. 2. The clock may not be plugged in. My vibration pad does not work 1. The battery charge may be too low or the battery is defective (additional Battery packs are available from Amplicom). 2. The vibration pad may not be switched on. 3. The vibration pad is too far away from the alarm clock. The alarm does not go off The alarm function is not switched on; turn the knob to “On”. Help and support 1-866-AMPLICOM (267-5426) 13 Maintenance and Warranty Maintenance • Please clean your equipment’s surfaces with a soft, lint-free cloth. • Never use cleaning agents or solvents. Warranty AMPLICOM equipment is produced and t…
Text truncated - open the document above for the full version.
INTERTEK TESTING SERVICES External Photos FCC ID: VNN-CB1000SHAKER external photos - 1 of 1
CB1000GNR0-USA-WH00 Packing Instruction for labels Page 3/4 Rev00 Shaker Battery Compartment Shaker Top P/N: 710+01000-00021-00 Desc. :”Remove the Cap” label RoHS Size: 50X15mm Color: black on white background. Location: Top of the shaker Scale: Full R E M O V E THIS C AP! BITTE SCHUTZKAPPE ABNEHMEN! SVP ENLEVERLE CACHE DE PROTECTION ! BITTE SCHUTZKAPPE ABNEHMEN! SVP ENLEVER LE CACHE DE PROTECTION ! Model No.:TCL 100 Bat t er y: Ni-M H A A A (1 . 2 V 80 0 mA h) x 3 FC C ID: VNN-C B10 0 0 S HA K ER Made in China G00116GC000001 S/N: Rubber Cap (Red) Print the Serial number here e.g. : G00116GC000001 P/N: 710+01000-02800-00 Desc: Shaker label, Dsize: 27 X 9mm Color: black on white background Material: Label paper with plastic lamination on top Location : Base batt. compartment.
INTERTEK TESTING SERVICES Internal photos FCC ID: VNN-CB1000SHAKER internal photos - 1 of 4 Bed Shaker Battery compartment Bed Shaker assembly (View 1) INTERTEK TESTING SERVICES Internal photos FCC ID: VNN-CB1000SHAKER internal photos - 2 of 4 Bed Shaker assembly (View 2) Bed Shaker Main PCB comp side INTERTEK TESTING SERVICES Internal photos FCC ID: VNN-CB1000SHAKER internal photos - 3 of 4 Bed Shaker Main PCB solder side Bed Shaker Vibrator PCB comp side INTERTEK TESTING SERVICES Internal photos FCC ID: VNN-CB1000SHAKER internal photos - 4 of 4 Bed Shaker Vibrator PCB solder side
Report no.: HK10051677-1 Model no.: CB1010GHR0 Charging by Clock AC MAINS “L” Ctrl No.: N/A PAGE 1 Report No.:HK10051677-1 Scan Settings (1 Range) |--------- Frequencies -----------||----------- Receiver Settings ------------| Start Stop Step IF BW Detector M-Time Atten Preamp OpRge 150k 30M 4.5k 10k PK+AV 10ms AUTO LN OFF 60dB Final Measurement: x QP / + AV Meas Time: 1 s Subranges: 16 Acc Margin: 20dB Transducer No. Start Stop Name 1 1 9k 30M 2454 2 9k 30M 0700 3 9k 30M 0090 0 10 20 30 40 50 60 70 80 90 dBuV 100 0.15 MHz 30 110 F15Q F15A Report no.: HK10051677-1 Model no.: CB1010GHR0 Charging by Clock AC MAINS “L” Ctrl No.: N/A Report No.:HK10051677-1 Scan Settings (1 Range) |--------- Frequencies -----------||----------- Receiver Settings ------------| Start Stop Step IF BW Detector M-Time Atten Preamp OpRge 150k 30M 4.5k 10k PK+AV 10ms AUTO LN OFF 60dB Final Measurement Results: Frequency QP Level QP Limit Delta MHz dB dB dB 0.35250 37.7 58.9 -21.2 0.55950 36.4 56.0 -19.6 0.61800 35.3 56.0 -20.7 0.97800 35.0 56.0 -21.0 1.51800 41.5 56.0 -14.5 1.63950 49.6 56.0 -6.4 2.85000 37.6 56.0 -18.4 3.99300 40.8 56.0 -15.2 4.77150 40.9 56.0 -15.1 6.32850 40.2 60.0 -19.8 8.91600 40.3 60.0 -19.7 Frequency AV Level AV Limit Delta MHz dB dB dB 1.44150 25.1 46.0 -20.9 1.63950 36.3 46.0 -9.7 3.83100 24.5 46.0 -21.5 4.30350 27.1 46.0 -18.9 * limit exceeded Report no.: HK10051677-1 Model no.: CB1010GHR0 Charging by Clock AC MAINS “N” Ctrl No.: N/A PAGE 1 Report No.:HK10051677-1 Scan Settings (1 Range) |--------- Frequencies -----------||----------- Receiver Settings ------------| Start Stop Step IF BW Detector M-Time Atten Preamp OpRge 150k 30M 4.5k 10k PK+AV 10ms AUTO LN OFF 60dB Final Measurement: x QP / + AV Meas Time: 1 s Subranges: 16 Acc Margin: 20dB Transducer No. Start Stop Name 1 1 9k 30M 2454 2 9k 30M 0700 3 9k 30M 0090 0 10 20 30 40 50 60 70 80 90 dBuV 100 0.15 MHz 30 110 F15Q F15A Report no.: HK10051677-1 Model no.: CB1010GHR0 Charging by Clock AC MAINS “N” Ctrl No.: N/A Report No.:HK10051677-1 Scan Settings (1 Range) |--------- Frequencies -----------||----------- Receiver Settings ------------| Start Stop Step IF BW Detector M-Time Atten Preamp OpRge 150k 30M 4.5k 10k PK+AV 10ms AUTO LN OFF 60dB Final Measurement Results: Frequency QP Level QP Limit Delta MHz dBuV dBuV dB 0.36150 46.7 58.7 -12.0 0.55500 42.2 56.0 -13.8 0.56850 43.3 56.0 -12.7 0.98250 41.1 56.0 -14.9 1.34250 39.5 56.0 -16.5 1.61700 39.7 56.0 -16.3 2.89500 38.0 56.0 -18.0 4.10100 40.2 56.0 -15.8 4.87500 40.5 56.0 -15.5 5.81100 38.6 60.0 -21.4 9.50100 39.8 60.0 -20.2 Frequency AV Level AV Limit Delta MHz dBuV dBuV dB 0.25350 36.5 51.7 -15.2 0.35250 39.3 48.9 -9.6 0.40650 33.9 47.7 -13.8 0.56850 29.9 46.0 -16.1 0.98250 29.3 46.0 -16.7 1.23450 25.8 46.0 -20.2 1.62150 25.9 46.0 -20.1 2.74650 25.7 46.0 -20.3 3.47550 27.5 46.0 -18.5 4.25850 27.9 46.0 -18.1 * limit exceeded
- The test report only allows to be revised within the retention period unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report Number: HK10051677-1 Application for Original Grant of 47 CFR Part 15 Certification 433MHz ASK Superheterodyne Bed Shaker FCC ID: VNN-CB1000SHAKER Prepared and Checked by: Approved by: Simple Shum Nip Ming Fung, Melvin Engineer Supervisor November 09, 2010 November 09, 2010 INTERTEK TESTING SERVICES Test Report Number: HK10051677-1 Page 1 of 17 FCC ID: VNN-CB1000SHAKER GENERAL INFORMATION Applicant Name: Global China Technology Limited Applicant Address: Room 308, 3/F., Kwong Sang Hong Centre, 151-153 Hoi Bun Road, Kwun Tong, Hong Kong. FCC Specification Standard: FCC Part 15: 2008 FCC ID: VNN-CB1000SHAKER FCC Model(s): CB1010GHR0, CB1000GNR0, TCL 200, TCL 100 Type of EUT: Superheterodyne Receiver Description of EUT: 433MHz ASK Superheterodyne Bed Shaker Serial Number: N/A Sample Receipt Date: May 31, 2010 Date of Test: July 29-August 16, 2010 Report Date: November 09, 2010 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Test Report Number: HK10051677-1 Page 2 of 17 FCC ID: VNN-CB1000SHAKER Table of Contents 1.0 Summary of Test Results................................................................................... 3 2.0 General Description............................................................................................ 5 2.1 Product Description ............................................................................................ 5 2.2 Test Methodology............................................................................................... 6 2.3 Test Facility........................................................................................................ 6 3.0 System Test Configuration................................................................................. 8 3.1 Justification ........................................................................................................ 8 3.2 EUT Exercising Software.................................................................................... 9 3.3 Details of EUT and Description of Accessories................................................. 10 3.4 Measurement Uncertainty ................................................................................ 10 3.5 Equipment Modification .................................................................................... 10 4.0 Test Results....................................................................................................... 12 4.1 Field Strength Calculation................................................................................. 12 4.2 Radiated Emissions from Receiver ................................................................... 13 4.2.1 Radiated Emission Configuration Photograph ................................................ 13 4.2.2 Radiated Emission Data ................................................................................ 13 4.3 AC Power Line Conducted Emission ................................................................ 16 4.3.1 AC Power Line Conducted Emission Configuration Photograph..................... 16 4.3.2 AC Power Line Conducted Emission Data ..................................................... 16 5.0 Equipment List................................................................................................. 17 Appendix – Exhibits for Application of Certification INTERTEK TESTING SERVICES Test Report Number: HK10051677-1 Page 3 of 17 FCC ID: VNN-CB1000SHAKER 1.0 Summary of Test Results Test Items FCC Part 15 Section Results Details see section Radiated Emission from Receiver AC Power Line Conducted Emission 15.109 15.107 Pass Pass 4.2 4.3 INTERTEK TESTING SERVICES Test Report Number: HK10051677-1 Page 4 of 17 FCC ID: VNN-CB1000SHAKER EXHIBIT 2 GENERAL DESCRIPTION INTERTEK TESTING SERVICES Test Report Number: HK10051677-1 Page 5 of 17 FCC ID: VNN-CB1000SHAKER 2.0 General Description 2.1 Product Description The CB1010GHR0 is a 433MHz ASK Superheterodyne Bed Shaker. It operates at frequency of 433.92MHz. The Bed Shaker is powered by a "Ni-MH" type rechargeable battery pack (3.6V 800mAh). The antenna used in bed shaker is integral, and the test sample is a prototype. The Model(s): CB1000GNR0, TCL 200 and TCL 100 are the same as the Model: CB1010GHR0 in electronics/electrical designs, including software & firmware, PCB layout and construction design/physical design/enclosure. The only differences between these models are brand name, model number and packing configuration to be sold for marketing purpose. The circuit description is attached in the Appendix and saved with filename: descri.pdf. INTERTEK TESTING SERVICES Test Report Number: HK10051677-1 Page 6 of 17 FCC ID: VNN-CB1000SHAKER 2.2 Test Methodology Both AC power line-…
Text truncated - open the document above for the full version.
INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: VNN-CB1000SHAKER config photos (radiated emission – bed shaker) - 1 of 1 Radiated Emission – Bed Shaker Front View Rear View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: VNN-CB1000SHAKER config photos (conducted emission) - 1 of 2 Conducted Emission Front View Right Side View INTERTEK TESTING SERVICES The Worst Case Configuration Photographs FCC ID: VNN-CB1000SHAKER config photos (conducted emission) - 2 of 2 Conducted Emission Left Side View
Flat D 5/F Garment Centre · Kowloon · Hong Kong
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15B | 433.92 MHz - 433.92 MHz | - |

Amplified DECT Phone
Equipment Class
PUE - Part 15 Unlicensed PCS portable Tx held to ear
1.9GHz DECT Cordless Phone
Equipment Class
PUE - Part 15 Unlicensed PCS portable Tx held to ear
433MHz ASK Alarm Clock
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
1.9GHz Cordless Phone
Equipment Class
PUB - Part 15 Unlicensed PCS Base Station
1.9GHz Cordless Phone
Equipment Class
PUT - Part 15 Unlicensed PCS portable Tx worn on body
