VON-BSH-01

DIMTON CO., LTD.

Bluetooth Stereo Headset

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Oct 02, 2007
Application Purpose: Original Equipment
Date of Application: Oct 02, 2007
Equipment Note: Bluetooth Stereo Headset
Frequency Range: 2402.00000000 - 2480.00000000
Company: DIMTON CO., LTD.
Country: Taiwan

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

Parts List/Tune Up Info

Test Report

Test Setup Photos

Document Text Content (7 documents)

Cover Letter(s)

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

ID Label/Location Info

Page 3 Page 4 Page 5

Internal Photos

FCC ID: VDGARCHER102 Report No.: RF960615L07 Technical Description The transmitter of the EUT (Bluetooth EDR 2.0 Class 2 USB Adapter) is powered by 5Vdc from host equipment. The antenna is PCB Printed antenna without antenna connector. This device is a Frequency Hopping device with 79 hopping frequencies. For more detailed instruction, please take a look at the user’s manual.

Parts List/Tune Up Info

FCC ID: VDGARCHER102 Report No: SA960615L07 1 RF EXPOSURE REPORT REPORT NO.: SA960615L07 MODEL NO.: Archer 102 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: eRune technology Corp. ADDRESS: 2F, No.38-1, Guang-Ming 9th Rd., Chupei, Hsinchu, Taiwan, R.O.C.302 ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: VDGARCHER102 Report No: SA960615L07 2 Conclusion No Evaluation Required if power is below this threshold: F(GHz) mW Low 2.402 High 2.480 24.58 Maximum measured transmitter power: Pout (dBm) Pout (mW) Conducted Power 3.820 2.410 EIRP Power 3.820 2.410 *Note: The antenna is PCB Printed antenna with 0dBi gain Threshold for no SAR evaluation is 24.58mW Transmitter power is 2.410mW Conclusion: No SAR evaluation required since Transmitter Pout is below FCC threshold

Test Report

Report No.: RF960615L07 1 Report Format Version 2.0.5 FCC TEST REPORT REPORT NO.: RF960615L07 MODEL NO.: Archer 102 RECEIVED: Jun. 15, 2007 TESTED: Jun. 22 ~ Jun. 23, 2007 ISSUED: Jun. 26, 2007 APPLICANT: eRune technology Corp. ADDRESS: 2F, No.38-1, Guang-Ming 9th Rd., Chupei, Hsinchu, Taiwan, R.O.C.302 ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 76 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. NO. 2177-01 Report No.: RF960615L07 2 Report Format Version 2.0.5 TABLE OF CONTENTS 1. CERTIFICATION.......................................................................... .................4 2. SUMMARY OF TEST RESULTS............................................................ .........5 2.1 MEASUREMENT UNCERTAINTY ..............................................................................6 3. GENERAL INFORMATION................................................................ .............7 3.1 GENERAL DESCRIPTION OF EUT............................................................................7 3.2 DESCRIPTION OF TEST MODES..............................................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST .........................................................8 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ..............................9 3.2.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................... 11 3.2.4 DESCRIPTION OF SUPPORT UNITS ........................

Contact Information

Applicant

andrew chen(Managing Director)

[email protected]886-2-89938099Fax: 886-2-89938066

Test Firm

Compliance Certification Services Inc.Kurt Chen

[email protected]886-2-86422071Fax: 886-2-86422256

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	880.00 µW

Confidentiality

Long Term

Grant Notes

Power Output listed is conducted. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
