VR3-101500XElectronic lock � wireless IEEE 802.15.4/2.4GHz and RFID/13.56MHz

Medeco Security Locks, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Dec 10, 2012
Application Purpose: Original Equipment
Date of Application: Dec 10, 2012
Equipment Note: Electronic lock � wireless IEEE 802.15.4/2.4GHz and RFID/13.56MHz
Frequency Range: 13.56000000 - 13.56000000
Company: Medeco Security Locks, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Rhein Tech Laboratories, Inc. Client: Medeco Security Locks, Inc. 360 Herndon Parkway Model #’s: 10-15007 & 10-15009 Suite 1400 Standards: FCC 15.247/IC RSS-210 Herndon, VA 20170 ID’s: VR3-101500X/7465A-101500X http://www.rheintech.com Report #: 2012180DTS Page 38 of 42 Appendix K: Manual Please refer to the following pages. Medeco Aperio M100 Installation Instructions Parts List The M100 installs in a similar fashion to a mechanical mortise lock, and requires the same adjustments to function properly with the mortise hardware. The following steps outline the mechanical installation and pairing to the hub. Please refer to the EAC panel or software provider’s specific instructions for programming and managing the M100. Removal of Existing Cylinder Remove the door-edge trim by removing the retaining screws and gently prying the trim plate loose. Loosen the cylinder clamp screw far enough to allow the existing cylinder to be removed. Using a key partially inserted, rotate the mortise cylinder counter-clockwise to remove it. Also remove any trim rings if they are used. Installation of M100: Verify that the cam on the M100 is the same style as was on the cylinder that was just removed. If the removed cylinder is a Medeco brand, the cam can be interchanged onto the M100. If different brands, please refer to the chart found at www.Medecocams.com Screw the M100 into the cylinder mounting hole on the mortise hardware. It is important to not over tighten, or to keep too loose on the door. The M100 should fit snugly against the mortise escutcheon. Re-tighten the cylinder clamp screw with the M100 in a vertical position. The screw should engage tightly in the slot along the edge of the cylinder so that cannot rotate. Re-Install the door edge trim Add back plate and locking nut Tighten with Locking Nut tool Connect Wire Housing to wire harness Install Battery Install cover Assembly Install Knob and Set Screw This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate this equipment. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

Test Report

Engineering Solutions & Electromagnetic Compatibility Services 360 Herndon Pkwy | Suite 1400 | Herndon | Virginia 20170 Phone: 703.689.0368 | Fax: 703.689.2056 | www.rheintech.com FCC Part 15.225 & Industry Canada RSS-210 Certification Application Report Test Lab: Rhein Tech Laboratories, Inc. Tel: 703-689-0368 360 Herndon Parkway Fax: 703-689-2056 Suite 1400 www.rheintech.com Herndon, VA 20170 E- Mail: [email protected] Applicant: Medeco Security Locks 3626 Alleghany Drive Salem, VA 24153 (USA) Contact: David Smith [email protected] FCC/IC ID VR3-101500X 7465A-101500X Test Report Date October 3, 2012 Platform N/A RTL Work Order # 2012180 Model #’s 10-15007 & 10-15009 RTL Quote # QRTL12-180A American National Standard Institute ANSI C63.4-2003: Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC Classification DXX – Part 15 Low Power Communication Device Transmitter FCC Rule Part(s)/Guidance FCC Rules Part 15.225: Operation within the band 13.110-14.010 MHz (10-01-11) Industry Canada RSS-210 Issue 8: Low Power License-Exempt Communications Devices RSS-Gen: Issue 3; 2010 General Requirements and Information for the Certification of Radio Apparatus Digital Interface Information Digital Interface was found to be compliant Frequency Range (MHz) Output Power (W) Frequency Tolerance Emission Designator 13.56 N/A N/A 51K3FXD I, the undersigned, hereby declare that the equipment tested and referenced in this report conforms to the identified standard(s) as described in this test report. No modifications were made to the equipment during testing in order to achieve compliance with these standards. Furthermore, there was no deviation from, additions to, or exclusions from, the applicable parts of FCC Part 2, FCC Part 15, RSS-210, and ANSI C63.4. Signature: Date: October 3, 2012 Typed/Printed Name: Desmond A. Fraser Position: President This report may not be reproduced, except in full, without the written approval of Rhein Tech Laboratories, Inc.and Medeco Security Locks, Inc. The test results relate only to the item(s) tested. These tests are accredited and meet the requirements of ISO/IEC 17025 as verified by ANSI-ASQ National Accreditation Board/ACLASS. Refer to certificate and scope of accreditation AT-1445. Rhein Tech Laboratories, Inc. Client: Medeco Security Locks, Inc. 360 Herndon Parkway Model #s: 10-15007 & 10-15009 Suite 1400 Standards: FCC 15.225/IC RSS-210 Herndon, VA 20170 ID’s: VR3-101500X/7465A-101500X http://www.rheintech.com Report #: 2012180DXX Page 2 of 28 Table of Contents 1 General Information ............................................................................................................................... 4 1.1 Scope ............................................................................................................................................ 4 1.2 Description of EUT ........................................................................................................................ 4 1.3 Test Facility ................................................................................................................................... 4 1.4 Related Submittal(s)/Grant(s) ....................................................................................................... 4 1.5 Modifications ................................................................................................................................. 4 2 Test Information ..................................................................................................................................... 5 2.1 Description of Test Modes ............................................................................................................ 5 2.2 Exercising the EUT ....................................................................................................................... 5 2.3 Test Result Summary .................................................................................................................... 5 2.4 Test System Details ...................................................................................................................... 6 2.5 Configuration of Tested System .................................................................................................... 6 3 Radiated Emissions – FCC §15.209, §15.225(a)&(d); IC RSS-210 §A2.6; RSS-Gen .......................... 7 3.1 Limits of Radiated Emissions Measurement ................................................................................. 7 3.2 Radiated Emissions Measurement Test Procedure...................................................................... 7 3.3 Radiated Emissions Test Results ................................................................................................. 8 3.4 Radiated Emissions Harmonics/Spurious Test Data .................................................................... 9 3.5 Radiated Emissions Digital Test Data ........................................................................................... 9 4 AC Conducted Emissions - FCC §15.207; IC RSS-Gen §7.2.4: Conducted Limits ........................... 10 5 20 dB Bandwidth – IC RSS-Gen .......................................................................................................... 10 5.1 20 dB Bandwidth Test Procedure ............................................................................................... 10 5.2 20 dB Modulated Bandwidth Test Data ...................................................................................... 10 5.3 20 dB Bandwidth Plots ................................................................................................................ 11 6 Frequency Stability – FCC §2.1055, §15.225(e): Frequency Stability; IC RSS-119 §5.3 Transmitter Frequency Stability ..................................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Rhein Tech Laboratories, Inc. Client: Medeco Security Locks, Inc. 360 Herndon Parkway Model #s: 10-15007 & 10-15009 Suite 1400 Standards: FCC 15.225/IC RSS-210 Herndon, VA 20170 ID’s: VR3-101500X/7465A-101500X http://www.rheintech.com Report #: 2012180DXX Page 25 of 28 Appendix L: Test Photographs Photograph 1: Radiated Testing – Front View Rhein Tech Laboratories, Inc. Client: Medeco Security Locks, Inc. 360 Herndon Parkway Model #s: 10-15007 & 10-15009 Suite 1400 Standards: FCC 15.225/IC RSS-210 Herndon, VA 20170 ID’s: VR3-101500X/7465A-101500X http://www.rheintech.com Report #: 2012180DXX Page 26 of 28 Photograph 2: Radiated Testing – Rear View
