VR3-101501XElectronic Lock - Wireless IEEE802.15.4/2.4GHz and RFID/125kHz

Medeco Security Locks, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Jul 17, 2014
Application Purpose: Original Equipment
Date of Application: Jul 13, 2014
Equipment Note: Electronic Lock - Wireless IEEE802.15.4/2.4GHz and RFID/125kHz
Frequency Range: 0.12500000 - 0.12500000
Company: Medeco Security Locks, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Rhein Tech Laboratories, Inc. Client: Medeco Security Locks, Inc. 360 Herndon Parkway Model #: 10-15013 Suite 1400 Standards: FCC 15.247/IC RSS-210 Herndon, VA 20170 ID’s: VR3-101501X/7465A-101501X http://www.rheintech.com Report #: 2014065DTS Page 35 of 39 Appendix K: Manual Please refer to the following pages. PK-120204 M100 Aperio Mortise Lock Series Installation Instructions Machine screw with washer Package Contents Additional Tools Needed Options not included: Gang box to mount hub Approved Credential: HID iCLASS ID Credential Flathead drivers 3/32”, 3/16” #2 Phillips Driver Pencil, Wire Stripper Wireless Frequency: 2.4 GHz, IEEE 802.15.4, using AES 128bit encryption Hub Power Requirement: 8-24VDC, 250mA Lock Battery Type: CR2, providing 30,000 Cycles Operating Temperature: -10C to 50C FCC Part 15, Class B Compliant Credentials Supported: 13.56MHz iCLASS credentials are supported Product Specifications For technical support please call 1-800-810-WIRE (9473) Hub Mounting Bracket and Hardware (Hardware not shown) Aperio Hub Scan the QR code with your Smartphone wherever you see this symbol to view our How-To videos 15 16 2 System Overview The M100 wireless mortise lock extends access control to an office door, stockroom door or any other door requiring additional accountability without the complexity and expense of running wires to the opening. The M100 lock connects to an access control system through the included communication hub. The communication hub connects to the access control system with wiegand wiring typical of a wiegand reader. When a credential card is presented to the reader on the lock the request for access is sent wirelessly to the communication hub. The communication hub then communicates through wiegand wiring to the access control system where the decision is made to grant or deny access. 3 Installation Steps A. 1 - Choose the hub location It is recommended that the hub be mounted near the top of a wall, on the ceiling or above the ceiling to reduce potential for interference. For a stable and reliable radio link, it is recommended that the hub is located within forty-five (45) feet of the lock. A maximum of two interior walls between the hub and lock is recommended Recommended locations: A: Wall Mount B: Ceiling Mount C: Inside Ceiling Mount D: Wall Mount, Adjacent Room C. Test the Lock A. Locate and Mount the Hub B. Connect the Hub D. Install the Lock 4 A.2 - Mounting the Hub. The included adapter plate can be used to mount the hub on a single or double gang box. B. Wiring the Hub. The Aperio Hub connects to the Access Control system via Wiegand wiring. The hub requires 8-24VDC power (250mA). The hub includes three form C relays that can be used to transmit Lock jamb status, low battery signal and a tamper signal. The hub connects to the mortise lock wirelessly. *Note: the Green LED input is used to grant access to the M100 lock. If the Green LED signal is not available to indicate approved access, the hub input can be activated by another unlock signal or relay. Connect Lock Jamb, Low Battery & Tamper Detection Form C Relays 5 C. Testing the Lock with the Access Control System With the hub connected to power and the access control system, test the lock with a known good credential to confirm it will open as desired when installed. D. Mounting the Lock Before You Begin please verify the following:  You have the proper Cam for the door hardware being used  Verify the rotation of the lock matches the hardware on the door Step 1: The M100 installs in a similar fashion to a mechanical mortise lock, and requires the same adjustments to function properly with the mortise hardware. The following steps outline the mechanical installation only. Removal of Existing Cylinder a) Remove the door-edge trim by removing the retaining screws and gently prying the trim plate loose (Fig. 1). b) Loosen the cylinder clamp screw far enough to allow the existing cylinder to be removed (Fig. 2). c) Using a key partially inserted, rotate the mortise cylinder counter-clockwise to remove it. Also remove any trim rings if they are used (Fig. 3). Fig. 1 Fig. 2 Fig. 3 Step 2: Verify that the cam on the M100 is the same style as was on the cylinder that was just removed. If the removed cylinder is a Medeco brand, the cam can be interchanged onto the M100 (Fig. 4). Installing the M100 6 Fig. 4 Screw the M100 into the cylinder mounting hole on the mortise hardware (Fig. 5). It is important to not over tighten, or to keep too loose on the door. The face of the M100 cylinder should stand proud of the escutcheon approximately 3/16"-1/4". Please also see (Fig. 12) before proceeding (Fig. 6). Fig. 5 Fig. 6 Step 3: Re-tighten the cylinder clamp screw with the M100 in a vertical position. The screw should engage tightly in the slot along the edge of the cylinder so the cylinder cannot rotate (Fig. 7). Fig. 7 Step 4: Add back plate and locking nut (Fig. 8). Warning: Wire harness goes through plate (Fig. 9). 7 Fig. 8 Fig. 9 Tighten with locking nut tool (Fig. 10). Warning: Only one or two threads should be visible for proper operation (Fig. 11). Fig. 10 Fig. 11 Step 5: Connect control unit to wire harness and install 4 mounting screws (Fig. 12 and Fig. 13). Warning: Avoid pinching wire harness when mounting the control unit. Fig. 12 Fig. 13 8 Step 6: Install Battery. Please verify the battery is inserted in the correct polarity position. Always use new batteries installed with correct polarity (Fig. 14 and 15). Fig. 14 Fig. 15 Step 7: Install cover assembly (Fig. 16) and cover screw (Fig. 17). Fig. 16 Fig. 17 9 Step 8: Install thumbturn (Fig. 18), set screw (Fig. 19), and re-install door edge trim (Fig. 20). Fig. 18 Fig. 19 Fig. 20 Warning: FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cau…

Text truncated - open the document above for the full version.

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

Test Report

Engineering Solutions & Electromagnetic Compatibility Services 360 Herndon Pkwy | Suite 1400 | Herndon | Virginia 20170 Phone: 703.689.0368 | Fax: 703.689.2056 | www.rheintech.com FCC Part 15.209 & Industry Canada RSS-210 Certification Application Report Test Lab: Rhein Tech Laboratories, Inc. Tel: 703-689-0368 360 Herndon Parkway Fax: 703-689-2056 Suite 1400 www.rheintech.com Herndon, VA 20170 E-Mail: [email protected] Applicant: Medeco Security Locks 3625 Alleghany Drive Salem, VA 24153 Contact: David Smith FCC/IC ID VR3-101501X 7465A-101501X Test Report Date July 1, 2014 Platform N/A RTL Work Order # 2014065 Model # 10-15013 RTL Quote # QRTL14-065A American National Standard Institute ANSI C63.4-2003: Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz FCC Classification DXX – Part 15 Low Power Communication Device Transmitter FCC Rule Part(s)/Guidance FCC Rules Part 15.209: Radiated Emission Limits: General Requirements (10-01-13) Industry Canada RSS-210 Issue 8: License-Exempt Radio Apparatus (All Frequency Bands): Category 1 Equipment RSS-Gen: Issue 3; 2010 General Requirements and Information for the Certification of Radio Apparatus Digital Interface Information Digital Interface was found to be compliant Frequency Range (MHz) Output Power (W) Frequency Tolerance Emission Designator 0.125 N/A N/A 14K6FXD I, the undersigned, hereby declare that the equipment tested and referenced in this report conforms to the identified standard(s) as described in this test report. No modifications were made to the equipment during testing in order to achieve compliance with these standards. Furthermore, there was no deviation from, additions to, or exclusions from, the applicable parts of FCC Part 2, FCC Part 15, RSS-210, and ANSI C63.4. Signature: Date: July 1, 2014 Typed/Printed Name: Desmond A. Fraser Position: President This report may not be reproduced, except in full, without the written approval of Rhein Tech Laboratories, Inc.and Medeco Security Locks, Inc. The test results relate only to the item(s) tested. These tests are accredited and meet the requirements of ISO/IEC 17025 as verified by ANSI-ASQ National Accreditation Board/ACLASS. Refer to certificate and scope of accreditation AT-1445. Rhein Tech Laboratories, Inc. Client: Medeco Security Locks, Inc. 360 Herndon Parkway Model #: 10-15013 Suite 1400 Standards: FCC 15.209/IC RSS-210 Herndon, VA 20170 ID’s: VR3-101501X/7465A-101501X http://www.rheintech.com Report #: 2014065DXX Page 2 of 26 Table of Contents 1 General Information ............................................................................................................................... 4 1.1 Scope ............................................................................................................................................ 4 1.2 Description of EUT ........................................................................................................................ 4 1.3 Test Facility ................................................................................................................................... 4 1.4 Related Submittal(s)/Grant(s) ....................................................................................................... 4 1.5 Modifications ................................................................................................................................. 4 2 Test Information ..................................................................................................................................... 5 2.1 Description of Test Modes ............................................................................................................ 5 2.2 Exercising the EUT ....................................................................................................................... 5 2.3 Test Result Summary .................................................................................................................... 5 2.4 Test System Details ...................................................................................................................... 6 2.5 Configuration of Tested System .................................................................................................... 6 3 Radiated Emissions – FCC §15.209; IC RSS-210 §A2.6; RSS-Gen .................................................... 7 3.1 Limits of Radiated Emissions Measurement ................................................................................. 7 3.2 Radiated Emissions Measurement Test Procedure...................................................................... 7 3.3 Radiated Emissions Test Results ................................................................................................. 8 3.4 Radiated Emissions Harmonics/Spurious Test Data .................................................................... 9 3.5 Radiated Emissions Digital Test Data ........................................................................................... 9 4 AC Conducted Emissions - FCC §15.207; IC RSS-Gen §7.2.4: Conducted Limits ........................... 10 5 20 dB Bandwidth – IC RSS-Gen .......................................................................................................... 10 5.1 20 dB Bandwidth Test Procedure ............................................................................................... 10 5.2 20 dB Modulated Bandwidth Test Data ...................................................................................... 10 5.3 20 dB Bandwidth Plots ................................................................................................................ 11 6 Conclusion ........................................................................................................................................... 12 Rhein Tech Laboratories, Inc. Client: Medeco Security Locks, Inc. 360 Herndo…

Text truncated - open the document above for the full version.

Test Setup Photos

Rhein Tech Laboratories, Inc. Client: Medeco Security Locks, Inc. 360 Herndon Parkway Model #: 10-15013 Suite 1400 Standards: FCC 15.209/IC RSS-210 Herndon, VA 20170 ID’s: VR3-101501X/7465A-101501X http://www.rheintech.com Report #: 2014065DXX Page 23 of 26 Appendix K: Test Photographs Photograph 1: Radiated Emissions Testing – Front View Rhein Tech Laboratories, Inc. Client: Medeco Security Locks, Inc. 360 Herndon Parkway Model #: 10-15013 Suite 1400 Standards: FCC 15.209/IC RSS-210 Herndon, VA 20170 ID’s: VR3-101501X/7465A-101501X http://www.rheintech.com Report #: 2014065DXX Page 24 of 26 Photograph 2: Radiated Emissions Testing – Rear View
