VR8-SSIINTR002Wireless Wall Switch

Sensor Switch, Inc.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 15, 2013
Application Purpose: Original Equipment
Date of Application: Dec 11, 2013
Equipment Note: Wireless Wall Switch
Frequency Range: 902.87500000 - 902.87500000
Company: Sensor Switch, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Catalog Number NotesType PRODUCT OVERVIEW Sensor Switch introduces its RDT Wireless occupancy sensor and switch. The CM PDT xx WR is a wireless, battery operated ceiling sensor that incorporates both Passive Infrared (PIR) and Sensor Switch’s patented Microphonics™ dual technology making this sensor ideal for rooms where line of site is obstructed. The battery powered sensor has an estimated battery life of 10 years (at default settings). The SPODMR WR is a stylish, easy to install, and simple to use Wall Switch for use with synched CM PDT xx WR occupancy sensors or other RDT dimming interface modules, kinetic switches, or plug-load controllers. Designed to replace a standard wall toggle switch, the SPODMR WR wires to the standard wiring already present in the wall switch box. Once wired, a few button pushes will synch the switch to desired RDT devices. OPERATION — The CM PDT xx WR sensors have Passive Dual Technology (PDT), first seeing motion using 100% digital Passive Infrared (PIR) detection and then engaging Microphonics™ to hear sounds that indicate continued occupancy. When occupancy is detected, a wireless signal is transmitted to compatible wireless receiver/relay devices that switch the lighting load on. The SPODMR WR wireless switch contains a line-voltage relay and communicates wirelessly with one or more synched sensors as well as other switches. The relay has a user adjustable time delay (30 seconds - 30 minutes) that counts down after the synched sensor detects occupancy and transmits that status to the switch. The switch then closes its relay and turn the lights ON. It also resets its timer and begins a new countdown. If the timer within the Switch expires, the relay will be opened to turn lights OFF. Multiple sensors or RDT devices may be synched with the RDT Switch. The SPODMR WR is also ideal for three-way applications. Since multiple RDT devices can be paired, simply add a second wall switch to provides quick and easy switching from multiple locations. 1 of 8900 Northrop Road, Wallingford, CT 06492 Phone: 1-800.PASSIVE Fax: 203-269-9621 www.sensorswitch.com ©2013 Acuity Brands Lighting, Inc. All rights reserved 12/06/13 WIRELESS SENSOR & SWITCH WIRELESS BATTERY POWERED CEILING MOUNT SENSOR PASSIVE INFRARED (PIR) or DUAL TECH (PDT) OPTIONS CM xx WR Only: PASSIVE DUAL TECHNOLOGY (PDT) Ideal for rooms with obstructions - e.g. bathrooms with stalls and open office cubicle areas • Incorporates PIR and Microphonics (patented) • Utilizes Automatic Gain Control (AGC) to self-adapt the sensor to its environment • 100% passive detection, no potential for interference with other building systems CM xx WR: RDT 902 MHz Compliant 10 Year Battery Life (at defaults) 360º Coverage Pattern Patented Dual Technology with PIR / Microphonics Detection Push-Button Programmable Adjustable Time Delays No Field Calibration or Sensitivity Adjustments Required Green LED Indicator Push-Button Pairing with Compatible Devices Retrofit Applications KEY FEATURES SPODMR WR: 100% wireless operation w/ synched CM xx WR, RDT Plug-Load controller, and/or RDT dimming interface module 2 Green LED Indicators Line power and load wires are interchangeable - impossible to wire backwards (patented) Compatible w/ LEDs, Electronic & Magnetic Ballasts, CFLs, & Incandescents Push-Button Programmable Adjustable Time Delays Matching wallplate included Retrofit Applications SPODMR WR Only: COLOR Available in 5 colors • White, Ivory, Gray, Light Almond, and Black WIRELESS WALL SWITCH WIRELESS RANGE GUIDELINES Line of Sight: 98.43 ft (30 m); e.g. corridor Plasterboard / Dry Wood: 98.43 ft (30 m), max 5 walls Concrete Walls / Ceiling: 32.81 ft (10 m), max 1 wall/ceiling CM xx WR: SIZE: 4.5” Diameter (11.56 cm) 2.39” Deep (6.07 cm) WEIGHT: 6 oz MOUNTING: Ceiling Surface 3.5” Octagon Box Single Gang Handy Box COLOR: White BATTERY TYPE: AA Lithium (1.5V) EXPECTED BATTERY LIFE: ~10 years (at factory defaults) ENVIRONMENTAL SPECS OPERATING TEMP CM xx WR: -4º to 122º F (-20º to 50º C) CM PDT xx WR: 25º to 122º F (-4º to 50º C) SPODMR WR: -4º to 122º F (-20º to 50º C) RELATIVE HUMIDITY 20 to 90% non-condensing SILICONE FREE ROHS COMPLIANT WIRELESS FREQUENCY: 902 MHz (RDT™) ELECTRICAL SPECS SPODMR WR: MAXIMUM LOAD: 800 W @ 120 VAC / 1200 W @ 277 VAC (Fluorescent/Tungston) 360 W @ 120 VAC / 830 W @ 277 VAC (LED) 1A @ 24 VAC/VDC MINIMUM LOAD: None MOTOR LOAD: 1/4 HP LOAD FREQUENCY: 50/60 Hz SPECIFICATIONS SPODMR WR: SIZE: 2.74”H x 1.68”W x 1.63”D 6.96 cm x 4.27 cm x 4.14 cm) (not including ground strap) WEIGHT: 5 oz MOUNTING: Single gang switch box 900 Northrop Road, Wallingford, CT 06492 Phone: 1-800.PASSIVE Fax: 203-269-9621 www.sensorswitch.com ©2013 Acuity Brands Lighting, Inc. All rights reserved 12/06/13 2 of 8 Wireless Sensor & Switch 0 ft 9 0 m 2.7 28 21 14 7 0 ft 7 14 21 28 8.5 6.4 4.3 2.1 0 m 2.1 4.3 6.4 8.5 SIDE VIEW TOP VIEW 28 14 0 ft 14 28 8.5 4.3 0 m 4.3 8.5 0 ft 9 0 m 2.7 28 21 14 7 0 ft 7 14 21 28 8.5 6.4 4.3 2.1 0 m 2.1 4.3 6.4 8.5 SIDE VIEW TOP VIEW 28 14 0 ft 14 28 8.5 4.3 0 m 4.3 8.5 • Large motion (e.g. walking) detection in a 360º coverage pattern around sensor • Provides ~28 ft (8.53 m) radial coverage when mounted to standard 9 ft (2.74 m) ceiling • 7 to 15 ft (2.13 to 4.57 m) mounting heights provide ~16 to 36 ft (4.88 to 10.97 m) radial coverage • Units with -PDT (Passive Dual Technology) option (also called Microphonics™) provide overlapping detection of sounds from human activity over the complete PIR coverage area. Advanced filtering is utilized to prevent non- occupant noises from keeping the lights on. EXTENDED RANGE 360º (model #s: CM 10 WR / CM PDT 10 WR) Note: Sensor’s screw axis is offset 7.5º from a long detection segment COVERAGE PATTERNS 0 ft 9 0 m 2.7 SIDE VIEW TOP VIEW 12 6 0 ft 6 12 3.7 1.8 0 m 1.8 3.7 12 6 0 ft 6 12 3.7 1.8 0 m 1.8 3.7 STANDARD RANGE 360º (model #s: CM 9 WR / CM PDT 9 WR) Note: Sensor’s screw axis is aligned with a long detection segment 0 ft 9 0 m 2.7 SIDE VIEW TOP VIEW 1…

Text truncated - open the document above for the full version.

Attestation Statements

10-28-2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: FCC ID: VR8-SSIINTR002 (sPODMR WR) To Whom It May Concern: Sensor Switch, certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is valid until further written notice from Sensor Switch, Inc. Sincerely, William Fassbender Sensor Switch, Inc. Acuity Brands Controls 900 Northrop Rd. Wallingford, CT 06492 (203) 265-2842 [email protected]

Cover Letter(s)

10-28-2013 Subject: Confidentiality Request for FCC ID: VR8-SSIINT002 (sPODMR WR) Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Permanent User’s Manual Sensor Switch has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 90 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, William Fassbender Principal Engineer Sensor Switch, Inc. 900 Northrop Rd Wallingford, CT 06492 (203) 265-2842

Cover Letter(s)

10-28-2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: Agent Authorization Letter for FCC ID: VR8-SSIINTR002 (sPODMR WR) To Whom It May Concern: Please be advised that Sensor Switch, authorizes any accredited TCB employee of TUV Rheinland of North America to act on our behalf on all matters relating to applications for equipment authorization before the Federal Communications Commission, including signing of documents related to these matters. Sincerely, William Fassbender Sensor Switch, Inc. Acuity Brands Controls 900 Northrop Rd. Wallingford, CT 06492 (203) 265-2842 [email protected]

External Photos

ID Label/Location Info

Label Location FCC ID: VR8-SSIINTR002 IC: 7791A-SSIINTR002

ID Label/Location Info

FCC ID: VR8-SSIINTR002 IC ID: 7791A-SSIINTR002 Label layout for sPOD:

Internal Photos

TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Internal Photos Page 1 of 7 EUT: Wireless Wall Switch, Model: sPODMR WR Internal Photos EUT Name: Wireless Wall Switch EUT Model: sPODMR WR FCC ID: VR8-SSIINTR002 IC ID: 7791A-SSIINTR002 FCC Title 47, Part 15, SubpartC, RSS-210 Issue 8 Prepared for: William Fassbender Sensor Switch, Inc. 900 Northrop Road Wallingford, CT 06492 USA Tel: 203-265-2842 Fax: 203-269-9621 Prepared by: TUV Rheinland of North America 762 Park Avenue Youngsville, NC 27596 Tel: (919) 554-3668 Fax: (919) 554-3542 http://www.tuv.com/ Report/Issue Date: 20 November 2013 Report Number: Supplement to 31352796.001 - Internal Photos TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Internal Photos Page 2 of 7 EUT: Wireless Wall Switch, Model: sPODMR WR Internal Photos: Figure 1: View of circuit board with transmitter assembly inside the case Main Board RF Daughter Board TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Internal Photos Page 3 of 7 EUT: Wireless Wall Switch, Model: sPODMR WR Figure 2: Component view of main and daughter boards. TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Internal Photos Page 4 of 7 EUT: Wireless Wall Switch, Model: sPODMR WR Figure 3: Bottom view of main board and transmitter daughter boards. TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Internal Photos Page 5 of 7 EUT: Wireless Wall Switch, Model: sPODMR WR Figure 4: View of separated main board and transmitter daughter board. TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Internal Photos Page 6 of 7 EUT: Wireless Wall Switch, Model: sPODMR WR Figure 5: Component view of transmitter daughter board with RF Module and antenna. Chip Antenna and PCB tuning trace TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Internal Photos Page 7 of 7 EUT: Wireless Wall Switch, Model: sPODMR WR Figure 6: Rear view of transmitter daughter board.

RF Exposure Info

FCCID: VR8-SSIINTR002 IC: 7791A-SSIINTR002 Report No.: 31352796.001 Page 1 of 25 The test results contained in this report refer exclusively to the product(s) presented for testing. No liability may be assumed for models or products not referred to herein. This test report may not be published or duplicated in part without permission of the testing body. This test report by itself does not constitute authorization for the use of any TUV Rheinland test mark. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA. TUV Rheinland of North America, Inc., 762 Park Avenue, Youngsville, NC 27596-9470, Tel: 919-554-3668, Fax: 919-554-3542 QF09B040 Revision 2.0 - Electromagnetic Compatibility Test Report Prepared in accordance with FCC Part 15C, RSS-210 Issue 8 On Wireless Wall Switch sPODMR WR Family of Devices Sensor Switch, Inc. 900 Northrop Road Wallingford, CT 06492 USA Prepared by: TUV Rheinland of North America, Inc. FCCID: VR8-SSIINTR002 IC: 7791A-SSIINTR002 Report No.: 31352796.001 Page 2 of 25 The test results contained in this report refer exclusively to the product(s) presented for testing. No liability may be assumed for models or products not referred to herein. This test report may not be published or duplicated in part without permission of the testing body. This test report by itself does not constitute authorization for the use of any TUV Rheinland test mark. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA. TUV Rheinland of North America, Inc., 762 Park Avenue, Youngsville, NC 27596-9470, Tel: 919-554-3668, Fax: 919-554-3542 QF09B040 Revision 2.0 Manufacturer’s statement - attestation The manufacturer; Sensor Switch, Inc., as the responsible party for the equipment tested, hereby affirms: a) That he has reviewed and concurs that the test shown in this report are reflective of the operational characteristics of the device for which certification is sought; b) That the device in this test report will be representative of production units; c) That all changes (in hardware and software/firmware) to the subject device will be reviewed. d) That any changes impacting the attributes, functionality or operational characteristics documented in this report will be communicated to the body responsible for approving (certifying) the subject equipment. William Fassbender Printed name of official Signature of official 900 Northrop Road Wallingford, CT 06492 USA 7 November 2013 Address Date 203-265-2842 [email protected] Telephone number Email address of official FCCID: VR8-SSIINTR002 IC: 7791A-SSIINTR002 Report No.: 31352796.001 Page 3 of 25 The test results contained in this report refer exclusively to the product(s) presented for testing. No liability may be assumed for models or products not referred to herein. This test report may not be published or duplicated in part without permission of the testing body. This test report by itself does not constitute authorization for the use of any TUV Rheinland test mark. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA. TUV Rheinland of North America, Inc., 762 Park Avenue, Youngsville, NC 27596-9470, Tel: 919-554-3668, Fax: 919-554-3542 QF09B040 Revision 2.0 Client: Sensor Switch, Inc. 900 Northrop Road Wallingford, CT 06492 USA William Fassbender 203-265-2842 / 203-269-9621 [email protected] Identification: Wireless Wall Switch Serial No.: Production Prototype Test item: sPODMR WR Date tested: 5 Nov 2013 Testing location: TUV Rheinland of North America 762 Park Avenue Youngsville, NC 27596-9470 U.S.A. Tel: (919) 554-3668 Fax: (919) 554-3542 Test specification: Emissions: FCC Part 15, Subpart C, RSS-210 Issue 8: FCC Parts 15.207(a) and RSS-GEN 7.2.4, FCC Parts 15.249(d), 15.209, 15.215(c) and RSS-210 A2.9, RSS-GEN 7.2.1 FCC Part 15.249 and RSS-210 Annex 2.9, FCC Parts 15.249(a), 15.249(c), RSS-210 A2.9(a), FCC Part 2.1093 and RSS-102, Issue 4, Test Result The above product was found to be Compliant to the above test standard(s) tested by: Mark Ryan reviewed by: Michael Moranha 8 November 2013 Date Signature 8 November 2013 Date Signature Other Aspects: None Abbreviations: OK, Pass, Compliant, Complies = passed Fail, Not Compliant, Does Not Comply = failed N/A = not applicable Industry Canada 90552 and 100881 Testing Cert #3331.05 2932H-1 and 2932H-2 FCCID: VR8-SSIINTR002 IC: 7791A-SSIINTR002 Report No.: 31352796.001 Page 4 of 25 The test results contained in this report refer exclusively to the product(s) presented for testing. No liability may be assumed for models or products not referred to herein. This test report may not be published or duplicated in part without permission of the testing body. This test report by itself does not constitute authorization for the use of any TUV Rheinland test mark. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA. TUV Rheinland of North America, Inc., 762 Park Avenue, Youngsville, NC 27596-9470, Tel: 919-554-3668, Fax: 919-554-3542 QF09B040 Revision 2.0 TABLE OF CONTENTS 1 GENERAL INFORMATION ......................................................................................................................... 5 1.1 S COPE ......................................................................................................................................................... 5 1.2 P URPOSE ..................................................................................................................................................... 5 1.3 R EVISION HISTORY ..................................................................................................................................... 5 1.4 S UMMARY OF TEST RESULTS ..................................................................................................................... 6 2 LABORATORY INFORMATION ..............…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Test Setup Photos

TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Test Setup Photos Page 1 of 7 EUT: Wireless Wall Switch Model: sPODMR WR Test Setup Photos EUT Name: Wireless Wall Switch EUT Model: sPODMR WR FCC ID: VR8-SSIINTR002 IC ID: 7791A-SSIINTR002 FCC Title 47, Part 15, SubpartC, RSS-210 Issue 8 Prepared for: William Fassbender Sensor Switch, Inc. 900 Northrop Road Wallingford, CT 06492 USA Tel: 203-265-2842 Fax: 203-269-9621 Prepared by: TUV Rheinland of North America 762 Park Avenue Youngsville, NC 27596 Tel: (919) 554-3668 Fax: (919) 554-3542 http://www.tuv.com/ Report/Issue Date: 20 November 2013 Report Number: Supplement to 31352796.001 - Test Setup Photos TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Test Setup Photos Page 2 of 7 EUT: Wireless Wall Switch Model: sPODMR WR Test Setup Photos: Figure 1: Radiated Emissions – 30 MHz to 1000 MHz. TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Test Setup Photos Page 3 of 7 EUT: Wireless Wall Switch Model: sPODMR WR Figure 2: Typical Radiated Emissions test setup at 3m – 1 GHz to 10 GHz. TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Test Setup Photos Page 4 of 7 EUT: Wireless Wall Switch Model: sPODMR WR Figure 3: Orientation 1 investigated. Notes: Orientation 1 produced the highest emissions from the EUT. Each orientation was rotated through 360º with the receiving antenna in Horizontal and then Vertical. The emissions were monitored using a spectrum analyzer to determine the worst-case orientation. TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Test Setup Photos Page 5 of 7 EUT: Wireless Wall Switch Model: sPODMR WR Figure 4: Orientation 2 investigated TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Test Setup Photos Page 6 of 7 EUT: Wireless Wall Switch Model: sPODMR WR Figure 5: Orientation 3 investigated TUV Rheinland 762 Park Ave., Youngsville, NC 27596 FCC ID: VR8-SSIINTR002 Tel: (919) 554-3668, Fax: (919) 554-3542 IC ID: 7791A-SSIINTR002 Report Number: Supplement to 31352796.001 - Test Setup Photos Page 7 of 7 EUT: Wireless Wall Switch Model: sPODMR WR Figure 6: Conducted Emissions test setup

Contact Information

Applicant

William Fassbender

[email protected]203 265-2842Fax: 203 269-9621

Test Firm

TUV Rheinland of North America Inc.David Spencer

[email protected](925) 249-9123 x2116Fax: 919 554 3542

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	902.875 MHz - 902.875 MHz	4.00 mW

Confidentiality

Long Term

Grant Notes

This device is to be used only for fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance..
