VR8-SSIINTR003Wireless ceiling mounted occupancy sensor

Sensor Switch, Inc.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 15, 2013
Application Purpose: Original Equipment
Date of Application: Dec 10, 2013
Equipment Note: Wireless ceiling mounted occupancy sensor
Frequency Range: 902.87500000 - 902.87500000
Company: Sensor Switch, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Catalog Number NotesType PRODUCT OVERVIEW Sensor Switch introduces its RDT Wireless occupancy sensor and switch. The CM PDT xx WR is a wireless, battery operated ceiling sensor that incorporates both Passive Infrared (PIR) and Sensor Switch’s patented Microphonics™ dual technology making this sensor ideal for rooms where line of site is obstructed. The battery powered sensor has an estimated battery life of 10 years (at default settings). The SPODMR WR is a stylish, easy to install, and simple to use Wall Switch for use with synched CM PDT xx WR occupancy sensors or other RDT dimming interface modules, kinetic switches, or plug-load controllers. Designed to replace a standard wall toggle switch, the SPODMR WR wires to the standard wiring already present in the wall switch box. Once wired, a few button pushes will synch the switch to desired RDT devices. OPERATION — The CM PDT xx WR sensors have Passive Dual Technology (PDT), first seeing motion using 100% digital Passive Infrared (PIR) detection and then engaging Microphonics™ to hear sounds that indicate continued occupancy. When occupancy is detected, a wireless signal is transmitted to compatible wireless receiver/relay devices that switch the lighting load on. The SPODMR WR wireless switch contains a line-voltage relay and communicates wirelessly with one or more synched sensors as well as other switches. The relay has a user adjustable time delay (30 seconds - 30 minutes) that counts down after the synched sensor detects occupancy and transmits that status to the switch. The switch then closes its relay and turn the lights ON. It also resets its timer and begins a new countdown. If the timer within the Switch expires, the relay will be opened to turn lights OFF. Multiple sensors or RDT devices may be synched with the RDT Switch. The SPODMR WR is also ideal for three-way applications. Since multiple RDT devices can be paired, simply add a second wall switch to provides quick and easy switching from multiple locations. 1 of 8900 Northrop Road, Wallingford, CT 06492 Phone: 1-800.PASSIVE Fax: 203-269-9621 www.sensorswitch.com ©2013 Acuity Brands Lighting, Inc. All rights reserved 12/06/13 WIRELESS SENSOR & SWITCH WIRELESS BATTERY POWERED CEILING MOUNT SENSOR PASSIVE INFRARED (PIR) or DUAL TECH (PDT) OPTIONS CM xx WR Only: PASSIVE DUAL TECHNOLOGY (PDT) Ideal for rooms with obstructions - e.g. bathrooms with stalls and open office cubicle areas • Incorporates PIR and Microphonics (patented) • Utilizes Automatic Gain Control (AGC) to self-adapt the sensor to its environment • 100% passive detection, no potential for interference with other building systems CM xx WR: RDT 902 MHz Compliant 10 Year Battery Life (at defaults) 360º Coverage Pattern Patented Dual Technology with PIR / Microphonics Detection Push-Button Programmable Adjustable Time Delays No Field Calibration or Sensitivity Adjustments Required Green LED Indicator Push-Button Pairing with Compatible Devices Retrofit Applications KEY FEATURES SPODMR WR: 100% wireless operation w/ synched CM xx WR, RDT Plug-Load controller, and/or RDT dimming interface module 2 Green LED Indicators Line power and load wires are interchangeable - impossible to wire backwards (patented) Compatible w/ LEDs, Electronic & Magnetic Ballasts, CFLs, & Incandescents Push-Button Programmable Adjustable Time Delays Matching wallplate included Retrofit Applications SPODMR WR Only: COLOR Available in 5 colors • White, Ivory, Gray, Light Almond, and Black WIRELESS WALL SWITCH WIRELESS RANGE GUIDELINES Line of Sight: 98.43 ft (30 m); e.g. corridor Plasterboard / Dry Wood: 98.43 ft (30 m), max 5 walls Concrete Walls / Ceiling: 32.81 ft (10 m), max 1 wall/ceiling CM xx WR: SIZE: 4.5” Diameter (11.56 cm) 2.39” Deep (6.07 cm) WEIGHT: 6 oz MOUNTING: Ceiling Surface 3.5” Octagon Box Single Gang Handy Box COLOR: White BATTERY TYPE: AA Lithium (1.5V) EXPECTED BATTERY LIFE: ~10 years (at factory defaults) ENVIRONMENTAL SPECS OPERATING TEMP CM xx WR: -4º to 122º F (-20º to 50º C) CM PDT xx WR: 25º to 122º F (-4º to 50º C) SPODMR WR: -4º to 122º F (-20º to 50º C) RELATIVE HUMIDITY 20 to 90% non-condensing SILICONE FREE ROHS COMPLIANT WIRELESS FREQUENCY: 902 MHz (RDT™) ELECTRICAL SPECS SPODMR WR: MAXIMUM LOAD: 800 W @ 120 VAC / 1200 W @ 277 VAC (Fluorescent/Tungston) 360 W @ 120 VAC / 830 W @ 277 VAC (LED) 1A @ 24 VAC/VDC MINIMUM LOAD: None MOTOR LOAD: 1/4 HP LOAD FREQUENCY: 50/60 Hz SPECIFICATIONS SPODMR WR: SIZE: 2.74”H x 1.68”W x 1.63”D 6.96 cm x 4.27 cm x 4.14 cm) (not including ground strap) WEIGHT: 5 oz MOUNTING: Single gang switch box 900 Northrop Road, Wallingford, CT 06492 Phone: 1-800.PASSIVE Fax: 203-269-9621 www.sensorswitch.com ©2013 Acuity Brands Lighting, Inc. All rights reserved 12/06/13 2 of 8 Wireless Sensor & Switch 0 ft 9 0 m 2.7 28 21 14 7 0 ft 7 14 21 28 8.5 6.4 4.3 2.1 0 m 2.1 4.3 6.4 8.5 SIDE VIEW TOP VIEW 28 14 0 ft 14 28 8.5 4.3 0 m 4.3 8.5 0 ft 9 0 m 2.7 28 21 14 7 0 ft 7 14 21 28 8.5 6.4 4.3 2.1 0 m 2.1 4.3 6.4 8.5 SIDE VIEW TOP VIEW 28 14 0 ft 14 28 8.5 4.3 0 m 4.3 8.5 • Large motion (e.g. walking) detection in a 360º coverage pattern around sensor • Provides ~28 ft (8.53 m) radial coverage when mounted to standard 9 ft (2.74 m) ceiling • 7 to 15 ft (2.13 to 4.57 m) mounting heights provide ~16 to 36 ft (4.88 to 10.97 m) radial coverage • Units with -PDT (Passive Dual Technology) option (also called Microphonics™) provide overlapping detection of sounds from human activity over the complete PIR coverage area. Advanced filtering is utilized to prevent non- occupant noises from keeping the lights on. EXTENDED RANGE 360º (model #s: CM 10 WR / CM PDT 10 WR) Note: Sensor’s screw axis is offset 7.5º from a long detection segment COVERAGE PATTERNS 0 ft 9 0 m 2.7 SIDE VIEW TOP VIEW 12 6 0 ft 6 12 3.7 1.8 0 m 1.8 3.7 12 6 0 ft 6 12 3.7 1.8 0 m 1.8 3.7 STANDARD RANGE 360º (model #s: CM 9 WR / CM PDT 9 WR) Note: Sensor’s screw axis is aligned with a long detection segment 0 ft 9 0 m 2.7 SIDE VIEW TOP VIEW 1…
