VUI-LSPX-PT1Moule

LSPX-P1 4-581-618-11(1) 4-581-618-11(1) Portable Ultra Short Throw Projector Reference Guide ©2016 Sony Corporation Printed in Korea LSPX-P1 Manuals supplied Startup Guide Read this manual first. The initial preparation, such as charging and connecting a smartphone, is described. Reference Guide (this document) Safety precautions and specifications. Help Guide (Web operating instructions) The Help Guide describes the features of the unit and how to use in detail. You can view the Help Guide on a smartphone or computer. http://xxxx Location of controls  Portable Ultra Short Throw Projector  Projection window(Laser Apeture)  Power button  Ventilation holes (intake/exhaust)  Power indicator  DC IN 19.5V jack  Distance sensor  RESET button  Charge indicator  Power jack for the stand (not supplied)  Wireless HDMI Unit  HDMI IN  HDMI OUT (pass-through)  IR BLASTER output  DC IN 5V jack  PAIRING button Owner’s Record The model and serial numbers are located on the bottom. Record the serial number in the space provided below. Refer to these numbers whenever you call your Sony dealer regarding this product. Model No. LSPX-P1 (Projector) Serial No. _____________________________ Model No. LSPX-PT1 (Wireless HDMI Unit) Serial No. _____________________________ WARNING To reduce fire or shock hazard, do not expose the unit to rain or moisture. IMPORTANT SAFETY INSTRUCTIONS -SAVE THESE INSTRUCTIONS DANGER TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS If the shape of the plug does not fit the power outlet, use an attachment plug adaptor of the proper configuration for the power outlet. CAUTION Observe the following cautions, as there may be a risk of heat generation, fire or explosion. * Lithium-ion battery is built into the product. • Charge the product by the designated charging method. • Do not place the product in or near fire, or put the product in a microwave. • Do not leave the product in a car in hot weather. • Do not store or use the product in a hot and humid place such as in a sauna bath. • Do not disassemble, crush or pierce the product. • Do not expose the product to excessive shock such as dropping from a high place. • Do not expose the product to high temperatures above 60 °C (140 °F). • Keep the product dry. Dispose of the product appropriately. Charge the product by the designated charging method in the instruction manual. • Use the nearby wall outlet (wall socket) when using this unit. If any trouble occurs while this unit is in use, unplug it from the wall outlet (wall socket) to disconnect the power. • For models with CHARGE lamp Even when the CHARGE lamp is off, the power is not disconnected. For Customers in the U.S.A. For supplied accessories This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Compliance with FCC requirement 15.407(c) Data transmission is always initiated by software, which is the passed down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In other words, this device automatically discontinue transmission in case of either absence of information to transmit or operational failure. Frequency Tolerance: ±15 ppm This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated keeping the radiator at least 20cm or more away from person's body. For Customers in the U.S.A. If you have any questions about this product, you may call: Sony Customer Information Center 1-800-222-SONY (7669) The number below is for the FCC related matters only. [ Regulatory Information Declaration of Conformity Trade Name: SONY Model No.: LSPX-P1 Responsible Party: Sony Electronics Inc. Address: 16535 Via Esprillo, San Diego, CA 92127 U.S.A. Telephone No.: 858-942-2230 This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment must not be co-located or operated in conjunction with any other antenna or tr ansmitter. CAUTION You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a cir…

Text truncated - open the document above for the full version.

Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 1 of 2 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Photographs of EUT Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 2 of 2 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973

Sujing 2015.08.19 Pantone Cool Gray 4C C:17.19; M:14.84; Y: 17.97; K:0; MOULE Product label for Moule Qiusi Note: 材質: 50#PET+25#可打印霧膜 尺寸: L 44 * W 44mm 公差: ±0.2mm Roll form packaging 包裝方式: 卷狀外翻 Outer diameter of the paper roll core: 3'(76.2mm) 紙張芯外直徑: 3'(76.2mm) Outer diameter of the paper roll: <8’(203mm) 紙張卷外直徑: <8’(203mm) **Printing with high temperature ribbon **配合高溫碳帶打印使用 Roll direction 卷紙方向 Cut dashed 切虛線 Release paper 離型紙 Printing position for factory: 工廠印刷位置: 44 mm 12 mm 44 mm 1510-xxxxxSO(A) Qiusi ±0.2 1:1 50#PET 25# 44 mm 44 mm HRC(MAC Address12桁+Space1桁+S/N7桁)

Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 1 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Photographs of EUT Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 2 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 3 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 4 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 5 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 6 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 7 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 8 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 9 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 10 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973 Report No.: 580519 SPORTON International Inc. PAGE NUMBER : 11 of 11 TEL : 886-3-327-3456 ISSUED DATE : Sep. 30, 2015 FAX : 886-3-327-0973

Report No.: FA580519 Report Format Version: 01 Page No. : i of ii FCC ID : VUI-LSPX-PT1 Issued Date : Sep. 30, 2015 Table of Contents 1. GENERAL DESCRIPTION.................................................................................................................................... 1 1.1. EUT General Information .....................................................................................................................................................................1 1.2. Testing Location..................................................................................................................................................................................1 2. MAXIMUM PERMISSIBLE EXPOSURE.................................................................................................................... 2 2.1. Limit of Maximum Permissible Exposure ..............................................................................................................................................2 2.2. MPE Calculation Method ....................................................................................................................................................................2 2.3. Calculated Result and Limit................................................................................................................................................................3 Report No.: FA580519 Report Format Version: 01 Page No. : ii of ii FCC ID : VUI-LSPX-PT1 Issued Date : Sep. 30, 2015 History of This Test Report REPORT NO. VERSION DESCRIPTION ISSUED DATE FA580519 Rev. 01 Initial issue of report Sep. 30, 2015 Report No.: FA580519 Report Format Version: 01 Page No. : 1 of 3 FCC ID : VUI-LSPX-PT1 Issued Date : Sep. 30, 2015 1. GENERAL DESCRIPTION 1.1. EUT General Information RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type 5GHz WLAN 5150-5250 5725-5850 5180-5240 5745-5825 802.11a/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) 1.2. Testing Location Testing Location HWA YA ADD : No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. TEL : 886-3-327-3456 FAX : 886-3-327-0973 JHUBEI ADD : No.8, Lane 724, Bo-ai St., Jhubei City, HsinChu County 302, Taiwan, R.O.C. TEL : 886-3-656-9065 FAX : 886-3-656-9085 Report No.: FA580519 Report Format Version: 01 Page No. : 2 of 3 FCC ID : VUI-LSPX-PT1 Issued Date : Sep. 30, 2015 2. MAXIMUM PERMISSIBLE EXPOSURE 2.1. Limit of Maximum Permissible Exposure (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 2.2. MPE Calculation Method The MPE was calculated at 20 cm to show compliance with the power density limit. The following formula was used to calculate the Power Density: E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   Report No.: FA580519 Report Format Version: 01 Page No. : 3 of 3 FCC ID : VUI-LSPX-PT1 Issued Date : Sep. 30, 2015 2.3. Calculated Result and Limit Exposure Environment: General Population / Uncontrolled Exposure For 5GHz Band : Antenna Type : Printed Antenna Conducted Power for IEEE 802.11n MCS0 (HT40): 19.95 dBm Average Output Power Distance (m) Test Freq. (MHz) Directional Gain or Antenna Gain (dBi) Antenna Gain (numeric) (dBm) (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 20 5230 4.894 3.0832 19.9536 98.9379 0.060717 1 Complies

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: Rev. 01 FCC RADIO TEST REPORT Applicant’s company PEGATRON CORPORATION Applicant Address 5F., NO. 76, LIGONG ST., BEITOU DISTRICT, TAIPEI CITY 11259, Taiwan FCC ID VUI-LSPX-PT1 Manufacturer’s company PEGATRON CORPORATION Manufacturer Address 5F., NO. 76, LIGONG ST., BEITOU DISTRICT, TAIPEI CITY 11259, Taiwan Product Name Moule Brand Name SONY Model No. LSPX-PT1 Test Rule Part(s) 47 CFR FCC Part 15 Subpart E § 15.407 Test Freq. Range 5150 ~ 5250 MHz / 5725 ~ 5850 MHz Received Date Jul. 27, 2015 Final Test Date Aug. 21, 2015 Submission Type Original Equipment Statement Test result included is for the IEEE 802.11n and IEEE 802.11a of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.10-2013, 47 CFR FCC Part 15 Subpart E, KDB789033 D02 v01, KDB662911 D01 v02r01 The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR580519 Report Format Version: Rev. 01 Page No. : i of ii FCC ID: VUI-LSPX-PT1 Issued Date : Sep. 30, 2015 Table of Contents 1. VERIFICATION OF COMPLIANCE ....................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details....................................................................................................................................................................................3 3.2. Accessories .........................................................................................................................................................................................4 3.3. Table for Filed Antenna.......................................................................................................................................................................5 3.4. Table for Carrier Frequencies .............................................................................................................................................................6 3.5. Table for Test Modes ...........................................................................................................................................................................7 3.6. Table for Testing Locations..................................................................................................................................................................8 3.7. Table for Supporting Units ...................................................................................................................................................................8 3.8. Table for Parameters of Test Software Setting .....................................................................................................................................9 3.9. EUT Operation during Test ...................................................................................................................................................................9 3.10. Duty Cycle ..........................................................................................................................................................................................9 3.11. Test Configurations ...........................................................................................................................................................................10 4. TEST RESULT ................................................................................................................................................... 12 4.1. AC Power Line Conducted Emissions Measurement.........................................................................................................................12 4.2. 26dB Bandwidth and 99% Occupied Bandwidth Measurement......................................................................................................16 4.3. 6dB Spectrum Bandwidth Measurement ..........................................................................................................................................26 4.4. Maximum Conducted Output Power Measurement .........................................................................................................................31 4.5. Power Spectral Density Measurement ..............................................................................................................................................34 4.6. Radiated Emissions Measurement ....................................................................................................................................................42 4.7. Band Edge Emissions Measurement .................................................................................................................................................65 4.8. Frequency Stability Measurement ....................................................................................................................................................73 4.9. Antenna Requirements .....................................................................................................................................................................78 5. LIST OF MEASURING EQUIPMENTS ...........…
