VW4A090489ATAVRRZ600-230

AVR600: RZ600 HW Manual Features • Contains the full selection of AT86RF family radio transceivers. • Covers the 2.4GHz ISM band and 700, 800 and 900 MHz frequency bands. • In total 3 pair of radio transceivers are available – one pair per radio transceiver. • Two AT32UC3A3256 based USB host boards are included - Based on Atmel ® AVR ® UC3 core - 80 Dhrystone MIPS and Draws Only 40 mA at 66 MHz - Low, full and high speed USB compliant - Ideal for PC to RF gateways, packet sniffers and network commissioning tools • On board ID chip for easy IEEE MAC address • Stub antennas for all frequency bands 1 Introduction The RZ600 kit is an evaluation kit for the Atmel AT86RF family of radio frequency devices. The family contains the two 2.4 GHz device AT86RF230 and AT86RF231. These are highly acclaimed networking devices within low power personal area networks. In addition to this the world’s first IEEE 802.15.4 enabled sub gigahertz radio is provided – the AT86RF212. With the kit you also receive two AVR UC3 based host nodes that can be used to evaluate a point to point network connection. That being said; the RZ600 radio boards sport an Atmel standardized 10-pin connector that will enable the RF boards to be connected to any AVR microcontroller. A wide range of the standard Atmel AVR design tools have the host end of the standardized 10-pin connector – so as a customer you will be able to evaluate Atmel radio transceivers in virtually any application segment. The RZ600 kit enables RF4CE, IEEE 802.15.4, ZigBee ® and 6lowPAN network technologies to run on the full Atmel portfolio of low power AVR microcontrollers. Figure 1-1. RZ600 HW Overview Microcontrollers Application Note Rev. 8293-AVR-02/10 2 AVR600 8293-AVR-02/10 2 Related Items AVR32 Studio (Atmel’s free IDE) http://www.atmel.com/dyn/products/tools_card.asp?tool_id=4116 GNU Toolchain (Atmel’s free Compiler and Utilities) http://www.atmel.com/dyn/products/tools_card.asp?tool_id=4118 JTAGICE mkII (On-chip programming and debugging tool) http://www.atmel.com/dyn/products/tools_card.asp?tool_id=3353 AVR ONE! (On-chip programming and debugging tool) http://www.atmel.com/dyn/products/tools_card.asp?tool_id=4279 3 Overview This section gives an overview of the RZ600 kit from a system perspective as well as what the kit contains and its minimum requirements. A set of condensed instructions are then given on how to get the evaluation application for the kit up and running in the shortest time possible. Figure 3-1 shows how the two processor boards paired with the radio frequency boards also available in the kit can form a wireless peer to peer data connection over USB. The application that is pre programmed by Atmel on the AT32UC3A3256 is indeed such a USB to RF gateway. AVR600 3 8293-AVR-02/10 Figure 3-1 RZ600 used in conjuntion with PC RF Link RZ600 Processor Board RZ600 RF Board 3.1 Kit Contents The RZ600 kit contains the following pieces of hardware: • 2 pcs. AT86RF230 radio cards: miniature carrier board with the AT86RF230 radio transceiver mounted, SMA antenna connector, one wire ID chip and Atmel standard 10-pin connector. • 2 pcs. AT86RF231 radio cards: miniature carrier board with the AT86RF231 radio transceiver mounted, SMA antenna connector, one wire ID chip and Atmel standard 10-pin connector. • 2 pcs. AT86RF212 radio cards: miniature carrier board with the AT86RF212 radio transceiver mounted, SMA antenna connector, one wire ID chip and Atmel standard 10-pin connector. • 2 pcs. AVR UC3 based processor cards: usb dongle form factor board with AT32UC3A3256 processor mounted, LEDs, UART connection and host side Atmel standard 10-pin connector. • 2 pcs. 2.4GHz SMA stub antenna. These are shared between the AT86RF230 and AT86RF231 radio transceivers. 4 AVR600 8293-AVR-02/10 • 2 pcs. Sub gigahertz SMA stub antenna. Used with the AT86RF212 radio transceiver. • 2 pcs. Bag with wires and squid cable: The squid cable fits the radio frequency boards and will enable wiring to a hardware that does not contain the standard Atmel 10-pin accessory header. • 1 pcs. Technical Library CD 3.2 System Requirements Table 3-1 contains the minimum system requirements for the RZ600 kit when connected to a PC for application development on the AT32UC3A3256 microcontroller. Table 3-1. Minimum System Requirements Parameter Value Comment Hardware PC/CPU Intel ® Pentium III or better, 800 MHz PC/RAM 128 MBytes PC/Video 1024x768, SVGA PC/ Hard disk free space 200 Mbytes On-Chip Debugger and programmer AVR JTAGICE mkII or AVRONE! The AVR JTAGICE mkII or AVRONE! is needed if the user wishes to debug and do custom application development. Software Operating System Windows ® 2000/XP/Vista IDE AVR32 Studio or IAR Embedded Workbench AVR32 Studio with compiler utilities is required for reprogramming the processor board and for application development. 3.3 Quick Start Guide To following sequence is suggested when testing the evaluation application the RZ600 kit: 1. Unpack the kit and verify contents 2. Identify the processor boards and select two radio frequency boards with the same radio transceiver mounted. It is suggested to do this even though there are two different radio transceivers for the 2.4GHz band that are fully compatible with each other: AT86RF230 vs. AT86RF231. 3. Mount a radio frequency board to each of the processor boards 4. Insert the assembly into a free USB port on the computer. 5. Let the devices enumerate – they should become available as two CDC virtual COM ports. 6. Open two terminal windows and start typing. Verify that the text in the two terminals is the same. AVR600 5 8293-AVR-02/10 4 Hardware Description This chapter walks through the different pieces of hardware that you will find in the RZ600 kit in greater detail. 4.1 Radio Frequency Board A total of six radio frequency boards included in the kit, two boards per radio transceiver: • AT86RF230: First generation 2.4GHz ISM band radio transceiver from Atmel. • AT86RF231: Second generation 2.4GHz …

Text truncated - open the document above for the full version.

Atmel Norway AS Vestre Rosten 79, 7075 Tiller, Norway Tlf:+47 72 88 43 88 Fax +47 72 88 43 99 15 th April 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: FCC ID: VW4A090489 To Whom It May Concern: Atmel Norway AS, certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is valid until further written notice from Atmel Norway AS Sincerely, Saravanakumar Marudhachalam Atmel Norway AS Vestre Rosten 79 7075 Tiller Norway

www.tuv.com Appendix 5 Prüfbericht - Nr.: Test Report No. 02423081 001 Seite 1 von 1 Page 1 of 1 Product Block Diagram

Atmel Norway AS Vestre Rosten 79, 7075 Tiller, Norway Tlf:+47 72 88 43 88 Fax +47 72 88 43 99 15 th April 2011 Cover Letter ATAVRRZ600-230, VW4A090489 This evaluation board/kit is intended for use for FURTHER ENGINEERING, DEVELOPMENT, DEMONSTRATION, or EVALUATION PURPOSES ONLY by professional users and must not be incorporated into any other device or system. The device is not sold retail, to the general public. Standard antenna connectors are used. The equipment is sold with the antennas that have been tested in this filing. Antenna instructions are provided in the hardware manual. Atmel Norway AS ____________________________________ Saravanakumar Marudhachalam Staff Engineer

www.tuv.com Appendix 2 Prüfbericht - Nr.: Test Report No. 02423081 001 Seite 1 von 2 Page 1 of 2 EUT Top View EUT Bottom View www.tuv.com Appendix 2 Prüfbericht - Nr.: Test Report No. 02423081 001 Seite 2 von 2 Page 2 of 2 EUT Dimensional View RF Module

www.tuv.com Appendix 4 Prüfbericht - Nr.: Test Report No. 02423081 001 Seite 1 von 1 Page 1 of 1 Label Diagram Label Location Label Location

www.tuv.com Appendix 3 Prüfbericht - Nr.: Test Report No. 02423081 001 Seite 1 von 2 Page 1 of 2 Microcontroller Top View RF Section Top View www.tuv.com Appendix 3 Prüfbericht - Nr.: Test Report No. 02423081 001 Seite 2 von 2 Page 2 of 2 Microcontroller Bottom View RF Section Bottom View

Atmel Norway AS Vestre Rosten 79, 7075 Tiller, Norway Tlf:+47 72 88 43 88 Fax +47 72 88 43 99 5 th May 2011 Product operation - ATAVRRZ600-230, VW4A090489 The ATAVRRZ600-230 is a an evaluation board for AT86RF230 Radio transceiver IC, operating at 2.4 GHz. Band, designed in compliance with IEEE standard 802.15.4, ZigBee, 6LoWPAN applications. This hardware is designed as a reference for the end user to follow on his design and to develop software for the AT86RF230 transceiver. The design contains a serial interface to the host controller board through a 10-pin connector on one side to receive configuration and RF data from the microcontroller board. This design also has the RF circuit implemented in an optimum way to carry the differential RF signal from the transceiver IC to the single ended 50 Ohm Antenna connector. ____________________________________ Saravanakumar Marudhachalam Staff Engineer

Page 1 of 2 Private & Confidential Atmel, Norway Product Name: AVRRZ600-230, RZ600 RF230 Subkit Model: ATAVRRZ600-230 Atmel Part Number: A09-0489 FCC ID: VW4A09489 PCB Assembly BOM Qty Component Name Location Description Manufacturing Part Number Manufacturer 2 A01-0005 C116, C105 Ceramic capacitor, SMD 0402, NP0, 50V, +/-0.25pF, 1.5p 2 A01-0016 C103, C104 Ceramic capacitor, SMD 0402, NP0, 50V, +/-5%, 12p 1 A01-0050 C111 Ceramic capacitor, SMD 0402, X7R, 25V, +/-10%, 10n 2 A01-0246 C110, C115 Ceramic capacitor, SMD 0402, X7R, 16V, +/-10%, 100n C0402C104K4RACTU Kemet 9 A01-0286 C101, C102, C106, C107, C108, C109, C112, C113, C114 Ceramic capacitor, SMD 0402, X5R, 6.3V, +/-10%, 1u C0402C105K9PAC Kemet 1 A01-0328 C117 Multi Layer High Q Capacitor, SMD 0402, 50V, +/- 5%, 22pF 500R07S220JV4 Johanson Technology 7 A02-0163 R101, R102, R103, R105, R107, R109, R112 Thick film resistor, SMD 0402, 1/16W, 1%, 0R 1 A02-0204 R106 Thick film resistor, SMD 0402, 1/16W, 1%, 470R 1 A02-0220 R111 Thick film resistor, SMD 0402, 1/16W, 1%, 2.2k 2 A02-0236 R113, R104 Thick film resistor, SMD 0402, 1/16W, 1%, 10k 1 A03-0004 L101 SMD RF inductor 0805. Z=1000Ohm (@100MHz), Max R(dc)=0.45Ohm, Max current=200mA, BLM21AG102SN1D BLM21AG102SN1D Murata 1 A03-0050 L102 2,4 - 2,5GHZ FilterBalun, 2x1,25mm, 2,4GHz FilterBalun 2450FB15L0001E Johanson Technology 1 A06-0221 U101 2.4GHz ZigBee/802.15.4 transceiver, AT86RF230-ZU AT86RF230-ZU ATMEL 1 A06-0410 U102 LDO 3.3V 150mA SOT23-5, LP2985 3.3V LP2985AIM5-3.3 National Semiconductor 1 A06-0509 U103 ATtiny13A - 8 bit AVR Microcontroller with 1K Bytes ISP Flash, ATtiny13A-MMU ATtiny13A-MMU ATMEL Page 2 of 2 Private & Confidential Atmel, Norway Qty Component Name Location Description Manufacturing Part Number Manufacturer 1 A07-0040 XC101 SMT Crystal Resonator, 16.000 MHz,10 ppm,12 pF, 2520(Q) , 16MHz SCQ18D48- 16.000MHZ TR SUNTSU FREQUENCY CONTROL 1 A08-0463 J101 Samtec SMH 2x5 Pin Socket Right-angle 2,54mm Pitch (Mirrored footprint), SMH-105-02-T-D-TR SMH-105-02-T-D-TR SAMTEC 1 A08-0671 PCB101 RZ600 RF board PCB, RZ600 RF board PCB NCAB 1 A08-0673 J102 SMA PCB mounted connector, LTI-SASF56GT LTI-SASF56GT Lighthorse Technologies inc. 1 A09-0847 Z102 Label for use on wireless PCBA that needs 64 bit MAC and FCC ID , Label PCBA with MAC64 and FCC ID 505462 ACT Logimark AS

www.tuv.com Appendix 10 Prüfbericht - Nr.: Test Report No. 02423081 001 Seite 1 von 1 Page 1 of 1 Radio Frequency Human Exposure Evaluation: The highest RF output power of the EUT at 2405 MHz was measured 4.14 dBm which is less than 20mW. Since maximum peak output power of the transmitter is <60/f (GHz) mW, i.e. 2.59mW<24.94(=60/2405) mW, hence the EUT is excluded from SAR evaluation according to FCC KDB publication 447498 D01: Mobile Portable RF Exposure.

Tekfun Co., Ltd. ________________________________________________________________________________________________________________________________________________________________________________________________________________________________ ___ TEKFUN CO., Ltd. E-mail: [email protected] URL: www.tekfun.com.tw 4F., No.32, Kunming St., Jhongli City, Taoyuan Hsien 32089, Taiwan Tel : 886-3-4280826 Fax:886-3-4280010 SPECIFICATION FOR APPROVAL CUSTOMER DESCRIPTION 2.4GHz Rubber Stubby Antenna with SMA Male Straight PART NO. M01-SS2 DATE DESIGNER DIRECTOR Approved by Customer/date: Tekfun Co., Ltd. Page1 of 6 ________________________________________________________________________________________________________________________________________________________________________________________________________________________________ ___ TEKFUN CO., Ltd. E-mail: [email protected] URL: www.tekfun.com.tw 4F., No.32, Kunming St., Jhongli City, Taoyuan Hsien 32089, Taiwan Tel : 886-3-4280826 Fax:886-3-4280010 ANTENNA SPECIFICATIONS FOR APPROVAL 1. GENERAL DESCRIPION 1.1 Type No. : M01-SS2 1.2 Customer P/N : 2. DESCRIPTION & APPLICATION 2.4GHz Rubber Stubby Antenna with SMA Male Straight 3. ELECTRICAL CHARACTERISTICS 3.1 Frequency Range : 2.4GHz (2.4~2.5GHz) 3.2 Electric Wave : 1/4, Monopole Antenna 3.3 V.S.W.R : < 2 3.4 Impedance : 50 Ω, Nominal 3.5 Gain : < 0dBi 3.6 Connector : SMA Male Straight 4. PACKING STYLE Poly Bag Tekfun Co., Ltd. ________________________________________________________________________________________________________________________________________________________________________________________________________________________________ ___ TEKFUN CO., Ltd. E-mail: [email protected] URL: www.tekfun.com.tw 4F., No.32, Kunming St., Jhongli City, Taoyuan Hsien 32089, Taiwan Tel : 886-3-4280826 Fax:886-3-4280010 5. APPEARANCE DRAWING Tekfun Co., Ltd. ________________________________________________________________________________________________________________________________________________________________________________________________________________________________ ___ TEKFUN CO., Ltd. E-mail: [email protected] URL: www.tekfun.com.tw 4F., No.32, Kunming St., Jhongli City, Taoyuan Hsien 32089, Taiwan Tel : 886-3-4280826 Fax:886-3-4280010 6. Test Report VSWR Tekfun Co., Ltd. ________________________________________________________________________________________________________________________________________________________________________________________________________________________________ ___ TEKFUN CO., Ltd. E-mail: [email protected] URL: www.tekfun.com.tw 4F., No.32, Kunming St., Jhongli City, Taoyuan Hsien 32089, Taiwan Tel : 886-3-4280826 Fax:886-3-4280010 7. Test Report Return LOSS

1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 DD CC BB AA A12-0171 ATAVRRZ600-230.SchDoc 113/4/20112:00:42 PM Atmel RF Board ATMEL Norway Vestre Rosten 79 N-7075 TILLER NORWAY PAGE:of TITLE: Document number:Revision:4 Date: Francis Azli Pankaj 12 34 56 78 910 SMH-105-02-T-D-TR J101 AVSS 1 AVSS 2 AVSS 3 RFP 4 RFN 5 AVSS 6 TST 7 RST 8 DVSS 9 DVSS 10 SLP_TR 11 DVSS 12 DVDD 13 DVDD 14 DEVDD 15 DVSS 16 CLKM 17 DVSS 18 SCLK 19 MISO 20 DVSS 21 MOSI 22 SEL 23 IRQ 24 XTAL1 25 XTAL2 26 AVSS 27 EVDD 28 AVDD 29 AVSS 30 AVSS 31 AVSS 32 AVSS 33 U101 AT86RF230-ZU UnBal 1 GND 2 BAL1 3 BAL2 4 GND 5 GND/NC 6 L102 2450FB15L0001 10K R104 1 2 3 CD75014 1X3 J104 1 24 3 SCQ18D48-16.000MHz TR XC101 RF_VCC 12pF C104 12pF C103 1uF C101 1uF C102 1uF C112 1uF C113 RF_VCC VCC 1uF C114 VCC 2.2K R111 VCC IRQ SEL MOSI MISO SCLK CLKM 1uF C106 100nF C110 RSTRST SLP_TR RST IRQ SEL MISO SLP_TR MOSI SCLK 12 CD075014 1X2 J103 RF_VCC TST ID LTI-SASF56GT RF 1 GND 2 GND 3 J102 0R / NM R108 0R R109 0R / NM R110 MISC MISC Private & Confidential BLM21AG102SN1D L1010R R105 470R R106 0R / NM R107 0R / NM R103 0R / NM R101 1.5pF C105 1uF C107 1uF C108 1uF C109 0R R102 GND 2 GND 1 GND 3 GND 4 Z101 Z102 PCBA Label Place Label on the Bottom Side Place EMI Shield on Top Side IN 1 OUT 5 2 BYP 4 ON/OFF 3 GND LP2985AIM5-3.3/NOPB U102 10nF C111 TP112 TP104TP105 TP109 TP113 TP101 TP102 TP107TP111 TP108 TP106 RF_P RF_N A a TP114 MISC RST SLP_TR MISC CLKM TP115 0R / NM R112 TP116TP117TP118TP119TP120TP121TP122 SCLKMOSISLP _TR SEL MISOIRQ RST TP123 MISC Transciever Current Measurement: Mount J103 & Remove R105 22pF C117 TP124 TP125 100nF C115 (PCINT/RESET/ADC0/dW) PB5 1 (PCINT3/CLKI/ADC3) PB3 2 (PCINT4/ADC2) PB4 4 GND 5 (MOSI/AIN0/OC0A/PCINT0) PB0 6 (MISO/AIN1/OC0B/PCINT1) PB1 7 (SCK/ADC1/T0/PCINT2) PB2 9 VCC 10 DNC 3 DNC 8 U103 ATtiny13A-MMU TP126 TP127 ISP_MOSI ISP_MISO ISP_SCK ISP_RST ISP Test Points: Place close to AVR ATTiny13A to avoid long loops. PCB101 A08-0671 VCC 10K R113 1.5pF C116 Product Name: ATAVRRZ600-230, RZ600 RF230 Subkit Model: ATAVRRZ600-230 FCC Code: VW4A090489 PIC10101PIC10102 COC101 PIC10201PIC10202 COC102 PIC10301 PIC10302 COC103 PIC10401 PIC10402 COC104 PIC10501 PIC10502 COC105 PIC10601 PIC10602 COC106 PIC10701 PIC10702 COC107 PIC10801 PIC10802 COC108 PIC10901 PIC10902 COC109 PIC11001 PIC11002 COC110 PIC11101 PIC11102 COC111 PIC11201 PIC11202 COC112 PIC11301 PIC11302 COC113 PIC11401 PIC11402 COC114 PIC11501 PIC11502 COC115 PIC11601 PIC11602 COC116 PIC11701 PIC11702 COC117 PIJ10101PIJ10102 PIJ10103PIJ10104 PIJ10105PIJ10106 PIJ10107PIJ10108 PIJ10109PIJ101010 COJ101 PIJ10201 PIJ10202 PIJ10203 COJ102 PIJ10301PIJ10302 COJ103 PIJ10401 PIJ10402 PIJ10403 COJ104 PIL10101PIL10102 COL101 PIL10201 PIL10202 PIL10203 PIL10204 PIL10205PIL10206 COL102 COPCB101 PIR10101PIR10102 COR101 PIR10201PIR10202 COR102 PIR10301PIR10302 COR103 PIR10401 PIR10402 COR104 PIR10501PIR10502 COR105 PIR10601 PIR10602 COR106 PIR10701 PIR10702 COR107 PIR10801 PIR10802 COR108 PIR10901 PIR10902 COR109 PIR11001 PIR11002 COR110 PIR11101 PIR11102 COR111 PIR11201 PIR11202 COR112 PIR11301 PIR11302 COR113 PITP10101 COTP101 PITP10201 COTP102 PITP10401 COTP104 PITP10501 COTP105 PITP10601 COTP106 PITP10701 COTP107 PITP10801 COTP108 PITP10901 COTP109 PITP11101 COTP111 PITP11201 COTP112 PITP11301 COTP113 PITP11401 COTP114 PITP11501 COTP115 PITP11601 COTP116 PITP11701 COTP117 PITP11801 COTP118 PITP11901 COTP119 PITP12001 COTP120 PITP12101 COTP121 PITP12201 COTP122 PITP12301 COTP123 PITP12401 COTP124 PITP12501 COTP125 PITP12601 COTP126 PITP12701 COTP127 PIU10101 PIU10102 PIU10103 PIU10104 PIU10105 PIU10106 PIU10107 PIU10108 PIU10109PIU101010PIU101011PIU101012PIU101013PIU101014PIU101015PIU101016 PIU101017 PIU101018 PIU101019 PIU101020 PIU101021 PIU101022 PIU101023 PIU101024 PIU101025PIU101026PIU101027PIU101028PIU101029PIU101030PIU101031PIU101032PIU101033 COU101 PIU10201 PIU10202 PIU10203PIU10204 PIU10205 COU102 PIU10301 PIU10302 PIU10303 PIU10304 PIU10305PIU10306 PIU10307 PIU10308 PIU10309 PIU103010 COU103 PIXC10101 PIXC10102 PIXC10103 PIXC10104 COXC101 PIZ10101PIZ10102PIZ10103PIZ10104 COZ101 COZ102 PIC10501 PIJ10401 PIR10601 PIR11001 NLCLKM PIC10101 PIC10201 PIC10302PIC10402 PIC10502 PIC10602PIC10702PIC10802PIC10902PIC11002 PIC11102 PIC11201PIC11301 PIC11402PIC11502 PIC11602 PIC11702 PIJ10109 PIJ10202 PIJ10203 PIL10205PIL10206 PIR10102 PIR10302 PIR10401 PIR10701 PIR11201 PITP11201 PITP11401 PIU10103 PIU10106 PIU101012PIU101016 PIU101018 PIU101021 PIU101027PIU101030PIU101031PIU101032PIU101033 PIU10202 PIU10305 PIZ10101PIZ10102PIZ10103PIZ10104 PIJ10402 PIR10901 PIR11101 PIU10302 NLID PIJ10103 PITP11701 PIU101024 NLIRQ PITP12501PIU10307 NLISP0MISO PITP12401PIU10306 NLISP0MOSI PIR11301 PITP12701PIU10301 NLISP0RST PITP12601PIU10309 NLISP0SCK PIJ10102 PIR10802PIR10902PIR11002 PITP12301 NLMISC PIJ10107 PITP12101 PIU101020 NLMISO PIJ10106 PITP12001 PIU101022 NLMOSI PIC10202 PITP10201 PIU101029 PIC10301 PIU101025 PIXC10101 PIC10401 PIU101026 PIXC10103 PIC10601 PIJ101010 PITP10701 PIU10201 PIU10203 PIC11101 PITP11101 PIU10204 PIC11202 PITP11301 PIU101013PIU101014 PIC11601 PIJ10201PIR10202 PIC11701 PIL10202 PIJ10301 PIL10101 PIR10502 PITP10601 PIL10201PIR10201 PIR10101 PITP10401 PIU10101 PIR10301 PITP10501 PIU10102 PIR10602 PIU101017 PIR10702 PITP10901 PIU10109 PIR11202 PITP11501 PIU101010 PIU10303 PIU10304 PIU10308 PIXC10102PIXC10104 PIJ10101 PITP11601 PIU10108 NLR\S\T\ PIL10203 PIU10105 NLRF0N PIL10204 PIU10104 NLRF0P PIC10102 PIC11302 PIL10102 PITP10101 PIU101015 PIU101028 PIJ10105 PITP11901 PIU101023 NLS\E\L\ PIJ10108 PITP12201 PIU101019 NLSCLK PIJ10104 PITP11801 PIU101011 NLSLP0TR PIJ10403 PIR10402 PIR10801 PIU10107 NLTST PIC10701PIC10801PIC10901PIC11001 PIC11401PIC11501 PIJ10302 PIR10501 PIR11102 PIR11302 PITP10801 PIU10205 PIU103010

1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 DD CC BB AA A12-0172 A08-0672 Rev4.SchDoc 113/23/20109:54:39 AM USB Adaptor Embedded Wireless Labs Sdn Bhd 702, Uptown 2, SS21/37 Damansara Uptown, PJ, Sel, Malaysia PAGE:of TITLE: Document number:Revision:Rev 3 Date: Jeyaraman * * USB_P USB_N PA0 G11 PA1 G12 PA2 D8 PA3 G10 PA4 F9 PA5 F10 PA6 F8 PA7 E10 PA8 C11 PA9 B12 PA10 C12 PA11 D10 PA12 E12 PA13 F11 PA14 J6 PA15 J7 PA16 F12 PA17 H7 PA18 K8 PA19 J8 PA20 J9 PA21 H9 PA22 H10 PA23 G8 PA24 G9 PA25 E9 PA26 D9 PA27 A4 PA28 A3 PA29 A6 PA30 C7 PC0/XIN32 K5 PC1/XOUT32 H6 PC2/XIN0 A7 PC3/XOUT0 B7 PC4/XIN1 A8 PC5/XOUT1 A9 PA31 B3 FSDM B10 FSDP C9 HSDM A11 HSDP A10 VBUS A12 VBIAS B9 RESET_N J12 TCK K12 TDO J11 TDI L12 TMS J10 VDDCORE E11 ONREG L8 VDDIN E8 GNDCORE C10 GNDPLL B11 VDDANA H11 GNDANA L11 VDDIO E2 GNDIO C3 VDDIO H2 GNDIO L2 VDDIO B5 GNDIO K3 VDDIO E5 GNDIO F6 GNDIO G6 VDDIO H5 VDDIO/VBOOST H8 GNDIO F7 VDDIO L5 GNDIO G7 GNDIO K10 VDDIO B8 PX0 G1 PX1 H1 PX2 J2 PX3 K1 PX4 J1 PX5 G2 PX6 F3 PX7 F2 PX8 D1 PX9 C1 PX10 B1 PX11 L1 PX12 D6 PX13 C6 PX14 M4 PX15 E6 PX16 C5 PX17 K6 PX18 L6 PX19 D5 PX20 L4 PX21 M5 PX22 M1 PX23 M6 PX24 M7 PX25 M8 PX26 L9 PX27 K9 PX28 L10 PX29 K11 PX30 M11 PX31 M10 PX32 M9 PX33 M12 PX34 J3 PX35 C2 PX36 D3 PX37 D2 PX38 E1 PX39 F1 PX40 A1 PX41 M2 PX42 M3 PX43 L7 PX44 K2 PX45 L3 PX46 K4 PX47 D4 PX48 F5 PX49 F4 PX50 G4 PX51 G5 PX52 K7 PX53 E4 PX54 E3 PX55 J5 PX56 J4 PX57 H4 PX58 H3 PX59 G3 PB0 A2 PB1 C4 PB2 B4 PB3 A5 PB4 B6 PB5 H12 PB6 D12 PB7 D11 PB8 C8 PB9 E7 PB10 D7 PB11 B2 U101 AT32UC3A3256S 10K R101 1uF C105 VCC RESET_N USB_P USB_N 6810R R102 VUSB VUSB 12 34 56 78 910 STL21-0730 G TT-10U J103 TCK TDO TMS TDI 1uF C111 VCC 12pF C104 12pF C103 22pF C102 22pF C101 1 2 SCP8-32.768KHz TR XC101 10R R103 12 34 56 78 910 TSM-105-01-L-DH-K-TR J101 RF_RST RF_IRQ RF_SEL RF_MISORF_SCLK RF_MOSI RF_SLP_TR RF_MISC 100nF C107 100nF C108 100nF C109 100nF C110 100nF C115 100nF C117 100nF C119 100nF C106 3.3uF C114 3.3uF C116 3.3uF C118 VCCVCCVCC VCCVCC VCC VCC 1 2 3 CD075014 1X3 J102 RF_ID RF_TST RF_CLKM 0R R105 0R R107 0R R106 0R R104 1nF C113 2.2uF C112 100nF C121 VCC 100nF C122 VCC VDDCORE VDDANA RF_IRQ RF_MOSI RF_MISO RF_SEL RF_SCLK RF_CLKM RF_ID RF_TST RF_RST RF_MISC RF_SLP_TR VBUS 1 DN 2 DP 3 GND 4 SHEILD 5 SHEILD 6 J104 USB-A Male USB_N VCC 1uF C123 100nF C127 USB_N USB_P USB_P VUSB VUSB Private & Confidential VCC PCB101 A08-0671 Z101 PCBA Label Place Label on the Bottom Side 1uF C126 1uF C125 1uF C124 3.3uF C120 IN 1 OUT 5 2 BYP 4 ON/OFF 3 GND LP2985AIM5-3.3/NOPB U102 10nF C128 VCC TP111 TP115TP114 TP110 TP109 TP108TP107 TP106 TP105 TP116 A a 1 2 3 CD075014 1X3 J105 UART_RX0 UART_TX0 470R R108 EL17-21USRC LD101 470R R109 EL17-21SYGC LD102 PGB1010603 D103 PGB1010603 D102 39R R110 39R R111 TP101TP102 TP104TP118 TP117 i PCB Rule i PCB Rule 10pF C129 TP120TP121 VUSB TCK TDO TMS TDI JTAG_RST JTAG_RST Place Close To Pin VCC VCC 12 43 FQ5032B-12-C-C-C-200-1 XC102 GSOT05-GS08 D101 TP122TP123TP124TP125TP126TP127TP128 RF_IRQRF_MISORF_MOSIRF_RSTRF_SELRF_SCLKRF_SLP_TR RF_MISC TP129 Place Close to Pins of U101 Place Least Value closer to Pin Place 3.3uF around U101 Place Close to Pins of U101 Place Close to Pins of U101 Place Close to Pins of U101 PIC10101PIC10102 COC101 PIC10201PIC10202 COC102 PIC10301PIC10302 COC103 PIC10401PIC10402 COC104 PIC10501 PIC10502 COC105 PIC10601 PIC10602 COC106 PIC10701 PIC10702 COC107 PIC10801 PIC10802 COC108 PIC10901 PIC10902 COC109 PIC11001 PIC11002 COC110 PIC11101 PIC11102 COC111 PIC11201 PIC11202 COC112 PIC11301 PIC11302 COC113 PIC11401 PIC11402 COC114 PIC11501PIC11502 COC115 PIC11601 PIC11602 COC116 PIC11701 PIC11702 COC117 PIC11801 PIC11802 COC118 PIC11901 PIC11902 COC119 PIC12001 PIC12002 COC120 PIC12101 PIC12102 COC121 PIC12201 PIC12202 COC122 PIC12301 PIC12302 COC123 PIC12401 PIC12402 COC124 PIC12501 PIC12502 COC125 PIC12601 PIC12602 COC126 PIC12701 PIC12702 COC127 PIC12801 PIC12802 COC128 PIC12901PIC12902 COC129 PID10101PID10102 PID10103 COD101 PID10201 PID10202 COD102 PID10301 PID10302 COD103 PIJ10101PIJ10102 PIJ10103PIJ10104 PIJ10105PIJ10106 PIJ10107PIJ10108 PIJ10109PIJ101010 COJ101 PIJ10201 PIJ10202 PIJ10203 COJ102 PIJ10301PIJ10302 PIJ10303PIJ10304 PIJ10305PIJ10306 PIJ10307PIJ10308 PIJ10309PIJ103010 COJ103 PIJ10401 PIJ10402 PIJ10403 PIJ10404 PIJ10405 PIJ10406 COJ104 PIJ10501 PIJ10502 PIJ10503 COJ105 PILD10101 PILD10102 COLD101 PILD10201 PILD10202 COLD102 COPCB101 PIR10101 PIR10102 COR101 PIR10201PIR10202 COR102 PIR10301 PIR10302 COR103 PIR10401PIR10402 COR104 PIR10501PIR10502 COR105 PIR10601PIR10602 COR106 PIR10701PIR10702 COR107 PIR10801PIR10802 COR108 PIR10901PIR10902 COR109 PIR11001PIR11002 COR110 PIR11101PIR11102 COR111 PITP10101 COTP101 PITP10201 COTP102 PITP10401 COTP104 PITP10501 COTP105 PITP10601 COTP106 PITP10701 COTP107 PITP10801 COTP108 PITP10901 COTP109 PITP11001 COTP110 PITP11101 COTP111 PITP11401 COTP114 PITP11501 COTP115 PITP11601 COTP116 PITP11701 COTP117 PITP11801 COTP118 PITP12001 COTP120 PITP12101 COTP121 PITP12201 COTP122 PITP12301 COTP123 PITP12401 COTP124 PITP12501 COTP125 PITP12601 COTP126 PITP12701 COTP127 PITP12801 COTP128 PITP12901 COTP129 PIU1010A1 PIU1010A2 PIU1010A3 PIU1010A4 PIU1010A5 PIU1010A6 PIU1010A7 PIU1010A8 PIU1010A9 PIU1010A10 PIU1010A11 PIU1010A12 PIU1010B1 PIU1010B2 PIU1010B3 PIU1010B4 PIU1010B5 PIU1010B6 PIU1010B7 PIU1010B8 PIU1010B9 PIU1010B10 PIU1010B11 PIU1010B12PIU1010C1 PIU1010C2 PIU1010C3 PIU1010C4 PIU1010C5 PIU1010C6 PIU1010C7 PIU1010C8 PIU1010C9 PIU1010C10 PIU1010C11 PIU1010C12 PIU1010D1 PIU1010D2 PIU1010D3 PIU1010D4 PIU1010D5 PIU1010D6 PIU1010D7 PIU1010D8 PIU1010D9 PIU1010D10 PIU1010D11PIU1010D12 PIU1010E1 PIU1010E2 PIU1010E3 PIU1010E4 PIU1010E5 PIU1010E6 PIU1010E7 PIU1010E8 PIU1010E9 PIU1010E10 PIU1010E11 PIU1010E12 PIU1010F1 PIU1010F2 PIU1010F3 PIU1010F4 PIU1010F5 PIU1010F6PIU1010F7 PIU1010F8 PIU1010F9 PIU1010F10 PIU1010F11 PIU1010F12 PIU1010G1 PIU1010G2 PIU1010G3 PIU1010G4 PIU1010G5 PIU1010G6PIU1010G7 PIU1010G8 PIU1010G9 PIU1010G10 PIU1010G11 PIU1010G12PIU1010H1 PIU1010H2 PIU1010H3 PIU1010H4 PIU1010H5 PIU1010H6 P…

Text truncated - open the document above for the full version.

Produkte Products TÜV Rheinland LGA Products GmbH  Tillystraße 2  D - 90431 Nürnberg  Tel.: +49 911 655 5225  Fax: +49 911 655 5226 Mail: [email protected]  Web: www.tuv.com Rev.:1.2 2009-12-29 / approved: M.Jungnitsch Prüfbericht - Nr.: 02423081 001 Seite 1 von 24 Test Report No.: Page 1 of 24 Auftraggeber: Client: Atmel Norway AS Vestre Rosten 79 7075 Tiller Norway Gegenstand der Prüfung: Test item: ATAVRRZ600-230 Bezeichnung: Identification: ATAVRRZ600-230 Serien-Nr.: Serial No. Engineering Sample Wareneingangs-Nr.: Receipt No.: 1403013231 Eingangsdatum: Date of receipt: 20-01-2011 Prüfort: Testing location: Refer Page 4 of 24 for test facilities Prüfgrundlage: Test specification: FCC 15, Subpart C Prüfergebnis: Test Result: Der Prüfgegenstand entspricht oben genannter Prüfgrundlage(n). The tests item passed the test specification(s). Prüflaboratorium: Testing Laboratory: TÜV Rheinland (India) Pvt. Ltd. Alpha Tower, Sigma Soft Tech Park, # 7, Whitefield Main Road, Varthur Kodi, Bangalore – 560066, India geprüft / tested by: kontrolliert / reviewed by: 02-02-2011 Vinay.N Test Engineer 03-02-2011 Varma Kalyan Manager Datum Date Name/Stellung Name/Position Unterschrift Signature Datum Date Name/Stellung Name/Position Unterschrift Signature Sonstiges /Other Aspects: FCC ID : VW4A090489 Abkürzungen: P(ass) = entspricht Prüfgrundlage F(ail) = entspricht nicht Prüfgrundlage N/A = nicht anwendbar N/T = nicht getestet Abbreviations: P(ass) = passed F(ail) = failed N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any safety mark on this or similar products. www.tuv.com Test Report No.:02423081 001 Date: 05-02-2011 Page 2 of 24 Test Result Summary Clause Test Item Result 15.247(b)(3) Conducted Peak RF Output Power Test Pass 15.247(a)(2) 6dB Bandwidth Pass 15.247(e) Power Spectral Density Pass 15.247(d) Band-edge Compliance Pass 15.209 Spurious Radiated Emissions Pass www.tuv.com Test Report No.:02423081 001 Date: 05-02-2011 Page 3 of 24 Content List of Test and Measurement Instruments .............................................................. 4 General Product Information ..................................................................................... 5 Product Function and Intended Use ............................................................................................. 5 Ratings and System Details ........................................................................................................... 5 Operation Descriptions .............................................................................................. 6 Test Set-up and Operation Mode ............................................................................... 7 Principle of Configuration Selection ............................................................................................ 7 Test Operation and Test Software ................................................................................................ 7 Special Accessories and Auxiliary Equipment ............................................................................ 7 Countermeasures to achieve EMC Compliance .......................................................................... 7 Test Methodology .....................................…
