RF Exposures Evaluation For Maximum Permissible Exposure (MPE) evaluation of the product, the maximum power density at 20 cm from this transmitter shall be less than the General Population / Uncontrolled MPE limit in OET Bulletin 65. For the product of tested model of SBW100, the measured maximum field strength measured (FS) was 108.1 dBμV/m (RBW=10 MHz, radiated measurement). The distance (D) between the antenna and the equipment under test (EUT) was 3 meters. And the maximum source-based time-averaging duty factor is 12.698 %. From these data, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated according to OET Bulletin 65 as follow: The radiated power = (FS*D) ^2 / 30 =19.4 mW The radiated (EIRP) source-based time-averaging output power = (19.4* 0.12698)mW = 2.46341mW The power density at 20 cm from the antenna = EIRP / 4πR^2 = 0.0005 mW/cm^2 In the frequency range of 1,500 - 100,000MHz, the MPE limit is 1.0 mWcm-2 for general population and uncontrolled exposure. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structures and body of the user or nearby persons. The following RF exposure statement is proposed to be included in the user manual: “FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the product at least 20cm from nearby persons.”

A Ref 10 dBmAtt 20 dB * 1 PK MAXH 2.5 MHz/Center 2.412 GHzSpan 25 MHz * * 3DB RBW 100 kHz VBW 300 kHz SWT 10 ms -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -3.77 dBm 2.412725000 GHz 2 Delta 2 [T1 ] -6.00 dB -5.462500000 MHz 3 Delta 3 [T1 ] -6.05 dB 4.137500000 MHz D1 -9.77 dBm Plot: B2A1 A Ref 10 dBmAtt 20 dB * 2.5 MHz/Center 2.438 GHzSpan 25 MHz * * 3DB RBW 100 kHz VBW 300 kHz SWT 10 ms 1 PK MAXH -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -4.64 dBm 2.438725000 GHz 2 Delta 2 [T1 ] -6.07 dB -5.537500000 MHz 3 Delta 3 [T1 ] -6.10 dB 4.162500000 MHz D1 -10.64 dBm Plot: B2B1 A Att 20 dB * Ref 10 dBm 2.5 MHz/Center 2.464 GHzSpan 25 MHz * * 3DB RBW 100 kHz VBW 300 kHz SWT 10 ms 1 PK MAXH -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -5.40 dBm 2.464750000 GHz 2 Delta 2 [T1 ] -6.50 dB -5.606500000 MHz 3 Delta 3 [T1 ] -6.00 dB 4.155000000 MHz D1 -11.4 dBm Plot: B2C1

Average Factor Calculation: Ref 20 dBmAtt 30 dB * A MAXH SGL * 3DB RBW 3 MHz VBW 3 MHz Center 2.464 GHz10 ms/ SWT 100 ms 1 PK -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] 5.01 dBm 24.800000 ms 1 Delta 1 [T1 ] 0.02 dB 2.600000 ms Ref 20 dBmAtt 30 dB * A MAXH SGL * 3DB RBW 3 MHz VBW 3 MHz Center 2.464 GHz1 ms/ SWT 10 ms 1 PK -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] 0.86 dBm 3.620000 ms 1 Delta 1 [T1 ] 0.01 dB 2.520000 ms Ref 20 dBmAtt 30 dB * A MAXH SGL * 3DB RBW 3 MHz VBW 3 MHz Center 2.464 GHz1 ms/ SWT 10 ms 1 PK -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] 0.86 dBm 3.620000 ms 1 Delta 1 [T1 ] 1.43 dB 320.000000 μs The duration of one cycle = 2.52 ms Effective period of the cycle = 320us Duty Cycle = 320us / 2.52 ms = 0.12698 or 12.698% Therefore, the averaging factor is found by 20 log 10 0.12698 = -17.9 dB

A Att 30 dB * Ref 20 dBm 5 MHz/Center 2.412 GHzSpan 50 MHz * * 3DB RBW 10 MHz VBW 10 MHz SWT 10 ms 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] 12.92 dBm 2.412400000 GHz Plot: B1A1 A Att 30 dB * Ref 20 dBm 5 MHz/Center 2.438 GHzSpan 50 MHz * * 3DB RBW 10 MHz VBW 10 MHz SWT 10 ms 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] 12.58 dBm 2.438550000 GHz Plot: B1B1 A Att 30 dB * Ref 20 dBm 5 MHz/Center 2.464 GHzSpan 50 MHz * * 3DB RBW 10 MHz VBW 10 MHz SWT 10 ms 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] 11.55 dBm 2.464100000 GHz Plot: B1C1

Ref 10 dBmAtt 20 dB ** A 1 PK MAXH Center 2.411303138 GHzSpan 15 kHz1.5 kHz/ * * 3DB RBW 3 kHz VBW 10 kHz SWT 5 s * -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -4.98 dBm 2.411303138 GHz Plot: B3A1 Ref 10 dBmAtt 20 dB ** A 1 PK MAXH Center 2.437303613 GHzSpan 15 kHz1.5 kHz/ * * 3DB RBW 3 kHz VBW 10 kHz SWT 5 s * -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -5.50 dBm 2.437303613 GHz Plot: B3B1 Ref 10 dBmAtt 20 dB ** A Center 2.463305 GHzSpan 15 kHz1.5 kHz/ * * 3DB RBW 3 kHz VBW 10 kHz SWT 5 s * 1 PK MAXH -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -6.04 dBm 2.463304588 GHz Plot: B3C1

Ref 10 dBmAtt 20 dB * A 1 PK MAXH 249.9 MHz/Start 1 MHzStop 2.5 GHz * * 3DB RBW 100 kHz VBW 300 kHz SWT 250 ms -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -3.97 dBm 2.412535000 GHz 1 Delta 1 [T1 ] -41.92 dB -1.739304000 GHz Plot: B4A1 Ref 10 dBmAtt 20 dB * A 1 PK MAXH 2.3 GHz/Start 2 GHzStop 25 GHz * * 3DB RBW 100 kHz VBW 300 kHz SWT 2.3 s -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -4.08 dBm 2.402500000 GHz 1 Delta 1 [T1 ] -38.73 dB 2.415000000 GHz Plot: B4A2 Ref 10 dBmAtt 20 dB * A 249.9 MHz/Start 1 MHzStop 2.5 GHz * * 3DB RBW 100 kHz VBW 300 kHz SWT 250 ms 1 PK MAXH -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -4.69 dBm 2.437525000 GHz 1 Delta 1 [T1 ] -41.51 dB -1.738054500 GHz Plot: B4B1 Ref 10 dBmAtt 20 dB * A 2.3 GHz/Start 2 GHzStop 25 GHz * * 3DB RBW 100 kHz VBW 300 kHz SWT 2.3 s 1 PK MAXH -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -4.77 dBm 2.437000000 GHz 1 Delta 1 [T1 ] -42.43 dB 2.438000000 GHz Plot: B4B2 Ref 10 dBmAtt 20 dB * A 249.9 MHz/Start 1 MHzStop 2.5 GHz * * 3DB RBW 100 kHz VBW 300 kHz SWT 250 ms 1 PK MAXH -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -5.21 dBm 2.463764500 GHz 1 Delta 1 [T1 ] -41.41 dB -1.738054500 GHz Plot: B4C1 Ref 10 dBmAtt 20 dB * A 1 PK MAXH 2.3 GHz/Start 2 GHzStop 25 GHz * * 3DB RBW 100 kHz VBW 300 kHz SWT 2.3 s -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] -5.61 dBm 2.460000000 GHz 1 Delta 1 [T1 ] -39.11 dB 816.500000000 MHz Plot: B4C2 A Ref 10 dBmAtt 20 dB * 3 MHz/Center 2.4 GHzSpan 30 MHz 1 PK MAXH * * 3DB RBW 300 kHz VBW 1 MHz SWT 10 ms -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] 1.73 dB m 2.411535000 GHz 1 Delta 1 [T1 ] -35.73 dB -12.105000000 MHz Plot: B4D1 A 1 PK MAXH Ref 10 dBmAtt 20 dB * 10 MHz/Center 2.4835 GHzSpan 100 MHz * * 3DB RBW 1 MHz VBW 3 MHz SWT 10 ms -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 1 Marker 1 [T1 ] 4.20 dB m 2.463050000 GHz 1 Delta 1 [T1 ] -48.87 dB 20.550000000 MHz Plot: B4D2
