VX5-375RXJUMBO SCREEN WEATHER STATION

1 atmosphere Jumbo Weather Monitor Moniteur Météorologique Géant Instruction Manual / Mode d’emploi 2 B. A. O. C.F. D.E. G. H. I. J. K L.M.N. 1. 2. 3. 6. 8. 5. 7. 4. Front View: Back View: Thank you for purchasing the BIOS Atmosphere 2.0 Jumbo Weather Monitor 3 Jumbo Weather Monitor Instruction Manual Monitor Front A. Wind Speed B. Time and Date C. Alarm D. Radio Controlled clock with auto DST E. Tide Indicator F. Sunrise and Sunset G. Heat Index / Wind chill H. Wind Direction I. Wind Gust J. 24 Hour Maximum Outdoor Temperature K. Outdoor Temperature and Humidity L. Indoor Temperature and Humidity M. Weather Forecast Icon N. Barometric Pressure O. Beaufort Wind Scale Monitor Back 1. Clock Button 2. C/F Button 3. Mode/Set Button 4. Alarm/Weather Set Button 5. Gust/Wind Max Button 6. Snooze Button 7. Temperature/Max/Min Button 8. DST On/Off/ RF Search Button 1.1 Radio Control Clock (RCC) RCC has the most accurate time within the continent. This unit receives the time signal transmitted by the National Institute of Standards and Technology (NIST) which is regulated by 3 atomic clocks and in average deviates less than 1 second in 3000 years. NIST transmits the time signal (WWVB, 60kHz) continuously from Fort Collins, Colorado. This signal can be received in the USA and parts of Canada, however some environmental effects may affect the transmitting distance. For more information please see www.boulder.nist.gov/timefreq/ 1: Wall Mount Hole 2: Transmission Indication LED 3: Temperature 4: Humidity 5:"C/F" button 6:"RESET" button 7: Wind Sensor Plug 8: Battery Compartment Included: 1 - Jumbo Weather Monitor 2 - Remote Sensor 3 - Wind Sensor with Cable 4 - Wind Sensor accesories 4 2.0 Getting Started: 2.1 BIOS Atmosphere 2.0:

        + – !
 #
 $  RESET button located at the rear of the main unit, the main unit is now ready for use 2.2 Outdoor Remote Sensor
 %     &'*+  9
 ;<<      + – !
 = > %  &?* 3.0 Installation 3.1 BIOS Atmosphere 2.0 @       Q  + XY        the back of the unit. 3.2 BIOS Atmosphere 2.0 sensor The remote sensor should be securely mounted onto a horizontal surface. NOTE: Transmission between the receiver and transmitter can reach up to 80m in an open area without any interfering obstacles such as buildings, trees, vehicles, high voltage lines, etc. 3.3 Wind Sensor Accessories Plastic BaseScrews and WashesPoleWashes & Screws, X2 Round U-shape bolts NOTE: The remote sensor should be placed in a shaded area for accurate readings. 3.4 Mounting and Setup for the Wind Sensor First, choose whether the wind sensor will be mounted vertically or horizontally (on a mast). Make sure that you position the wind sensor in a free, open area that is not protected by objects, which may distort or interfere with the wind (e.g. large buildings, trees, chimney, etc.). NOTE: The following contents have been included with your BIOS Atmosphere 2.0 for mounting the wind sensor:
;$\
'Y
]
'^9;_Y&`        *
];9?_Y&`    Q  + * 5 Cable Preparation for Vertical Mounting 1. Run the cable that is already fastened to the wind sensor through the vertical joining section (see right). 2. Run the cable through the extension pole but do not secure the pole to any sections yet. 3. Now run the cable through the top of the base- bracket and then through the small rectangular section found on one side of the base-bracket. NOTE: Make sure that you completely pull the cable through the wind sensors extension pole and base- bracket to reduce the amount of slack on the cord. Vertical Mount 1. Make sure that the wind vane can rotate freely before fastening the unit permanently into position. 2. Insert one end of the extension pole provided into the base-bracket. 3. Secure the connection point of the extension pole and base-bracket using the 0.25” metal screws provided to prevent rotation at the joining point. (Use 4 x 0.25” screws to ensure stability). 4. Insert the vertical joining section on the bottom of the wind sensor into the top of the extension pole. (Ensure that you pull all cable slack through the side of the base-bracket to prevent creasing or cutting the cable). 5. Secure the wind sensor to the extension pole using the 0.25” screws provided to make sure that the pole connection does not rotate. (Use 4 x 2.75” screws to ensure stability). IMPORTANT: For accurate readings, it is important to mount the wind sensor so that the q&*   +    &*9+ X     compass to determine north. {9$ ];9?_Y X Y  \   Q  + 9 NOTE: Make sure that when you are securing the base bracket with the 2.75” screws, you are aware of the cable. Prevent driving a screw through the cable! NOTE: For proper wind speed measurement ensure the vertical joining section is at 90º the horizon (Fig.A). Horizontal Mounting Cable Preparation for Horizontal Mounting 1. Run the cable that is already fastened to the wind sensor through the horizontal joining section (see below). 2. Run the cable through the extension pole but do not secure the pole to any sections yet. 3. Now run the cable through the top of the base-bracket and then through the small rectangular section found on one side of the base-bracket. NOTE: Make sure that you completely pull the cable through the wind sensor’s extension pole and base-bracket to reduce the amount of slack on the cord. Horizontal mount - using a mast/antenna/pole NOTE: It is…

Text truncated - open the document above for the full version.

12 B. A. O. C.F. D.E. G. H. I. J. K L.M.N. 1. 2. 3. 6. 8. 5. 7. 4. Vue de face : Vue arrière :             !  Atmosphere 2.0. 13 "     "   Capteur à distance 1 : Trou pour montage mural 2 : Voyant DEL de transmission 3 : Température 4 : Humidité 5 : Bouton "C/F" 6 : Bouton "RESET" (RÉINITIALISATION) ?†=     ”  ” Œ  8 : Compartiment des piles Inclus : ‡\ƒ   ”” Œ ”  2 - Capteur à distance \   ”  ” Œ  •  4 - Accessoires du capteur  ”  ” Œ  14 15 Section jonction verticale Câble Tige rallonge Câble Support de base Câble 16 Câble Câble Câble Tige rallonge Support de base Horizontalement

17 ENSOLEILLÉPARTIELLEMENT NUAGEUX NUAGEUXPLUVIEUXORAGEUX 18 VENT 19 A: Nouvelle lune D: Lune gibbeuse croissante –† Œ   B: Premier croissant E: Pleine lune H: Dernier croissant †= Œ   F: Lune gibbeuse décroissante 20 21
