VYTLP-761511n PCI Adaptor

Loopcomm Technology,.Inc.
11n PCI Adaptor - FCC ID VYTLP-7615 - Loopcomm Technology,.Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
May 03, 2010
Application Purpose
Original Equipment
Date of Application
May 03, 2010
Equipment Note
11n PCI Adaptor
Frequency Range
2422.00000000 - 2452.00000000
Company
Loopcomm Technology,.Inc.
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

β†—

Attestation Statements

β†—

Cover Letter(s)

β†—
β†—

External Photos

β†—

ID Label/Location Info

β†—

Internal Photos

β†—

Parts List/Tune Up Info

β†—

RF Exposure Info

β†—

Test Report

β†—

Test Setup Photos

β†—

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Β© 2010 802.11n Wireless PCI Adapter USER MANUAL 1.0.0 -2- Table of Contents Chapter I Introduction 4 ................................................................................................................................... 41. Welcome ................................................................................................................................... 4 2. Product Feature ................................................................................................................................... 4 3. Contents of Package ................................................................................................................................... 4 4. Before you begin Chapter II Designing Your PCI Adapter 5 Chapter III Installation 5 ................................................................................................................................... 51. Install Your PCI Adapter ................................................................................................................................... 6 2. Install Driver and Utility Chapter IV Utility Config 11 ................................................................................................................................... 111. WZC ......................................................................................................................................................... 111.1 Ralink Wireless Utility (RaUI) or Windows Zero Configuration (WZC) ......................................................................................................................................................... 12 1.2 Use WZC to configure wireless NIC ................................................................................................................................... 182. RaUI ......................................................................................................................................................... 182.1 Start .................................................................................................................................................. 18 2.1. Start RaUI ......................................................................................................................................................... 24 2.2 Profile .................................................................................................................................................. 24 2.2. Profile .................................................................................................................................................. 26 2.2. Add/Edit Profile .................................................................................................................................................. 27 2.2. Example to Add Profile in Profile ......................................................................................................................................................... 31 2.3 Network .................................................................................................................................................. 31 2.3. Network .................................................................................................................................................. 38 2.3. Example on Adding Profile in Network ......................................................................................................................................................... 42 2.4 Advanced .................................................................................................................................................. 42 2.4. Advanced ......................................................................................................................................................... 43 2.5 Statistics .................................................................................................................................................. 43 2.5. Statistics ......................................................................................................................................................... 45 2.6 WMM .................................................................................................................................................. 45 2.6. WMM .................................................................................................................................................. 46 2.6. Example to Configure to Enable DLS (Direct Link Setup) .................................................................................................................................................. 51 2.6. Example to Configure to Enable Wi-Fi Multi-Media .................................................................................................................................................. 52 2.6. Example to Configure to Enable WMM - Power Save ......................................................................................................................................................... 53 2.7 WPS .................................................................................................................................................. 53 2.7. WPS .................................................................................................................................................. 56 2.7. WPS Information on AP .................................................................................................................................................. 57 2.7. Example to Add to Registrar Using PIN Method .................................................................................................................................................. 63 2.7. Example to Add to Registrar Using PBC Method ......................................................................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

910805 2 Loopcomm Technology,Ltd 1F,No.114,Lian Chen Rd.,Chung-Ho City,Taipei Hsian,235,Taiwan Date: Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: We, the undersigned, hereby authorize ELECTRONICS TESTING CENTER, TAIWAN, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by ELECTRONICS TESTING CENTER, TAIWAN on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing ELECTRONICS TESTING CENTER, TAIWAN as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; f) use certification only to indicate the products are certified as being in conformity with specified standards;

External Photos

ETC Report No. : 10-03-RBF-041 FCC ID.: VYTLP-7615 Sheet 1 of 3Sheets Rev. No 1.0 CONSTRUCTION PHOTOS OF EUT 1. Top View of EUT 2. Bottom View of EUT ETC Report No. : 10-03-RBF-041 FCC ID.: VYTLP-7615 Sheet 2 of 3Sheets Rev. No 1.0 CONSTRUCTION PHOTOS OF EUT 3. Rear View of EUT

ID Label/Location Info

910805 1 LABEL

Internal Photos

ETC Report No. : 10-03-RBF-041 FCC ID.: VYTLP-7615 Sheet 3 of 3Sheets Rev. No 1.0 CONSTRUCTION PHOTOS OF EUT 4. Component View of PCB 5. Solder View of PCB

RF Exposure Info

FCC ID: VYTLP-7615 RF Exposure Evaluation of E.U.T. : 11n PCI Adapter FCC ID. : VYTLP-7615 MODEL : LP-7615 for APPLICANT : Loopcomm Technology, Ltd. ADDRESS : 1F, No. 114, Lian Chen Rd., Chung Ho City, Taipei Hsien, 235, Taiwan Prepared by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5. DINGFU TSUEN, LINKOU SHIANG TAIPEI COUNTY, TAIWAN, 24442, R.O.C. Tel:(02)26023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : 10-03-RBF-041-MPE FCC ID: VYTLP-7615 Product Information: Type of EUT: 11n PCI Adapter FCC ID: VYTLP-7615 Manufacturer: Loopcomm Technology, Ltd. Model: LP-7615 Description: Frequency Range: 2.400GHz-2.4835GHz Modulation Technique: Orthogonal frequency division multiplexing (OFDM) Direct Seqiemce Spread Spectrum (CCK, DQPSK, DBPSK) Maximum conducted output power (measured): 18.4 dBm or 69.183mW The following table lists the provided authorized antennas: Antenna Gain Model Antenna Type (dBi) Numeric WF2400-10901B Dipole-type Antenna 2 1.58 Below is an example of the RF Exposure Statement: IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. No change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. FCC ID: VYTLP-7615 Relative Requirement for Compliance According to section 1.1310 of FCC 47 CFR Part 1, limits for maximum permissible exposure (MPE) are as following: TABLE 1 – LIMITS FOR MAXIMUN PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.0 .................. 614 1.63 *(100) 6 3-30 ..................... 1842/f 4.89/f *(900/f 2 ) 6 30-300 .................. 61.4 0.163 1.0 6 300-1500 ............... ...................... ...................... f/300 6 1500-100,000 ......... ...................... ...................... 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 ............... 614 1.63 *(100) 30 1.34-30 ............... 824/f 2.19/f *(180/f2) 30 30-300 .................. 27.5 0.073 0.2 30 300-1500 ............... ...................... ...................... f/1500 30 1500-100,000 ......... ...................... ...................... 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density NOTE 1 TO TABLE 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational / controlled limits apply provided he or she is made aware of the potential for exposure. NOTE 2 TO TABLE 1: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. FCC ID: VYTLP-7615 RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0 mW/cm 2 uncontrolled exposure limit. The formula shown in OET Bulletin 65 is used in the calculation. Equation from page 19 of OET Bulletin 65, Edition 97-01 is: S= PG / 4R 2 where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) hence R= PG / 4S) 1/2 For our device P = 69.183mW G = 1.58 R = 20 cm S = (69.183 * 1.58) / (4**20 2 ) = 0.022 mW/cm 2 < 1.0 mW/cm 2 For complying the FCC limits for general population/uncontrolled exposure, the power density limit is 1.0 mW/cm 2 . The calculation result of the power density at a distance of 20 cm of our device is less than the limit. This means that according to OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01), the equipment fulfills the requirements on power density for general population/uncontrolled exposure and therefore fulfills the requirements of 47 CFR Part 15.247 (b)(5).

Test Report

Rev. No 2.0 FCC Part 15 EMI TEST REPORT of E.U.T. : 11n PCI Adapter FCC ID. : VYTLP-7615 Model No. : LP-7615 for APPLICANT : Loopcomm Technology, Ltd. ADDRESS : 1F, No. 114, Lian Chen Rd., Chung Ho City, Taipei Hsien, 235, Taiwan Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO.34, LIN 5, DINGFU TSUEN, LINKOU SHIANG TAIPEI COUNTY, TAIWAN, 24442, R.O.C. Tel : (02)26023052 Fax : (02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : 10-03-RBF-041 ETC Report No. : 10-03-RBF-041 FCC ID.: VYTLP-7615 Rev. No 1.0 TEST REPORT CERTIFICATION Applicant : Loopcomm Technology, Ltd. 1F, No. 114, Lian Chen Rd., Chung Ho City, Taipei Hsien, 235, Taiwan Manufacturer : Loopcomm Technology, Ltd. 1F, No. 114, Lian Chen Rd., Chung Ho City, Taipei Hsien, 235, Taiwan, Description of EUT a) Type of EUT 11n PCI Adapter b) Trade Name 11n 1T1R Wireless PCI Card c) Model No. LP-7615 d) Power Supply : : : : Power From PC Regulation Applied : FCC Rules and Regulations Part 15 Subpart C (2008) I HEREBY CERTIFY THAT: The data shown in this report were made in accordance with the procedures given in ANSI C63.4, and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note: 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of ETC. ETC Report No. : 10-03-RBF-041 FCC ID.: VYTLP-7615 Rev. No 1.0 Date Test Item Received : Mar. 05, 2010 Date Test Campaign Completed : Apr. 01, 2010 Date of Issue : Apr. 12, 2010 Test Engineer : ( Falcon Shi, Engineer ) Check By : ( Charles Wang, Supervisor ) Approve & Authorized Signer : Will Yauo, Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No. : 10-03-RBF-041 FCC ID.: VYTLP-7615 Rev. No 1.0 Table of Contents Page 1 GENERAL INFORMATION.......................................................................................................1 1.1 Product Description........................................................................................................................1 1.2 Characteristics of Device................................................................................................................1 1.3 Test Methodology..........................................................................................................................1 1.4 Test Facility....................................................................................................................................1 2 PROVISIONS APPLICABLE.......................................................................................................2 2.1 Definition........................................................................................................................................2 2.2 Requirement for Compliance...........................................................................................................3 2.3 Restricted Bands of Operation........................................................................................................5 2.4 Labeling Requirement.....................................................................................................................5 2.5 User Information............................................................................................................................6 3. SYSTEM TEST CONFIGURATION...........................................................................................7 3.1 Justification.....................................................................................................................................7 3.2 Devices for Tested System.............................................................................................................7 4 RADIATED EMISSION MEASUREMENT..............................................................................8 4.1 Applicable Standard.......................................................................................................................8 4.2 Measurement Procedure.................................................................................................................8 4.3 Measuring Instrument...................................................................................................................10 4.4 Radiated Emission Data................................................................................................................11 4.5 Field Strength Calculation.............................................................................................................28 4.6 Photos of Radiation Measuring Setup............................................................................................29 5 CONDUCTED EMISSION MEASUREMENT........................................................................30 5.1 Standard Applicable.....................................................................................................................30 5.2 Measurement Procedure...............................................................................................................30 5.3 Conducted Emission Data.............................................................................................................31 5.4 Result Data Calculation.................................................................................................................33 5.5 Conducted Measurement Equipment.............................................................................................33 5.6 Photos of Conduction Measuring Setup........................................................................................34 6 ANTENNA REQUIREMENT....................................................................................................35 6.1 Standard Applicable................................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

ETC Report No. : 10-03-RBF-041 FCC ID.: VYTLP-7615 Sheet 29 of 104Sheets Rev. No 2.0 4.6 Photos of Radiation Measuring Setup ETC Report No. : 10-03-RBF-041 FCC ID.: VYTLP-7615 Sheet 34 of 104Sheets Rev. No 2.0 5.6 Photos of Conduction Measuring Setup

Contact Information

Applicant

Jane Lee(vice president)
[email protected]+886-2-8686-9685Fax: +886-2-8686-9687

Test Firm

Electronics Testing Center, TaiwanWill Yauo
[email protected]886-3-3280026Fax: 886-3-3280034

Technical Specifications

#Rule PartsFrequency RangePower Output
215C2.42 GHz - 2.45 GHz22.00 mW
Confidentiality
Long Term
Grant Notes
Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
