W2E-ICHIME33Wireless sensor for temperature monitoring

iControl Incorporated http://www.iControl-Inc.com iCHIME Module iTAG Repeater for iCHIME’s iCHIME and iTAG Reader iCHIME iCHIME Module Operating Manual Background. The iCHIME is 2.4GHz bi-directional radio transceiver. A User may configure the device to operate as a Radio Frequency Identification Device (RFID) to support tracking shipping containers in a worldwide supply chain using the Marine Asset Tag Tracking System (MATTS) communication protocol. An iCHIME module utilizes a low power, wireless, radio operating in the 2.4 GHz band as its primary mode of communication. The wireless radio operates in compliance with IEEE Standard 802.15.4-2006. The iCHIME utilizes the same radio, processor, and User interface software as iControl’s iTAG . The iCHIME also supports the same command list as iControl’s iTAG. The iCHIME is User configurable to periodically transmit the iCHIME’s status via the MATTS radio network. The module may operate as stand alone device or may be used as a radio transceiver for devices that communicate data as a part of a larger system. There are no physical connections to the iCHIME other than two charging contacts for the rechargeable LI button cell battery. Figure 1 iCHIME and Network Related Devices iControl Incorporated http://www.iControl-Inc.com iCHIME Radio Operation. The iCHIME is controlled via the radio network for initial configuration and checkout. All commands for controlling the iCHIME radio are identified in the iTAG Command List. Once a User as completed the initial iCHIME configuration, complete control and operation of the iCHIME can be accomplished through the radio interface using the same commands available in the iTAG Command List. The radio in the iCHIME is normally operated in a power saving mode with the receiver periodically enabled and “listening” for commands or data requests. A key element to the power saving mode is the principle of “tag-talks-last”. In this mode, battery power is conserved by only responding to messages that are sent directly to the specific iCHIME MAC address or mutual broadcast address. For a majority of iCHIME operation, the iCHIME is in a deep power saving mode (~98% of the time). The iCHIME will only transmit when it receives a properly encrypted message while it’s receiver is active. The encrypted message directed to the iCHIME may include information about which channel the iCHIME uses for further transmissions. Once, the communication parameters are exchanged, there will typically be a period a several seconds of active radio transmission as the iCHIME relays data. The data transmitted may either be security data destined for government servers, and/or commercial data destined for the end customer. This data may originate from internal flash storage or it may be received and relayed from another compatible device. Other Features. In addition to the wireless radio, the iCHIME provides other features for system integration. 1. There is an onboard temperature sensor integrated with iCHIME. The default iCHIME data packet includes the device temperature, radio signal strength, and battery status. 2. The ICHIME has non-volatile on board data storage which may collect data for later upload 3. iCHIME provide date time stamps for all data. The onboard clock for the iCHIME is set to UTC by readers in the network or from the iTAG GPS by commands. iControl Incorporated http://www.iControl-Inc.com Functional Block Diagram. The iCHIME module integrates a low power microprocessor and a 2.4Ghz radio . The iCHIME includes a software user interface for radio control and data transmission. Please note that the iCHIME uses the same command list as the iTAG command list . For iCHIME command and control, please refer to the iTAG Command List for a complete description of commands that control the iCHIME module. The iCHIME module is equipped with an integrated trace antenna rated at 3.0 dBi. All mobile applications will utilize the integral antenna provided with the iCHIME module. NOTE: Users may not modify the antenna or it’s connection in anyway or risk violating radio law. iControl Incorporated http://www.iControl-Inc.com Absolute Maximum Ratings. Under no circumstances must the absolute maximum ratings giving in this table be violated. Stress exceeding one or more of the limiting values may cause permanent damage to the device. Parameter Min Max Units Condition Charger Supply Voltage 4.75 6.5 V Users must utilize an iControl providing charging station for the iCHIME Voltage on any digital pin -0.3 3.6 V N/A Input RF level 10 dBm Storage temperature range -50 150 C Operating ambient temperature -40 85 C Figure 3 Maximum Ratings iControl Incorporated http://www.iControl-Inc.com General Characteristics. Programmable in 5MHz steps starting at 2405MHz per IEEE 802.15.4 iControl Incorporated http://www.iControl-Inc.com iCHIME Radio Specification (Transmit). 3 5 iControl Incorporated http://www.iControl-Inc.com iCHIME Radio Specification (Receive). iControl Incorporated http://www.iControl-Inc.com Module Unique Address Identification. Each iCHIME module is assigned a unique 8 byte MAC address by iControl Incorporated. The MAC address is used for radio network address identification. The MAC address can not be modified by the User and is located in protected flash memory. Figure 5 depicts the communication protocol between iControl iCHIME and the iGATE reader. The communication protocol utilizes a unique 8 byte MAC address defined by the IEEE 802.15.4 standard. In Figure 5, The iCHIME address is (0x0035A923000000002). The iGATE address is (0x0035A9230A010203) Figure 5 iControl Incorporated http://www.iControl-Inc.com FCC Compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequen…

Text truncated - open the document above for the full version.

iControl Incorporated iCHIME Command List Revision 2.2 Date: January 2015 Command List 24-Aug-15 i Command List Index iTAG_Mode ...................................................................................................................................... 8 iTAG_ID ......................................................................................................................................... 10 No_OP............................................................................................................................................. 11 Forward_Packet .............................................................................................................................. 12 Load_Config ................................................................................................................................... 13 Send_Config ................................................................................................................................... 14 Network........................................................................................................................................... 15 Port_CFG ........................................................................................................................................ 17 Set_Time ......................................................................................................................................... 18 Net_Type......................................................................................................................................... 19 Power_Cfg ...................................................................................................................................... 20 IO_Addr .......................................................................................................................................... 21 Default_Dest ................................................................................................................................... 22 Power_Override .............................................................................................................................. 23 Power_Save..................................................................................................................................... 24 AT_Dial .......................................................................................................................................... 25 AT_Answer ..................................................................................................................................... 26 Modem_Type .................................................................................................................................. 27 Hangup_Modem ............................................................................................................................. 28 Enable_Schedule ............................................................................................................................. 29 Radio_Parameter ............................................................................................................................. 30 Broadcast_Address ......................................................................................................................... 31 LAN_Device ................................................................................................................................... 32 CMD_Retry..................................................................................................................................... 33 Phone_Number ............................................................................................................................... 34 Password ......................................................................................................................................... 35 Upload_ACL ................................................................................................................................... 36 Upload_Data ................................................................................................................................... 36 Upload_Macros ............................................................................................................................... 36 Upload_TextMsg ............................................................................................................................ 36 Upload_Schedules........................................................................................................................... 36 Save_Data ....................................................................................................................................... 37 Modem_Parms ................................................................................................................................ 38 iModem ........................................................................................................................................... 40 Serial_R/W ...................................................................................................................................... 41 General_R/W .................................................................................................................................. 42 Beacon............................................................................................................................................. 43 Track ............................................................................................................................................... 44 Test_Condition ................................................................................................................................ 46 MAC_Addr ..................................................................................................................................... 48…

Text truncated - open the document above for the full version.

iControl Incorporated 1885 De La Cruz Santa Clara, CA 95050 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: July 30, 2015 Subject; Request for Confidentiality FCC ID: W2E-ICHIME33 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely.  Schematic Diagram  Block Diagram  Part List  Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission' s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant shot-term confidentiality request on the following attachment(s) for 180 days after the grant as outlined in Public Notice DA 04-1705.  External Photos  Internal Photos  Test Setup Photos  User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: E. Fred Tubb Title: Chief Technical Officer

MiCOM Labs DofC 1.1 August 18, 2015 iControl Incorporated 1885 De La Cruz Santa Clara, CA 95050 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia, MD 21046 Subject: FCC ID: W2E-ICHIME33 To Whom It May Concern: We hereby attest to the fact that we have applied the Declaration of Conformity procedure for a Class B Computer Peripheral to the digital portion of this composite filing. The procedures identified in 47CFR 2.948(d) and 2.948(e), along with the requirements listed in KDB 349827 have been followed. The report has been issued by Micom Labs 575 Boulder Court, Pleasanton, CA and can identified by report number ICON12-U2 Sincerely Yours, E. Fred Tubb iControl Incorporated 1885 De La Cruz, Suite 203 Santa Clara, CA 95050

Letter of Authorization iControl Incorporated 1885 De La Cruz Suite 203 Santa Clara, California 95050 Product Name: iCHIME Model Number: IDC-ICH-V3.3 FCC Identifier: W2E-ICHIME33 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: E. Fred Tubb Date: July 30, 2015 Title: Chief Technical Officer Signature of applicant:

iCHIME External Photographs iCHIME3.0 - Bottom View iCHIME3.0 - Open Case iCHIME3.0 - Side 1 View iCHIME3.0 - Side 2 View iCHIME3.0 - Side 3 View iCHIME3.0 - Side 4 View iCHIME3.0 - Top View

iCHIME Internal Photographs iCHIME3.0 - Internal Bottom View iCHIME3.0 - Internal Top View

iControl Incorporated http://www.iControl-Inc.com iCHIME Module iTAG™ Repeater for iCHIME™’s iCHIME™ and iTAG™ Reader iCHIME™ iCHIME™ Operational Description Background. The iCHIME™ is 2.4GHz bi-directional radio transceiver. A User may configure the device to operate as a Radio Frequency Identification Device (RFID) to support tracking shipping containers in a worldwide supply chain using the Marine Asset Tag Tracking System (MATTS) communication protocol. An iCHIME™ module utilizes a low power, wireless, radio operating in the 2.4 GHz band as its primary mode of communication. The wireless radio operates in compliance with IEEE Standard 802.15.4-2006. The iCHIME™ utilizes the same radio, processor, and User interface software as iControl’s iTAG™ . The iCHIME™ also supports the same command list as iControl’s iTAG™. The iCHIME™ is User configurable to periodically transmit the iCHIME™’s status via the MATTS radio network. The module may operate as stand alone device or may be used as a radio transceiver for devices that communicate data as a part of a larger system. There are no physical connections to the iCHIME™ other than two charging contacts for the rechargeable LI button cell battery. Figure 1 iCHIME™ and Network Related Devices iControl Incorporated http://www.iControl-Inc.com iCHIME™ Radio Operation. The iCHIME™ is controlled via the radio network for initial configuration and checkout. All commands for controlling the iCHIME™ radio are identified in the iTAG™ Command List. Once a User as completed the initial iCHIME™ configuration, complete control and operation of the iCHIME™ can be accomplished through the radio interface using the same commands available in the iTAG™ Command List. The radio in the iCHIME™ is normally operated in a power saving mode with the receiver periodically enabled and “listening” for commands or data requests. A key element to the power saving mode is the principle of “tag-talks-last”. In this mode, battery power is conserved by only responding to messages that are sent directly to the specific iCHIME™ MAC address or mutual broadcast address. For a majority of iCHIME™ operation, the iCHIME™ is in a deep power saving mode (~98% of the time). The iCHIME™ will only transmit when it receives a properly encrypted message while it’s receiver is active. The encrypted message directed to the iCHIME™ may include information about which channel the iCHIME™ uses for further transmissions. Once, the communication parameters are exchanged, there will typically be a period a several seconds of active radio transmission as the iCHIME™ relays data. The data transmitted may either be security data destined for government servers, and/or commercial data destined for the end customer. This data may originate from internal flash storage or it may be received and relayed from another compatible device. Other Features. In addition to the wireless radio, the iCHIME™ provides other features for system integration. 1. There is an onboard temperature sensor integrated with iCHIME™. The default iCHIME™ data packet includes the device temperature, radio signal strength, and battery status. 2. The ICHIME™ has non-volatile on board data storage which may collect data for later upload 3. iCHIME™ provide date time stamps for all data. The onboard clock for the iCHIME™ is set to UTC by readers in the network or from the iTAG™ GPS by commands. iControl Incorporated http://www.iControl-Inc.com Functional Block Diagram. The iCHIME™ module integrates a low power microprocessor and a 2.4Ghz radio . The iCHIME includes a software user interface for radio control and data transmission. Please note that the iCHIME™ uses the same command list as the iTAG™ command list . For iCHIME™ command and control, please refer to the iTAG Command List for a complete description of commands that control the iCHIME™ module. The iCHIME™ module is equipped with an integrated trace antenna rated at 3.0 dBi. All mobile applications will utilize the integral antenna provided with the iCHIME™ module. NOTE: Users may not modify the antenna or it’s connection in anyway or risk violating radio law. iControl Incorporated http://www.iControl-Inc.com Absolute Maximum Ratings. Under no circumstances must the absolute maximum ratings giving in this table be violated. Stress exceeding one or more of the limiting values may cause permanent damage to the device. Parameter Min Max Units Condition Charger Supply Voltage 4.75 6.5 V Users must utilize an iControl providing charging station for the iCHIME™ Voltage on any digital pin -0.3 3.6 V N/A Input RF level 10 dBm Storage temperature range -50 150 C Operating ambient temperature -40 85 C Figure 3 Maximum Ratings iControl Incorporated http://www.iControl-Inc.com General Characteristics. Programmable in 5MHz steps starting at 2405MHz per IEEE 802.15.4 iControl Incorporated http://www.iControl-Inc.com iCHIME Radio Specification (Transmit). 3 5 iControl Incorporated http://www.iControl-Inc.com iCHIME Radio Specification (Receive). iControl Incorporated http://www.iControl-Inc.com Module Unique Address Identification. Each iCHIME™ module is assigned a unique 8 byte MAC address by iControl Incorporated. The MAC address is used for radio network address identification. The MAC address can not be modified by the User and is located in protected flash memory. Figure 5 depicts the communication protocol between iControl iCHIME™ and the iGATE™ reader. The communication protocol utilizes a unique 8 byte MAC address defined by the IEEE 802.15.4 standard. In Figure 5, The iCHIME™ address is (0x0035A923000000002). The iGATE™ address is (0x0035A9230A010203) Figure 5 iControl Incorporated http://www.iControl-Inc.com FCC Compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equi…

Text truncated - open the document above for the full version.

Company: iControl Incorporated Assessment of: iControl iCHIME3.3 To: FCC CFR 47 Part 15 RF Exposure requirements Industry Canada RSS-102 No.: ICON12 – iCHIME3.3 MPE MPE TEST REPORT MPE REPORT FROM Assessment of: iControl Incorporated iControl iCHIME3.3 to To: FCC CFR 47 Part 15 RF Exposure requirements Industry Canada RSS-102 Test Report Serial No.: ICON12 – iCHIME3.3 MPE This report supersedes: NONE Applicant: iControl Incorporated 3235 Kifer Rd, Suite 260 Santa Clara, 95051 USA Product Function: Asset Tracking Issue Date: 28th August 2015 This Test Report is Issued Under the Authority of: MiCOM Labs, Inc. 575 Boulder Court Pleasanton California 94566 USA Phone: +1 (925) 462-0304 Fax: +1 (925) 462-0306 www.micomlabs.com MiCOM Labs is an ISO 17025 Accredited Testing Laboratory Title: iControl Incorporated iControl iCHIME3.3 To: FCC CFR 47 Part 15 RF Exposure requirements Serial #: ICON12 - 2.4GHz Zigbee FCC IC Issue Date: 28th August 2015 Page: 3 of 5 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. All changes will be noted in the Document History section of the report. MiCOM Labs, 575 Boulder Court, Pleasanton, California 94566 USA, Phone: +1 (925) 462 0304, Fax: +1 (925) 462 0306, www.micomlabs.com 1. MAXIMUM PERMISSABLE EXPOSURE Calculations for Maximum Permissible Exposure Levels Power Density = Pd (mW/cm 2 ) = EIRP/(4*π*d 2 ) EIRP = P * G P = Peak output power (mW) G = Antenna numeric gain (numeric) d = Separation distance (cm) Numeric Gain = 10 ^ (G (dBi)/10) Because the EUT belongs to the General Population/Uncontrolled Exposure the limit of power density is 1.0 mW/cm 2 The calculations in the table below use the highest conducted power values together with the lowest antenna gain specified for the EUT. These calculations represent worst case in terms of the exposure levels. Freq. Band (MHz) Ant Gain (dBi) Numeric Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Calculated Safe Distance (cm) @ 1mW/cm 2 Calculated Power Density (mW/cm 2 ) @ 20cm Minimum Separation Distance (cm) 2400.0 - 2483.5 3.50 2.24 4.70 2.95 0.72 0.001 20.00 Note: for mobile or fixed location transmitters the minimum separation distance is 20cm, even if calculations indicate the MPE distance to be less. Title: iControl Incorporated iControl iCHIME3.3 To: FCC CFR 47 Part 15 RF Exposure requirements Serial #: ICON12 - 2.4GHz Zigbee FCC IC Issue Date: 28th August 2015 Page: 4 of 5 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. All changes will be noted in the Document History section of the report. MiCOM Labs, 575 Boulder Court, Pleasanton, California 94566 USA, Phone: +1 (925) 462 0304, Fax: +1 (925) 462 0306, www.micomlabs.com Specification Maximum Permissible Exposure Limits FCC §1.1310 Limit = 1mW / cm 2 from 1.310 Table 1 RSS-Gen §3.2 In addition to RSS-Gen, the requirements in Radio Standards Specification RSS-102 shall be met. 575 Boulder Court Pleasanton, California 94566, USA Tel: +1 (925) 462 0304 Fax: +1 (925) 462 0306 www.micomlabs.com

Company: iControl Incorporated Test of: iCHIME3.3 To: FCC Part 15 Subpart C 15.247 (DTS) & IC RSS-247 Report No.: ICON12-U2 Rev A CONDUCTED TEST REPORT CONDUCTED TEST REPORT FROM Test of: iControl Incorporated iCHIME3.3 to To: FCC CFR 47 Part 15 Subpart C 15.247 (DTS) & IC RSS-247 Test Report Serial No.: ICON12-U2 Draft This report supersedes: NONE Applicant: iControl Incorporated 1185 De La Cruz Blvd, Suite 203 Santa Clara, California 95050 USA Product Function: Asset Tracking Issue Date: 6 th August 2015 This Test Report is Issued Under the Authority of: MiCOM Labs, Inc. 575 Boulder Court Pleasanton California 94566 USA Phone: +1 (925) 462-0304 Fax: +1 (925) 462-0306 www.micomlabs.com MiCOM Labs is an ISO 17025 Accredited Testing Laboratory Title: iControl Incorporated iCHIME3.3 To: FCC CFR 47 Part 15 Subpart C 15.247 (DTS) & IC RSS-247 Serial #: ICON12-U2 Rev A Issue Date: 6 th August 2015 Page: 3 of 56 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. All changes will be noted in the Document History section of the report. MiCOM Labs, 575 Boulder Court, Pleasanton, California 94566 USA, Phone: +1 (925) 462 0304, Fax: +1 (925) 462 0306, www.micomlabs.com Table of Contents 1. ACCREDITATION, LISTINGS & RECOGNITION................................................................................. 4 1.1. TESTING ACCREDITATION ......................................................................................................... 4 1.2. RECOGNITION ............................................................................................................................. 5 1.3. PRODUCT CERTIFICATION ........................................................................................................ 6 2. DOCUMENT HISTORY ......................................................................................................................... 7 3. TEST RESULT CERTIFICATE .............................................................................................................. 8 4. REFERENCES AND MEASUREMENT UNCERTAINTY ..................................................................... 9 4.1. Normative References ................................................................................................................... 9 4.2. Test and Uncertainty Procedure .................................................................................................. 10 5. PRODUCT DETAILS AND TEST CONFIGURATIONS ...................................................................... 11 5.1. Technical Details ......................................................................................................................... 11 5.2. Scope Of Test Program ............................................................................................................... 12 5.3. Equipment Model(s) and Serial Number(s) ................................................................................. 13 6.1. Antenna Details ........................................................................................................................... 13 6.2. Cabling and I/O Ports .................................................................................................................. 13 6.3. Test Configurations...................................................................................................................... 13 6.4. Equipment Modifications ............................................................................................................. 13 6.5. Deviations from the Test Standard .............................................................................................. 13 7. TEST SUMMARY ................................................................................................................................ 14 8. TEST EQUIPMENT CONFIGURATION(S) ......................................................................................... 15 8.1. Conducted ................................................................................................................................... 15 8.2. Radiated Emissions - 3m Chamber ............................................................................................. 17 9. MEASUREMENT AND PRESENTATION OF TEST DATA ............................................................... 19 10. TEST RESULTS ................................................................................................................................ 20 10.1. 6 dB & 99% Bandwidth .............................................................................................................. 20 10.2. Conducted Output Power .......................................................................................................... 22 10.3. Conducted Spurious Emissions ................................................................................................. 25 10.3.1. Spurious Emissions ............................................................................................................…

Text truncated - open the document above for the full version.
