W3Z-W9460Remote Controlled Locking Wheel

® Le present appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. (1) This device may not cause harmful interference, and (2) This device must accept any interference The Gatekeeper Wheel This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: CartControl User Manual 17 INSTRUCTIONS TO THE USER FOR FCC - received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide a reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet or a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help. Information for Canadian Users (IC Notice) Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Any changes or modifications not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. FCC Declaration of Conformance Product devices comply with FCC Part 15. The socket-outlet shall be installed near the equipment and shall be easily accessible. le socle de prise de courant doit être installé à proximité du matériel et doit être aisément accessible. This device complies with Industry Canada licence-exempt RSS standard(s). L'exploitation est autorisee aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d'en compromettre le fonctionnement. Table Of Contents Introduction 1 System Overview 2 System Components 3 Customer Awareness Component 3 Equipment 4 System Operation 6 Unlocking Carts 6 Master Unlock Procedure 7 Changing CartKey Battery 7 System Maintenance 8 Troubleshooting 10 System Component: CentralTransmitter 10 System Component: The Gatekeeper wheel 11 System Component: The Gatekeeper wheel 12 System Component: CartKey 13 Service 13 Customer Responsibilities 14 Technical Specifications 15 Cart Containment Log 16, 17 The specifications and information regarding the products in this manual are subject to change without notice. All statements, information, and recommendations in this manual are believed to be accurate but are presented without warranty of any kind, express or implied. Users must take full responsibility for their application of any products. Gatekeeper Systems CartControl Shopping Cart Containment System User Manual Copyright © 2010 Gatekeeper Systems Inc. All Rights Reserved. CartControl User Manual CartControl User Manual 01 INTRODUCTION To Our Valued Customers: Thank you for allowing us to install the Gatekeeper Systems CartControl Shopping Cart Contain- ment system at your store. The CartControl system is the most technologically advanced and user- friendly cart containment system on the market. We are confident that it will dramatically improve your store’s existing efforts to keep shopping carts on the premises. In addition to providing the best cart containment system available, it is our aim to provide you with unparalleled customer service. Gatekeeper Systems offers a 24-hour toll-free customer service line as well as a nationwide network of field representatives and service technicians to handle any service issues. Should you have any questions or need to schedule a field service call, please call our toll-free 24-hour customer service number. GATEKEEPER SYSTEMS 24-HOUR CUSTOMER SERVICE HOTLINE Toll Free (888) 808-9433 Press Option “1” Between the hours of 7 p.m. CST and 7 a.m. CST, select Option #5 to activate our emergency dispatch service. vice. The CartControl User Manual is designed to provide store personnel with a general information source regarding the shopping cart containment system. Making this manual available to all new employees who have not yet worked with the system will help ensure proper operation and added longevity. Properly trained employees are an integral part of the system’s operation. The manual also contains technical information and is a good place to refer maintenance work- ers and contractors with questions about the system. If questions concerning the system arise and answers are not available in this manual, please call the toll-free number to speak with a Gatekeeper Customer Service Representative. Never hesitate to contact Gatekeeper with your questions about the system. We encourage your store to designate an employee who can act as a “contact person”. Gatekeeper will ask for this person by name when scheduling service or performing routine preventative mainte- nance calls. Gatekeeper will also train this individual in additional system functions and troubleshoot- ing procedures. SYSTEM OVERVIEW According to retail industry research, a shopping cart is stolen, damaged, or destroyed every ninety seconds in the United States, costing retailers approximately $180 million annually. The CartControl system combines a digital locking signal, pe…

Text truncated - open the document above for the full version.

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT BOTTOM VIEW

STC Test Report Date : 2011-04-06 Page 1 of 29 No. : HM166381 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre Ltd. For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of Homepage. Applicant (GAS003): Gatekeeper Systems (HK) Ltd. Unit 2318-2319, Level 23, Tower 1, Metroplaza No. 223 Hing Fong Road, Kwai Fong, N.T., Hong Kong. Manufacturer: Gatekeeper Systems (HK) Ltd. Unit 2318-2319, Level 23, Tower 1, Metroplaza No. 223 Hing Fong Road, Kwai Fong, N.T., Hong Kong. Description of Sample(s): Submitted sample(s) said to be Product: Remote Controlled Locking Wheel Brand Name: Gatekeeper Systems Model Number: W-9460 FCC ID: W3Z-W9460 Date Sample(s) Received: 2011-03-03 Date Tested: 2011-03-23 to 2011-06-08 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2010 and ANSI C63.4:2009 for FCC Certification. Conclusion(s): The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remark(s): --- Dr. LEE Kam Chuen Authorized Signatory ElectroMagnetic Compatibility Department For and on behalf of The Hong Kong Standards and Testing Centre Ltd. STC Test Report Date : 2011-04-06 Page 2 of 29 No. : HM166381 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage CONTENT: Cover Page 1 of 29 Content Page 2-3 of 29 1.0 General Details 1.1 Equipment Under Test [EUT] Page 4 of 29 Description of EUT operation 1.2 Description of EUT Operation 1.3 Date of Order Page 4 of 29 1.4 Submitted Sample Page 4 of 29 1.5 Test Duration Page 4 of 29 1.6 Country of Origin Page 4 of 29 2.0 Technical Details 2.1 Investigations Requested Page 5 of 29 2.2 Test Standards and Results Summary Page 5 of 29 3.0 Test Results 3.1 Emission Page 6-26 of 29 STC Test Report Date : 2011-04-06 Page 3 of 29 No. : HM166381 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage Appendix A List of Measurement Equipment Page 27 of 29 Appendix B Photographs Page 28-29 of 29 STC Test Report Date : 2011-04-06 Page 4 of 29 No. : HM166381 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.0 General Details 1.1 Equipment Under Test [EUT] Description of Sample(s) Product: Remote Controlled Locking Wheel Manufacturer: Gatekeeper Systems (HK) Ltd. Unit 2318-2319, Level 23, Tower 1, Metroplaza No. 223 Hing Fong Road, Kwai Fong, N.T., Hong Kong. Brand Name: Gatekeeper Systems Model Number: W-9460 Input Voltage: 3.0Vd.c. (Li-MH battery x 1) 1.2 Description of EUT Operation The Equipment Under Test (EUT) is a Gatekeeper Systems (HK) Ltd., Remote Controlled Locking Wheel. The transmission signal is frequency hopping with channel frequency range 2401.4-2478.6MHz during normal use. The EUT was set to fixed frequency test mode by applicant. 1.3 Date of Order 2011-03-03 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2011-03-23 to 2011-06-08 1.6 Country of Origin China STC Test Report Date : 2011-04-06 Page 5 of 29 No. : HM166381 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2010 Regulations and ANSI C63.4:2009 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Fail N/A Field Strength of Fundamental & Harmonics Emissions FCC 47CFR 15.249 ANSI C63.4:2009 N/A Radiated Emissions FCC 47CFR 15.209 ANSI C63.4:2009 N/A Note: N/A - Not Applicable STC Test Report Date : 2011-04-06 Page 6 of 29 No. : HM166381 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 3.0 Test Results 3.1 Emission 3.1.1 Radiated Emissions Test Requiremen…

Text truncated - open the document above for the full version.

PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP
