  1. Home/
  2. Rosewill Inc./
  3. W6RRNX-N150HG

W6RRNX-N150HGRNX-N150HG

Rosewill Inc.
RNX-N150HG - FCC ID W6RRNX-N150HG - Rosewill Inc.
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Nov 07, 2011
Application Purpose
Original Equipment
Date of Application
Nov 06, 2011
Equipment Note
RNX-N150HG
Frequency Range
2422.00000000 - 2452.00000000
Company
Rosewill Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Wireless High Gain USB Adapter RNX-N150HG User Manual 1910020408 FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the dealer or an experienced radio/ TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1). This device may not cause harmful interference. 2). This device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. “To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this transmitter must be installed to provide a separation distance of at least 0.5 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. National Restrictions 2400.0-2483.5 MHz Country Restriction Reason/remark Bulgaria General authorization required for outdoor use and public service France Outdoor use limited to 10 mW EIRP. within the band 2454-2483.5 MHz Military Radiolocation use. Refarming of the 2.4 GHz band has been ongoing in recent years to allow current relaxed regulation. Full implementation planned 2012 Italy If used outside of own premises, general authorization is required Luxembourg General authorization required for network and service supply(not for spectrum) Norway Implemented This subsection does not apply for the geographical area within a radius of 20 km from the centre of Ny-Ålesund Russian Federation Only for indoor applications Note: Please don’t use the product outdoors in France. Table of Content Package Contents.......................................................................................... 1 Chapter 1 Overview ...................................................................................... 2 1.1 Overview of the product ................................................................... 2 1.2 Features........................................................................................... 2 1.3 LED Status ....................................................................................... 2 Chapter 2 Installation Guide ........................................................................ 3 2.1 Hardware Installation ....................................................................... 3 2.2 Software Installation......................................................................... 3 2.2.1 For Windows XP................................................................................... 3 2.2.2 For Windows Vista................................................................................ 8 2.2.3 For Windows 7.................................................................................... 10 Chapter 3 Configuration Guide ................................................................. 13 3.1 For Windows XP ............................................................................ 13 3.1.1 Current Status.................................................................................... 14 3.1.2 Profile Management........................................................................... 15 3.1.3 Diagnostics ......................................................................................... 23 3.2 For Windows Vista ......................................................................... 25 3.3 For Windows 7 ............................................................................... 27 Chapter 4 WPS Configuration ................................................................... 30 4.1 PBC (Push Button Configuration) method ..................................... 30 4.2 PIN method .................................................................................... 33 4.2.1 Enter a PIN into your AP device ......................................................... 33 4.2.2 Enter the PIN from your AP device..................................................... 34 Appendix A: Specifications......................................................................... 36 Appendix B: Glossary................................................................................. 37 Appendix C: FAQ ......................................................................................... 39 Package Contents The following contents should be found in your box: ¾ One RNX-N150HG Wireless High Gain USB Adapter ¾ Quick Installation Guide ¾ One USB cable ¾ One Resource CD for RNX…

Text truncated - open the document above for the full version.

Cover Letter(s)

Rosewill Inc. Attestation for FCC Declaration of Conformity FCC ID: W6RRNX-N150HG Date: Aug 5, 2011 Please be notified that we, the undersigned, Rosewill Inc., declare that the product bears the above FCC ID is also complying with the requirements of FCC DoC. The test report number for FCC DoC is EM-F1000712 , with is issued by an accredited lab, Audix Technology Corporation, EMC Department located at No. 53-11, Tin-Fu Tsun, Lin-Kou , Taipei Hsien , Taiwan. Which has been accredited in accordance to all of the requirements of 47CFR 2.948(d and (e) of the FCC rules and KDB349827. Sincerely, Name of authorized signer: Jett Chu Title of authorized signer: Product Manager Company Name: Rosewill Inc. Tel: 886-2-8752-3555 Fax: 886-2- 8572-3556 Web site: WWW.ROSEWILL.COM

Cover Letter(s)

Rosewill Inc. Date: July 8, 2011 Communications Commission Authorization and Evaluation Division FCC ID: W6RRNX-N150HG Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1. Block diagram 2. Schematics 3. Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might to harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Name of authorized signer: Jett Chu Title of authorized signer: Product Manager Company Name: Rosewill Inc. Tel: 886-2-8752-3555 Fax: 886-2- 8572-3556 Web site: WWW.ROSEWILL.COM

Cover Letter(s)

Rosewill Inc. AGENCY AUTHORIZATION LETTER FCC ID:W6RRNX-N150HG Date: July 8, 2011 To whom it may concern: We, the undersigned, hereby authorize Audix Technology (Shenzhen) Co., Ltd (No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park,Nantou,Shenzhen, Guangdong, China)to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Audix within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months form original date. If you have any Questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely, Name of authorized signer: Jett Chu Title of authorized signer: Product Manager Company Name: Rosewill Inc. Tel: 886-2-8752-3555 Fax: 886-2- 8572-3556 Web site: WWW.ROSEWILL.COM

External Photos

R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 13-1 13. PHOTOS OF THE EUT Figure 1 General Appearance of the EUT Figure 2 General Appearance of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 13-2 Figure 3 General Appearance of the EUT Figure 4 General Appearance of the EUT Figure 5 R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 13-3 General Appearance of the EUT Figure 6 General Appearance of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 13-4 Figure 7 General Appearance of the EUT Figure 8 Inside of the EUT

ID Label/Location Info

Label

Internal Photos

R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 13-5 Figure 9 Inside of the EUT Figure 10 Inside of the EUT R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 13-6 Figure 11 Inside of the EUT Figure 12 Inside of the EUT

RF Exposure Info

Report No. RZA1107-1176SAR01R5 Page 1 of 76 TESTING No. L2264 TEST REPORT Product Name Wireless High Gain USB Adapter Model RNX-N150HG FCC ID W6RRNX-N150HG Client Rosewill Inc. TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA1107-1176SAR01R5 Page 2 of 76 GENERAL SUMMARY Product Name Wireless High Gain USB Adapter Model RNX-N150HG FCC ID W6RRNX-N150HG Report No. RZA1107-1176SAR01R5 Client Rosewill Inc. Manufacturer Rosewill Inc. Reference Standard(s) IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438, published June 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radio frequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radio frequency Emissions. KDB 248227 D01 SAR meas for 802 11 a b g v01r02: SAR Measurement Procedures for 802.11a/b/g Transmitters. KDB 447498 D02 SAR Procedures for Dongle Xmtr v02: SAR Measurement Procedures for USB Dongle Transmitters. Tracking Number 402779 Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: October 31 st , 2011 Comment The test result only responds to the measured sample. Approved by Director Revised by SAR Manager Performed by SAR Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA1107-1176SAR01R5 Page 3 of 76 TABLE OF CONTENT 1. General Information ........................................................................................................................ 5 1.1. Notes of the Test Report.......................................................................................................... 5 1.2. Testing Laboratory ................................................................................................................... 5 1.3. Applicant Information ............................................................................................................... 6 1.4. Manufacturer Information ......................................................................................................... 6 1.5. Information of EUT................................................................................................................... 7 1.6. The Maximum SAR 1g Values ................................................................................................... 8 1.7. Power of Each Tested Mode.................................................................................................... 8 1.8. Test Date ................................................................................................................................. 8 2. Operational Conditions during Test ................................................................................................. 9 2.1. General Description of Test Procedures .................................................................................. 9 2.2. Test Position of Portable Devices........................................................................................... 10 2.3. Picture of Host Product .......................................................................................................... 11 3. SAR Measurements System Configuration ................................................................................... 12 3.1. SAR Measurement Set-up .....................................................................................................12 3.2. DASY4 E-field Probe System ................................................................................................ 13 3.2.1. EX3DV4 Probe Specification .......................................................................................... 13 3.2.2. E-field Probe Calibration ................................................................................................. 14 3.3. Other Test Equipment ............................................................................................................14 3.3.1. Device Holder for Transmitters ....................................................................................... 14 3.3.2. Phantom .........................................................................................................................15 3.4. Scanning Procedure ..............................................................................................................15 3.5. Data Storage and Evaluation ................................................................................................. 17 3.5.1. Data Storage...................................................................................................................17 3.5.2. Data Evaluation by SEMCAD ......................................................................................... 17 3.6. System Check........................................................................................................................ 20 3.7. Equivalent Tissues ................................................................................................................. 22 4. Laboratory Environment................................................................................................................ 22 5. Characteristics of the Test ............................................................................................................. 23 5.1. Applicable Limit Regulations .................................................................................................. 23 5.2. Applicable Measurement Standards...................................................................................... 23 6. Conducted Ou…

Text truncated - open the document above for the full version.

Test Report

R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of Rosewill Inc. Wireless High Gain USB Adapter Model No.: RNX-N150HG FCC ID: W6RRNX-N150HG Prepared for : Rosewill Inc. 17708 Rowland Street, City of Industry, CA91748, USA Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number : ACS-F11150 Date of Test : Jul.03~17, 2011 Date of Report : Jul.19, 2011 R AUDIX Technology (Shenzhen) Co., Ltd. FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 TABLE OF CONTENTS Description Page 1. SUMMARY OF STANDARDS AND RESULTS .......................................................... 1-1 1.1. Description of Standards and Results .................................................................................. 1-1 2. GENERAL INFORMATION ......................................................................................... 2-1 2.1. Description of Device (EUT) ............................................................................................... 2-1 2.2. Test Information ................................................................................................................... 2-2 2.3. Tested Supporting System Details ....................................................................................... 2-3 2.4. Block diagram of connection between the EUT and simulators .......................................... 2-3 2.5. Test Facility ......................................................................................................................... 2-4 2.6. Measurement Uncertainty (95% confidence levels, k=2) .................................................... 2-4 3. POWER LINE CONDUCTED EMISSION TEST ....................................................... 3-1 3.1. Test Equipments ................................................................................................................... 3-1 3.2. Block Diagram of Test Setup ............................................................................................... 3-1 3.3. Power Line Conducted Emission Test Limits ...................................................................... 3-1 3.4. Configuration of EUT on Test ............................................................................................. 3-2 3.5. Operating Condition of EUT ................................................................................................ 3-2 3.6. Test Procedure ...................................................................................................................... 3-2 3.7. Power Line Conducted Emission Test Results .................................................................... 3-2 4. RADIATED EMISSION TEST ...................................................................................... 4-7 4.1. Test Equipment .................................................................................................................... 4-7 4.2. Block Diagram of Test Setup ............................................................................................... 4-7 4.3. Radiated Emission Limit ...................................................................................................... 4-8 4.4. EUT Configuration on Test .................................................................................................. 4-9 4.5. Operating Condition of EUT ................................................................................................ 4-9 4.6. Test Procedure ...................................................................................................................... 4-9 4.7. Radiated Emission Test Results ......................................................................................... 4-10 5. CONDUCTED SPURIOUS EMISSIONS...................................................................... 5-1 5.1. Test Equipment .................................................................................................................... 5-1 5.2. Limit ..................................................................................................................................... 5-1 5.3. Test Procedure ...................................................................................................................... 5-1 5.4. Test result ............................................................................................................................. 5-1 6. BAND EDGE COMPLIANCE TEST ............................................................................ 6-1 6.1. Test Equipment .................................................................................................................... 6-1 6.2. Limit ..................................................................................................................................... 6-1 6.3. Test Produce ......................................................................................................................... 6-1 6.4. Test Results .......................................................................................................................... 6-1 7. 6dB Bandwidth Test ......................................................................................................... 7-1 7.1. Test Equipment .................................................................................................................... 7-1 7.2. Limit ..................................................................................................................................... 7-1 7.3. Test Procedure ...................................................................................................................... 7-1 7.4. Test Results ................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 12-1 12. PHOTOGRAPH OF TEST 12.1.Photos of Power Line Conducted Emission Test USB Line R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 12-2 No USB Line R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 12-1 12.2.Photos of Radiated Emission Test USB Line R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 12-2 No USB Line R AUDIX Technology (Shenzhen) Co., Ltd. page FCC ID:W6RRNX-N150HG Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F11150 12-1 (Above 1000MHz) USB Line No USB Line

Contact Information

Applicant

Dennis Auyang(Product Management Director)
[email protected]626-271-1420Fax: 626-271-9504

Technical Contact

AUDIX Technology (Shenzhen) Co., Ltd.Ken Lu
86-755-26639497

52 Block Shenzhen Science&Industry · Shenzhen · China

Test Firm

Audix Technology (Shenzhen) Co.Smart Tsai
[email protected]86-755-663-9495Fax: 86-755-663-2877

Technical Specifications

#Rule PartsFrequency RangePower Output
215C2.42 GHz - 2.45 GHz117.00 mW
Confidentiality
Long Term
Grant Notes
Power Output is conducted. The SAR data in this filing is applicable to demonstrate compliance for the USB Dongle only as shown in this filing. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The highest reported SAR values are: Body: 0.957 W/kg;
