WAP2005Bluetooth Module

PRELIMINARY CYBLE-222005-00 EZ-BLE TM PRoC TM Module Cypress Semiconductor Corporation198 Champion CourtSan Jose,CA 95134-1709408-943-2600 Document Number: 002-00214 Rev. ** Revised September 10, 2015 General Description The Cypress CYBLE-222005-00 is a fully certified and qualified module supporting Bluetooth  Low Energy (BLE) wireless communication. The CYBLE-222005-00 is a turnkey solution and includes onboard crystal oscillators, chip antenna, passive components, and Cypress PRoC™ BLE. The CYBLE-222005-00 supports a number of peripheral functions (ADC, timers, counters, PWM) and serial communication protocols (I 2 C, UART, SPI) through its programmable architecture. The CYBLE-222005-00 includes a royalty-free BLE stack compatible with Bluetooth 4.1 and provides up to 16 GPIOs in a small 10 × 10 × 1.80 mm package. The CYBLE-222005-00 is a complete solution and an ideal fit for applications requiring BLE wireless connectivity. Module Description nModule size: 10.0 mm ×10.0 mm × 1.80 mm (with shield) nDrop-in compatible with CYBLE-022001-00 and includes additional V REF input nBluetooth 4.1 single-mode module nIndustrial temperature range: –40 °C to +85 °C n32-bit processor (0.9 DMIPS/MHz) with single-cycle 32-bit multiply, operating at up to 48 MHz n256-KB flash memory n32-KB SRAM memory nWatchdog timer with dedicated internal low-speed oscillator (ILO) nTwo-pin SWD for programming nUp to 16 GPIOs configurable as open drain high/low, pull-up/pull-down, HI-Z analog, HI-Z digial, or strong output nCertified to FCC, CE MIC, KC, and IC regulations nBluetooth SIG 4.1 qualified Power Consumption nTX output power: –18 dbm to +3 dbm nReceived signal strength indicator (RSSI) with 1-dB resolution nTX current consumption of 15.6 mA (radio only, 0 dbm) nRX current consumption of 16.4 mA (radio only) nLow power mode support pDeep Sleep: 1.3 μA with watch crystal oscillator (WCO) on pHibernate: 150 nA with SRAM retention pStop: 60 nA with XRES wakeup Functional Capabilities nUp to 15 capacitive sensors for buttons or sliders with best-in-class signal-to-noise ration (SNR) and liquid tolerance n12-bit, 1-Msps SAR ADC with internal reference, sample-and-hold (S/H), and channel sequencer nTwo serial communication blocks (SCBs) supporting I 2 C (master/slave), SPI (master/slave), or UART nFour dedicated 16-bit timer, counter, or PWM blocks (TCPWMs) nProgrammable low voltage detect (LVD) from 1.8 V to 4.5 V nI 2 S master interface nBluetooth Low Energy protocol stack supporting generic access profile (GAP) Central, Peripheral, Observer, or Broadcaster roles nSwitches between Central and Peripheral roles on-the-go nStandard Bluetooth Low Energy profiles and services for interoperability nCustom profile and service for specific use cases Benefits The CYBLE-222005-00 module is provided as a turnkey solution, including all necessary hardware required to use BLE communication standards. nProven, qualified, and certified hardware design ready to use nSmall footprint (10 × 10 mm × 1.80 mm), perfect for space constrained applications nReprogrammable architecture nFully certified module eliminates the time needed for design, development and certification processes nBluetooth SIG qualified with QDID and Declaration ID nFlexible communication protocol support nPSoC Creator™ provides an easy-to-use integrated design environment (IDE) to configure, develop, program, and test a BLE application CYBLE-222005-00 Document Number: 002-00214 Rev. **Page 2 of 33 Contents Overview............................................................................ 3 Module Description...................................................... 3 Pad Connection Interface ................................................ 5 Recommended Host PCB Layout ................................... 6 Power Supply Connections and Recommended External Components...................................................................... 9 Connection Options..................................................... 9 External Component Recommendation ...................... 9 Critical Components List ........................................... 11 Antenna Design......................................................... 11 Electrical Specification .................................................. 12 GPIO ......................................................................... 14 XRES......................................................................... 15 Digital Peripherals ..................................................... 18 Serial Communication ............................................... 20 Memory ..................................................................... 21 System Resources .................................................... 21 Environmental Specifications ....................................... 24 Environmental Compliance ....................................... 24 RF Certification.......................................................... 24 Environmental Conditions ......................................... 24 ESD and EMI Protection ........................................... 24 Regulatory Information.................................................. 25 FCC........................................................................... 25 Industry Canada (IC) Certification............................. 26 European R&TTE Declaration of Conformity ............ 26 MIC Japan................................................................. 27 KC Korea................................................................... 27 Packaging........................................................................ 28 Ordering Information...................................................... 30 Part Numbering Convention...................................... 30 Document Conventions............................................. 31 Document History Page................................................. 32 Sales, Solutions, and Legal Information ...................... 33 Wor…

Text truncated - open the document above for the full version.

Cypress Semiconductor We Name: Cypress Semiconductor Address: 198 Champion Ct, San Jose, California 95134 United States City: California . Country: United States . Declare that: Name Representative of agent: Dream Cao (1) Agent Company name: QuieTek Technology (Suzhou) Co., Ltd. Address: No.99 Hongye Rd., Suzhou Industrial Park , City: Suzhou Country China is authorized to apply for Certification of the following product(s): Product description: EZ-BLE PRoC Module ............ Type designation: CYBLE-222005-00 FCC ID: WAP2005 IC: 7922A-2005 on our behalf. Date:  2015-09-29.. Sincerely, __________________ Yedan Li / System engineer Cypress Semiconductor Notes: (1): Required for FCC & IC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Cypress Semiconductor 198 Champion Ct, San Jose, California 95134 United States Request of Confidentiality TUV SUD BABT TCB/FCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Pursuant to FCC Sections 0.457 and 0.459 of the Commission’s Rules and IC RSP100 Paragraph 10, we, Cypress Semiconductor hereby requests confidential treatment of information accompanying of following product: Product Name: EZ-BLE PRoC Module FCC ID: WAP2005 The following information should be held confidential: (1) Operational description (2) Circuit Schematics; (3) Block diagram; ...... The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Exhibits/Items which are not here are allowed to be published. And also, Pursuant to RSP100 Paragraph 10, we request confidential treatment of information accompanying this application of the following product: Product Name: EZ-BLE PRoC Module IC Model No.: CYBLE-222005-00 IC : 7922A-2005 The following information should be held confidential: (1) Operational description (2) Circuit Schematics; (3) Block diagram; ...... The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. Cypress Semiconductor 198 Champion Ct, San Jose, California 95134 United States The Exhibits/Items which are not here are allowed to be published. Yours Sincerely, Name: Yedan Li Sign: Date: 2015-09-29 Email: [email protected] Phone No: 021-61622600-2655

Cypress Semiconductor 198 Champion Ct, San Jose, California 95134 United States Modular Approval Request Letter FCC ID: WAP2005 Data: Sep. 30, 2015 Gentlemen: There’s an EZ-BLE PRoC Module that would like to have your authorization as a modular approval. The specific product as below, EZ-BLE PRoC Module, with its designed features and specified description, meets special requirements for full modular approval on FCC Part 15.212 Released list below. Company : Cypress Semiconductor Model Name : EZ-BLE PRoC Module Model Number : CYBLE-222005-00 FCC ID : WAP2005 Requirement of FCC Part 15.212 Reference to CYBLE-222005-00 1. The modular transmitter must have its own RF shielding. The module has its own RF shielding. Please see external photo.pdf 2. The modular transmitter must have buffered modulation/data inputs. The modular has buffered data inputs, Please see schematic.pdf 3. The modular transmitter must have its own power supply regulation. All power lines derived from the host device are regulated before energizing other circuits internal to the CYBLE-222005-00. Please see schematic.pdf 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The CYBLE-222005-00 meets the FCC antenna requirements. It has a unique connector. 2.98dBi for 2.4G, 5.16dBi for 5G. please see external photo.pdf 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. The CYBLE-222005-00 is tested in a stand-alone configuration Please see conducted set-up photo.pdf and spurious set-up photo.pdf 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. The label position of CYBLE-222005-00 is clearly indicated. Please see the label.pdf 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The CYBLE-222005-00 is compliant with all applicable FCC rules. Detail instructions are given in the Users Manual. Please see Installation guide.pdf 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). The CYBLE-222005-00 complies with applicable RF exposure requirements. Please see RF safety evaluation. Pdf Thank you. Sincerely, __________________ Yedan Li / System engineer Cypress Semiconductor

Cypress Semiconductor 198 Champion Court, San Jose, CA, USA, 95134 Date: 9/24/2014 Authorization letter for equipment authorization before FCC and or IC Canada, Re: FCC ID: WAP2005 IC: 7922A-2005 To whom it may concern: Please be advised that Cypress Semiconductor Corporation authorizes Yedan LI of Cypress Semiconductor Technology (shanghai) co. ltd., to act on our behalf on all matters relating to application for equipment authorization before the federal communication Commission and Industry Canada, including signing of documents related to these matters. Cypress Semiconductor Corporation, Certifies that neither the applicant nor any party to this application, as defined in 47CFR Ch.1.2002 (b), is subjected to denial to federal benefits that includes FCC benefits, pursuant to section 5301 of anti-drug abuse act of 1998, 21 U.S.C.835 (a). Sincerely Brian Booker Applications Director Cypress Semiconductor Corporation Phone: 425-787-4469 Email: [email protected]

(1) EUT Photo (2) EUT Photo (3) EUT Photo (4) Carrier board Photo (5) EUT Photo (6) Carrier board Photo

(1) EUT Photo (2) EUT Photo (3) EUT Photo (4) Carrier board Photo (5) EUT Photo (6) Carrier board Photo

RF Exposure Evaluation Declaration Product Name : EZ-BLE PRoC Module Model No. : CYBLE-222005-00 FCC ID : WAP2005 IC : 7922A-2005 Applicant : Cypress Semiconductor Corporation Address : 198 Champion Ct, San Jose, California 95134 United States Date of Receipt : Sept. 09, 2015 Test Date : Sept. 09, 2015~ Sept. 30, 2015 Issued Date : Oct. 12, 2015 Report No. : 1590279R-RF-US-P20V01 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No: 1590279R-RF-US-P20V01 Page: 3 of 7 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF USA :FCC Japan :VCCI China :CNAS Report No: 1590279R-RF-US-P20V01 Page: 4 of 7 History of This Test Report REPORT NO. VERSION DESCRIPTION ISSUED DATE 1590279R-RF-US-P20V01 V1.0 Initial Issued Report Oct. 12, 2015 Report No: 1590279R-RF-US-P20V01 Page: 5 of 7 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No: 1590279R-RF-US-P20V01 Page: 6 of 7 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. 1.3. Test Result of RF Exposure Evaluation Product : EZ-BLE PROC MODULE Test Item : RF Exposure Evaluation Test Site : AC-6 z Antenna Gain: No. Peak Gain ANT 0.5dBi Report No: 1590279R-RF-US-P20V01 Page: 7 of 7 RF Exposure Evaluation z Output Power into Antenna & RF Exposure Evaluation Distance: Test Mode Frequency Band (MHz) Maximum Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) Bluetooth 2402~2480MHz 0.778 0.000174 Note: The standalone power density Pd (4th column) at a distance of 20 cm calculated from the Friis transmission formula is below the limit of 1 mW/cm2. The End

Test Report FCC Part15 Subpart C Product Name : EZ-BLE PRoC Module Model No. : CYBLE-222005-00 FCC ID : WAP2005 IC : 7922A-2005 Applicant : Cypress Semiconductor Corporation Address : 198 Champion Ct, San Jose, California 95134 United States Date of Receipt : Sept. 09, 2015 Test Date : Sept. 09, 2015~ Sept. 30, 2015 Issued Date : Oct. 12, 2015 Report No. : 1590279R-RF-US-P06V02 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No.: 1590279R-RF-US-P06V02 Page: 3 of 52 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site :http://www.quietek.com/tw/ctg/cts/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No.5-22, Ruishukeng, Linkou Dist., New Taipei City 24451, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF USA :FCC Japan :VCCI China :CNAS Report No.: 1590279R-RF-US-P06V02 Page: 4 of 52 TABLE OF CONTENTS Description Page 1. General Information ................................................................................................................... 7 1.1. EUT Description ......................................................................................................................... 7 1.2. Mode of Operation ..................................................................................................................... 8 1.3. Tested System Details ................................................................................................................ 9 1.4. Configuration of Tested System ............................................................................................... 10 1.5. EUT Exercise Software ............................................................................................................ 11 2. Technical Test ........................................................................................................................... 12 2.1. Summary of Test Result ........................................................................................................... 12 2.2. Test Environment ..................................................................................................................... 14 3. Conducted Emission ................................................................................................................ 15 3.1. Test Equipment ........................................................................................................................ 15 3.2. Test Setup ................................................................................................................................ 15 3.3. Limit .......................................................................................................................................... 16 3.4. Test Procedure ......................................................................................................................... 16 3.5. Uncertainty ............................................................................................................................... 16 3.6. Test Result ............................................................................................................................... 17 4. Radiated Emission ................................................................................................................... 19 4.1. Test Equipment ........................................................................................................................ 19 4.2. Test Setup ................................................................................................................................ 20 4.3. Limit .......................................................................................................................................... 21 4.4. Test Procedure ......................................................................................................................... 21 4.5. Uncertainty ............................................................................................................................... 21 4.6. Test Result ............................................................................................................................... 22 5. RF Antenna Conducted Spurious ............................................................................................. 25 5.1. Test Equipment ........................................................................................................................ 25 5.2. Test Setup .......................................................................…

Text truncated - open the document above for the full version.

Test Setup Photograph for Part 15.247/15.407 Description: Front View of Conducted Test Setup Description : Back View of Conducted Test Setup Description: Radiated Emission Test Setup for Below 30MHz Description: Radiated Emission Test Setup for Below 1GHz Description: Radiated Emission Test Setup for 1~18GHz
